Installation Guide
For the i1200/i1300 Series Scanners
Additional instructions can be found in the User's Guide and other supporting documentation.
1
Install the Kodak Driver Software
Insert the Kodak Scanner installation CD
in the CD-ROM drive of your computer.
The software installation starts
automatically.
Select Install Scanner Software and
follow the on-screen instructions.
When the software is finished installing,
click Exit and remove the CD from the
CD-ROM drive.
6
Turn on the power
IMPORTANT: Do not power-on the scanner
until the software is finished loading.
Press the power switch on the back of the
scanner to turn the scanner on.
NOTES:
The scanner will go through an initialization
process. When finished, the LED will stay green.
The operating software will auto detect the
scanner. The New Hardware Wizard will be
launched. Follow the on-screen instructions.
When the scanner has been recognized, it has
been installed successfully.
Package
Contents
2
Attaching the output tray
Slide the output tray along the center
guide underneath the scanner platform
as shown below.
Align
center
guide
The output tray can be placed in a variety of
positions. For more information, see the
section entitled, "Adjusting the output tray" in
Chapter 3 of the User's Guide.
7
Setting up a test scan
Place a document to scan facedown in
the input tray.
Select Start>Programs>Kodak>
Document Imaging>Scan Validation
Tool.
• Kodak i1200 or i1300 Series Scanner
• Output trays
• USB 2.0 cable
• Dangler
• Power supply
• Power cord bundle
• Sample Cleaning Kit
3
Adjusting the input tray and
side guides
Lift the input tray up as shown below.
Adjust the side guides by sliding them in
or out to accommodate the document
size.
Side guides
8
Scanning an image/verification
The Scan Validation Tool dialog box will be
displayed.
Select TWAIN for the Driver Types and
Kodak Scanner: i1210/i1220 or
i1310/i1320 as the Driver.
The Scan Validation Tool dialog box will
be displayed:
View buttons
Start icon
Welcome Folio including:
For information about Kodak Scanners and Kodak Capture
• Installation and application CDs
Software visit our website:
• Registration sheets
Included with the Kodak i1200/i1300 Series Scanners:
• Printed User's Guide, English
• Kodak Capture Software Lite
• Printed Quick Tips Guide
• Nuance ScanSoft OmniPage
• Service contact sheets
• Nuance ScanSoft PaperPort®
• Miscellaneous flyers
4
Connecting the power cord
Use only the power supply that was provided
with your scanner.
Select the appropriate AC power cord.
Attach the appropriate power cord to the
power supply as shown below.
Plug the output power cord from the
power supply into the power port located
on the back of the scanner.
Plug the other end of the power cord into
the wall outlet.
9
Scanning an image/verification
Click one of the View
buttons.
Click the Start
icon. The scanned
document will be displayed in the image
viewer window.
Once you verify the scanned image, the
installation and verification of your
scanner is complete. Congratulations!
If the document did not scan correctly,
refer to the User's Guide for Kodak i1200
or i1300 Series Scanner for more
information.
After verifying a successful scan, a third-
party scanning application software may
be installed to be used with the scanner.
www.kodak.com/go/docimaging
5
Connecting the USB cable
Attach the A end of the USB cable to the
proper USB port on your PC.
B
A
Attach the B end of the USB cable to the
scanner USB port located on the back of
the scanner proper USB port on your PC.
EASTMAN KODAK COMPANY
343 State Street
Rochester, NY 14650 U.S.A
A-61562 Part No. 9E8786
February 2008
©Eastman Kodak Company 2008
TM: Kodak
