Setup Manual
Color LCD Monitor
Software Version 6.0
Important
Please read this "Setup Manual", and "PRECAUTIONS" (separate
volume) carefully to familiarize yourself with safe and effective
usage.
Please retain this manual for future reference.
• For the latest product information including the "Setup Manual",
refer to our web site :
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo DuraVision FDF2712W-IP
Summary of Contents for Eizo DuraVision FDF2712W-IP
- Page 1 Setup Manual Color LCD Monitor Software Version 6.0 Important Please read this “Setup Manual”, and “PRECAUTIONS” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For the latest product information including the “Setup Manual”, refer to our web site : www.eizoglobal.com...
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product specifications are subject to change without notice.
-
Page 3: Notice For This Product
When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not scratch or press on the LCD panel with any sharp objects, at this may result in damage to the LCD panel. -
Page 4: Cleaning
Cleaning • Periodic cleaning is recommended to keep the product looking new and to prolong its operation lifetime. • Stains on the product can be removed by moistening part of a soft cloth with water or by using our ScreenCleaner and gently wiping. Attention •... -
Page 5: Table Of Contents
Contents Notice for this product ......... 3 4-5. Checking a Camera Connection with Ping ............... 30 Cleaning ..............4 4-6. Checking for Duplicate IP Addresses ..31 Disclaimer ..............4 4-7. Checking the IP Address of a Computer ...31 Network Security Request ........4 Appendix .............. -
Page 6: Chapter 1 Introduction
This chapter describes the settings required for displaying camera (network camera) images on the monitor. 1-1. Package Contents Check that all of the following parts are included. If any of these are missing or damaged, contact your dealer or local EIZO representative. • Setup Manual • Monitor Unit •... -
Page 7: Controls And Functions
1-2. Controls and Functions Front FDF2712W-IP FDF2312W-IP Names Details 1. Remote control light Receives signals from the remote control. reception section Pressing and holding this button for 10 seconds will initialize the following information: 2. Reset button • Camera information •... - Page 8 Back FDF2712W-IP FDF2312W-IP Names Details Emits the beep sound of the product main unit. It does not support the 7. Speakers audio output of cameras. FDF2712W-IP: Adjusts the height and angle (tilt, swivel). The monitor can also be rotated vertically. FDF2312W-IP: Adjusts the viewing angle (tilt).
-
Page 9: System Configuration
1-3. System Configuration This product is used by connecting to a network. This product Camera Network cable USB mouse Network hub FUNC POWER MUTE VOLUME- VOLUME+ WXYZ CLEAR ZOOM- ZOOM+ ENTER RETURN FULL LAYOUT SEQUENCE PAGE+ PAGE- REMOTE CONTROLLER FR-IP2 Joystick Remote control USB keyboard... -
Page 10: Computer
● Computer Used to configure this product and cameras. After configuring, it can be removed from the network. The following settings are available only if you are using a computer. • Entering characters other than alphanumeric characters and symbols in the camera name •... -
Page 11: Chapter 2 Setup
Additional features are available with the purchase of a license. For details on features, refer to the User’s Manual. For details on purchasing a license, contact your dealer or local EIZO representative. 2-2. Setting Cameras To use this product to display camera images, cameras must be set up in advance. -
Page 12: Stream
“ONVIF”: H.264 or MJPEG Note • For the latest support status for H.265, refer to the camera compatibility information on the EIZO website. Bit rate Set the value to 8192 kbps or less. (4096 kbps recommended) Resolution / Frame rate Set the resolution and frame rate according to the number of cameras to be simultaneously displayed on the live image screen. - Page 13 Note Camera stream Typically, cameras support multiple streams and can transmit video at different resolutions and frame rates simultaneously. Video recorder Stream 1 Compression format: H.265 Resolution: 1920 x 1080 Frame rate: 30 Hz Bit rate: 4096 kbps This product Stream 2 Compression format: H.264 Resolution: 1280 x 720...
