Head Office

TOTO Europe GmbH

Zollhof 2, 40221 Düsseldorf Germany

Tel:+49 (0)700 8686 0700

You are advised to record the following information to allow quick service.

Date of purchase :

Name of shop :

Date : year month day

Tel :

NEOREST

TCF996RWG / RWSW

TCF994RWG / RWSW

■ Thank you for your recent purchase of the TOTO NEOREST. Please read the enclosed

information to ensure the safe use of your product.

■ Be sure to read this Instruction Manual before using your product and keep it in a safe

place for future reference.

2017.8.10

D07209

Printed in China.

Instruction Manual

with Warranty Information

See Page 64.

Table of Contents

Summary of Contents for Toto NEOREST TCF996RWG/RWSW

Page 1 Name of shop : Date : year month day ■ Thank you for your recent purchase of the TOTO NEOREST. Please read the enclosed information to ensure the safe use of your product. ■ Be sure to read this Instruction Manual before using your product and keep it in a safe place for future reference.
Page 2: Table Of Contents
The available functions vary according to the model. Part number system Table of Contents Cleaning Check your model name Model name Top unit and write a check mark in Bowl unit Safety Precautions ....4 Part No. TCF○○○○ this field as needed. CW○○○○...
Page 3: Safety Precautions
Safety Precautions These precautions are important for safe usage. Be sure to follow them and use the product correctly. WARNING Symbols and Meanings Do not use the NEOREST if a malfunction occurs. WARNING • In case of breakdown or other problem, be sure to cut off power by means such as unplugging May result in death or serious injury.
Page 4 When sitting for a long time on the toilet seat, switch the toilet seat temperature adjustment to "OFF". has been dropped or damaged, or if it has been dropped in water. Return the product to TOTO When any of the following persons use a heated seat or warm air drying, someone should switch Europe GmbH for examination and repair.
Page 5 Safety Precautions (Continued) CAUTION WARNING Do not use the product if the top unit is unstable. Insert the power plug securely into the outlet. • Doing so may cause the top unit to come loose and fall, resulting in injury. Check that the power cord is connected.
Page 6: Operational Precautions
Safety Precautions Operational Precautions (Continued) ■ For prevention of malfunctions ■ For prevention of damage CAUTION ● Do not block the body sensor or the remote control ● Wipe plastic areas such transmitter or receiver. as the top unit and remote control with a soft, wet <...
Page 7: Parts Names
Parts Names Control panel Main display Remote control receiver POWER ON/OFF FRONT ON/OFF REAR ON/OFF Soft light POWER LED ENERGY SAVER LED FLUSH CLEAN indicator Model name, Toilet lid cushion part no., etc. UV lamp Toilet lid Top side of the top unit Toilet seat cushions Cover Body sensor A...
Page 8: Preparation
Preparation Using the Product for the First Time 2.Turn on the power Remove the side-panel and Loosen the bottom screw of the side-panel (right) with a insert the power plug. flat-head screwdriver, pull the side-panel diagonally upward, and then pull it out downward. Switch the breaker on the If the remote control is secured 1.Insert the battery...
Page 9: Basic Operations
Basic Operations Press a button on the remote control; a beep sounds when the top unit receives the signal. When flushing and opening/closing the toilet lid and [REAR] Cleanses your rear. toilet seat with the remote control Cleansing [SOFT] Washes your rear with mild water pressure. [ FLUSH] Perform a flush.
Page 10 Basic Operations About the Menu Screen Set up easily with simple steps! This section is an overview Level 1 Level 2 of the settings that can be configured with the remote MENU control. MANUAL CLEANING 1.MANUAL CLEANING ● See the corresponding pages START 2.ENERGY SAVER 1.WAND CLEANING...
