Service Manual
Change for Life
Service Manual
Models:
GPC07AH-K3NNC3D
GPC08AH-K3NNC3D
GPC09AH-K3NNC3D
GPC08AH-K3NNC4A
GPC08AH-K3NNC4B
GPC07AH-K3NNC4B
GPC07AH-K3NNC4D
GPC08AH-K3NNC4D
GPC08AH-K3NNC5A
GPC09AH-K3NNC5A
GPC07AH-K3NNC5B
GPC08AH-K3NNC5B
GPC08AH-K3NNC5C
GPC09AH-K3NNC5C
GPC07AH-K3NNC5D
GPC08AH-K3NNC5D
GPC09AH-K3NNC5D
(Refrigerant R410A)
GREE ELECTRIC APPLIANCES,INC.OF ZHUHAI
Advertisement
Table of Contents
Related Manuals for Gree GPC07AH-K3NNC3D
Summary of Contents for Gree GPC07AH-K3NNC3D
- Page 1 Service Manual Change for Life Service Manual Models: GPC07AH-K3NNC3D GPC07AH-K3NNC5B GPC08AH-K3NNC3D GPC08AH-K3NNC5B GPC09AH-K3NNC3D GPC08AH-K3NNC5C GPC08AH-K3NNC4A GPC09AH-K3NNC5C GPC08AH-K3NNC4B GPC07AH-K3NNC5D GPC07AH-K3NNC4B GPC08AH-K3NNC5D GPC07AH-K3NNC4D GPC09AH-K3NNC5D GPC08AH-K3NNC4D (Refrigerant R410A) GPC08AH-K3NNC5A GPC09AH-K3NNC5A GREE ELECTRIC APPLIANCES,INC.OF ZHUHAI...
-
Page 2: Table Of Contents
Service Manual Table of Contents Part Ⅰ : Technical Information ............1 1. Summary ....................1 2. Specifications ..................2 3. Outline Dimension Diagram ............20 4. Refrigerant System Diagram ............23 5. Electrical Part ..................24 5.1 Wiring Diagram ..................24 5.2 PCB Printed Diagram ................ -
Page 3: Part Ⅰ : Technical Information
Service Manual Part : Technical Information Ⅰ 1. Summary Models: GPC08AH-K3NNC5A GPC09AH-K3NNC5A GPC07AH-K3NNC5B GPC08AH-K3NNC5B GPC08AH-K3NNC4A GPC08AH-K3NNC5C GPC07AH-K3NNC4B GPC09AH-K3NNC5C GPC07AH-K3NNC3D GPC08AH-K3NNC4B GPC07AH-K3NNC5D GPC08AH-K3NNC3D GPC07AH-K3NNC4D GPC08AH-K3NNC5D GPC09AH-K3NNC3D GPC08AH-K3NNC4D GPC09AH-K3NNC5D Remote Controller: YX1F T-ON T-OFF AUTO SWING COOL SLEEP LOCK SPEED HEAT ON/OFF... -
Page 4: Specifications
Service Manual 2. Specifications Parameter Unit Value Model GPC08AH-K3NNC4A GPC08AH-K3NNC5A CK01001471 Product Code CK01001431 CK01001476 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 8000 8000 Heating Capacity Btu/h Cooling Power Input Heating Power Input Cooling Power Current 3.95 3.87... - Page 5 Service Manual Compressor Manufacturer/ Xi’an Qing’an Refrigeration Equipment Xi’an Qing’an Refrigeration Equipment Trademark Co., Ltd Co., Ltd Compressor Model YZG-A082Y2T2 YZG-A082Y2T2 Compressor Oil POE(RB68EP) POE(RB68EP) Compressor Compressor Type Rotary Rotary L.R.A. 17.00 17.00 Compressor RLA 3.50 3.50 Compressor Power Input Overload Protector B135-140-241E B135-140-241E...
- Page 6 Service Manual Parameter Unit Value Model GPC09AH-K3NNC5A GPC09AH-K3NNC3D Product Code CK01001484 CK010023000 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 9000 9000 Heating Capacity Btu/h Cooling Power Input 1000 1010 Heating Power Input Cooling Power Current 4.44 4.44 Heating Power Current...
- Page 7 Service Manual ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Compressor Manufacturer/Trademark C0.LTD. / GREE CO., LTD. Compressor Model QXA-B102T130 QXA-B102T130A Compressor Oil POE(RB68EP) RB68EP Compressor Type Rotary Rotary Compressor L.R.A. 19.1 Compressor RLA Compressor Power Input Overload Protector UP3-21 HPA-318 Fan Type...
- Page 8 Service Manual Parameter Unit Value Model GPC07AH-K3NNC4B GPC07AH-K3NNC5B CK010018600 Product Code CK010018500 CK010018601 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 7000 7000 Heating Capacity Btu/h Cooling Power Input Heating Power Input Cooling Power Current 3.50 3.50 Heating Power Current...
