19-3994; Rev 0; 2/06
General Description
The MAX7349 evaluation kit (EV kit) is an assembled
and tested circuit board that demonstrates the
MAX7349 2-wire-interfaced, low-EMI key switch and
sounder controller. Windows
provides a handy user interface to exercise the features
of the MAX7349.
Windows is a registered trademark of Microsoft Corp.
DESIGNATION
QTY
0.1µF, 10V min X7R ceramic
C1, C12–C16,
capacitors (0603)
8
C23, C24
TDK C1608X7R1E104K
22µF, 16V ceramic capacitor (1210)
TDK C3225X5R1C226K
C3
1
TDK C3225X5R1C226M
0.033µF, 6.3V min X7R ceramic
capacitor (0603)
C5
1
TDK C1608X7R1E333K
Murata GRM188R71E333K
Taiyo Yuden EMK107BJ333KA
22pF C0G ceramic capacitors (0603)
TDK C1608C0G1H220J
C6, C7
2
Murata GRM1885C1H220J
10pF C0G ceramic capacitors (0603)
Murata GRM1885C1H100J
C8, C9
2
TDK C1608C0G1H100J
1µF, 6.3V min X7R ceramic
capacitors (0603)
C18, C19
2
TDK C1608X5R0J105K
Murata GRM188R60J105K
Taiyo Yuden JMK107BJ105MA
0.22µF ceramic capacitor (0603),
C31
0
not installed
TDK C1608X7R1A224K
0.068µF ceramic capacitor (0603),
C32
0
not installed
TDK C1608X7R1E683K
0.022µF ceramic capacitor (0603),
C33
0
not installed
TDK C1608X7R1H223K
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim's website at www.maxim-ic.com.
®
98SE/2000/XP software
DESCRIPTION
MAX7349 Evaluation Kit
♦ Proven PC Board Layout
♦ Complete Evaluation System
♦ 7 x 8 Key Matrix Included
♦ Sounder Included
♦ Fully Assembled and Tested
PART
TEMP RANGE
MAX7349EVKIT
DESIGNATION
QTY
C34
0
C35
0
H1, H2
2
JU1
1
JU2, JU3, JU6
3
JU4, JU5, JU9,
4
JU10
JU7, JU8, JU11
0
KEY0–KEY55
56
LED1, LED2
2
P1
1
P2
1
P5 (JTAG)
0
R1
1
R2, R5, R6
3
R7, R8, R9
3
R12, R13
2
R14, R15
2
R21
0
Features
Ordering Information
INTERFACE TYPE
0°C to +70°C
Windows software
Component List
DESCRIPTION
220pF ceramic capacitor (0603),
not installed
TDK C1608X7R1H221K
0.1µF ceramic capacitor (0603),
not installed
TDK C1608X7R1C104K
12-pin headers
2 x 4 dual-row vertical header
3-pin headers
2-pin headers
2-pin headers, not installed
M om entar y 6m m p ushb utton sw i tches
Omron B3F1000
Red LEDs (T1-3/4)
Pizeoelectric sounder
Murata PKM22EPPH-4001-B0
USB series B right-angle PC mount
receptacle
Vertical header, 2 x 5 pins, keyed
pin 7
2.2kΩ ±5% resistor (1206)
1.5kΩ ±5% resistors (1206)
470Ω ±5% resistors (1206)
27Ω ±5% resistors (1206)
10kΩ ±5% resistors (1206)
2.61kΩ ±1% resistor (1206),
not installed
1