Page 11: Automatic Functions (Cleaning Features)
Automatic Functions Support Cleaning Cleaning Features ■ CLEAN indicator ■ Bowl light Lights to show that the "CLEAN" Lights to show that auto bowl cleaning and [ewater+] is used automatically to clean the wand and functions are operating. auto wand cleaning are operating. bowl unit.
Page 12: Automatic Functions (Convenience Features)
Automatic Functions Convenience Features Various automatic As you As you sit As you stand up As you move away approach functions are available, such as a toilet lid that opens and closes automatically. • Changing Operation under the initial settings is described below. Note settings When using the toilet seat...
Page 13: Temperature Adjustment
Temperature Adjustment Warm Water / Toilet Seat / Drying You can adjust the temperature levels or turn the settings to "OFF". Remove the remote control from Press [TEMP]. to select the item to select the <Settings the hanger. you want to set. temperature level.
Page 14: Energy Saver Features
Energy Saver Features Type You can save energy by turning the toilet seat heater to a low temperature (or turning the heater "OFF") during periods when the toilet will be used infrequently. • It takes about 10 days for the product to determine the periods when it is used relatively less frequently. When energy saver is set When energy saver is in operation Type...
Page 15 Energy Saver Features How to set Set the timer energy saver at the time you want to start it. MENU to select ENERGY SAVER 1.MANUAL CLEANING 1.AUTO ENERGY SAVER [AUTO ENERGY 2.ENERGY SAVER 2.TIMER SAVER SAVER]. Press [MENU]. SELECT [●ENTER]PUSH [●ENTER]PUSH SELECT AUTO ENERGY...
Page 16: Power Plug / Top Unit
Maintenance Power plug Top unit Power plug WARNING Caution with use of detergent (Perform monthly) <Europe and Russia Only> ● The NEOREST is an electric appliance. Be careful not to let water seep inside or leave detergent in the Always disconnect the power plug from gap between the top unit and bowl unit.
Page 17: Bowl Unit
Maintenance Bowl unit Wand Deodorizing ﬁ lter Wand Deodorizing ﬁ lter Bowl unit (Perform daily) (Perform monthly) (Perform monthly) <Wand cleaning> If you notice dirt <If you notice odors> • Strongly acidic cleaners or strong alkaline cleaners Unplug the power plug. (Page 15) •...
Page 18: Wand Cleaning
(included item) (included item) MENU to select 1.MANUAL CLEANING [MANUAL CLEANING]. 2.ENERGY SAVER PUSH Descaling agent (TOTO speciﬁ ed) ● Attention! Press [ ENTER]. MANUAL CLEANING 1.WAND CLEANING ON/OFF ● Please use one of the following descaling agents at specified concentration. (Failure to do so may cause 2.DESCALING MODE...
Page 19 Maintenance Descaling mode <If you think the water pressure has weakened> Descaling mode <When [POWER] LED (blue) and [ENERGY SAVER] LED (orange) ﬂ ash> (Continued) Drain water passage. Insert funnel and pour diluted agent. (1st time) Attention! Beaker START Funnel to select [YES].
Page 20: Water Filter Drain Valve
Maintenance Descaling mode Water Filter Drain Valve Descaling mode Water Filter Drain Valve <If you think the water pressure has weakened> (Perform once every 6 months) <When [POWER] LED (blue) and [ENERGY SAVER] LED (orange) ﬂ ash> (Continued) <If you think the water pressure has weakened> Remove the funnel and put cap and cover back on.
Page 21: Changing Settings
Changing Settings Setting List WATER TEMP SEAT TEMP DRYER TEMP Remote control back side Setting Types Available Settings* Setting Ref.Page • Set whether or not to clean the bowl unit AUTO FLUSH ON/OFF automatically AUTO FLUSH Page 42 • Change the amount of time before the toilet AUTO FLUSH DELAY 5S/10S/15S ﬂ...
