u BATTERY INDICATOR
Indicates remaining battery power.
Indication
Battery level Full
i LOCK INDICATOR (p. 10)
Appears while the lock function is activated.
o SUB CHANNEL READOUT
• Indicates channel 16 during priority scan. (p. 13)
• Indicates channel 16 during dualwatch or tri-watch.
(p. 14)
!0 DUPLEX INDICATOR
Appears when a duplex channel is selected.
!1 SCRAMBLER INDICATOR
Appears when the optional voice scrambler is activated.
(p. 10)
!2 DUALWATCH/TRI-WATCH INDICATORS (p. 14)
• "DUAL" blinks during dualwatch.
• "TRI" blinks during tri-watch.
Charging No
Middle
required battery
PANEL DESCRIPTION
!3 WEATHER CHANNEL/WEATHER ALERT INDICATOR
(p. 8)
• "WX" appears when weather channel group is selected.
• "ALT" appears while the weather alert function is acti-
vated; blinks when alert tone is received.
!4 LOW POWER INDICATOR (p. 9)
• Appears when low power is selected.
• Blinks when extra low power is selected.
!5 CALL CHANNEL INDICATOR (p. 7)
Appears when a call channel is selected.
!6 TAG CHANNEL INDICATOR (p. 13)
Appears when a tag channel is selected.
