D Rapid charging with the BC-121N+AD-114
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. The following options are addition-
ally required.
• Six AD-114 charger adapters
• An AC adapter or the DC power cable
(BC-157)
Transceiver
Turn power OFF
Battery pack
AC adapter
(Purchase
separately)
DC power cable (OPC-656)
(Connect with the DC power supply;
13.8 V/at least 7 A)
(OPC-656)
AD-114 charger adapters
are installed in each slot.
BATTERY CHARGING
