below the bottom of the screen, automatically moves up/down the current zoomed
Fish Finder Display view and re-position the Variable Depth Marker (VDM) at the
center of the screen.
NOTE Pressing [CLEAR] hides the Depth Cursor and if the Fish Finder is in Auto
Range or Bottom Lock mode switches into Bottom Lock Zoom mode.
2.4

INFO ON FISH FINDER: SYSTEM INFORMATION

If you want to know information about the Fish Finder connected, follow the
procedure:
[MENU] + "SETUP" + [ENTER] + "SYSTEM INFORMATION" + [ENTER]
A window will be shown with the desired information on the Fish Finder Library
row and on the Fish Finder module row.

2.4.1 The System Update menu

The System Update menu allows downloading the Fish Finder firmware into the
Fish Finder device. To select this menu follow the procedure:
[MENU] + "SETUP" + [ENTER] + "SYSTEM INFORMATION" + [ENTER] +
[MENU] + "Update BBFF Firmware" + [ENTER]
The current Fish Finder firmware version is shown in the System Update window
that appears on the screen.
Insert the C-CARD with the firmware in one of the chart plotter available slots, and
the press [ENTER] to update. Now select "YES" and press [ENTER] to confirm.
Turn Off and after a few seconds turn On the 50-200 FISH FINDER in case of
failed firmware upload.
18
Fig. 2.4 - System Information page
