Page 1: Parts List
71142 ISSUED: MARCH 10, 1999 REVISED: MAY 30, 2000 HOSHIZAKI SELF-CONTAINED CUBER MODEL IM-51BAE IM-51BAE-B PARTS LIST... - Page 2 Auxiliary Codes IM-51BAE IM-51BAE-B Jan. 1999 Apr. 2000 Dec. 1999...
-
Page 4: Ice Cuber Assembly
IM-51BAE, BAE-B A. ICE CUBER ASSEMBLY J-0, K-0... - Page 5 IM-51BAE MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT ICE MAKING MECHANISM ASSEMBLY TRUSS HEAD SCREW CONTROL BOX ASSEMBLY TRUSS HEAD SCREW DOOR ASSY WATER CIRCUIT ASSEMBLY - LABEL LOCATION UNIT FRAME HEX T2 SCREW TOOTH WASHER TOP PANEL FRONT PANEL TRUSS HEAD SCREW...
- Page 6 IM-51BAE MODEL INDEX DESCRIPTION DRAIN PIPE SLOPE INSULATION – BIN COVER – BIN INSULATION – UNIT POWER SUPPLY CORD BUSHING BRACKET – CORD T2 SCREW TOOTH WASHER TOGGLE SWITCH BRACKET – SW TRUSS HEAD SCREW T2 SCREW SPACER (A) SPACER (B) A.
- Page 7 IM-51BAE-B MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT ICE MAKING MECHANISM ASSEMBLY TRUSS HEAD SCREW CONTROL BOX ASSEMBLY TRUSS HEAD SCREW DOOR ASSY WATER CIRCUIT ASSEMBLY - LABEL LOCATION UNIT FRAME HEX T2 SCREW TOOTH WASHER TOP PANEL FRONT PANEL TRUSS HEAD SCREW...
- Page 8 IM-51BAE-B MODEL INDEX DESCRIPTION DRAIN PIPE SLOPE INSULATION – BIN COVER – BIN INSULATION – UNIT POWER SUPPLY CORD BUSHING BRACKET – CORD T2 SCREW TOOTH WASHER TOGGLE SWITCH BRACKET – SW TRUSS HEAD SCREW T2 SCREW SPACER (A) SPACER (B) A.
-
Page 9: Refrigeration Assembly
IM-51BAE, BAE-B B. REFRIGERATION ASSEMBLY J-0, K-0... - Page 10 IM-51BAE MODEL INDEX DESCRIPTION COMPRESSOR PTC RELAY MOTOR PROTECTOR PROTECTOR COVER CLAMP CLIP RUBBER GROMMET GROMMET SLEEVE BOLT CONDENSER – AIR COOLED - TRUSS HEAD SCREW SHROUD T2 SCREW FAN MOTOR FAN BLADE WASHER HEX NUT SCREW BRACKET-FAN MOTOR HEX BOLT SW...
- Page 11 IM-51BAE MODEL INDEX DESCRIPTION T2 SCREW COPPER TUBE (H) COPPER TUBE – COND EVAPORATOR COPPER TUBE (L) PROCESS TUBE (B) INSULATION TUBE BOLT HEAT EXCHANGER COPPER TUBE – HOT GAS INSULATION TUBE SILICONE TUBE COPPER TUBE STRAINER ACCESS VALVE CHARGE TUBE (A)
- Page 12 IM-51BAE-B MODEL INDEX DESCRIPTION COMPRESSOR PTC RELAY MOTOR PROTECTOR PROTECTOR COVER CLAMP CLIP RUBBER GROMMET GROMMET SLEEVE BOLT CONDENSER – AIR COOLED - TRUSS HEAD SCREW SHROUD T2 SCREW FAN MOTOR FAN BLADE WASHER HEX NUT SCREW BRACKET-FAN MOTOR HEX. BOLT SW...
- Page 13 IM-51BAE-B MODEL INDEX DESCRIPTION COPPER TUBE – COND EVAPORATOR COPPER TUBE (L) PROCESS TUBE (B) INSULATION TUBE BOLT HEAT EXCHANGER COPPER TUBE – HOT GAS INSULATION TUBE SILICONE TUBE COPPER TUBE STRAINER ACCESS VALVE CHARGE TUBE (A) CHARGE TUBE (B)
-
Page 14: Ice Making Mechanism Assembly
IM-51BAE, BAE-B C. ICE MAKING MECHANISM ASSEMBLY J-0, K-0... - Page 15 IM-51BAE MODEL INDEX DESCRIPTION WATER PAN ASSY BRACKET - ICE MAKING MECHANISM ACTUATOR MOTOR BOLT CAM (A) CAM (B) CAM SHAFT SPLIT PIN SPRING PIN TOGGLE SWITCH WASHER - TOGGLE SWITCH - CABLE TIE SPRING HOLDER - THERMISTOR TRUSS HEAD SCREW (FT)
- Page 16 IM-51BAE MODEL INDEX DESCRIPTION COVER - ACTUATOR MAGNET CAM SHAFT BEARING HEX BOLT HEX FLANGE NUT C. ICE MAKING MECHANISM ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 4X6234-01 MFT-2019 455938-01 307256-01 5X16, SS 7B02-0516 5, SS 7J02-0500 REQUIRED NUMBER...