- Page 9 Service Manual Compressor Manufacturer/ ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Trademark CO., LTD. CO., LTD. Compressor Model QXA-A071L130A QXA-A071L130A Compressor Oil RB68EP RB68EP Compressor Compressor Type Rotary Rotary L.R.A. 13.50 13.50 Compressor RLA 2.80 2.80 Compressor Power Input Overload Protector B120-135A-241E B120-135A-241E Fan Type...
- Page 10 Service Manual Parameter Unit Value Model GPC08AH-K3NNC4B GPC08AH-K3NNC5B CK010018900 Product Code CK010018800 CK010018901 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 8000 8000 Heating Capacity Btu/h Cooling Power Input Heating Power Input Cooling Power Current 4.00 4.00 Heating Power Current...
- Page 11 Service Manual Compressor Manufacturer/ ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Trademark CO., LTD. CO., LTD. Compressor Model QXA-A081L130 QXA-A081L130 Compressor Oil RB68EP RB68EP Compressor Compressor Type Rotary Rotary L.R.A. 15.50 15.50 Compressor RLA 3.30 3.30 Compressor Power Input Overload Protector B130-140B-241E B130-140B-241E Fan Type...
- Page 12 Service Manual Parameter Unit Value Model GPC08AH-K3NNC5C GPC09AH-K3NNC5C Product Code CK010019800 CK010019900 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 8000 9000 Heating Capacity Btu/h Cooling Power Input 1100 Heating Power Input Cooling Power Current Heating Power Current Rated Input 1100...
- Page 13 Service Manual Compressor Manufacturer/ ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Trademark CO., LTD. CO., LTD. Compressor Model QXA-A086R130 QXA-B102T130 Compressor Oil RB68EP POE(ZE-GLES RB68EP) Compressor Compressor Type Rotary Rotary L.R.A. 15.5 Compressor RLA Compressor Power Input Overload Protector B155-150-241E UP3-21 Fan Type Centrifugal Centrifugal...
- Page 14 Service Manual Parameter Unit Value Model GPC07AH-K3NNC3D GPC08AH-K3NNC3D Product Code CK010020900 CK010021000 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 7000 8000 Heating Capacity Btu/h Cooling Power Input Heating Power Input Cooling Power Current...
- Page 15 Service Manual Compressor Manufacturer/ ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Trademark CO., LTD. CO., LTD. Compressor Model QXA-A071L130B QXA-A083A130 Compressor Oil RB68EP RB68EP Compressor Compressor Type Rotary Rotary L.R.A. Compressor RLA Compressor Power Input Overload Protector UP3-B0 UP3-A0 Fan Type Centrifugal Centrifugal Diameter Length(DXL)
- Page 16 Service Manual Parameter Unit Value Model GPC07AH-K3NNC4D GPC08AH-K3NNC4D Product Code CK010021100 CK010021200 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 7000 8000 Heating Capacity Btu/h Cooling Power Input Heating Power Input Cooling Power Current Heating Power Current Rated Input 1130...
- Page 17 Service Manual Compressor Manufacturer/ ZHUHAI LANDA COMPRESSOR ZHUHAI LANDA COMPRESSOR Trademark CO., LTD. CO., LTD. Compressor Model QXA-A071L130B QXA-A083A130 Compressor Oil RB68EP RB68EP Compressor Compressor Type Rotary Rotary L.R.A. Compressor RLA Compressor Power Input Overload Protector UP3-B0 UP3-A0 Fan Type Centrifugal Centrifugal Diameter Length(DXL)
- Page 18 Service Manual Parameter Unit Value Model GPC07AH-K3NNC5D GPC08AH-K3NNC5D CK010021300 CK010021400 Product Code CK010021301 CK010021401 CK010021302 Rated Voltage V ～ 220-240 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 7000 8000 Heating Capacity Btu/h Cooling Power Input Heating Power Input Cooling Power Current Heating Power Current Rated Input...
- Page 19 Service Manual ZHUHAI LANDA COMPRESSOR Compressor Manufacturer/ ZHUHAI LANDA COMPRESSOR Trademark CO., LTD. CO., LTD. Compressor Model QXA-A071L130B QXA-A083A130 Compressor Oil RB68EP RB68EP Compressor Compressor Type Rotary Rotary L.R.A. Compressor RLA Compressor Power Input Overload Protector UP3-B0 UP3-A0 Fan Type Centrifugal Centrifugal Diameter Length(DXL)
- Page 20 Service Manual Parameter Unit Value Model GPC09AH-K3NNC5D Product Code CK010023800 Rated Voltage V ～ 220-240 Power Rated Frequency Supply Phases Cooling Capacity Btu/h 9000 Heating Capacity Btu/h Cooling Power Input 1010 Heating Power Input Cooling Power Current 4.44 Heating Power Current Rated Input 1250 Rated Current...
