Change for life
AIR CONDITIONER
Owner's Manual
Original Instructions
Portable room air conditioner
Model: GPC07AJ-A3NNA1A
GPH07AJ-A3NNA1A
Thank you for choosing our product.
Please read this Owner's Manual carefully before operation and
retain it for future reference.
If you have lost the Owner's Manual, please contact the local agent
or visit www.gree.com or send an email to global@gree.com.cn for
the electronic version.
Advertisement
Table of Contents
Related Manuals for Gree GPC07AJ-A3NNA1A
Summary of Contents for Gree GPC07AJ-A3NNA1A
- Page 1 Thank you for choosing our product. Please read this Owner’s Manual carefully before operation and retain it for future reference. If you have lost the Owner's Manual, please contact the local agent or visit www.gree.com or send an email to global@gree.com.cn for the electronic version.
-
Page 2: Table Of Contents
Content OPERATION ENVIRONMENT............1 SAFETY WARNING ................2 SUMMARY ..................3 WORKING PRINCIPLE...............3 STRUCTURE ..................4 OPERATING METHODS..............5--7 ...8--9 NAMES AND FUNCTIONS OF THE REMOTE CONTROLLER OPERATION OF THE REMOTE CONTROLLER .....10--12 MALFUNCTION ANALYSIS ............13--15 ACCESSORIES AND INSTALLATION OF HEAT EXHAUST HOSE ....................16--17 INSTALLATION INSTRUCTIONS .......... 18--26 INSTALLATION OF DRAINAGE HOSE .......... - Page 3 Explanation of Symbols Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury.
-
Page 4: Operation Environment
Operation Environment ● The working range of COOL mode and DRY mode: 16 ℃ (61°F)-35 ℃ (95°F). ● The working range of HEAT mode: 10℃ (50°F)-27℃ (80.6°F). ● The Max Cooling operation temperature for the air conditioner is: DB/WB 35 ℃ (95°F)/24℃ (75.2°F). ●... -
Page 5: Safety Warning
Safety Warning ● This appliance can be used by children aged from 8 years and above and persons with reduced physical,sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. -
Page 6: Summary
● The fuse style:T3.15AH250V;Allowed maximal current pass throught the fuse can not above 3.15A. Summary This PORTABLE AIR CONDITIONER is a small, movable air conditioner. It possessed the functions of COOL, HEAT,DRY and the Separate Ventilation, and depends on different places, it can be moved as will.It is fit for home and office use, especially fit for the house with many rooms. -
Page 7: Structure
Structure Front Display Board Air outlet Remote control receptor Rear Handle Upper air inlet grille Heat air exhaust vent Lower air inlet grille Power cord... -
Page 8: Operating Methods
Including an air switch with suitable capacity, please note the following table. Air switch should be included magnet buckle and heating buckle function, it can protect the circuit-short and overload. (Caution: please do not use the fuse only for protect the circuit) Air-conditioner (W) Air switch capacity GPC07AJ-A3NNA1A GPH07AJ-A3NNA1A... - Page 9 Press once to start and press once more to stop the unit. 2.Mode: Press this button to change the operation mode in order of: GPH07AJ-A3NNA1A: GPC07AJ-A3NNA1A: COOL → DRY → FAN →HEAT COOL → DRY → FAN " " "...
- Page 10 Operating methods COOL mode 1). To select a place near the door and window, install the exhaust duct. 2). Press "MODE" key to select "COOL" mode. 3). Press" "or " " key to set the suitable temp.16 ( 61°F ) 30 (86°F). HEAT mode 1).
-
Page 11: Names And Functions Of The Remote Controller
Names and functions of the remote controller ON/OFF Press it to start or stop operation. MODE AUTO Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT). HEALTH X-FAN HUMIDITY FILTER : Press it to decrease temperature setting. TURBO HOUR ON/OFF : Press it to increase temperature setting. - Page 12 Names and functions of the remote controller AUTO HEALTH X-FAN HUMIDITY FILTER TURBO HOUR ON/OFF Up & down swing icon: MODE icon: is displayed when pressing If MODE button is pressed, current operation mode icon button. up & down swing (AUTO), ( COOL), Press this button again to clear the...
-
Page 13: Operation Of The Remote Controller
Operation of the remote controller Remote controller description This is a general use remote controller, it could be used for the air conditioners with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status. - Page 14 Operation of the remote controller HEALTH SAVE: Press HEALTH part of this button to turn on or off HEALTH function. Pressing SAVE part of this button, is displayed and the unit goes into SAVE operation mode. Press SAVE part of the button again to cancel SAVE function. During SAVE operation, the temperature and fan speed is not adjustable.
- Page 15 Operation of the remote controller SLEEP : Press this button to go into the SLEEP operation mode. Press it again to cancel this function. This function is available in COOL, HEAT (Only for models with heating function) or DRY mode to maintain the most comfortable temperature for you. LIGHT: Press LIGHT button to turn on the display's light and press this button again to turn off the display's light.
-
Page 16: Malfunction Analysis
Malfunction analysis Please check below items before asking for maintenance. If the malfunction still can’t be eliminated, please contact local dealer or qualified professionals. Phenomenon Troubleshooting Solution ● Power failure? ● Wait after power recovery. ● Is plug loose? ● Reinsert the plug. ●... - Page 17 Malfunction analysis Phenomenon Troubleshooting Solution ● Whether air outlet or air inlet is ● Eliminate the obstacles. blocked? ● Under heating mode, whether ● Indoor unit will stop blowing indoor temperature is reached fan after reachingto set to set temperature? temperature.
