Instruction Manual
Color LCD Monitor
Software Version 5.3
Important
Please read this "Instruction Manual", "Installation Manual", and
"Setup Manual" carefully to familiarize yourself with safe and
effective usage.
• For the latest product information including the "Instruction
Manual", refer to our web site :
www.eizoglobal.com

Advertisement

Table of Contents
loading

Related Manuals for Eizo DuraVision FDF2711W-IP

Summary of Contents for Eizo DuraVision FDF2711W-IP

  • Page 1 Instruction Manual Color LCD Monitor Software Version 5.3 Important Please read this “Instruction Manual”, “Installation Manual”, and “Setup Manual” carefully to familiarize yourself with safe and effective usage. • For the latest product information including the “Instruction Manual”, refer to our web site : www.eizoglobal.com...
  • Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.

  • Page 3: Cleaning

    Cleaning The stains on the cabinet and LCD panel surface can be removed by moistening part of a soft cloth with water. Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or LCD panel, and also quality deterioration of the image.

  • Page 4: Table Of Contents

    CONTENTS Cleaning ..............3 To use the monitor comfortably ......3 CONTENTS ............. 4 Chapter 1 Product Overview ......5 1-1. System Configuration ........5 Chapter 2 Turning On / Off the Power ....6 2-1. Turning On the Power ........6 2-2.

  • Page 5: Chapter 1 Product Overview

    Chapter 1 Product Overview This product is a color LCD monitor capable of displaying images from a maximum of 32 network cameras *1 A type of camera which converts images into network signals and transmits the signals. 1-1. System Configuration Product main unit Network camera Ethernet...

  • Page 6: Chapter 2 Turning On / Off The Power

    Chapter 2 Turning On / Off the Power 2-1. Turning On the Power Turn on the main power switch on the back of the monitor. The main power switch is turned on by factory settings. Press on the front of the monitor. The power indicator lights up blue and the live image screen is displayed.

  • Page 7: Chapter 3 Operating The System

    Chapter 3 Operating the System This product can be operated using a USB mouse, USB keyboard, or joystick. This chapter describes operation using a USB mouse. Attention • Please connect a USB mouse, USB keyboard, or joystick to the USB downstream port in advance. 3-1.

  • Page 8: Basic Menu Operations

    ● Basic menu operations The menu is used to set display settings of the image display area and to set the settings of the system and network cameras. Screen Layout Display mode menu Current time System menu / Camera control menu Image display area •...
  • Page 9 Display mode menu Camera images displayed on the live screen can be operated. With the Enterprise edition, the icons displayed can be changed from the setting screen. For details, see the “Installation Manual”. Display mode menu Shortcut key Details (Default settings) Displays or hides the menu.

  • Page 10: Logging In

    3-2. Logging In Attention • The operable range differs according to the user account level for accessing this product. Levels include “LIVE”, “CAMERA CONTROL”, and “ADMIN”. The operable range for each level is as shown below. (√: Operable, -: Inoperable) System menu Switching camera Operation...
  • Page 11 Entering characters • When entering using a USB mouse Clicking an item that requires characters to be input, such as a text box, will display a software keyboard. When the focus is moved out of the software keyboard, the software keyboard is hidden. •...

  • Page 12: Setting Screen Display

    3-3. Setting Screen Display Note • With the Enterprise edition, the icons displayed can be changed from the setting screen. For details, see the “Installation Manual”. ● To change over the screen layout Set the number of images to be displayed simultaneously on the live image screen. Procedure 1.

  • Page 13: To Change Over The Page Displayed On The Screen

    ● To change over the page displayed on the screen Camera images are displayed by changing over pages. Pages can be changed over either manually or automatically at a set interval (sequence display). Note • When “Custom Screen” is specified for the screen layout, the number of pages varies depending on the specified number of screens.

  • Page 14: To Switch Camera Image Display Positions

    ● To switch camera image display positions If the image layout is displayed in multiple screens other than one screen, camera image display positions can be switched. Attention • It is necessary to log in as a user with a user level of “ADMIN”. •...

  • Page 15: Operating Network Cameras

    3-4. Operating Network Cameras ● Before operation Network camera control is allowed only when the level of the user accessing this product is “CAMERA CONTROL” or “ADMIN”. Be sure to log in to the system with a user account of this level. Procedure 1.

  • Page 16: To Operate Network Cameras

    ● To operate network cameras Procedure 1. Select the network camera to operate. Select a network camera displayed in the Live Image Screen. The frame around the selected camera image become bold. 2. Operate each function. Attention • Depending on the type of the network camera you are using, some functions may not be available. •...
  • Page 17 Brightness / Preset / Focus Function Description Brightness Adjust the network camera brightness. The image becomes darker. Returns the brightness to the default setting. The image becomes brighter. Preset Moves the camera orientation to the position registered in advance. 1. Select the preset number. Note •...
  • Page 18 Auxiliary Command Function Description Auxiliary Operates the auxiliary functions of a network camera, or executes actions of registered Command event rules. 1. Select the “Auxiliary Command” list box. 2. Select • The auxiliary functions of the network camera can only be operated with specific devices that have protocols set to “ONVIF”...
  • Page 19 03V28080B1 UM-FDF2711W-IP Copyright © 2019 - 2020 EIZO Corporation. All rights reserved. 2nd Edition - August, 2020...