- Page 21 Service Manual Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD. Compressor Model QXA-B102T130A Compressor Oil RB68EP Compressor Type Rotary Compressor L.R.A. 19.1 Compressor RLA Compressor Power Input Overload Protector HPA-318 Fan Type Centrifugal Diameter Length(DXL) Φ146X108.5 Fan Motor Speed(H/M/L) r/min 1250/1150/1050 Output of Fan Motor Fan Motor RLA 0.41...
-
Page 22: Outline Dimension Diagram
Service Manual 3. Outline Dimension Diagram GPC07AH-K3NNC3D, GPC08AH-K3NNC3D, GPC09AH-K3NNC3D Unit:mm Technical Information... - Page 23 Service Manual GPC08AH-K3NNC4A, GPC07AH-K3NNC4B, GPC08AH-K3NNC4B, GPC07AH-K3NNC4D, GPC08AH-K3NNC4D Unit:mm Technical Information...
- Page 24 Service Manual GPC07AH-K3NNC5A, GPC09AH-K3NNC5A, GPC07AH-K3NNC5B, GPC08AH-K3NNC5B, GPC08AH-K3NNC5C, GPC09AH-K3NNC5C, GPC07AH-K3NNC5D, GPC08AH-K3NNC5D, GPC09AH-K3NNC5D MODE ON/OFF MODE ON/OFF Unit:mm Technical Information...
-
Page 25: Refrigerant System Diagram
Service Manual 4. Refrigerant System Diagram CENTRIFUGAL FAN CENTRIFUGAL FAN Discharge HEAT HEAT EXCHANGE EXCHANGE (EVAPORATOR) (CONDENSER) Suction Accumlator COMPRESSOR Capillary Strainer Technical Information... -
Page 26: Electrical Part
Service Manual 5. Electrical Part 5.1 Wiring Diagram ●Instruction Symbol Symbol Color Symbol Symbol Color Symbol Name White Green COMP Compressor Yellow Brown Grounding wire Blue YEGN Yellow/Green Black Violet Orange ●Electric Diagram GPC08AH-K3NNC4A, GPC08AH-K3NNC5A, GPC08AH-K3NNC5C POWER BN(BK) ROOM TEMP. TUBE TEMP. - Page 27 Service Manual GPC07AH-K3NNC4B, GPC07AH-K3NNC5B, GPC08AH-K3NNC4B, GPC08AH-K3NNC5B POWER BN(BK) TUBE TEMP. ROOM TEMP. WATER MOTOR SENSOR SENSOR BU(WH) YEGN YEGN(GN) TUBE ROOM L(3) WATER1 COMP. K201 DISP2 MOTOR YEGN DISP2 COMP COMP(4) R(M) DISP1 ELECTRIC BOX DISP1 HIGH-WP YEGN WATER LEVEL SWITCH UP FAN MOTOR...
- Page 28 Service Manual GPC07AH-K3NNC3D, GPC07AH-K3NNC4D, GPC07AH-K3NNC5D, GPC08AH-K3NNC3D, GPC08AH-K3NNC4D, GPC08AH-K3NNC5D, GPC09AH-K3NNC3D, GPC09AH-K3NNC5D, These wiring diagrams are subject to change without notice; please refer to the one supplied with the unit. Technical Information...
-
Page 29: Pcb Printed Diagram
Service Manual 5.2 PCB Printed Diagram (1)Silk screen on main board GPC08AH-K3NNC4A, GPC08AH-K3NNC4B, GPC07AH-K3NNC4B, GPC08AH-K3NNC5A, GPC09AH-K3NNC5A, GPC07AH-K3NNC5B, GPC08AH-K3NNC5B, GPC08AH-K3NNC5C, GPC09AH-K3NNC5C TOP VIEW NAME 1 Indoor fan 2 Fuse 3 Copper fin N3 of neutral wire 4 Piezoresistor 5 Copper fin N1 of neutral wire 6 Rectifier 7 Water1 8 Buzzer... - Page 30 Service Manual GPC07AH-K3NNC3D, GPC07AH-K3NNC4D, GPC07AH-K3NNC5D, GPC08AH-K3NNC3D, GPC08AH-K3NNC4D, GPC08AH-K3NNC5D, GPC09AH-K3NNC3D TOP VIEW NAME 1 Connect neutral wire 2 Piezoresistance 3 Fuse 4 Drive replay of compressor 5 Buzzer 6 Interface of display board Interface of high-level detection switch Terminal of outdoor tube...
