Clarion XDZ616w Owner's Manual

Clarion XDZ616w Owner's Manual

Clarion am/fm cd player with cd/md changer control owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
Clarion Co., Ltd.
All Rights Reserved. Copyright © 2001: Clarion Co., Ltd.
2001/1 (D·C)
Printed in China /
Imprimé en Chine
PE-2398B
280-7628-00
/ Inpreso en China
Owner's manual
Mode d'emploi
Manual de instrucciones
XDZ616
AM/FM CD PLAYER
WITH CD/MD CHANGER CONTROL
•
LECTEUR CD AM/FM AVEC
COMMANDE DE CHANGEUR CD/MD
•
RADIO DE AM/FM Y REPRODUCTOR DE DISCOS
COMPACTOS CON CONTROL DE CAMBIADOR
DE DISCOS COMPACTOS/MINIDISCOS

Advertisement

Table of Contents
loading

Related Manuals for Clarion XDZ616w

Summary of Contents for Clarion XDZ616w

  • Page 1 Clarion Co., Ltd. All Rights Reserved. Copyright © 2001: Clarion Co., Ltd. 2001/1 (D·C) Printed in China / Imprimé en Chine / Inpreso en China PE-2398B 280-7628-00 Owner’s manual Mode d’emploi Manual de instrucciones XDZ616 AM/FM CD PLAYER WITH CD/MD CHANGER CONTROL •...

  • Page 2: Table Of Contents

    Touch-n-GO Flip Down Detachable Aluminum Face Controller for Optional DSP/EQ, TV Tuner and DVD Deck Modules Built-In CD TEXT, Also Reads CD TEXT Data from Clarion Compatible CD Changer BEAT EQ with 3 Adjustment Modes CeNET with Balanced Audio Line Transmission and Dynamic Noise Canceling ®...

  • Page 3: Precautions

    ENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTER- FERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR SUB-CHAPTER J APPLICABLE AT DATE OF MANUFACTURE. CLARION CO., LTD. 50 KAMITODA, TODA-SHI, SAITAMA-KEN, JAPAN. MANUFACTURED: SERIAL No. 286- Clarion Co.,Ltd.

  • Page 4: Controls

    3. CONTROLS / LES COMMANDES / CONTROLES Source unit / Appareil pilote / Unidad fuente With the FLIP DOWN PANEL opened / Ouverture du PANNEAU RABATTABLE Apertura del PANEL ABATIBLE Display / Afficheur / Visualizador & ¥ Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter. Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre.

  • Page 5: Remote Control

    Functions of Remote Control Unit Buttons Mode Radio Button * FUNC Turns power on and off. When pressed and held for 1 second: Turns power off. Switches among radio, CD, CD changer, MD changer, AUX, TV, DAB, DSP, and DVD. ( BAND Switches reception DISC UP...

  • Page 6: Operations

    7. OPERATIONS Basic Operations CAUTION Be sure to lower the volume before switching off the unit power or the ignition key. The unit remembers its last volume setting. If you switch the power off with the volume up, when you switch the power back on, the sudden loud volume may hurt your hearing and dam- age the unit.

  • Page 7: Adjusting The Tone

    When you have entered a title in a CD, it ap- pears in the sub display. If you have not en- tered a title, “NO-TITLE” appears in the title display instead. For information on how to en- ter a title, refer to the subsection “Entering titles”...

  • Page 8: Radio Operations

    Basic Operations Adjusting the Beat EQ 1. Press BEQ button 7 and select the Beat EQ mode (1 to 3) to adjust. 2. Press A-M button @ and select “BEQ”. 3. Turning the Rotary knob $ clockwise adjusts in the + direction; turning it counterclockwise adjusts in the –...

  • Page 9: Manual Tuning

    Manual tuning There are 2 ways available: Quick tuning and step tuning. When you are in the step tuning mode, the fre- quency changes one step at a time. In quick tun- ing mode, you can quickly tune the desired fre- quency.

  • Page 10: Cd Operations

    CD Operations Loading a CD 1. Press OPEN button 1 to access the CD in- sertion slot behind the FLIP DOWN PANEL. 2. Insert a CD into the center of the insertion slot with the label side facing up. The CD plays automatically after loading.

  • Page 11: Other Handy Functions

    CD Operations Scan play The scan play locates and plays the first 10 sec- onds of each track on a disc automatically. This function continues on the disc until it is canceled. The scan play is useful when you want to select a desired track.

  • Page 12: Message Display

    Other Handy Functions 7. Turn the Rotary knob $ to select the desired character. Turning the Rotary knob $ clock- wise moves the cursor to the next character; turning it counterclockwise moves the cursor to the previous character. 8. Repeat steps 5 to 7 to enter up to 10 charac- ters for the title.

