Eizo DuraVision FDF2382WT-A User Manual

Touch panel color lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Touch Panel Color LCD Monitor
Important
Please read this "User's Manual", and "PRECAUTIONS" (separate
volume) carefully to familiarize yourself with safe and effective
usage.
• See the Setup Guide for monitor installation and connection.
• For the latest product information including the "User's Manual", refer to
our web site:
www.eizoglobal.com

Advertisement

Table of Contents
loading

Related Manuals for Eizo DuraVision FDF2382WT-A

Summary of Contents for Eizo DuraVision FDF2382WT-A

  • Page 1 User’s Manual Touch Panel Color LCD Monitor Important Please read this "User’s Manual", and "PRECAUTIONS" (separate volume) carefully to familiarize yourself with safe and effective usage. • See the Setup Guide for monitor installation and connection. • For the latest product information including the "User’s Manual", refer to our web site: www.eizoglobal.com...

  • Page 2: Location Of Caution Statement

    EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information.

  • Page 3: About This Product

    When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • Do not scratch or press on the LCD panel with any sharp objects, at this may result in damage to the LCD panel.

  • Page 4: About The Installation

    About This Product About the Installation • If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to the composition of the rubber. Check the desk surface before use. • When the product is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur on the interior and exterior surfaces of the product.

  • Page 5: Table Of Contents

    CONTENTS CONTENTS Location of Caution Statement ................. About This Product ....................About the Usage of This Product................ About the LCD Panel ..................About the Installation ..................Cleaning......................To Use the Monitor Comfortably................. 1 Introduction......................... Features......................1.1.1 Full-Flat Design..................1.1.2 Easy-to-touch Stand Mechanism ............1.1.3 10-point Multi-touch Support..............
  • Page 6 CONTENTS 6 Troubleshooting ......................28 No Picture ......................28 Imaging Problems (Digital and Analog) .............. 29 Imaging Problems (Analog only)................. 30 Touch Panel Problems ..................30 Other Problems....................32 7 Reference ........................34 Arm Installation Procedure ................. 34 Connecting Multiple PCs ..................36 Using the USB Hub Function................

  • Page 7: Introduction

    Introduction | 1 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1.1 Features 1.1.1 Full-Flat Design A full-flat design with a flat bezel is adopted. You can properly touch right to the edge of the screen. 1.1.2 Easy-to-touch Stand Mechanism The tilt angle can be adjusted steplessly.

  • Page 8: Controls And Functions

    1 | Introduction 1.2 Controls and Functions 1.2.1 Front 1. Power Indicator Indicates the monitor’s operation status. Blue: Screen display Orange: Power saving mode Off: Main power / power off button Enables/disables and adjusts the sensitivity of the touch panel. button Switches the input signals to be displayed. button Selects items displayed in the Setting menu, adjusts or sets the functions, and displays the brightness adjustment screen.

  • Page 9: Rear

    Introduction | 1 1.2.2 Rear 1. Main power switch Turns the main power on or off. ｜: On, ○: Off 2. Power connector Connects the power cord. 3. Touch pen holder For mounting the touch pen holder. (see Mounting the Touch Pen mounting hole Holder [} 10])

  • Page 10: Mounting The Touch Pen Holder

    1 | Introduction 1.3 Mounting the Touch Pen Holder Note The touch pen holder is included with the touch pen (optional accessory). Mount the touch pen holder in either of the holes to the left and right on the rear side of the monitor.

  • Page 11: Basic Adjustment / Setting

    Basic Adjustment / Setting | 2 2 Basic Adjustment / Setting 2.1 Enabling / Disabling the Touch Panel You can switch between enabling and disabling the touch panel. You can use this when you want to temporarily disable the touch panel function.

  • Page 12: Adjusting Touch Sensitivity

    2 | Basic Adjustment / Setting 2.2 Adjusting Touch Sensitivity Holding down allows you to adjust (calibrate) the touch sensitivity. You make adjustments if you are having problems with touch operations. Note • Please make sure to run TPOffset after setting up the monitor. •...

  • Page 13: Adjusting Brightness

    Basic Adjustment / Setting | 2 2.4 Adjusting Brightness Settings: "0" – "100" The brightness of the screen can be adjusted to suit the installation environment or personal preference. The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel).

