Operation, Repair, Parts
Free Flow Applicator
For portable spraying of water-based materials. Can be used for application of
solvent-based materials only when solvent compatible seals are installed and solvent
compatible, conductive hoses are used. For professional use only.
Not approved for use in European explosive atmosphere locations.
Models 24B327, 17Z128
1000 psi (6.9 MPa, 69 bar) Maximum Fluid Working Pressure
250 psi (1.7 MPa, 17 bar) Maximum Air Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual and in
the T-Max operation manual before using the equipment.
Save these instructions.
Related Manuals:
3A6748
T-Max Operation, Repair, Parts
313537E
EN
Advertisement
Table of Contents
Related Manuals for Graco 24B327
Summary of Contents for Graco 24B327
- Page 1 For professional use only. Not approved for use in European explosive atmosphere locations. Models 24B327, 17Z128 1000 psi (6.9 MPa, 69 bar) Maximum Fluid Working Pressure 250 psi (1.7 MPa, 17 bar) Maximum Air Working Pressure...
-
Page 2: Fire And Explosion Hazard
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable. -
Page 3: Personal Protective Equipment
Warnings EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alcohol. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system component. -
Page 4: Pressure Relief Procedure
Pressure Relief Procedure Pressure Relief Procedure 3. If you suspect the spray tip or hose is clogged or Follow the Pressure Relief Procedure whenever that pressure has not been fully relieved: you see this symbol. a. If installed, turn prime valve down to prime position. -
Page 5: Flush The Equipment (Solvent-Based Materials)
Flush the Equipment (Solvent-Based Materials) Flush the Equipment (Solvent-Based Materials) To avoid fire and explosion, always ground equipment and waste container. To avoid static sparking and injury from splashing, always flush at the lowest possible pressure. • Flush before changing materials, before fluid can dry or cure in the equipment, at the end of the day, before storing, and before repairing equipment. - Page 6 Setup Setup Install Applicator Tip and Guard 1. If equipment has recently been operated, perform Pressure Relief Procedure, page 4. Make sure pressure control is turned off and gasoline engine is shut off or power cord is unplugged from power source.
-
Page 7: Operation
Operation Operation 2. Rotate SwitchTip back to spray position. Turn applicator ON. Spray test pattern. UNCLOG Airless Spray 1. Be sure the arrow shaped tip (31) faces forward (spray). 2. Hold applicator perpendicular and approximately 40 in. (1 m) from surface. Move applicator first, then open applicator to spray a test pattern. - Page 8 Operation Parts 24B327 Ref. Part Description Qty. Ref. Part Description Qty. 20† 289922 FILTER, screen, texture, 18 mesh 15W371 HOUSING, valve, htx 20a† 289923 FILTER, screen, texture, 30 mesh 24B329 KIT, spool, includes 3a - 3d, 8 15X791 PLUG, air, passage...
- Page 9 Operation Parts 17Z128 Ref. Part Description Qty. Ref. Part Description Qty. 122521 SCREW, machine, 1/4-20 x 2.5 17Z226 HOUSING, valve, htx 24B328 HANDLE, applicator (includes 17) 24B329 KIT, spool, includes 3a - 3d, 8 289874 COUPLER, female, qd 121576 PACKING, o-ring, urethane 114 15G352 GASKET 15W376 WASHER, bearing 19A680 GASKET, solvent-compatible...
-
Page 10: Spool Valve Repair
250 psi (1.7 MPa, 17 bar) Air Requirements 30 scfm (0.84 m3/min) Maximum Fluid Inlet Size 1 in.(m) cam and groove (Graco HP) Air Inlet Size 1/4 npsm(m) Wetted Parts Aluminum, stainless steel, PE, POM, polyurethane, nitrile, nylon, PVC, tungsten carbide Weight †... -
Page 11: Graco Standard Warranty
Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective. This warranty applies only when the equipment is installed, operated and maintained in accordance with Graco’s written... -
Page 12: Graco Information
For patent information, see www.graco.com/patents. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. All written and visual data contained in this document reflects the latest product information available at the time of publication.
