DRYER INSTALLATION INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION DU SECHE-LINGE
Modèles de 737 mm (29") de largeur – À gaz et Électrique
INSTRUCCIONES DE INSTALACIÓN DE LA SECADORA
Modelos de 737 mm (29") – A gas y eléctrica
ISTRUZIONI DI INSTALLAZIONE DELL'ASCIUGATRICE
TROCKNER – INSTALLATIONSANWEISUNGEN
737 mm (29 Zoll) breite Modelle – Gas und Elektro
DRYER SAFETY ........................................................................................ 2
SPECIFICATIONS ...................................................................................... 4
INSTALLATION REQUIREMENTS ............................................................ 5
ELECTRIC DRYER POWER HOOKUP ..................................................... 7
INSTALL LEVELING LEGS ........................................................................ 8
GAS DRYER POWER HOOKUP ............................................................... 8
ELECTRICAL REQUIREMENTS ............................................................. 10
ELECTRICAL CONNECTION ................................................................. 10
SÉCURITÉ DU SECHE-LINGE ............................................................... 22
CARACTERISTIQUES ............................................................................. 24
EXIGENCES D'INSTALLATION .............................................................. 25
RACCORDEMENT À L'ALIMENTATION ÉLECTRIQUE
DU SECHE-LINGE ÉLECTRIQUE ........................................................... 28
INSTALLATION DES PIEDS DE NIVELLEMENT ................................... 29
RACCORDEMENT D'UN SECHE-LINGE À GAZ ................................... 29
SPÉCIFICATIONS ÉLECTRIQUES .......................................................... 31
RACCORDEMENT ÉLECTRIQUE ........................................................... 31
SEGURIDAD DE LA SECADORA ........................................................... 44
ESPECIFICACIONES .............................................................................. 46
REQUISITOS DE INSTALACIÓN ............................................................ 47
CONEXIÓN DE ENERGÍA DE LA SECADORA ÉLECTRICA ................. 50
INSTALACIÓN DE LAS PATAS NIVELADORAS..................................... 51
CONEXIÓN DE ENERGÍA DE LA SECADORA A GAS .......................... 52
REQUISITOS ELÉCTRICOS ................................................................... 53
CONEXIÓN ÉLECTRICA ......................................................................... 54
VENTILACIÓN ......................................................................................... 57
SICUREZZA DELL'ASCIUGATRICE ....................................................... 67
SPECIFICHE ............................................................................................ 69
REQUISITI PER L'INSTALLAZIONE ....................................................... 70
ALLACCIAMENTO DELL'ASCIUGATRICE ELETTRICA
ALL'ALIMENTAZIONE ............................................................................ 72
INSTALLAZIONE DEI PIEDINI DI MESSA IN PIANO ............................ 73
ALLACCIAMENTO DELL'ASCIUGATRICE A GAS
ALL'ALIMENTAZIONE ............................................................................. 73
REQUISITI ELETTRICI ............................................................................ 75
SICHERHEIT DES TROCKNERS............................................................ 87
SPEZIFIKATIONEN ................................................................................. 89
INSTALLATIONSANFORDERUNGEN .................................................... 90
ELEKTROTROCKNER – ELEKTRISCHER ANSCHLUSS ..................... 92
STELLFÜSSE INSTALLIEREN ................................................................ 93
GASTROCKNER – ELEKTRISCHER ANSCHLUSS ............................... 93
ELEKTRISCHE ANFORDERUNGEN ...................................................... 95
ELEKTRISCHER ANSCHLUSS .............................................................. 95
W10849532D
737 mm (29") Wide Models – Gas & Electric
Modelli da 737 mm (29") – A gas ed elettrici
TABLE OF CONTENTS (Original Instructions)
TABLE DES MATIÈRES (Instructions d'origine)
ÍNDICE (Instrucciones originales)
SOMMARIO (Istruzioni originali)
INHALTSVERZEICHNIS (Originalanweisungen)
VENTING .................................................................................................. 13
MAKE GAS CONNECTION ..................................................................... 16
CONNECT VENT ..................................................................................... 17
LEVEL DRYER ......................................................................................... 17
POWER CORD INSTALLATION .............................................................. 18
COMPLETE INSTALLATION CHECKLIST ............................................. 18
REVERSE DOOR SWING (OPTIONAL) .................................................. 19
TROUBLESHOOTING ............................................................................. 21
L'ÉVACUATION........................................................................................ 34
RACCORDEMENT AU GAZ .................................................................... 38
RACCORDEMENT DU CONDUIT D'ÉVACUATION .............................. 38