  • Page 14: Touch Panel Settings

    3 | Touch Panel Settings 3 Touch Panel Settings 3.1 Setting Up the Touch Panel The touch panel functions of this product differ according to the driver used and the driver setup. Set it according to your application. Function Windows standard Dedicated touch panel driver (DMT-DD) driver Driver installation Not required...
  • Page 15 Touch Panel Settings | 3 2. Click "Hardware and Sound" - "Tablet PC Settings". The "Tablet PC Settings" screen appears. 3. In the "Display" tab, click "Setup". The white touch screen specification screen appears in the background. Attention • If using the monitor in a multi-monitor environment, specify the touch screen according to the screen that is displayed.

  • Page 16: Set Touch Panel Operations

    3 | Touch Panel Settings 3.3 Set Touch Panel Operations 1. Open the Windows control panel. How to open differs depending on the operating system (see Correcting the Touch Position [} 14]). 2. Click "Hardware and Sound" - "Pen and Touch". The "Pen and Touch" screen appears. Configure the touch panel operation settings in the "Pen and Touch"...

  • Page 17: Advanced Adjustments / Settings

    Advanced Adjustments / Settings | 4 4 Advanced Adjustments / Settings This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For basic functions, see Basic Adjustment / Setting [} 11]. 4.1 Basic Operation of the Setting Menu 1. Press The Setting menu appears.

  • Page 18: Setting Menu Functions

    4 | Advanced Adjustments / Settings 4.2 Setting Menu Functions 4.2.1 Color The color mode settings can be adjusted according to personal preference. The adjusted settings are saved for each color mode. Functions that can be adjusted differ depending on the color mode. ✓: Adjustable, -: Not adjustable Function Color Mode...
  • Page 19 Advanced Adjustments / Settings | 4 Brightness Settings: "0" – "100" The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). Note • If the image is too dark even when the brightness is set to 100, adjust the contrast. Contrast Settings: "0"...
  • Page 20 4 | Advanced Adjustments / Settings Advanced Settings - Overdrive Settings: "Enhanced" / "Standard" / "Off" This function allows you to set the overdrive intensity based on the use of the monitor. Image lag can be reduced by using the "Enhanced" setting when displaying moving images. Note •...

  • Page 21: Signal

    Advanced Adjustments / Settings | 4 4.2.2 Signal Set the details regarding input signal, such as the screen size and color format. • D-Sub input • HDMI/DisplayPort input The functions that can be set differ depending on the input signal. ✓: Can be set, -: Cannot be set. Function Input Signal DisplayPort...
  • Page 22 4 | Advanced Adjustments / Settings Note • Setting example Full-screen Fixed aspect ratio Actual size (input signal) Sharpness Settings: "-2" – "2" When a low-resolution image is displayed using picture expansion mode ("Full Screen" or "Aspect Ratio"), the text and lines of the image may appear blurry. This blurriness can be reduced by configuring the settings for sharpness.
  • Page 23 Advanced Adjustments / Settings | 4 Note • When "YUV" is selected in "Input Color Format", the setting is automatically set to "Limited". Additionally, when "Auto" is selected and the monitor determines the input color format to be YUV, the setting is automatically set to "Limited". Sound Source Settings: "Stereo Mini Jack"...

  • Page 24: Preferences

    4 | Advanced Adjustments / Settings Analog Adjustment - Phase Flickering or bleeding of the screen as a whole can be minimized. Note • Flickering or bleeding may not fully disappear, depending on the PC and graphics board you are using. • If vertical stripes appear on the screen after completing the setting, adjust "Clock" again. Analog Adjustment - Hor.

  • Page 25: Languages

    Advanced Adjustments / Settings | 4 Note • At the time of shifting to power saving mode, a message that indicates the transition is displayed five seconds in advance. • When not using the monitor, you can turn off the main power supply or disconnect the power plug so that the power is cut completely.

  • Page 26: Administrator Settings

    5 | Administrator Settings 5 Administrator Settings This chapter describes how to configure monitor operation using the "Administrator Settings" menu. 5.1 Basic Operation of the "Administrator Settings" Menu 1. Press to turn the monitor off . 2. Holding down and pressing for more than 2 seconds will turn on the monitor. The "Administrator Settings"...
  • Page 27 Administrator Settings | 5 • "On" When the monitor is connected to multiple PCs, if a specific PC enters power saving mode or no signals are input to the monitor, the connector is automatically changed to another one to which signals are input. •...

  • Page 28: Troubleshooting

    6 | Troubleshooting 6 Troubleshooting 6.1 No Picture Power switch indicator does not light up. • Check whether the power cord is connected properly. • Turn the main power switch on. • Press • Turn off the main power, and then turn it on again a few minutes later. Power switch indicator lights up: Blue •...

