INSTALLATION
INSTRUCTIONS
30² ² ² ² CONVENIENCE WALL OVEN
1 1 1/4² Dia. Conduit Access Hole*
2 5/8² Plywood Floor (Must Support 200 lbs.)
DIMENSIONS
inches
A 30 MIN
B 24 MIN
C 22 5/8 + 1/16
D 24 MIN
E 28 1/2 + 1/16
F 23 1/16
G 29 3/4
H 25 7/16
I 4 to 37.5
30² ² ² ² WALL OVEN UNDER COUNTER
1 1 1/4² Dia. Conduit Access Hole*
2 5/8² Plywood Floor (Must Support 200 lbs.)
DIMENSIONS
inches
A 25
B 24 MIN
C 22 5/8 + 1/16
D 24 MIN
E 28 1/2
F 23 1/16
G 29 3/4
H 25 7/16
I 36
J 1 1/2
30² ² ² ² WALL OVEN
K All JA Cooktops
*
NOTE: Hole must be cut as close to corner of cabinet as possible.
**
See dealer for approved cooktops.
Built-In 30² ² ² ²
Electric Wall Ovens
cm
76.20
60.96
57.47
60.96
72.39
58.58
75.57
64.61
10.2 to 95.25
cm
63.50
60.96
57.47
60.96
72.39
58.58
75.57
64.61
91.44
3.81
inches cm
9 1/2 MAX 24.13 MAX
Z Do not block air exhaust slots along bottom of oven.
Y Gas or electric cooktops may be installed over ovens. See cooktop installation
instructions for cutout size.
W Electrical connection for electric cooktop must in adjacent accessible location. Cook
top and wall oven must be on separate 120/240 or 120/208 volt 60 Hz AC circuits.
CONVENIENCE WALL OVEN
UNDER COUNTER WALL OVEN
NOTES
403 WEST FOURTH STREET, NORTH
NEWTON, IA 50208
8101P485-60
(05-03-00)
