1-4 I
NTRODUCTION

Theory of Operation

Where To Go From
Here
Figure 1-2

Typical 24-Port Module Application

The 24-Port module incorporates repeaters and twisted pair transceivers
in its hardware. Transceivers receive and restore amplitude to incoming
signals. A repeater restores phase and frequency. Repeated signals
synchronize to the system clock and enter on the CoreBuilder 5000
hub's backplane. Outgoing signals from the backplane are sent directly
to transceivers to be transmitted to twisted pair link segments.
Now that you are familiar with the 24-Port module, we suggest that
you evaluate the environment in which you plan to use this module.
Chapter 2, Designing and Expanding the
considerations and configuration examples specific to the 24-Port
module in the CoreBuilder 5000 hub.
1
3
Network, lists cabling
2 1 2
4 3 4
1 1
2 2
3 3
