Summary of Contents for Zeiss VivaTome
- Page 2 Violations will entail an obligation to pay compensation. All rights reserved in the event of granting of patents or registration of a utility model. Issued by: Carl Zeiss Microscopy GmbH Carl-Zeiss-Promenade 10 07745 Jena, Germany microscopy@zeiss.com www.zeiss.com/microscopy...
-
Page 3: Table Of Contents
DESCRIPTION ........................9 Intended Use ........................9 Functional Principle ......................9 Description of the Instrument and Main Features ............... 11 System Overview VivaTome....................12 Technical Data ........................13 START-UP ........................15 Installation Requirements ....................15 Requirements as to the Microscope Stand ................. 16 Basic Microscope Settings .................... -
Page 4: Notes On Instrument Safety
NOTES ON INSTRUMENT SAFETY General Indications VivaTome has been designed, manufactured and tested in compliance with the standard DIN EN 61010-1 (IEC 61010-1) "Safety Regulations for Electrical Measuring, Control and Laboratory Instruments". The instrument meets the requirements of the EC Directives 2006/95/EC "Low-Voltage Directive" and 2004/108/EC "Electromagnetic Compatibility", as well as the standard DIN EN 62471 (IEC 62471) -
Page 5: Safety Notes
Safety Notes Carl Zeiss Safety Notes VivaTome including its original accessories must not be used for applications other than those described in the present operating manual. Please observe the following warnings: Follow the instructions given in the manufacturers' operating manuals of the HXP 120 and... - Page 6 The white light source must not be switched on until after having connected the output of the liquid light guide tightly with VivaTome and VivaTome firmly screwed to the coupling point of the microscope. Take appropriate protective measures if the specimen releases noxious gases, dust, and vapors,...
- Page 7 NOTES ON INSTRUMENT SAFETY VivaTome Safety Notes Carl Zeiss ® The immersion oil Immersol 518 F irritates the skin. Avoid any contact with skin, eyes and clothing. After skin contact, wash the oil off with plenty of water and soap. After eye contact, immediately rinse the eye with plenty of water for at least five minutes.
-
Page 8: Warning And Information Labels On The Device
No maintenance or repair work other than the operations mentioned in the present manual may be carried out to VivaTome. Repairs are only permitted to the Carl Zeiss Service staff or to persons specifically authorized by this department. In case of fault please turn first to the Carl Zeiss representative competent for you. -
Page 9: Description
Product name: VivaTome VivaTome is a system for creating and imaging optical sections in real time with the aid of a so-called spinning disk provided with a grid pattern. As light source, an HXP 120 / HXP 120 C is used. - Page 10 In this case, K represents a fixed constant correcting differences in the light efficiency of both imaging pathways. A scaled addition of both images yields a conventional widefield image. Thus, all the information from the specimen is captured by VivaTome in a raw data image and is available for further analysis. 423639-9000-701 M60-2-0046 e 05/2012...
-
Page 11: Description Of The Instrument And Main Features
− HXP 120 or HXP 120 C illumination − VivaTome is mounted to the side port (Axio Observer) or camera port (Axio Imager and Axio Examiner) of the microscope using a c-mount camera adapter. Four different filter sets are available. -
Page 12: System Overview Vivatome
DESCRIPTION Carl Zeiss System Overview VivaTome VivaTome System Overview VivaTome Fig. 2-2 System overview 423639-9000-701 M60-2-0046 e 05/2012... -
Page 13: Technical Data
Technical Data Dimensions of VivaTome (W x D x H) ..........approx. 280 mm x 150 mm x 70 mm Dimensions of power supply unit (W x D x H) ........approx. 120 mm x 55 mm x 40 mm Dimensions of HXP 120 / HXP 120 C (W x D x H) ...... - Page 14 Electrical safety............in compliance with DIN EN 61010-1 (IEC 61010-1) Optical Data Light output VivaTome - microscope ..........risk group 2 according to IEC 62471 Light guide coupling VivaTome ......risk group 2 according to IEC 62471 (HXP 120 coupling) 423639-9000-701 M60-2-0046 e 05/2012...
-
Page 15: Start-Up
Stable laboratory bench for microscope system on vibration-isolated base plate or vibration-isolating, − air-cushioned microscope stage Power Requirements: Two additional wall outlets are required to connect the system (VivaTome and HXP 120). Ambient Conditions: 1. Operation, specified power T = 22 °C ±3 °C without interruption (24 h per day,... -
Page 16: Requirements As To The Microscope Stand
The manufacturer does not assume liability for any use that is unrelated to the intended use. Any use of VivaTome in combination with microscope stands having an order number other than that indicated in the present manual is not in accordance with the intended use. -
Page 17: Basic Microscope Settings
Mounting VivaTome The white light source must not be switched on until after having connected the output of the liquid light guide tightly with VivaTome and VivaTome firmly screwed to the coupling point of the microscope. Before mounting VivaTome to the Axio Observer side port it is necessary to screw two supporting feet to it. -
Page 18: Mounting Supporting Feet
START-UP Carl Zeiss Mounting Supporting Feet VivaTome Mounting Supporting Feet Before mounting VivaTome to the Axio Observer side port it is necessary to screw two supporting feet to it. • Unscrew setscrews (Fig. 3-2/1) approximately half way from the supporting feet (Fig. -
Page 19: Connecting Vivatome
Screwing the camera adapter onto the camera Connecting VivaTome • Connect the VivaTome power supply unit with a mains socket outlet. • Connect the DC output of the power supply unit to the socket (Fig. 3-5/2) on the back of the device. -
Page 20: Operation
OPERATION For detailed information on the operation of VivaTome, please see the manufacturer's operating manual included in the delivery. The present chapter describes only the operation of the device in connection with Zeiss peripherals. Control and Functional Elements VivaTome has the following control elements: ON/OFF switch (Fig. -
Page 21: Controlling The Scanhead Via Axiovision
Carl Zeiss Controlling the Scanhead via AxioVision After switching on the scanhead, VivaTome can be controlled completely via the AxioVision software. In this case, the device must be connected to the computer via the USB connector. For operating the AxioVision software please see the operating manual of AxioVision. - Page 22 Non-observance may result in malfunctions. • Mount supporting feet, if necessary (see chapter 3.5). • Connect VivaTome again to the microscope (see chapter 3.4). • Connect the liquid light guide, the power cable and, if necessary, the USB cable (see chapter 3.7).
-
Page 23: Care, Maintenance, Troubleshooting And Service
• Indications for maintenance work are contained in the operating manual of the microscope as well as in the operating manual of your computer system. There is no maintenance work for VivaTome that can be carried out by the customer. Please contact the competent Carl Zeiss Service for any maintenance issues. -
Page 24: Troubleshooting
Service Request Any interventions to mechanical, optical and electronic components inside the device as well as work to the electrical system of VivaTome may be performed only by the Carl Zeiss Microscopy GmbH Service or by explicitly authorized specialist staff.
