Positioning Electrophoresis Gels/Film or Transparent
Film
This procedure applies when you use the lower scan bed of the Bio-5000 Plus to scan
the electrophoresis gels/film or transparent film.

Using the Leak-Free Glass Holder

1. Place the gel or film to be scanned on top of the glass surface of the Leak-Free
2. Insert the holder all the way into the transparency bay (lower compartment) of the
The correct side up is the side
showing the holder labels
facing up
6 Bio-5000 Plus Supplement
Glass Holder.
scanner. Make sure the holder is inserted correct side up.
Please take note of it if you want to scan
film, place the film to be scanned face
down on top of the holder, and secure the
film to the glass surface if needed with the
vinyl strips provided.
Keep calibration strip clear
and free of any obstruction
Vinyl strip