-
Page 14: Connecting Devices
2-3. Connecting Devices Connect this product and the cameras to a network hub with network cables. Connect the power cord to the power connector of the monitor and plug in the cord to the wall socket. Insert the power cord all the way into the monitor. Connect the USB mouse to the USB downstream port. -
Page 15: Turn On The Power And Display The Live Image Screen
2-4. Turn on the Power and Display the Live Image Screen Check if the main power switch is on. Press the power button ( ) on the front of the product. The power indicator lights up blue and the live image screen is displayed. Live Image Screen Note •... -
Page 16: Displaying The Setting Screen
2-5. Displaying the Setting Screen The setting screen can be operated using the monitor console (screen displayed on the monitor) or the web console (screen displayed on the browser). To display the setting screen, it is necessary to log in as a user with a user level of “ADMIN”. Note •... -
Page 17: When Using The Web Console
● When Using the Web Console Use a computer connected to the network to perform operations. Note • For information on computer network settings, refer to “4-7. Checking the IP Address of a Computer” (page 31). Launch the browser. Enter the following address to access the site. Address: http://<IP address of this product>/ In the default settings, the IP address is http://192.168.0.150/. -
Page 18: Setting The Date And Time
2-6. Setting the Date and Time Setting the correct date and time in the system will prevent problems communicating with cameras. Select “System” > “Date and Time”. Set the current date and time. Time Zone Settings Item Description Range Time Zone Set the time zone. -
Page 19: Configuring The Language
2-8. Configuring the Language Select “System” > “Other”. Select a language from the “Language” list box. Click “Apply”. 2-9. Registering a Camera Using Auto Discovery Cameras connected to the network can be automatically detected and registered. Attention The following cameras and video encoders must be registered manually (refer to “3-4. Registering a Camera Manually”... -
Page 20: Preparing The Remote Control
2-10. Preparing the Remote Control Press the knob to unlock and remove the cover. Insert AA batteries and put the cover back on. Chapter 2 Setup... -
Page 21: Chapter 3 Other Settings
Chapter 3 Other Settings 3-1. Updating software Use the web console to perform operations. For stable operation of the system, it is recommended to use the latest software. It is not possible to revert to an older version. Select “System” > “Maintenance”. The current software version is displayed. -
Page 22: Save And Load Settings Data To Other Products
3-3. Save and Load Settings Data to Other Products Use the web console to perform operations. You can save settings data for products that have completed setup and load them to other products on the network. This eliminates the need to set up one unit at a time. Save Settings Data Product in which settings data will be copied from... -
Page 23: Registering A Camera Manually
Select the settings data file and enter the password you have set. Do not check “Network Settings”. Click “Execute”. The process is performed. 3-4. Registering a Camera Manually The following cameras and video encoders must be registered manually. • Cameras that cannot be discovered automatically •... - Page 24 Item Description Range Protocol Select the protocol for controlling the camera. Panasonic/i-PRO “Panasonic/i-PRO”: Panasonic/i-PRO camera / AXIS / ONVIF / “AXIS”: Axis camera (VAPIX) DirectUri / SRT “ONVIF”: ONVIF Profile S compatible camera “DirectUri”: Select to connect to a RTSP stream URI (URI starting with rtsp://) or a RTP stream URI (URI starting with rtp://).
- Page 25 When “ONVIF” is selected Item Description Range Media Profile Specify the stream to connect to by selecting a media profile. Depends on the Click “Obtain Profile” to get a list of profiles from the camera. camera Transmission Mode Select the transmission mode. Unicast / Multicast Comm.
-
Page 26: Chapter 4 Troubleshooting
• Make sure you can connect to the camera (refer to “4-5. Checking a Camera Connection with Ping” (page 30)). • Cameras not verified by EIZO may not be compatible with this product. Consider registering cameras with the “DirectUri” protocol. -
Page 27: Video Problems
4-3. Video Problems Problem Possible cause and remedy 1. Error message “E**-**” is • E01-** displayed - Check if the camera streaming settings are correct (refer to “2-2. Setting Cameras” (page 11)). If the problem is not resolved, refer - The camera may not be operating properly due to high load. to “3. - Page 28 Problem Possible cause and remedy • E04-** - A resolution which is incompatible with this product may be set. Try changing the resolution of the camera (refer to “2-2. Setting Cameras” (page 11)). • E05-** - The stream format from the camera may be different from that of this product.
- Page 29 Problem Possible cause and remedy 3. Correct image is not displayed • Select “Live Image Screen” > “Other” and turn “Network traffic • Images are distorted condition” to “On”. A circle indicating the communication status • Displayed images are not smooth is displayed in the upper right corner of the image.
-
Page 30: Ping
4-4. Other Problems Problem Possible cause and remedy 1. Cannot log in • Re-enter the username and password. • Reset the account information using the Reset button and log in as the default setting account (refer to “1-2. Controls and Functions” (page 7)). -
Page 31: Checking For Duplicate Ip Addresses
4-6. Checking for Duplicate IP Addresses Select “Troubleshooting” > “Network Connection Status”, and click “Current Status”. If the IP address of this product is duplicated with other devices, “Unicast reply from” will be displayed for the number of duplicated units. Set unique IP addresses. Example) Execution Result - If there are no duplicate IP addresses ARPING 192.168.0.150 from 0.0.0.0 eth0... -
Page 32: Appendix
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. - AC Cord... -
Page 33: Declaration Of Compliance With India Rohs
Declaration of compliance with India RoHS We, EIZO Corporation, hereby declare and guarantee that this product has been designed and manufactured in compliance with the E-Waste management rule 2016 which prohibit the inclusion of the following substances except for the exemptions listed in schedule II. -
Page 34: Limited Warranty
Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts (excluding design parts) of the Product upon expiration of seven (7) years after the production of the Product is discontinued. In repairing the Product, EIZO and Distributors will use renewal parts which comply with our QC standards. - Page 36 00N0N358A1 SUM-FDF27_2312W-IP Copyright © 2023 EIZO Corporation. All rights reserved. 1st Edition - January , 2023 Printed in Japan.