  • Page 29: Imaging Problems (Digital And Analog)

    [} 18]). (The LCD monitor backlight has a limited life span. If the screen becomes dark or begins to flicker, contact your local EIZO representative.) Letters and images are blurred • Check whether the PC is configured to meet the resolution and vertical scan frequency...

  • Page 30: Imaging Problems (Analog Only)

    6 | Troubleshooting • Check whether the setting for the resolution of the PC matches the resolution of the monitor. Fog remains even after wiping the screen / Condensation inside the glass • If fog remains even after wiping the screen, there may be condensation on the inside of the protective glass on the LCD panel.
  • Page 31 Troubleshooting | 6 The touch and cursor positions are misaligned / The cursor jumps • Connect the monitor and PC via the supplied cable. The touch panel may not work correctly if a conversion adapter is used. • Turn off the monitor, and then turn it on again. •...

  • Page 32: Other Problems

    USB downstream port are not operational. Change the setting for "Compatibility Mode" to "On" (see Compatibility Mode [} 27]). • If the peripheral devices work correctly when they are directly connected to the PC, contact your local EIZO representative.
  • Page 33 Troubleshooting | 6 • Check the PC’s BIOS setting for USB when using Windows. (Refer to the User’s Manual of the PC for details.) • Update the PC OS. Power indicator is flashing orange • This symptom may occur when the PC is connected to the DisplayPort connector. Use a signal cable recommended by us for the connection.

  • Page 34: Reference

    7 | Reference 7 Reference 7.1 Arm Installation Procedure An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our website for supported optional arms (or optional stands). (www.eizoglobal.com) When attaching an arm or stand, the installable orientations and movement range (tilt angle) are as follows: •...
  • Page 35 Reference | 7 3. Attach the arm or stand to the monitor. Use the screws specified in the arm or stand User’s Manual for installation. Note • To install vertically, use the following procedure to remove the leg from underneath the monitor. 1.

  • Page 36: Connecting Multiple Pcs

    7 | Reference 7.2 Connecting Multiple PCs This product can be connected to multiple PCs and allows you to switch between the connections for display. Connection Examples HDMI DisplayPort D-Sub HDMI cable DisplayPort cable D-Sub cable (HDMI - HDMI) (DisplayPort - DisplayPort) (D-Sub - D-Sub) HH200HS PP200...

  • Page 37: Using The Usb Hub Function

    Reference | 7 7.3 Using the USB Hub Function This monitor is equipped with a USB hub. It functions as a USB hub when connected to a USB-compatible PC, allowing the connection of peripheral USB devices. 1. Connect the USB cable. 2. If necessary, connect a mouse, keyboard, or other device to the USB downstream port. USB-A downstream USB-B...
  • Page 38 7 | Reference Attention • This function may not work depending on the PC you are using, your OS, and your peripheral devices. Contact the manufacturer of each device for information about USB compatibility. • Even when the monitor is in power saving mode, devices connected to the USB downstream port are operational.

  • Page 39: Specifications

    Microsoft Windows 10 (32 bit / 64 bit) Microsoft Windows 8.1 (32 bit / 64 bit) Number of simultaneous touch points Max. 10 points EIZO support will end when OS vendor support ends. 7.4.3 Video Signals Input Terminals DisplayPort (HDCP 1.3 compatible) x 1, HDMI (HDCP 1.4 compatible)

  • Page 40: Audio

    7 | Reference 7.4.5 Audio Audio Input Format DisplayPort 2ch linear PCM (32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz / 176.4 kHz / 192 kHz) HDMI 2ch linear PCM (32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz / 176.4 kHz / 192 kHz) Speakers 1 W + 1 W...

  • Page 41: Compatible Resolutions

    Reference | 7 7.5 Compatible Resolutions The monitor supports the following resolutions: ✓: Supported, -: Not supported Resolution Vertical scan DisplayPort HDMI D-Sub frequency (Hz) 640 x 480 59.940 ✓ ✓ ✓ 640 x 480 60.000 ✓ ✓ 640 x 480 72.809 ✓...

  • Page 42: Appendix

    ENERGY STAR is a registered trademark of the United States Environmental Protection Agency in the United States and other countries. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries.
  • Page 43 03V60141A1 UM-FDF2382WT-A Copyright © 2022 EIZO Corporation. All rights reserved. 1st Edition – May, 2022...
