Specifications / System Requirements - Microtek Bio-5000 Plus Supplement Manual

Specifications
Image Sensor
Scanning Modes
Light Source
Scanning Area
Resolution
Dynamic Range
Interface
Dimensions (L x W x H)
Weight
Voltage
Power Consumption
Environment
System Requirements
General Requirements
• CD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 512 MB RAM or more
PC and compatibles
• Pentium IV PC or higher with USB, or Hi-Speed USB (USB 2.0) port
• • Microsoft Windows XP, Vista, Windows 7; compatible with Windows 8
Important
Specifications, software bundles, and accessories are subject to change without
notice. Not responsible for typographic errors.
CCD
Color and grayscale in a single scanning pass
True 48-bit color (approx. 281 x 10
16-bit grayscale (approx. 65,536 shades of gray)
LED
Reflective:
Max. 8.5" x 14" (216 mm x 356 mm)
Min. 0.5" x 0.5" (12.7 mm x 12.7 mm)
Transparency:
Max. 8" x 10" (203 mm x 254 mm)
Min. 0.5" x 0.5" (12.7 mm x 12.7 mm)
Optical: 4800 dpi x 9600 dpi
Interpolated: 65,535 dpi
Transparency: 0.05D ~ 3.7D, 3.77 Dmax
Hi-Speed USB (USB 2.0)
22.3" x 15.2" x 6.2" (567 mm x 385 mm x 158 mm)
26.5 lbs (12 kg)
AC 100V to 240V , 50-60 Hz, 1.5-0.75 A
95 W (Max.)
Operating Temperature: 41° F to 104° F (5° C to 40° C)
Relative Humidity: 20% to 85%
12
colors)
Bio-5000 Plus Supplement 15
