- Page 1 <ORIGINAL> Air-Conditioners PEA-M100, 125, 140GAA OPERATION MANUAL FOR USER English For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit.
-
Page 2: Table Of Contents
In the worst case, this could lead to a serious impediment to securing product safety. - It may also be in violation of applicable laws. - MITSUBISHI ELECTRIC CORPORATION cannot be held responsible for malfunctions or accidents resulting from the use of the wrong type of refrigerant. -
Page 3: Parts Names
Caution: • Never block or cover the indoor or outdoor unit’s intakes or • Do not use any sharp object to push the buttons, as this may outlets. Tall items of furniture underneath the indoor unit, or damage the remote controller. bulky items such as large boxes placed close to the outdoor unit •... - Page 4 2. Parts Names ■ Wired Remote Controller Controller interface The functions of the function buttons change depending on the screen. Refer to the button function guide that appears at the bottom of the LCD for the functions they serve on a given screen. When the system is centrally controlled, the button function guide ⑤...
- Page 5 2. Parts Names Display The main display can be displayed in two different modes: “Full” and “Basic”. The factory setting is “Full”. To switch to the “Basic” mode, change the setting on the Main display setting. (Refer to operation manual included with remote controller.) <Full mode>...
- Page 6 2. Parts Names ■ Wireless Remote-Controller (option) SET TEMPERATURE button CHECK TEST RUN ON/OFF button MODEL SELECT SET TEMPERATURE button Pushing button starts operation. sets and any desired room Pushing again stops operation. temperature. NOT AVAILABLE TEMP ON/OFF FAN SPEED button AUTO STOP/AUTO START button This button is used to set fan Used for selecting timed starting...
-
Page 7: Operation
3. Operation ■ About the operation method, refer to the operation manual that comes with each remote controller. 3.1. Turning ON/OFF 3.1.1. For wired remote controller [ON] [OFF] Press the [ON/OFF] button. Press the [ON/OFF] button again. The ON/OFF lamp will come off, and The ON/OFF lamp will light up in the operation will stop. - Page 8 3. Operation 3.4. Fan speed setting Automatic operation ■ According to a set temperature, cooling operation starts if the room 3.4.1. For wired remote controller temperature is too hot and heating operation starts if the room temperature is too cold. ■...
- Page 9 3. Operation 3.5. Ventilation (For wired remote controller) <Returning to the Operation menu> Press the [RETURN] button to go back 3.5.1. Navigating through the Main menu to the Operation menu. <Accessing the Main menu> Press the [MENU] button. The Main menu will appear. 3.6.
-
Page 10: Timer
4. Timer ■ Timer functions are different by each remote controller. ■ For details on how to operate the remote controller, refer to the appropriate operation manual included with each remote controller. 4.1. For wireless remote controller (option) 1) Set the current time 1 Press the CLOCK button using a thin stick and blink the time A. -
Page 11: Trouble Shooting
6. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) Air conditioner does not heat or cool well. ■ Clean the filter. (Airflow is reduced when the filter is dirty or clogged.) ■ Check the temperature adjustment and adjust the set temperature. ■... -
Page 12: Specifications
6. Trouble Shooting Having trouble? Here is the solution. (Unit is operating normally.) Noise is louder than specifications. ■ The indoor operation sound level is affected by the acoustics of the particular room as shown in the following table and will be higher than the noise specification, which was measured in an echo-free room. - Page 16 Please be sure to put the contact address/telephone number on this manual before handing it to the customer. HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN VN79D608H03...
