SPECIFICATIONS

D D GENERAL
• Frequency coverage
• Mode
• Power supply requirement
• Current drain
(at 7.5 V DC; approx.)
TX High
(at 6 W)
TX Mid.
(at 3 W)
TX Low
(at 1 W)
RX Max. audio
• Useable temperature range : –20°C to +60°C; –4°F to +140°F
• Frequency error
• Antenna connector
• Dimensions
(Projections not included)
• Weight
(with BP-245)
D D TRANSMITTER
• Output power
(at 7.5 V DC)
• Modulation system
• Max. frequency deviation
• Adjacent channel power
• Spurious emissions
32
: TX 156.025–157.425 MHz
RX 156.050–163.275 MHz
: 16K0G3E
: Specified Icom's battery pack only
:
1.7 A
1.3 A
0.7 A
400 mA
(internal speaker)
200 mA
(external speaker)
: ±10 ppm
: SMA (50 Ω nominal)
: 52.5(W) × 125(H) × 30(D) mm
(W) × 4 (H) × 1
1 29 3
2 ⁄ ⁄ ⁄ (D) inch
16 32 16
: Approx. 280 g (9.9 oz)
: 6 W* , 3 W
(High) (Middle)
and 1 W
(Low) *5 W for some versions
: Variable reactance frequency mod-
ulation
: ±5 kHz
: 70 dB
: –68 dBc typical
D D RECEIVER
• Receive system : Double-conversion superhetero-
• Sensitivity : 0.22 µV typical
(12 dB SINAD)
• Squelch sensitivity : 0.35 µV typical
• Intermodulation rejection ratio: 70 dB typical
• Spurious response rejection ratio:
• Adjacent channel selectivity : 70 dB typical
• Audio output power :
Internal speaker
External speaker
All stated specifications are subject to change without notice or
obligation.
dyne
(at threshold)
70 dB typical
0.6 W typical
at 10% distortion with an
8 Ω load
0.35 W typical
at 10% distortion with an
8 Ω load