- Page 31 Service Manual (2)Silk screen on display board GPC08AH-K3NNC4A, GPC08AH-K3NNC4B, GPC07AH-K3NNC4B, GPC08AH-K3NNC5A, GPC09AH-K3NNC5A, GPC07AH-K3NNC5B, GPC08AH-K3NNC5B, GPC08AH-K3NNC5C, GPC09AH-K3NNC5C TOP VIEW receiving head connect with main baord BOTTOM VIEW Technical Information...
- Page 32 Service Manual GPC07AH-K3NNC3D, GPC07AH-K3NNC4D, GPC07AH-K3NNC5D, GPC08AH-K3NNC3D, GPC08AH-K3NNC4D, GPC08AH-K3NNC5D, GPC09AH-K3NNC3D TOP VIEW receiving head connect with main baord BOTTOM VIEW Technical Information...
-
Page 33: Function And Control
6.1 Introduction of control panel signal receiving window cool mode indicator dry mode indicator water full indicator dual-8 nixie tube fan mode indicator GPC07AH-K3NNC3D, GPC08AH-K3NNC4A, GPC07AH-K3NNC4B, GPC08AH-K3NNC4B, GPC07AH-K3NNC4D, GPC08AH-K3NNC3D, GPC08AH-K3NNC4D, GPC09AH-K3NNC3D, MODE button + / - button ON/OFF button water full indicator... -
Page 34: Remote Controller Introduction
Service Manual 6.2 Remote Controller Introduction Buttons on Remote Controller ON/OFF button T-ON T-OFF MODE button AUTO SWING COOL SLEEP LOCK SPEED HEAT +/- botton MODE ON/OFF FAN button SWING SWING button SLEEP TIMER SLEEP button TIMER button Icon Display on Remote Controller Timer on Timer off Sending signal T-ON T-OFF... - Page 35 Service Manual When selecting auto mode, air conditioner will operate automatically according to ex-factory setting. Set temperature can't be adjusted and won't be displayed either. Press FAN button to adjust fan speed. (This function is not available in this air conditioner.) When selecting cool mode, air conditioner will operate under cool mode.
- Page 36 Service Manual Replacement of Batteries in Remote Controller battery 1. Press the back side of remote controller on the spot marked with , and then push out the cover of battery box along the arrow direction. 2. Replace two No.7 (AAA 1.5V) dry batteries and make sure the positions of + and -- polar are correct.
-
Page 37: Introduction Of Basic Mode Function
Service Manual 6.3 Introduction of Basic Mode Function 1. Temperature Parameter ◆ Indoor setting temperature (T preset ◆ Indoor ambient temperature (T amb. 2. Basic Functions of System After the unit is energized, the interval of start-up time for compressor is no less than 3min under any conditions; when the compressor is started, the unit is off without the temperature change in 6min. - Page 38 Service Manual 3.4 TIMER Function ● General timer a) TIMER ON: It can set timer on when the system is off, the setting time range is 0.5h-24h, when the time of setting timer on reaches, and the system runs with the previous setting mode. b) TIMER OFF: It can set timer on when the system is on, the setting time range is 0.5h-24h, when the time of setting timer off reaches, the system stop to work.
-
Page 39: Part Ⅱ : Maintenance
Service Manual Part Ⅱ : Installation and Maintenance 7. Notes for Installation and Maintenance Safety Precautions: Important! 10. Check if there is electric leakage on the unit body. If yes, please eliminate the electric leakage. Please read the safety precautions carefully before 11. - Page 40 Service Manual Main Tools for Installation and Maintenance 1. Level meter, measuring tape 2.Screw driver 3.Scissors, saw 4.Electroprobe 5. Universal meter 6.Torque wrench, open-end wrench, inner hexagon spanner 7. Electronic leakage detector 8. Vacuum pump 9. Pressure meter 10. Pipe pliers, pipe cutter 11.
- Page 41 Service Manual Installation procedures Start installation Preparation before installation Read the requirements Prepare tools for electric connection Install wire hook Install drainage pipe Install window frame Install heat discharge pipe and joint pack up heat discharge pipe Check after installation and test operation Finish installation Note: this flow is only for reference;...
-
Page 42: Install
Service Manual 8. Install 8.1 Install Drainage Pipe 8.2 Install Window Frame Note: install drainage pipe before using, otherwise poor Note: If the inner width of window is below 28"(718mm), drainage will affect normal operation of the unit. please remove the adjusting plate from window frame and then cut the window frame to make its width the same as the width of window. -
Page 43: Installation And Disassembly Of Heat Discharge Pipe
Service Manual (3) Cut the sponge B to a proper length and attach it to the window sash window frame. sponge B (adhesive) clip of rear connection plate Window height (H) window sash windowsill (3) Cut the sponge B to a proper length and attach it to the window (4) Close the window securely against the window frame. - Page 44 Service Manual (2) Insert joint A of heat discharge pipe (the side with "TOP" is upwards) into the groove until you hear a sound.(As shown in following fig) the side with "TOP" is upwards clasp groove (3) Aim the locating pole of joint B of heat discharge pipe at the opening of joint C;...
