Setup Manual
Color LCD Monitor
Software Version 5.2
Important
Please read this "Setup Manual", "Installation Manual", and
"Instruction Manual" carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
• For the latest product information including the "Setup Manual",
refer to our web site :
www.eizoglobal.com

Advertisement

Table of Contents
loading

Related Manuals for Eizo DuraVision FDF2711W-IP

Summary of Contents for Eizo DuraVision FDF2711W-IP

  • Page 1 Setup Manual Color LCD Monitor Software Version 5.2 Important Please read this “Setup Manual”, “Installation Manual”, and “Instruction Manual” carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For the latest product information including the “Setup Manual”, refer to our web site : www.eizoglobal.com...
  • Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.

  • Page 3: Precautions

    PRECAUTIONS IMPORTANT To ensure personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. Location of the Caution Statements PRECAUTIONS...
  • Page 4 A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
  • Page 5 Otherwise, the unit may become detached, resulting in injury and/or equipment damage. If the unit falls, please ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same screws and tighten them securely.
  • Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. When carrying the unit, grasp and hold it firmly by the bottom as shown in the illustration on the right.

  • Page 7: Notice For This Monitor

    The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not press on the LCD panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc.

  • Page 8: About The Installation

    About the Installation When installing the monitor in a rack, ensure that there is adequate space around the sides, back and top of the monitor. When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur on the interior and exterior surfaces of the monitor.

  • Page 9: Table Of Contents

    CONTENTS PRECAUTIONS ............3 IMPORTANT .............. 3 Notice for this monitor ......... 7 About the Usage of This Product ......7 About the LCD Panel ..........7 About the Installation ..........8 Cleaning ..............8 Disclaimer ..............8 Network Security Request ........8 CONTENTS .............

  • Page 10: Package Contents

    Package Contents Check that all of the following parts are included. If any of these are missing or damaged, contact your dealer or local EIZO representative. • Monitor Unit • Contact Addresses • Setup Manual (this manual) Attention • No power cord is supplied with this product. Use a power cord that complies with the rating and standards of the country or region where this product is used.
  • Page 11 Names Details 1. Remote control light Receives signals from the remote control. (A function for use with models reception section equipped with a remote control) Pressing and holding this button for 10 seconds will initialize the following information: 2. Reset button •...

  • Page 12: Setup

    Setup Set up the system until network camera images are displayed on the monitor. This product is operated or set using a USB mouse or USB keyboard. Setup Flow Connect the network camera(s) (page 13) Turn On the Power (page 14) Perform Initialization (page 16) Set the following items.

  • Page 13: Connecting The Network Cameras

    Connecting the Network Cameras Connect the network camera and the monitor according to the following procedure. Connect the network camera to the monitor via the network hub. 1. Connect the network cable (straight cable, Cat 5e or higher) to the monitor and the LAN port of the network hub.

  • Page 14: Connecting Operating Devices

    Connecting Operating Devices ● Connecting a USB Mouse or Keyboard Connect the mouse or keyboard to the USB downstream port at the back of the monitor. Note • Both the USB mouse and USB keyboard can be used. Turning On the Power Turn on the main power switch on the back of the monitor.

  • Page 15: Live Image Screen

    ● Live Image Screen Describes basic operation of live image screen. For details, refer to the “Instruction Manual”. Menu Operations The various menus can be operated using a USB mouse or USB keyboard. If a menu is not displayed, click the screen with the USB mouse to display a menu. Display mode menu System setup menu / Camera control menu Display mode menu...

  • Page 16: Perform Initialization

    Perform Initialization This section describes settings to display network camera images on the monitor. Note • Initial settings can be made from the Web browser of a computer connected to the same network. For details on setting from a Web browser, refer to the "Installation Manual". ●...

  • Page 17: Setting The Date And Time

    Select “Login”. The display returns to the live image screen where you can select (Settings). Settings ● Setting the Date and Time Attention • Set the correct dates. Incorrect dates may result in failure of secure communication during certificate validation. If you use SSL for communication with the camera or LDAP setting, avoid the state of power turned off for a long time of period or make sure correct time is set using NTP.

  • Page 18: Performing Network Settings

    Set the current date and time. Date/Time Display Settings Item Detail Setting range Date Format Set the date format and time format. yyyy/mm/dd, Mmm/dd/yyyy, dd/ Mmm/yyyy, mm/dd/yyyy, dd/ mm/yyyy Time Format 24h / 12h Time Zone Settings Item Detail Setting range Time Zone Set the time zone.
  • Page 19 Set the following items. Network Settings Item Detail Setting range IP Setting Method Select an IP Setting Method. DHCP / Manual IP Address When “Manual” is selected under “IP Setting Method”, “IP 0.0.0.0 to Subnet Mask Address”, “Subnet Mask”, and “Gateway” can be set. 255.255.255.255 Gateway Attention...

  • Page 20: Registering Cameras

    ● Registering Cameras Start network cameras. For setting the network cameras, refer to the network camera User’s Manual. Select (Settings). The setting screen is displayed. Select “Camera Registration”. A screen is displayed to show a list of camera registration information. Select a position where the camera is to be registered.
  • Page 21 Set each item and select “OK”. Item Detail Setting range Camera Name Enter the camera name. If "Obtain Camera Name" is Alphanumeric, kana selected, the camera name is automatically obtained kanji (Up to 24 from the network camera. characters) • If “Protocol” is “DirectUri,” “Obtain Camera Name” cannot be used.
  • Page 22 *1 Can only be acquired when “IP Address,” “Port,” “Username,” and “Password” are entered. *2 If “Protocol” is “DirectUri,” the “Obtain Camera Name” button is not displayed. *3 This can be used only when displayed on the Web browser. *4 When “Protocol” is set to “DirectUri” and “URI” starts with rtp://, the setting range will be 1024 to 65534. *5 Can only be set if “Protocol”...