Page 22 Changing Settings AUTO FLUSH to select MENU AUTO FLUSH 1.MANUAL CLEANING 1.AUTO FLUSH [AUTO FLUSH]. 2.ENERGY SAVER 2.AUTO FLUSH DELAY Press [MENU]. PUSH SELECT [●ENTER]PUSH Set whether or not to clean the bowl unit automatically MENU to select AUTO FLUSH 2.ENERGY SAVER AUTO FLUSH 3.AUTO FUNCTION...
Page 23 Changing Settings AUTO OPEN / CLOSE to select MENU AUTO OPEN/CLOSE 1.AUTO OPEN/CLOSE 1.MANUAL CLEANING [AUTO OPEN/ 2.AUTO CLOSE DELAY 2.ENERGY SAVER Set whether or not to open CLOSE]. SELECT PUSH Press [MENU]. PUSH the toilet lid automatically AUTO OPEN/ to select [ON/ AUTO OPEN/CLOSE MENU...
Page 24 Changing Settings AUTO CLEANING to select MENU AUTO CLEANING 1.MANUAL CLEANING 1.AUTO WAND CLEAN [AUTO WAND 2.ENERGY SAVER 2.DEODORIZER CLEAN]. Press [MENU]. PUSH SELECT [●ENTER]PUSH Set whether or not to clean the wand automatically AUTO WAND MENU to select 2.ENERGY SAVER AUTO CLEANING CLEAN 3.AUTO FUNCTION...
Page 25 Changing Settings LIGHT to select MENU LIGHT 1.MANUAL CLEANING 1.SOFT LIGHT [SOFT LIGHT]. 2.ENERGY SAVER 2.BOWL LIGHT Press [MENU]. PUSH PUSH Set whether or not to use the soft light MENU SOFT LIGHT to select 2.ENERGY SAVER LIGHT 3.AUTO FUNCTION 1.SOFT LIGHT [ON/OFF] and SOFT LIGHT OFF...
Page 26 Changing Settings OTHER SETTING to select MENU OTHER SETTING 1.MANUAL CLEANING 1.BEEP [BEEP]. 2.ENERGY SAVER 2.PERSONAL SETTING LOCK Press [MENU]. PUSH SELECT [●ENTER]PUSH Set whether or not to make a beep sound MENU BEEP to select 3.AUTO FUNCTION OTHER SETTING 4.OTHER SETTING 1.BEEP [ON/OFF] and...
Page 27: What To Do
What to Do? What to Do? Freeze Damage Prevention When the ambient temperature is likely to drop to 0°C or lower, take measures to prevent freezing. If there is no water due to a power outage or water failure Attention! ■...
Page 28: Long Periods Of Disuse
What to Do? Troubleshooting Long Periods of Disuse If the toilet is in a location you will not visit for a long time, drain the water. First, try the actions described on pages 55 to 62. If the problem persists, consult CAUTION (The water in the tank may become contaminated and cause skin irritation or other problems.) the installer, seller or the contact listed on the back cover of this manual.
Page 29 Troubleshooting Rear and front cleansing, wand Warm air drying Ref. Ref. Trouble Please check Trouble Please check Page Page ● Can you operate with the control panel? (Check while sitting on the toilet seat.) The dryer ● Is the remote control preset temperature set to a low level? ➞Check "Is the remote control working?"...
Page 30 Troubleshooting Flushing Toilet Seat and Toilet Lid (AUTO OPEN/CLOSE) Ref. Ref. Trouble Please check Trouble Please check Page Page ● Is the water supply to the toilet disrupted by other running water ﬁ xtures? ● Is "AUTO OPEN/CLOSE (LID)" set to "OFF"? ➞ Set to "ON". ➞Cease using other fixtures and then flush the toilet.
Page 31 Troubleshooting Toilet Seat and Toilet Lid Sanitary Ref. Ref. Trouble Please check Trouble Please check Page Page The soft light or bowl ● Is the setting "OFF"? ● Is the toilet seat temperature set to "OFF" or a low level? ➞Set to "ON".
Page 32 *1 Volume when used in combination with the dedicated concealed tank. ➞Please peroform Descaling mode. product main body are *2 Temperature around the warm air outlet measured by TOTO. blinking ● When disposing of this product, please follow your local or state guidelines for proper disposal.
Page 33 TOTO distributor or product service contractor, or directly to a TOTO sales ofﬁ ce. If, because of the size of the product or nature of the defect, the product cannot be returned to TOTO, receipt by TOTO of a written notice of the defect shall constitute delivery.
Page 34 MEMO MEMO...
