Remove the optical drive (3).
4.
If it is necessary to replace the optical drive bracket, position the optical drive with the optical drive
5.
bracket toward you.
Remove the two Phillips PM2.0×3.0 screws (1) that secure the optical drive bracket to the optical
6.
drive.
Remove the optical drive bracket (2).
7.
Reverse the above procedure to reassemble and install the optical drive.

Keyboard

Description
For use in:
Denmark, Finland, Norway, and
Sweden
Europe
France
50 Chapter 4 Removal and replacement procedures
Spare part number For use in:
448159-DH1 South Korea
448159-021 Spain
448159-051 Switzerland
Spare part number
448159-AD1
448159-071
448159-111