- Page 17 IM-51BAE-B MODEL INDEX DESCRIPTION WATER PAN ASSY BRACKET - ICE MAKING MECHANISM ACTUATOR MOTOR BOLT CAM (A) CAM (B) CAM SHAFT SPLIT PIN SPRING PIN TOGGLE SWITCH WASHER - TOGGLE SWITCH - CABLE TIE SPRING HOLDER - THERMISTOR TRUSS HEAD SCREW (FT)
-
Page 18: Control Box Assembly
IM-51BAE, BAE-B D. CONTROL BOX ASSEMBLY J-0, K-0... - Page 19 IM-51BAE MODEL INDEX DESCRIPTION CONTROL BOX COVER - CONTROL BOX T2 SCREW SHIELD PLATE TRUSS HEAD SCREW CONTROLLER BOARD NYLON TIE GROMMET SURGE ABSORBER T2 SCREW BRACKET - PCB T2 SCREW PCB RAIL CAPACITOR T2 SCREW CUSHION TRANSFORMER T2 SCREW D.
- Page 20 IM-51BAE-B MODEL INDEX DESCRIPTION CONTROL BOX COVER - CONTROL BOX T2 SCREW SHIELD PLATE TRUSS HEAD SCREW CONTROLLER BOARD NYLON TIE GROMMET SURGE ABSORBER T2 SCREW BRACKET - PCB T2 SCREW PCB RAIL CAPACITOR T2 SCREW CUSHION TRANSFORMER T2 SCREW D.
-
Page 21: Door Assembly
IM-51BAE, BAE-B E. DOOR ASSEMBLY J-0, K-0... - Page 22 IM-51BAE MODEL INDEX DESCRIPTION DOOR GASKET STOPPER (R) STOPPER (L) PAN HEAD SCREW S FLAT HEAD SCREW E. DOOR ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 2H3895G01 3X2346-01 4X6420G01 4X6421G01 4X12, SS 7C12-0412 4X10, SS 7C22-0410 REQUIRED NUMBER...
- Page 23 MODEL INDEX DESCRIPTION DOOR GASKET STOPPER (R) STOPPER (L) PAN HEAD SCREW S FLAT HEAD SCREW IM-51BAE-B E. DOOR ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER NUMBER 2H3895G02 3X2346-01 4X6420G01 4X6421G01 4X12, SS 7C12-0412 4X10, SS 7C22-0410 REQUIRED NUMBER...
-
Page 24: Water Circuit Assembly
IM-51BAE, BAE-B F. WATER CIRCUIT ASSEMBLY J-0, K-0... - Page 25 IM-51BAE MODEL INDEX DESCRIPTION WATER VALVE PIPE - WATER SUPPLY (A) PIPE - WATER SUPPLY (B) T2 SCREW SILICONE TUBE SILICONE TUBE CLAMP CLAMP PIPE - WATER SUPPLY (C) T2 SCREW RUBBER GASKET DRAIN PIPE T2 SCREW VINYL HOSE CLAMP...
- Page 26 IM-51BAE-B MODEL INDEX DESCRIPTION WATER VALVE PIPE - WATER SUPPLY (A) PIPE - WATER SUPPLY (B) T2 SCREW SILICONE TUBE SILICONE TUBE CLAMP CLAMP PIPE - WATER SUPPLY (C) T2 SCREW RUBBER GASKET DRAIN PIPE T2 SCREW VINYL HOSE CLAMP...
-
Page 27: Label Location
IM-51BAE, BAE-B G. LABEL LOCATION J-0, K-0... - Page 28 IM-51BAE MODEL INDEX DESCRIPTION NAMEPLATE LABEL - R134a CONTROL LABEL WIRING LABEL CAUTION LABEL (G) MAINTENANCE LABEL CAUTION LABEL CAUTION LABEL (D) EMBLEM LABEL PENGUIN (L) G. LABEL LOCATION TITLE MATERIAL PART OR MODEL NUMBER NUMBER 4X6616-01 444463-01 456472-01 3X2349-01...
- Page 29 IM-51BAE-B MODEL INDEX DESCRIPTION NAMEPLATE LABEL - R134a CONTROL LABEL WIRING LABEL CAUTION LABEL (G) MAINTENANCE LABEL CAUTION LABEL CAUTION LABEL (D) EMBLEM LABEL PENGUIN (L) G. LABEL LOCATION TITLE MATERIAL PART OR MODEL NUMBER NUMBER 4A2111-01 444463-01 456472-01 3X2349-01...
-
Page 30: Water Pan Assembly
IM-51BAE, BAE-B H. WATER PAN ASSEMBLY J-0, K-0... - Page 31 IM-51BAE MODEL INDEX DESCRIPTION WATER PLATE WATER TANK (AD) PLATE - LUBRICATION GUIDE - DRAIN SCREW - SPRING HOOK (C) BRACKET (A) - WATER PAN BRACKET (B) - WATER PAN T2 SCREW PUMP MOTOR PACKING HEX BOLT FLAT WASHER HEX FLANGE NUT...
- Page 32 IM-51BAE-B MODEL INDEX DESCRIPTION WATER PLATE WATER TANK (AD) PLATE - LUBRICATION GUIDE - DRAIN SCREW - SPRING HOOK (C) BRACKET (A) - WATER PAN BRACKET (B) - WATER PAN T2 SCREW PUMP MOTOR PACKING HEX BOLT FLAT WASHER HEX FLANGE NUT...
- Page 33 IM-51BAE, BAE-B J. ACCESSORIES J-0, K-0...
- Page 34 MODEL INDEX DESCRIPTION SCOOP BRUSH INSTRUCTION MANUAL IM-51BAE J. ACCESSORIES TITLE MATERIAL PART OR MODEL NUMBER NUMBER 204336-01 4A1987-01 PAPER 91U1UA10B REQUIRED NUMBER...
