MAX2654/MAX2655/MAX2656 Evaluation Kits
General Description
The MAX2654/MAX2655/MAX2656 evaluation kits
(EV kits) simplify evaluation of the MAX2654/MAX2655/
MAX2656 low-noise amplifiers (LNAs). These kits
enable testing of the devices' performance and require
no additional support circuitry. The signal input and out-
put use SMA connectors to facilitate connection of RF
test equipment.
The MAX2654/MAX2655/MAX2656 EV kits are fully
assembled with the MAX2654/MAX2655/MAX2656 on
board, and incorporate input matching components opti-
mized for specific frequency operation.
Component List MAX2654
DESIGNATION
QTY
6pF ±0.5pF ceramic capacitor
C1
1
(0402), Murata GRM36COG060D050A
1.6pF ±0.1pF ceramic capacitor
C2
1
(0402), Murata GRM36COG1R6B050A
100pF ±5% ceramic capacitors
C3, C8
2
(0603), Murata GRM36COG101J050
22pF ±5% ceramic capacitor
C4
1
(0603), Murata GRM36COG220J050
4.7µF tantalum capacitor 'C' case
C5
1
AVX TAJC475K020
C6
1
Not installed
R4
1
0Ω resistor (0603)
R5
1
10kΩ ±1% resistor (0402)
5.6nH inductor
L1
1
Murata LQW1608A5N6C00T1
L2
1
0nH inductor (0402)
U1
1
MAX2654EXT 6-pin SC70
SMA connectors (edge mount)
RFIN, RFOUT
2
tab contact, EFJohnson 142-0701-851
VCC, GND
2
Test points, Digi-Key 5000K-ND
1
JU1
1
Digi-Key S1012-36-ND
JU1
1
Shunt, Digi-Key S9000-ND
—
1
MAX2654 EV kit circuit board, rev A
________________________________________________________________ Maxim Integrated Products
For price, delivery, and to place orders, please contact Maxim Distribution at 1-888-629-4642,
or visit Maxim's website at www.maxim-ic.com.
DESCRIPTION
3 header (0.1in centers)
✕
o Easy Evaluation of MAX2654/MAX2655/MAX2656
o +2.7V to +5.5V Single-Supply Operation
o RF Input and Output Matched to 50Ω
o Jumper Included for Gain/Shutdown Setting
o Fully Assembled and Tested
Ordering Information
PART
TEMP. RANGE
MAX2654EVKIT
-40°C to +85°C
MAX2655EVKIT
-40°C to +85°C
MAX2656EVKIT
-40°C to +85°C
Component List MAX2655
DESIGNATION
QTY
1800pF ±10% ceramic capacitor
C1
1
(0402), Murata GRM36X7R182K050A
1.5pF ±0.1pF ceramic capacitor
C2
1
(0603), Murata GRM39COG1R5B050A
100pF ±5% ceramic capacitors
C3, C8
2
(0402), Murata GRM36COG101J050A
12pF ±5% ceramic capacitor (0603)
C4
1
Murata GRM39COG120J050A
4.7µF tantalum capacitor 'C' case
C5
1
AVX TAJC475K025
C6
1
Not installed
27pF ±5% ceramic capacitor (0402)
C7
1
Murata GRM36COG270J050A
R1
1
698Ω ±1% resistor (0603)
R2
1
511Ω ±1% resistor (0603)
R3
1
357Ω ±1% resistor (0603)
R4
1
0Ω resistor (0603)
R5
1
10kΩ ±1% resistor (0402)
5.6nH inductor
L1
1
Murata LQW1608A5N6C00T1
Features
IC PACKAGE
6 SC70-6
6 SC70-6
6 SC70-6
DESCRIPTION
1