-
Page 45: Operation Test
Service Manual (2) Press the clasp and lift joint A upwards to remove it.(As shown in following fig) disassemble upwards clasp joint A 8.4 Operation test ●Put through the power supply and then press ON/OFF button on remote controller to start the unit. ●Press mode button to select auto, cooling, drying, fan or heating function, and then check if the unit operates normally. -
Page 46: Clean And Maintenance
Service Manual 8.6 Clean and Maintenance Warning ●Before cleaning the air conditioner, please turn off the unit and disconnect power. Otherwise, it may cause electric shock. ●Do not wash air conditioner with water. Otherwise, it may cause electric shock. ●Do not use volatile liquid (such as thinner or gas) to clean the air conditioner. Otherwise, it may damage the appearance of air conditioner. -
Page 47: Maintenance
Service Manual 9. Maintenance 9.1 Error Code Display Method of Indoor Unit Indicator lamp (During blinking, ON for 0.5S and NO. Malfunction OFF for 0.5 S) A/C Status Possible Causes Error Name Code Operation COOL HEAT Inidicato Indicator Indicator 1. The wiring terminal between indoor ambient temperature sensor and main Indoor board is loosened or poorly contacted. - Page 48 Service Manual Display Method of Indoor Unit Indicator lamp (During blinking, ON for 0.5S and Malfunction OFF for 0.5 S) A/C Status Possible Causes Error Name Code Operation COOL HEAT Inidicato Indicator Indicator During cooling or drying operation,condensate water will flow into Water chassis.
-
Page 49: Malfunction Detection Flowchart
Service Manual 9.2 Malfunction Detection Flowchart (1) Malfunction of temperature sensor F1, F2, F4 Troubleshooting for F1,F2,F4 malfunction the wiring terminal between the temperature sensor and the controller loosened or poorly contacted? Insert the temperature sensor tightly Is malfunction eliminated Is there short circuit due to trip - over of the parts? Make the parts upright... - Page 50 Service Manual (2) Malfunction of Overcurrent Protection E5 Troubleshooting for E5 malfunction Is the supply voltage unstable Normal fluctuation is within 10 % of the rated Malfunction is with big fluctuation? voltage on the nameplate eliminated Is the supply voltage too low Malfunction is Adjust the supply voltage to maintain it within Malfunction is...
- Page 51 Service Manual (3) Bucket full protection H8 Start up the unit H8 is displayed Discharge water by referring Whether water tray is full to instruction manual Check whether wires for water-level Whether malfunction switch are connected tightly is eliminated? Adjust connection Whether malfunction Replace water-level is eliminated?
- Page 52 Service Manual (4) Malfunction of Insufficient fluorine protection F0 （4） Troubleshooting for F0 malfunction Heat exchangers are Clean the heat exchangers and remove Malfunction is too dirty or the air inlet/outlet eliminated. blockage of air inlet/outlet. is blocked. Compressor doesn't work Malfunction is Make compressor run normally.
- Page 53 Service Manual （5） (5) Malfunction of Overload protection for compressor H3 Troubleshooting for H3 malfunction Heat exchangers are Clean the heat exchangers and remove Malfunction is too dirty or the air inlet/outlet eliminated. blockage of air inlet/outlet. is blocked. Fan motor is not working Check motor and re-install the moto Malfunction is Abnormal fan speed;...
- Page 54 Service Manual (6) Overload malfunction E8 Troubleshooting for E8 malfunction Operate the unit after ambient tempeature and Whether the environment Malfunction is humidity is decreased or move the unit to the eliminated. is formidable． place with low abient temprature and humidity. Heat exchangers are Clean the heat exchangers and remove...
-
Page 55: Maintenance Method For Common Malfunction
Service Manual 9.3 Maintenance Method for Common Malfunction 1. Air Conditioner Can't be Started Up Possible Causes for Malfunction Distinguish Method (A/C status) Maintenance Method No power supply; power plug Check whether there’s power supply; hasn’t been inserted tightly and Operation indicator is OFF and buzzer won’t give Check power plug and wire connection. - Page 56 Service Manual 3. Fan Can't Swing Possible Causes Discriminating Method (Air conditioner Status) Troubleshooting Connect wires according to wiring diagram to Wrong wire connection, or poor Check the wiring status according to circuit make sure all wiring terminals are connected connection diagram firmly...