- Page 18 Malfunction analysis Malfunction code 1. Pour out the water inside chassis. 2. If "H8" still exits, please contact professional Chassis is full of water. person to maintain the unit. Malfunction of ambient Please contact previsional person to deal temperature sensor. with it.
-
Page 19: Accessories And Installation Of Heat Exhaust Hose
Accessories and installation of heat exhaust hose Note of Installingheat discharge pipe The discharge pipe is suggested to be installed according to below figure by the manufacturer. correct under 51 inchs about 24 inchs User can adjust the installation method of the discharge pipe basing on the requirement, while the similar installation methods as below which will lead to unsmoothly air-out are not allowed. - Page 20 Accessories and installation of heat exhaust hose The length of the heat discharge pipe is less than 40 inchs. ● It is recommended to use it with shortest length. When installing,heat discharge pipe should be as flat as possible. ● Don’t prolong the pipe or connect it with other heat discharge pipe.
-
Page 21: Installation Instructions
Installation instructions Installation in a double-hung sash window Attach the guard combined above to the Projection window panel Push the insect guard net firmly to ensure that its four projections fit into the holes in the window panel. Cut the foam seal A (adhesive type) to the proper length and attach it to the window stool. - Page 22 Installation instructions Adjustment panel If the inner width of the window is between 24" (609mm) and 36.8" (934mm) inclusive. (1) Open the window sash and place the window panel on the window stool. (2) Slide the adjustment panel to fi t the window frame width.
- Page 23 Installation instructions Installation in a sliding sash window Attach the guard combined above to the window panel. Push the insect guard net firmly to ensure that its four projections fit into the holes in the window panel. Projection Cut the foam seal A (adhesive type) to the proper length and attach it to the window frame.
- Page 24 Installation instructions If the inner height of the window is b e t w e e n 2 4 " ( 6 0 9 m m ) a n d 3 6 . 8 " Adjustment (934mm) inclusive. panel (1) Open the window sash and place the window panel on the window frame.
- Page 25 Installation instructions Cut the foam seals (adhesive type) A and B to the proper length and attach them to the window panel. Attach foam seal A to the window panel and extension panel, and attach foam seal B to the adjustment panel. Close the window sash securely against the Window panel.
- Page 26 Installation instructions clasp Install rear clip — aim the rear clip(upper) at the rear clip(lower), fix them together, press the clasp forcibly in to the groove. hose rear clip Install the hose at the rear clip — aim the opening of hose at the round mouth of rear clip, rotate the hose anticlockwise into the rear clip.
- Page 27 Installation instructions screw This length can be adjusted according The length of rear plate 1 and rear plate 2 can be to user’s requirement adjusted according to user’s requirement. Loosen the screws fixing the rear plate 1, rear plate 2 and adjustable plate to move the rear plate 2 and adjustable plate (can slide freely in the sliding adjustable plate...
- Page 28 Installation instructions Install the exhaust hose sub-assy at the rear plate — fix joint 1 of exhaust hose sub-assy at the air outlet of back plate and the groove at the two side of back plate air outlet, then insert joint 1 into the groove downwards.
- Page 29 Installation instructions Filter 2 — hold the buckle of filter 2 to pull it outwards. buckle of filter 2 filter 2 Install wire hook — press the clasp at the upper side of back plate, assemble the first wire hook downwards into the groove of upper clasp;...
-
Page 30: Installation Of Drainage Hose
Installation of drainage hose ■ Instructions for drainage pipe installation. 1. Fix the drainage pipe clip on the right of rear side plate near drainage port with a screw. drainage pipe clip screw 2. Remove the rubber plug at drainage port. drainage port 3. -
Page 31: Care And Maintenance
Care and maintenance Move unit There are wheels at the bottom of the unit, according to the demand, it can be moved in the room very conveniently. Air inlet grille WARNING Before maintenance, please pull out the power plug and cut off power supply to avoid electric shock. -
Page 32: Electric Schematic Diagram
Before cleaning, please pull out the power plug. Electric Schematic Diagram The Electric schematic diagram are subject to change without notice. Please refer to which one on the unit, GPC07AJ-A3NNA1A: GPH07AJ-A3NNA1A: ROOM TEMP. TUBE TEMP. OUTTUBE TEMP. -
Page 33: Troubleshooting
Troubleshooting If malfunction occur, please check the following before maintenance: Solutions Troubles Possible Causes The power supply is not connected The air conditioner doesn't 1.Insert the power plug tightly. well. start. 2.Replace the power plug or socket. The power plug is not inserted tightly. 3.Ask for the maintenance man to There is the malfunction of power replace the fuse. -
Page 34: User Notices
User notices Location Do not install the unit in the hermetic place, and keep well ventilation, to avoid malfunction occurs. Do not install the unit at where it will be exposed to direct sunlight, in order to avoid fading and efficiency reducing. Do not install the unit in the moist place, it can cause electrical leakage. -
Page 35: After Sales Service
● Meaning of crossed-out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. ● Contact you local government for information regarding the collection systems available. ● If electrical appliances are disposed of in landfills of dumps, hazardous substances can leak into the groundwater and get into the food chain,damaging your health and well-being. - Page 36 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai,Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com 600005060539...
