Kodak i1210 Quick Tips

CLEANING THE ROLLERS
The scanner transport rollers and imaging area should be
cleaned routinely for optimum performance. Some paper
types and operating environments require cleaning more
often then specified in the User's Guide.
1. Turn off the scanner.
2. Open the scanner cover.
3. With a roller cleaning pad, wipe the rollers from side to
side. Rotate the rollers to clean the entire surface.
IMPORTANT:The Roller Cleaning Pad contains sodium
lauryl ether sulfate which can cause eye
irritation. Refer to the MSDS for more
information.
4. Dry the rollers with a lint-free cloth.
CLEANING OR REPLACING THE SEPARATION
MODULE
1. Open the scanner cover.
2. Push the separation module release lever down and
lift the separation module up and out of position.
3. Manually rotate and wipe the separation module tires
with a roller cleaning pad.
4. Inspect the separation module. If the tires show signs of
wear or damage, replace the tires or the separation
module.
5. Insert the separation module by aligning the pins and
placing it into position.
CLEANING THE IMAGING AREA
1. Remove dust and debris from this area by using a Stati-
cide wipe or a small brush. Be careful not to scratch the
.
imaging area when cleaning
IMPORTANT:Staticide wipes contain isopropanol which can
cause eye irritation and dry skin. Wash your
hands with soap and water after performing
maintenance procedures. Refer to the MSDS
for more information.
2. Wipe the upper and lower imaging area again with an
almost-dry Staticide wipe to remove any streaks
SUPPLIES*
CAT No. Description
148 4864 Kodak Feed Rollers for i1200/i1300
Series Scanners
173 6115 Kodak Separation Module for i1200/
i1300 Series Scanners
826 9607 Kodak Feed Module for i1200/i1300
Series Scanners
853 5981 Kodak Digital Science Roller Cleaning
Pads (qty 24)
896 5519 Staticide Wipes for Kodak Scanners
(qty 144)
* Items are subject to change.
