Rear cover (see
e.
Top cover (see
f.
Remove the front USB board:
Disconnect the front USB board cable (1) from the system board.
1.
Remove the two Phillips PM2.5×4.0 screws (2) that secure front USB board the to the computer.
2.
Remove the front USB board (3).
3.
Reverse this procedure to install the front USB board.
Power connector LED board
Description
Power connector LED board (includes cable)
Before removing the power connector LED board, follow these steps:
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
1.
computer on, and then shut it down through the operating system.
Disconnect all external devices connected to the computer.
2.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
3.
then unplugging the AC adapter from the computer.
Remove the battery (see
4.
Remove the following components:
5.
Hard drive (see
a.
Optical drive (see
b.
Keyboard (see
c.
Hinge cover (see
d.
Rear cover on page
53)
Top cover on page
55)
Battery on page
36).
Hard drive on page
42)
Optical drive on page
Keyboard on page
50)
Hinge cover on page
49)
52)
Component replacement procedures
Spare part number
452318-001
65
