General Description

The MAX9993 evaluation kit (EV kit) simplifies the evalua-
tion of the MAX9993 UMTS, DCS, and PCS base-station
downconversion mixer. It is fully assembled and tested
at the factory. Standard 50Ω SMA connectors are
included on the EV kit for the input and output to allow
quick and easy evaluation on the test bench.
This document provides a list of equipment required to
evaluate the device, a straight-forward test procedure
to verify functionality, a description of the EV kit circuit,
the circuit schematic, a bill of materials (BOM) for the
kit, and artwork for each layer of the PC board.
Contact MaximDirect sales at 888-629-4642 to check
on pricing and availibility for these kits.
Component Suppliers
SUPPLIER PHONE
Coilcraft 800-322-2645
Digi-key 800-344-4539
Johnson 507-833-8822
Mini-Circuits 718-934-4500
Murata 770-436-1300
DESIGNATION QTY
4.0pF ±0.25pF, 50V C0G-type
C1 1 ceramic capacitor (0603)
Murata GRM1885C1H4R0C
22pF ±5%, 50V C0G-type ceramic
C2, C6, C7,
capacitors (0603)
5
C9, C10
Murata GRM1885C1H220J
0.01µF ±10%, 50V X7R-type ceramic
capacitor (0603)
C3, C5, C8 3
Murata GRM188R71H103K
10pF ±5%, 50V C0G-type ceramic
C4 1 capacitor (0603)
Murata GRM1885C1H100J
150pF ±5%, 50V C0G-type ceramic
C11, C12, C13 3 capacitors (0603)
Murata GRM1885C1H151J
PC board edge-mount SMA RF
J1–J4 4 connectors (flat tab launch)
Johnson 142-0741-856
470nH ±5% wi r e-w ound i nd uctor s ( 1008)
L1, L2 2
Coilcraft 1008CS-471XJBC
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim's website at www.maxim-ic.com.
WEBSITE
www.coilcraft.com
www.digikey.com
www.johnsoncomponents.com
www.minicircuits.com
www.murata.com
DESCRIPTION
MAX9993 Evaluation Kit
o Fully Assembled and Tested
o +23.5dBm Input IP3
o 1700MHz to 2200MHz RF Frequency
o 1400MHz to 2000MHz LO Frequency
o 40MHz to 350MHz IF Frequency
o 8.5dB Conversion Gain
o 9.5dB Noise Figure
o Integrated LO Buffer
o Switch-Selectable (SPDT), Two LO Inputs
o Low 0dBm to +6dBm LO Drive
o 40dB LO1 to LO2 Isolation
PART
MAX9993EVKIT
*EP = Exposed paddle.
DESIGNATION QTY
L3 1
R1 1
R2 1
R3, R4 2
R5 1
R6 1
T1 1
TP1 1
TP2 1
TP3 1
U1 1
**The exposed paddle conductor on U1 must be solder attached
to a grounded pad on the circuit to ensure a proper electrical/
thermal design.
Features

Ordering Information

TEMP RANGE IC PACKAGE
Thin QFN 20-EP*
-40°C to +85°C
(5mm x 5mm)
Component List
DESCRIPTION
10nH ± 5% w i r e- w ound i nd uctor ( 0805)
Coilcraft 0805CS-100XJBC
523Ω ±1% resistor (0603)
383Ω ±1% resistor (0603)
7.15Ω ±1% resistors (1206)
Digi-key 311-7.15FCT-ND
200Ω ±5% resistor (0603)
47kΩ ±5% resistor (0603)
4:1 transformer (200:50)
Mini-Circuits TC4-1W-7A
Large test point for 0.062in
PC board (red) Mouser 151-107
Large test point for 0.062in
PC board (black) Mouser 151-103
Large test point for 0.062in
PC board (white) Mouser 151-101
MAX9993ETP-T**
1