-
Page 57: Exploded View And Parts List
Service Manual 10. Exploded View and Parts List GPC07AH-K3NNC3D, GPC08AH-K3NNC3D, GPC09AH-K3NNC3D 36 37 40 41 42 Maintenance... - Page 58 Service Manual Part Code Description GPC07AH-K3NNC3D GPC08AH-K3NNC3D Product Code CK010020900 CK010021000 Membrane 63066036 63066036 Display Board 30567026 30567026 Guide blade lever 2 10586015 10586015 Guide blade 1 10516059 10516059 Guide blade 2 10516062 10516062 Front Panel 20006078S 20006078S Right side plate...
- Page 59 Service Manual Part Code Description GPC09AH-K3NNC3D Product Code CK010023000 Membrane 63066036 Display Board 30567026 Guide blade lever 2 10586015 Guide blade 1 10516059 Guide blade 2 10516062 Front Panel 20006078S Right side plate 20056112 Discharge Tube 03636571 Inhalation Tube 03001000227 Compressor and fittings 00106544 Overload Protector...
- Page 60 Service Manual GPC08AH-K3NNC4A, GPC07AH-K3NNC4B, GPC08AH-K3NNC4B, GPC07AH-K3NNC4D, GPC08AH-K3NNC4D Maintenance...
- Page 61 Service Manual Part Code Description GPC07AH-K3NNC4B GPC07AH-K3NNC4D Product Code CK010018500 CK010021100 Membrane 63066055 63066055 Front Panel(up) 20006086 20006086 Display Board 30567018 30567025 Guide blade lever 10586017 10586017 Guide blade 1 10516064 10516064 Guide blade 2 10516063 10516063 Front Panel(down) 20006087S 20006087S Right side plate 20056112...
- Page 62 Service Manual Part Code Description GPC08AH-K3NNC4B GPC08AH-K3NNC4A Product Code CK010018800 CK01001431 Membrane 63066055 63066055 Front Panel(up) 20006086 20006086 Display Board 30567018 30567018 Guide blade lever 10586017 10586017 Guide blade 1 10516064 10516064 Guide blade 2 10516063 10516063 Front Panel(down) 20006087S 20006087S Right side plate 20056112...
- Page 63 Service Manual Part Code Description GPC08AH-K3NNC4D Product Code CK010021200 Membrane 63066055 Front Panel(up) 20006086 Display Board 30567025 Guide blade lever 10586017 Guide blade 1 10516064 Guide blade 2 10516063 Front Panel(down) 20006087S Right side plate 20056112 Discharge Tube 03001300037 Inhalation Tube 03001000047 Compressor and fittings 00106531...
- Page 64 Service Manual GPC08AH-K3NNC5A, GPC07AH-K3NNC5B, GPC08AH-K3NNC5B, GPC08AH-K3NNC5C, GPC09AH-K3NNC5C, GPC09AH-K3NNC5A, GPC07AH-K3NNC5D, GPC08AH-K3NNC5D, GPC09AH-K3NNC5D Maintenance...
- Page 65 Service Manual Part Code Description GPC08AH-K3NNC5A Product Code CK01001471 CK01001476 Front Panel Assy 20006109 20006123 Front Panel(up) 20006105 2000610501 Membrane 63066048 63066048 Display Board 30567017 30567017 Guide blade 1 10516064 1051606401 Guide blade 2 10516063 1051606301 Guide blade lever 10586017 1058601502 Decorative Board 20196026...
- Page 66 Service Manual Part Code Description GPC08AH-K3NNC5B Product Code CK010018900 CK010018901 Front Panel Assy 20006123 2000610904 Front Panel(up) 2000610501 20006105 Membrane 63066048 6306603201 Display Board 30567017 30567017 Guide blade 1 1051606401 1051606402 Guide blade 2 1051606301 1051606302 Guide blade lever 1058601502 1058601501 Decorative Board 2019602601S...
- Page 67 Service Manual Part Code Description GPC08AH-K3NNC5C GPC09AH-K3NNC5C Product Code CK010019800 CK010019900 Front Panel Assy 20006123 2000610902 Front Panel(up) 2000610501 2000610501 Membrane 6306603201 6306603201 Display Board 30567017 30567017 Guide blade 1 1051606401 1051606401 Guide blade 2 1051606301 1051606301 Guide blade lever 1058601502 1058601502 Decorative Board...
- Page 68 Service Manual Part Code Description GPC07AH-K3NNC5B Product Code CK010018600 CK010018601 Front Panel Assy 20006109 20006133 Front Panel(up) 20006105 20006105 Membrane 63066048 63066048 Display Board 30567017 30567017 Guide blade 1 10516064 10516064 Guide blade 2 10516063 10516063 Guide blade lever 10586017 10586017 Decorative Board 20196026...
- Page 69 Service Manual Part Code Description GPC07AH-K3NNC5D Product Code CK010021300 CK010021301 CK010021302 Front Panel Assy 20006559 00000300019 00000300141 Front Panel(up) 20006105 2000610501 2000610502 Membrane 6306603201 6306603201 6306603201 Display Board 30567026 30567026 30567032 Guide blade 1 10516064 1051606401 10516064 Guide blade 2 10516063 1051606301 1051606301...
