4

. 50-200 FISH FINDER

This chapter provides instructions to assist in planning the installation of the
50-200 FISH FINDER.
4.1

TECHNICAL SPECIFICATIONS

Display Colors
Display Vertical Resolution
Power Requirements
Over Voltage protection
Reverse Polarity protection
Power Consumption - operating:17W max
Power Consumption - stand by : 1.7W max
Operating Frequency
Output Power
Depth Range*
1KW/200kHz
1KW/50kHz
500W/200kHz
500W/50kHz
NOTE* This is not a guaranteed specification. The actual maximum depth capability
of the system depends on the type of transducer fitted, the reflectivity of the
bottom, water condition, etc.
Status LED
External Buzzer
Speed Sensor
Temperature Sensor
NMEA Output sentences
Operating temperature range
Storage temperature range
Weight
Water Proof Specification
Case Size
User Manual
: 16 colors on color chart plotter or 16 gray
levels on gray levels chart plotter
: up to 400 pixels (depending on chart
plotter screen resolution)
: 10 - 35 Volt dc
: Dual 50 and 200kHz
: 500/1000W (4000/8000Wpp)
: 2.5Ft (0.76m) to 1200Ft (366m)
Max Typical = 980Ft (299m)
:
5Ft (1.52m) to 4000Ft (1219m)
Max Typical = 2700Ft (823m)
2.5Ft (0.76m) to
:
Max Typical = 600 Ft (183m)
: 5Ft (1.52m) to 1500Ft (457m)
Max Typical = 1350 Ft (411m)
: 12VDC, 400mA
: if available on transducer
: one channel TEMP1 (if available on
transducer), optional second channel
TEMP2
: Depth: $SDDPT, $SDDBT
Speed: $VWVHW
Trip Log: $VWVLW
Water Temperature: $YXMTW
TEMP2 Temperature: $YXXDR
: 0C to +50C
: -20C to +70C
: 1 kg (2,20 LBS)
: IP 54
: 7.62" (193.30mm)
(174.30mm) x 2.19" (55.50mm)
700Ft (213m)
x 6.87"
25
