- Page 1 Model: 202355, 202356 Lit. #: 98-2387/09-12...
- Page 2 ® ™ Congratulations on your purchase of the Bushnell® Scout DX 1000 ARC™, our most compact and versatile laser rangefinder. The Scout DX 1000 ARC™ is a precision Laser Rangefinder optical instrument designed to provide many years of enjoyment. This booklet will help you achieve optimum performance by explaining its adjustments and features as well as how to care for this precise laser rangefinding optical instrument.
- Page 3 HOW OUR DIGITAL TECHNOLOGY WORKS The Scout DX 1000 ARC™ emits invisible, eye safe, infrared energy pulses. The Scout DX 1000 ARC’s Advanced Digital microprocessor and ASIC chip (Application-Specific Integrated Circuit) results in instantaneous and accurate readings every time. Sophisticated digital technology instantaneously calculates distances by measuring the time it takes for each pulse to travel from the rangefinder, to the target, and back.
- Page 4 GETTING STARTED OPERATIONAL SUMMARY While looking through the Scout DX 1000 ARC™, depress the power button once to activate the display. Place the aiming circle (located in the center of the field of view) upon a target at least 5 yards away, depress and hold the power button down until the range reading is displayed near the bottom of the in-view display.
-
Page 5: Table Of Contents
DISPLAY INDICATORS Your Scout DX 1000 ARC™ display incorporates the following illuminated indicators: Angle Range Compensation Symbols Rifle Mode (1) Bow Mode (2) Battery Life Indicator (3) Aiming Circle (4) Active Laser (5) SIGHT DIST Targeting Symbols BullsEye Mode (6) Brush Mode (7) Primary Numeric Display displays Line-of-sight Distance (8) Holdover / Bullet-drop measure for Rifle Mode... -
Page 6: Angle Range Compensation Symbols
-90 to +90 degrees of elevation and is +/- 1.0 degree accurate. The Bushnell® Scout DX 1000 ARC™ solves a problem hunters have been faced with for years. The problem: Bow and rifle hunters have struggled with extreme uphill and downhill angles because of how these angles alter true horizontal distance to your target. -
Page 7: Battery Life Indicator
BATTERY LIFE INDICATOR Battery Indicator: Full charge 2/3 battery life remaining 1/3 battery Life remaining Battery Indicator Blinks - Battery needs to be replaced and unit will not be operable. INSERTING THE BATTERY Remove the Posi-Thread™ battery door by lifting the battery door tab and then rotating counter clockwise. Insert a CR2 3-volt lithium battery into the compartment negative end first, then replace the battery cap. - Page 8 Standard with Automatic SCAN: This setting allows most targets to be distanced up to 1000 yards. Used for moderately reflective targets that are typical of most distancing situations. The minimum distance in the standard mode is 10 yards. To use the Automatic SCAN feature, simply hold down on the POWER button for approximately 3 seconds and move the rangefinder from object to object while leaving the POWER button depressed.
- Page 9 Brush (Indicator - ): This advanced mode allows objects such as brush and tree branches to be ignored so that ™ distance only to background objects are displayed. When more than one object has been acquired, distance of the further object will be displayed and a circle will surround the Brush™ indicator informing the user that distance of the farthest object is being displayed.
-
Page 10: Moa
displayed and flashing, or no indicators lit and the message ( ) flashing. The modes can be cycled through in a circular fashion by pressing and releasing the mode button. The order of modes is a follows: BOW, RIFLE A, RIFLE B, RIFLE C, RIFLE D, RIFLE E, RIFLE F, RIFLE G, RIFLE H, RIFLE I, RIFLE J, REG, etc. - Page 11 SETUP Menu Normal Operating Menu SETUP MENU NORMAL OPERATING MENU When the unit automatically powers down, operation will always return to the normal operation (i.e. away from SETUP) with the last used ARC™ mode active (i.e. BOW, RIFLE, or REGULAR) along with the last used TARGETING modes active (Standard SCAN, BULLSEYE, or BRUSH).
- Page 12 In BOW mode, the line of sight distance will display in the primary numeric display and the inclination and horizontal distance will display in the secondary numeric displays. Bushnell® determined through extensive testing and interviews with high-profile bow hunting experts that multiple bow ballistic groups were not necessary. Bow-hunters want to know true horizontal distance because that is how they practice shooting, and once they confidently know that, they can make any necessary adjustments.
-
Page 13: Secondary Numeric Display
KNOWING WHICH BALLISTIC GROUP TO SELECT Bushnell® engineers have worked with Sierra® Bullets ballistic programs and grouped many of the most popular calibers and loads into eight ballistic groups (A,B,C,D,E,F,G,H). Once you know what caliber and load you are... - Page 14 shooting simply look through the chart to determine which one of the eight ballistic groups match with your particular load and caliber. For Muzzleloaders, we have worked with PowerBelt Bullets to incorporate ballistic data into two ballistic groups (I and J). POPULAR CALIBER &...
- Page 15 Winchester .308 dia. 300 WSM, 180 gr. Ballistic Silver Tip at 3010 FPS Winchester .308 dia. 300 WSM, 180 gr. Fail Safe at 2970 FPS Remington Arms .308 dia. 300 R.S.A.U.M., 180 gr. PSPCL Ultra at 2960 FPS Remington Arms .308 dia. 300 Wby Mag, 180 gr. PSPCL at 3120 FPS Above are a few of the most popular caliber/load combinations.
- Page 16 If you cannot find your load in our ballistic tables, you can still use the bullet drop feature of the laser rangefinder. As above, sight in your rifle at 100 yds. Then shoot the rifle, without adjusting the riflescope, at 300 yds. Measure the bullet drop from the point of aim.
- Page 17 CLEANING Gently blow away any dust or debris on the lenses (or use a soft lens brush). To remove dirt or fingerprints, clean with a soft cotton cloth, rubbing in a circular motion. Use of a coarse cloth or unnecessary rubbing may scratch the lens surface and eventually cause permanent damage.
- Page 18 SPECIFICATIONS Dimensions 1.3 x 4 x 2.9 inches Weight 8 oz. Ranging Accuracy Up to ½ yard accuracy from 5-125 Yards, +/- 1 yards accuracy from 125- 1000 yards. Range 5–1000 Yards / 5–914 Meters Magnification Objective Diameter 21 mm Optical Coatings Fully Multi-Coated Power Source...
- Page 19 TROUBLE SHOOTING TABLE If unit does not turn on, LCD does not illuminate: • Depress power button. • Check and if necessary, replace battery. If unit does not respond to key presses, replace the battery with a good quality CR2 3-volt Lithium battery. •...
