Summary of Contents for Bushnell 202208
- Page 1 L A S E R R A N G E F I N D E R S Model: 202208/202208C 01-14...
- Page 2 Features/Display Simple One Button Operation In-view LCD 4x Magnification Vertical Configuration Rainproof Housing LCD INDICATORS Aiming Reticle Battery Life Indicator Distance Displayed in Yards/Meters...
- Page 3 ACCURACY The ranging accuracy of the Bushnell Bone Collector Laser Rangefinder is plus or minus one yard under most circumstances. The maximum range of the instrument depends on the reflectivity of the target.
-
Page 4: Operational Summary
(LCD). Aim the rangefinder at a target at least 10 yards away, depress and hold the power button down until range reading is displayed. Release the power button. Note: Once activated, the Bushnell Bone Collector Laser Rangefinder’s LCD will remain active and display the last distance measurement for 30 seconds. - Page 5 OPTICAL DESIGN The Bushnell Bone Collector Laser Rangefinder features a fixed focus monocular optical system for viewing your target. A liquid crystal display (LCD) is mounted within the optical system and when...
- Page 6 activated, displays a reticle for targeting, yards, and low battery indicators. Inherent in the manufacturing process are small black spots that appear in the optical system. These are a natural characteristic of the LCD and cannot be fully eliminated in the manufacturing process. They do not affect the distancing performance of the unit.
-
Page 7: Troubleshooting Table
TROUBLE SHOOTING TABLE Before returning your laser rangefinder for repair, consult the Trouble Shooting Table below. If unit does not turn on – LCD does not illuminate : • Depress power button. • Check and if necessary, replace battery. If unit powers down (display goes blank when attempting to power the laser) : •...
