LED and Network
Verification
Using the
CoreBuilder 5000
Controller Module
to Verify LED
Operation
Table 3-3

Interpretation of the 24-Port Module LEDs

LED Name
Color
Module Status green
Activity
yellow
(Ports 1-24)
Status
green
(Ports 1-24)
This section provides information on LED and Network verification
information for the 24-Port module. The following topics are discussed:
Using the CoreBuilder 5000 Controller Module to Verify LED
Operation
Using the DMM to Verify Network Connections
For more information on the DMM, refer to the Distributed
Management Module User Guide.
The CoreBuilder 5000 hub's controller module is equipped with an LED
Test button on the front panel. The LED Test button is used to verify
LED operation. When you press this button, the module initiates a test
to all modules in the hub. All LEDs should respond by lighting
continuously for approximately five seconds. Any LED that does not
light is defective. This test will not disrupt network operation.

LED and Network Verification

State
Indicates
Off
No power.
Blinking
Module failed self diagnostics.
On
Module powered up OK.
Off
No packets are received on the ports.
On
Constant activity on port.
Blinking
Normal activity on the port.
On
Port enabled and links OK or Link
Integrity disabled.
1 blink
Link failure on the port.
2 blinks
Port partitioned.
Off
Port disabled.
3-23