  • Page 13: Operations Of Accessories

    8. OPERATIONS OF ACCESSORIES CD Changer Operations CD changer functions When an optional CD changer is connected through the CeNET cable, this unit controls all the CD changer functions. This unit can control a total of 2 changers (MD and/or CD). Press FNC button 3 and select the CD changer mode to start play.

  • Page 14: Random Play

    CD Changer Operations Top function The top function plays from the first track (track No. 1) of the disc. When playing a disc 1 to 6 Press the Direct button 8 (1 to 6) with the same number as the CD playing. When playing a disc 7 to 12 (only when a 12 disc CD changer is used.) Press and hold for 1 second or longer the Direct...

  • Page 15: Md Changer Operations

    MD Changer Operations MD changer functions When an optional MD changer is connected through the CeNET cable, this unit controls all the MD changer functions. This unit can control a total of 2 changers (MD and/or CD). Press FNC button 3 and select the MD changer mode to start play.

  • Page 16: Tv Operations

    MD Changer Operations Repeat play The repeat play continuously plays the current track. This function continues automatically until it is canceled. 1. Press RPT button 5. “RPT” lights in the dis- play and the current track is repeated. 2. To cancel the repeat play, press RPT button 5 again.
  • Page 17 Manual tuning There are 2 ways available: Quick tuning and step tuning. When you are in the step tuning mode, the frequency changes one step at a time. In quick tuning mode, you can quickly tune the desired frequency. 1. Press BND button ! and select the desired band (TV1 or TV2).

  • Page 18: Ac Processor Operations

    AC Processor Operations DSP control function If the DSP (DPH910), sold separately, is con- nected to this unit using the CeNET cable, all functions of the AC Processor can be controlled. DSF functions There are 2 modes available in DPH910, STD mode and professional mode.
  • Page 19 G.EQ effect ON/OFF While the “G.EQ” indication ¥ is lit in the dis- play, the G.EQ effect is set to “ON”. The factory default setting is “ON”. 1. Press A-M button @ and select “G.EQ”. While “G.EQ” is selected, “G.EQ” blinks in the dis- play.

  • Page 20: User Memory

    AC Processor Operations Editing/storing a sound field menu (User memory) 1. Select a sound field menu which you want to edit on the basis of. 2. Press and hold ADJ button 2 for 1 second or longer. 3. Press the right or left side of SEARCH button % to select the item to be adjusted.
  • Page 21 Selecting a P.EQ menu 1. Press A-M button @ and select “P.EQ”. “P.EQ” blinks in the display. 2. Press BND button ! to select “BASC” (ba- sic). “BASC” is displayed in the function mode indication 0 in the display. 3. Press one of Direct buttons 8 and select the desired P.EQ menu.

  • Page 22: Digital Radio / Dab Operations

    Note: Be sure to read this chapter referring to the front diagrams of chapter “3.CONTROLS” on page 5 (unfold). Digital Radio / DAB Operations DAB control function When a CeNET cable is used to connect a DAB (sold separetely), all functions can be operated. Listening to the DAB station 1.
  • Page 23 Manual memory The main unit has a manual memory function for DAB programmes. Up to 18 programmes (6 programmes each) can be preset in the pre- set buttons. [M1], [M2] and [M3] 1. Press FNC button 3 to select DAB mode. 2.
  • Page 24 Digital Radio / DAB Operations Information select This is a function for selecting INFORMATION ON or OFF in Information interrupt mode. You can set ON up to 6 information items. You can select any of the 6 items below: INFORMATION item ENGLISH Contents TRAVEL...

  • Page 25: Dvd Operations

    DVD operation DVD deck control When an optional DVD deck (sold separately) is connected through the CeNET cable, this unit controls some DVD deck functions. Listening to DVD Press FNC button 3 and select the DVD mode. Adjust the volume Turning the Rotary Knob $ clockwise increases the volume;...

  • Page 26: Troubleshooting

    9. TROUBLESHOOTING Problem Power does not Fuse is blown. turn on. (No sound is produced.) Incorrect wiring. No sound output Power antenna lead is when operating shorted to ground or the unit with excessive current is required amplifiers or for remote-on the amplifiers power antenna or power antenna.

  • Page 27: Error Displays

    10. ERROR DISPLAYS If an error occurs, one of the following displays is displayed. Take the measures described below to eliminate the problem. Error Display ERROR 2 A CD is caught inside the CD deck and is not ejected. ERROR 3 A CD cannot be played due to scratches, etc.

  • Page 28: Specifications

    11. SPECIFICATIONS FM Tuner Frequency Range: 87.9 MHz to 107.9 MHz Usable Sensitivity: 9 dBf 50dB Quieting Sensitivity: 15 dBf Alternate Channel Selectivity: 70 dB Stereo Separation (1 kHz): 35 dB Frequency Response (±3 dB): 30 Hz to 15 kHz AM Tuner Frequency Range: 530 kHz to 1710 kHz...
