COMPACT COMPONENT SYSTEM
CA-V908T/MX-V608T/MX-V688T
DISC
DISC
DISC
DISC 1
DISC 2
DISC 3
PRO LOGIC
3CH LOGIC
TEST TONE
SLEEP
–
CENTER
+
ONSCREEN
SOUND
LEVEL
CENTER MODE
MODE
–
REAR
+
V.INTRO
FM MODE
LEVEL
DELAY TIME
/ECHO
HIGHLIGHT
L BALANCE R
S.A.BASS
FM/AM
REC PAUSE
SHIFT A
TAPE
AUX
TAPE A
TAPE B
SHIFT B
SELECT
STILL
CD
FADE MUTING
RETURN
REPEAT
+
NEXT
VOLUME
–
PREV
KEY CONTROL
CA-V908T
Consists of CA-V608T and SP-V608
CA-V608T SP-V608
PROGRAM
/RANDOM
REPEAT
EDIT
DISC 1
DISC 2
DISC 3
SLEEP
ONSCREEN
SOUND
MODE
V.INTRO
FM MODE
/ECHO
HIGHLIGHT
S.A.BASS
FM/AM
REC PAUSE
SHIFT A
TAPE
AUX
TAPE A
TAPE B
SELECT
STILL
CD
FADE MUTING
RETURN
REPEAT
+
NEXT
VOLUME
–
PREV
KEY CONTROL
INSTRUCTIONS
MX-V608T
PROGRAM
/RANDOM
DISC
REPEAT
DISC
EDIT
DISC
DISPLAY
CA-V608T
SP-V608
PlayBack
Control
Consists of CA-V688T and SP-V688
CA-V688T SP-V688
MX-V688T
DISC
DISC
DISC
DISPLAY
DISC 1
DISC 2
DISC 3
SLEEP
ONSCREEN
SOUND
MODE
V.INTRO
FM MODE
/ECHO
HIGHLIGHT
S.A.BASS
FM/AM
REC PAUSE
SHIFT A
TAPE
AUX
TAPE A
TAPE B
SELECT
STILL
CD
FADE MUTING
RETURN
REPEAT
+
NEXT
VOLUME
–
PREV
KEY CONTROL
CA-V688T
SP-V688
DIGITAL AUDIO
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
GVT0007-001A
[ U, UT, US, UB ]
PROGRAM
/RANDOM
REPEAT
EDIT
COMPACT
Advertisement
Table of Contents
Related Manuals for JVC CA-V908T
Summary of Contents for JVC CA-V908T
- Page 1 COMPACT COMPONENT SYSTEM CA-V908T/MX-V608T/MX-V688T PROGRAM /RANDOM DISC REPEAT DISC EDIT DISC DISC 1 DISC 2 DISC 3 PRO LOGIC 3CH LOGIC TEST TONE SLEEP – CENTER ONSCREEN SOUND LEVEL CENTER MODE MODE – REAR V.INTRO FM MODE LEVEL DELAY TIME...
