- Page 1 INSTALLATION MANUAL PC-101 Paper Feed Cabinet for Product Code 4036 NOTES • Before installing, be sure to unplug the power cord of the machine. • Keep all packing materials out of the reach of children. 4348-7781-03 Printed in Japan...
- Page 2 PC-101 ■ Outline of Installation Procedures for 4036 System When installing the machine and associated options as a system, follow the order shown on the left. PC-101 PC-201 PC-401 DK-501 NOTE For the detailed installation procedures for each option, follow the instructions given in the corresponding Installation Manual and perform the procedures correctly.
- Page 3 PC-101 ■ Unpacking the Paper Feed Cabinet 1. Check that the following accessories are available in the box. 1 Fixing Leg....................4 NOTE 2 Fixing Leg Cover ..................4 When removing the Paper Feed Cabinet from its shipping carton, do not hold onto the reinforcement bracket (indicated by the arrow in the illustration below) (as a 3 Fixing Bracket ..................4...
- Page 4 PC-101 ■ Attaching the machine to the Paper Feed Cabinet 5. Using the Fixing Brackets and Shoulder 1. Remove the Drawer Rear Cover from the Screws furnished with the Paper Feed machine (four screws). Cabinet, secure the machine to the Paper NOTE Feed Cabinet (at two places in the rear).
-
Page 5: Loading Paper
PC-101 ■ Loading Paper ① 2. Install the Fixing Legs at two locations in the 1. Slide out the 3rd Drawer. front shown in the illustration (six screws ✍ furnished with the Paper Feed Cabinet). ③ ③ ① ✍ 4348U023AD 4348U048AA 3. - Page 6 PC-101 ■ Installing the Ornamental Cover ■ Checking and Adjusting the Paper Reference Position 1. Install the Ornamental Cover attached to the 1. Plug the power cord into the power outlet machine (two screws). and turn on the machine. 2. Display the Tech. Rep. Mode screen.
- Page 7 PC-101 7. Measure width A from the edge of the paper 11. Watching the graduations provided in the to the pattern printed on the test print and drawer, move the Edge Guide in the rear. • If width A is greater than the specified value, check that it falls within the specified range.