- Page 70 Service Manual Part Code Description GPC08AH-K3NNC5D Product Code CK010021400 CK010021401 Front Panel Assy 20006559 00000300031 Front Panel(up) 20006105 2000610501 Membrane 6306603201 6306603201 Display Board 30567026 30567026 Guide blade 1 10516064 1051606402 Guide blade 2 10516063 1051606302 Guide blade lever 10586017 1058601702 Decorative Board 20196026S...
- Page 71 Service Manual Part Code Description GPC09AH-K3NNC5A GPC09AH-K3NNC5D Product Code CK01001484 CK010023800 Front Panel Assy 20006109 00000300129 Front Panel(up) 20006105 20006105 Membrane 63066048 6306603201 Display Board 30567017 30567032 Guide blade 1 10516064 10516064 Guide blade 2 10516063 10516063 Guide blade lever 10586017 10586015 Decorative Board...
-
Page 72: Removal Procedure
Service Manual Warning: disconnect power supply before 11. Removal Procedure removal; discharge the refrigerant completely before unsoldering the pipes. NOTE:Take GPC08AH-K3NNC4A for example. 1.Remove remote controller box remote controller box Break out the remote controller box, then push the middle of remote controller box to make clasps remove from remote controller box. - Page 73 Service Manual 3.Remove panel assy Remove the five screws fixing panel, lift and pull outward to remove the panel. panel screws assy for C4 panel 4.Remove rear plate Remove the six screws fixing rear plate to remove the rear plate. screws rear plate...
- Page 74 Service Manual Step Procedure 5.Remove left & right side plate screws screws Remove left side plate: unscrew 7 screws as diagram shown to remove left side plate. Remove right side plate: unscrew 7 screws of right side plate to remove it. left side plate right side plate 6.Remove electric box cover...
- Page 75 Service Manual Step Procedure 7.Remove electric box assembly electric box wiring Pull out wiring of electric box, then unscrew 3 screws of electric box to remove electric box assembly. electric box screws assembly 8.Remove facing bar screws facing bar Unscrew 2 screws fixing facing bar to remove it.
- Page 76 Service Manual Step Procedure 10.Remove evaporator assembly spot weld screws screws Unsolder the spot weld, then unscrew 5 screws fixing evaporator to remove it. (note: The refrigerant must be discharg- ed before unsoldering.) evaporator assembly 11.Remove facing bar 2 screws facing bar 2 Unscrew 3 screws fixing facing bar to remove the facing bar 2.
- Page 77 Service Manual Step Procedure 12.Remove facing bar 1 screws facing bar 1 Unscrew 4 screws fixing facing bar to remove the facing bar 1. 13.Remove duct assembly Unscrew 2 screws to remove duct assembly. duct assembly screws Maintenance...
- Page 78 Service Manual Step Procedure 14.Remove connecting rod and vertical louver connecting rod vertical louver 1 Break out connecting rod and vertical louver by hand to remove them. vertical louver 2 15.Remove volute (upper) and mesh enclosure volute (upper) Unscrew 4 screws as diagram shown to remove volute (upper) and mesh enclosure.
- Page 79 Service Manual Step Procedure 16.Remove centrifugal louver (upper) centrifugal louver (upper) Unscrew nuts of centrifugal louver (upper) and motor to remove centrifugal louver (upper). 16.Remove volute (lower) and water tray volute (lower) Unscrew 3 screws as diagram shown to remove volute (lower) and water tray. water tray screws Maintenance...
- Page 80 Service Manual Step Procedure 18.Remove diversion ring screws Unscrew 4 screws fixing diversion ring to remove diversion ring. diversion ring 19.Remove centrifugal louver (lower) centrifugal louver (lower) Unscrew nuts of centrifugal louver anticlockwise, take out gasket to remove the centrifugal louver (lower). 20.Remove motor screws Unscrew 3 screws fixing motor to remove...
- Page 81 Service Manual Step Procedure 21.Remove water retaining tray screws water retaining tray Unscrew 2 screws fixing water retaining tray to remove water retaining tray. 22.Remove condenser assembly spot weld screws Unscrew 2 screws, then unsolder the spot weld to remove condenser assembly. (Note: The refrigerant must be discharged before unsoldering.) condenser assembly...
- Page 82 Service Manual Step Procedure 23.Remove compressor assembly bolts Unscrew 3 bolts of compressor chassis, then take out gasket to remove compressor. compressor and spareparts 24.Remove motor sub-assy, water level switch sub-assy and caster wheel screws screws (1) Unscrew 2 screws of bottom of sub-assy to remove motor sub-assy.
