Guidelines for the design, purchase and installation of Slant/Fin Caravan gas-fired, hot water modular boiler systems.
CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Ratings and dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . .2,3
Recommended Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Optional factory supply and return headers . . . . . . . . . . . . . .5
Boiler room design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Boiler room air supply requirements . . . . . . . . . . . . . . . . . . . .6
Typical layouts for gas-fired systems . . . . . . . . . . . . . . . . . . .7
Venting a gas-fired system . . . . . . . . . . . . . . . . . . . . . . . . . .8,9
Gas piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10,11
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11,12
CODES AND STANDARDS
All Caravan installations must comply to local codes or, in the
absence of local codes, to the National Fuel Gas Code, ANSI,
Z223.1-latest edition.
In addition where required by the authority having jurisdiction, the
installation must conform to American Society of Mechanical
Engineers Safety Codes for controls and safety devices for
automatically fired boilers, No. CSD-1. The installation must also
conform to the additional requirements of Slant/Fin Instruction Book
publication no. GG-100-40 latest edition.
All electrical wiring is to be done in accordance with the National
Electrical Code ANSI/NFPA No. 70-latest edition and all local electri-
cal codes. The unit must be electrically grounded if an external
power source is used.
In Canada, the installation must be in accordance with standards
CGA B149.1 and B149.2, installation codes for gas burning
appliances and equipment and/or local codes. All electrical
connections are to be made in accordance with Standard C.S.A.
C22.1 Canadian Electrical Code Part 1 and/or local codes.
Many state and local codes require intermittent ignition devices for
gas boilers. Please specify if necessary.
LOCAL CODE APPROVALS
New York City:
GGT and GGHT Caravan Modules - MEA 283-93-E Vol. II
Slant/Fin vent damper NYS approval No. 8859
Pennsylvania:
Caravan boilers are approved in Pennsylvania by PA Cert. 174-BT-S
®
HOT WATER/GAS
APPLICATION GUIDE
SC- control bill of materials . . . . . . . . . . . . . . . . . . . . . . . . . .12
Field wiring at modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
SC-3 system wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
SC-3 ladder wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
SC-9 space heating wiring . . . . . . . . . . . . . . . . . . . . . . . . . .16
SC-9 space heating ladder wiring . . . . . . . . . . . . . . . . . . . . .17
SC-9 space and domestic hot water wiring . . . . . . . . . . . . .18
SC-9 space and domestic hot water ladder wiring . . . . . . . .19
Caravan warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21,22
Request for Caravan rating plate . . . . . . . . . . . . . . . . . . .23,24
INTRODUCTION OF FRESH WATER
Introduction of excessive amounts of fresh water into a system can
cause scaling and leave deposits in the boiler and the surrounding
pipes. This will lead to inefficient boiler operation and breakdown.
Fresh water will enter the system as a result of hidden leaks such
as may occur in underground piping. Relief valves should be piped
to a location that shows visible signs of relief.
Process applications that use fresh water, require the use of heat
exchangers. Any process application that results in introduction of
fresh water into a boiler can cause scaling with deposits forming in
the boiler and surrounding piping. This will damage the boiler.
Introduction of fresh water from leaks will cause similar damage.
In some areas it may be necessary to use a feed water treatment to
control the corrosive makeup of the feed water. Check with the local
authority, to determine if the feed water will need a conditioning
treatment before being supplied to the boiler.
Modular Boilers
Publication No. CG-10-HWG
Printed in the U.S.A. 1212
www.slantfin.com