  • Page 23: Setting The Language

    ● Setting the Language Select (Settings). The setting screen is displayed. Select “Other” under “System”. The “Other” screen is displayed. Select a language from the "Language" list box. Select “Apply”. The setting complete screen is displayed. Select “OK”. Setup...

  • Page 24: Reference

    Reference Confirming the Software Version Select (Settings). The setting screen is displayed. Select “Basic Information”. The current software version is displayed in the system information. Installation of Optional Arm The stand of this product can be replaced by an optional arm (or optional stand). For details of supported optional arms (or optional stands), refer to our web site (www.eizoglobal.com).

  • Page 25: Installation

    ● Installation To avoid damaging the LCD panel, spread out a soft cloth on a stable surface and place the LCD panel facing down on the cloth. Remove the stand. Prepare a screwdriver separately. Use the screwdriver to remove four screws that secure the stand on the main unit.

  • Page 26: Specifications

    Specifications LCD panel Type Backlight Size 69 cm (27.0 inch) (Diagonal Viewable Size: 68.6 cm) Resolution 1920 dots × 1080 lines Viewable image size (W x H) 597.6 mm × 336.15 mm Pixel pitch 0.311 mm Display colors 8 bit color 16.77 million Viewing angles 89˚...
  • Page 27 *1 Images are not displayed when the maximum resolution is exceeded. Reduce the resolution and the bit rate for the network camera. *2 The maximum frame rate differs depending on the resolution. (Refer to “Display capability” (page 27) ) Display capability Display capability of this product is as follows: H.264 / H.265 (when “Bit rate”...

  • Page 28: Troubleshooting

    Troubleshooting The screen is not displayed Problem Possible cause and remedy 1. The screen is not displayed • Is the main power turned on? • Power indicator is not turned on • Is the power correctly connected? Connect the power cord. •...

  • Page 29: Imaging Problems

    Imaging Problems Problem Possible cause and remedy 1. The display images are not • Reduce the resolution and/or bit rate set for the network camera. (For smooth / camera images are not details, refer to the “Installation Manual”.) displayed (when camera images •...

  • Page 30: Setting Problems

    Setting Problems Problem Possible cause and remedy 1. Cannot log in • Enter the user name and password again. • Reset the account information using the Reset button and log in as the default setting account. (For details, refer to “Controls and Functions”...

  • Page 31: Other Problems

    Other Problems Problem Possible cause and remedy 1. The mouse / keyboard does not • Check whether the USB cable is connected properly. work • Pull out the USB cable and connect it again. • Isn't the USB lock function enabled? (For details, refer to the “Installation Manual”.) 2.

  • Page 32: Appendix

    If the open source software contains a product for which usage us granted under a GPL (GNU GENERAL PUBLIC LICENSE) license, EIZO Corporation will, in line with the GPL usage license conditions, provide the source code for corresponding GPL software via a medium, such as CD-ROM, at a cost to individuals and organizations who make contact via the following contact information for a minimum period of three years after purchase of the product.

  • Page 33: Warning For Radio Interference

    Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. - AC Cord...

  • Page 34: Limited Warranty

    Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts (excluding design parts) of the Product upon expiration of seven (7) years after the production of the Product is discontinued. In repairing the monitor, EIZO and Distributors will use renewal parts which comply with our QC standards.

  • Page 35: Recycling Information/Informationen Zum Thema Recycling/Informations Sur Le Recyclage/Сведения По Утилизации

    Este producto debe desecharse y reciclarse según la legislación del país para reducir el impacto medioambiental. Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una filial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. www.eizoglobal.com...
  • Page 36 Este produto, quando o deitar fora, deve ser recolhido e reciclado de acordo com a legislação do seu país para reduzir a poluição. Quando deitar fora este produto, contacte um distribuidor ou uma filial no seu país. Os endereços de contacto estão listados no website do EIZO, abaixo. www.eizoglobal.com...
  • Page 37 страна за да се намали замърсяването на околната среда. Когато искате да се освободите от този продукт, моля свържете се с търговския му представител или със съответните органи отговарящи за това във вашата страна. Данните за връзка с нас са описани на следния Интернет сайт на EIZO: www.eizoglobal.com Informaţie referitoare la reciclare Acest produs, când debarasat, trebuie colectat şi reciclat conform legislaţiei ţării rspective ca să...
  • Page 38 Bu ürünün, atılacağı zaman, ülkenizin çevre kirliliğinin azaltılması konusundaki mevzuatına göre toplanması ve yeniden değerlendirilmesi gerekmektedir. Ürünü atacağınız zaman lütfen ülkenizdeki bir distribütör veya ilgili kuruluşla temasa geçiniz. İrtibat adresleri aşağıdaki EIZO web sitesinde verilmiştir. www.eizoglobal.com Recycling Information/Informationen zum Thema Recycling/Informations sur le recyclage/Сведения по утилизации...
  • Page 39 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan Helmut-Grashoff-Strasse 18, 41179 Mönchengladbach, Germany 中国苏州市苏州工业园区展业路 8 号中新科技工业坊 5B 00N0N180A1 www.eizoglobal.com SUM-FDF2711W-IP-4 Copyright © 2019 EIZO Corporation. All rights reserved. 1st Edition-December, 2019 Printed in Japan.