-
Page 83: Appendix
Service Manual Appendix: Appendix 1: Reference Sheet of Celsius and Fahrenheit Conversion formula for Fahrenheit degree and Celsius degree: Tf=Tcx1.8+32 Set temperature Fahrenheit Fahrenheit Fahrenheit display Fahrenheit display Fahrenheit display Fahrenheit Celsius （℃） Celsius （℃） Celsius （℃） temperature temperature temperature （℉）... -
Page 84: Appendix 2: List Of Resistance For Temperature Sensor
Service Manual Appendix 2: List of Resistance for Temperature Sensor Resistance table of temperature sensor (15K) Temp( Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) 138.1 18.75 3.848 1.071 128.6 17.93 3.711 1.039 121.6 17.14 3.579 1.009 16.39 3.454 0.98 108.7 15.68 3.333 0.952... - Page 85 Service Manual Resistance table of temperature sensor (20K) Temp( Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) 181.4 25.01 5.13 1.427 171.4 23.9 4.948 1.386 162.1 22.85 4.773 1.346 153.3 21.85 4.605 1.307 20.9 4.443 1.269 137.2 4.289 1.233 129.9 19.14 4.14 1.198 18.13...
- Page 86 Service Manual Resistance table of temperature sensor (50K) Temp( Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) Temp( Resistance(kΩ) 853.5 18.34 4.75 799.8 93.42 17.65 4.61 89.07 16.99 4.47 703.8 84.95 16.36 4.33 660.8 81.05 15.75 4.20 620.8 77.35 15.17 4.08 580.6 73.83 14.62 3.96 548.9...
-
Page 87: Appendix 3: Resistance Value Table Of Humidity Sensor
Service Manual Appendix 3: Resistance Value Table of Humidity Sensor HIS-06 temperature and humidity characteristic5℃～ 14℃ Unit:KΩ Relative Temperature（℃） humidity 5℃ 6℃ 7℃ 8℃ 9℃ 10℃ 11℃ 12℃ 13℃ 14℃ 5.35 4.92 4.55 4.23 3.95 3.70 3.47 3.25 3.05 2.87 5.80 5.33 4.93... - Page 88 Service Manual 1128.50 1033.61 953.39 883.90 822.61 767.78 704.83 647.37 594.51 545.56 1325.87 1213.40 1118.31 1035.94 963.29 898.30 823.48 755.17 692.34 634.16 1563.51 1430.14 1317.38 1219.71 1133.55 1056.48 967.04 885.39 810.28 740.74 1855.67 1695.83 1560.69 1443.63 1340.37 1248.00 1140.34 1042.06 951.64 867.93 2213.60...
- Page 89 Service Manual 50.20 46.55 43.12 39.89 36.83 33.93 31.76 29.69 27.71 25.82 56.00 51.92 48.08 44.47 41.05 37.80 35.35 33.02 30.79 28.65 62.80 58.20 53.88 49.80 45.95 42.29 39.51 36.87 34.34 31.92 70.00 64.95 60.21 55.74 51.51 47.50 44.33 41.31 38.42 35.65 78.80...
- Page 90 Service Manual 5.49 5.21 4.94 4.68 4.43 4.19 3.97 3.75 3.54 3.34 5.93 5.62 5.33 5.04 4.77 4.50 4.26 4.02 3.80 3.57 6.49 6.13 5.79 5.46 5.14 4.84 4.57 4.32 4.07 3.83 7.00 6.61 6.24 5.88 5.53 5.20 4.91 4.63 4.35 4.09 7.59...
- Page 91 Service Manual HIS-06 Characteristic of temperature and humidity 35℃ ~ 45℃ Unit:KΩ Relative Temperature（℃） humidity 35℃ 36℃ 37℃ 38℃ 39℃ 40℃ 41℃ 42℃ 43℃ 44℃ 45℃ 1.20 1.17 1.14 1.11 1.08 1.05 1.02 1.00 0.98 0.95 0.93 1.27 1.23 1.20 1.16 1.13 1.10...
- Page 92 Service Manual 89.40 82.99 76.75 70.68 64.76 59.00 55.58 52.24 48.98 45.80 42.68 103.00 95.43 88.06 80.89 73.91 67.10 63.17 59.33 55.59 51.93 48.35 119.00 110.35 101.94 93.75 85.77 78.00 73.18 68.47 63.88 59.39 55.00 139.00 129.32 119.90 110.73 101.80 93.10 86.80 80.66...
- Page 93 Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn Http://www.gree.com HONG KONG GREE ELECTRIC APPLIANCES SALES LIMITED Add: Unit 2612,26/F.,Miramar Tower 132 Nathan Road,TST,Kowloon,HK Tel: (852) 31658898 Fax: (852) 31651029 For product improvement, specifications and appearance in this manual are subject to change without prior notice.