RÉGLAGE DE L'APLOMB DU SECHE-LINGE ....................................... 39
INSTALLATION DU CORDON D'ALIMENTATION ................................. 39
ACHEVER L'INSTALLATION – LISTE DE VÉRIFICATION ..................... 40
INVERSION DU SENS DE L'OUVERTURE
DE LA PORTE (FACULTATIF) .................................................................. 41
DÉPANNAGE ........................................................................................... 43
CONEXIÓN DEL SUMINISTRO DE GAS................................................ 60
CONEXIÓN DEL DUCTO DE ESCAPE................................................... 61
NIVELACIÓN DE LA SECADORA........................................................... 61
INSTALACIÓN DEL CABLE ELÉCTRICO .............................................. 62
LISTA DE CONTROL DE LA INSTALACIÓN TERMINADA ................... 63
CAMBIO DEL SENTIDO DE ABERTURA
DE LA PUERTA (OPCIONAL).................................................................. 63
SOLUCIÓN DE PROBLEMAS ................................................................. 66
COLLEGAMENTO ELETTRICO .............................................................. 75
SISTEMA DI SFIATO ............................................................................... 78
COLLEGAMENTO ALL'IMPIANTO A GAS ............................................. 81
COLLEGAMENTO ALLO SFIATO ........................................................... 82
MESSA IN PIANO DELL'ASCIUGATRICE .............................................. 82
INSTALLAZIONE DEL CAVO DI ALIMENTAZIONE ............................... 83
COMPILAZIONE DELLA CHECKLIST DI INSTALLAZIONE ................. 83
INVERSIONE DELL'APERTURA DELLO SPORTELLO (OPZIONALE) ................ 84
RISOLUZIONE DEI PROBLEMI .............................................................. 86
ENTLÜFTUNGSSYSTEM ........................................................................ 98
GASANSCHLUSS HERSTELLEN ......................................................... 101
ENTLÜFTUNGS ANSCHLIESSEN ........................................................ 102
TROCKNER NIVELLIEREN................................................................... 102
INSTALLATION DES NETZKABELS ..................................................... 103
KOMPLETTE INSTALLATIONS-CHECKLISTE .................................... 103
TÜRANSCHLAG WECHSELN (OPTIONAL) ......................................... 104
FEHLERBEHEBUNG ............................................................................. 106
Advertisement
Related Manuals for Maytag 4KMEDC315FW0
Summary of Contents for Maytag 4KMEDC315FW0
- Page 1 DRYER INSTALLATION INSTRUCTIONS 737 mm (29") Wide Models – Gas & Electric INSTRUCTIONS D’INSTALLATION DU SECHE-LINGE Modèles de 737 mm (29") de largeur – À gaz et Électrique INSTRUCCIONES DE INSTALACIÓN DE LA SECADORA Modelos de 737 mm (29") – A gas y eléctrica ISTRUZIONI DI INSTALLAZIONE DELL’ASCIUGATRICE Modelli da 737 mm (29") –...
- Page 2 DRYER SAFETY CAUTION – RISK OF FIRE FLAMMABLE MATERIALS This is an additional safety alert symbol that alerts you to the risk of re.
- Page 3 FOR YOUR SAFETY 1. DO NOT USE OR STORE PETROL OR OTHER FLAMMABLE MATERIALS IN THIS APPLIANCE OR NEAR THIS APPLIANCE. 2. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION. 3. DO NOT MODIFY THIS APPLIANCE. IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING:...
- Page 4 This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help avoid potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The symbol on the product, or on the documents accompanying the product, indicates that this appliance may not be treated as household waste.
- Page 5 INSTALLATION REQUIREMENTS Tools needed for gas installations: Tools and Parts Gather the required tools and parts before starting installation. Tools needed for all installations: 203 mm or 254 mm 203 mm or 254 mm (8" or 10") pipe wrench (8" or 10") adjustable wrench (for gas connections) Flat-blade screwdriver #2 Phillips screwdriver...
- Page 6 Dryer Dimensions Location Requirements 737 mm 737 mm 29" 29" (29") (29") (737 mm) (737 mm) 1102 mm 1102 mm " " ⁄ ") (1102 mm) ⁄ ") (1102 mm) " 13 mm " 38 mm (38 mm) (13 mm) ⁄...
- Page 7 Installation spacing for recessed area or closet NOTE: In accordance with the European EMC Directive (2014/30/EU), the maximum electricity supply system impedance The dimensions shown are for the minimum spacing allowed. to which the electric dryer should be connected is declared n A dditional spacing should be considered for ease of to be 0.191 + j0.119 Ohms.
- Page 8 INSTALL LEVELING LEGS GAS DRYER POWER HOOKUP Gas Supply Requirements Prepare dryer for leveling legs To avoid damaging floor, use a large flat piece of cardboard from dryer carton; place under entire back edge of dryer. Firmly grasp dryer body (not console panel) and gently lay dryer down on cardboard.
- Page 9 Gas supply line Dryer gas pipe 13 mm (1/2") NPT pipe is recommended. The gas pipe that comes out through the rear of your dryer has a 9.5 mm (3/8") male pipe thread. 9.5 mm (3/8") approved tubing is acceptable for lengths under 6.1 m (20 ft.) if local codes and gas supplier permit.
- Page 10 ELECTRICAL REQUIREMENTS ELECTRICAL CONNECTION Electrical Connection Options Choose electrical connection type Power supply cord: Go to steps 1–2 on page 11 for power supply cord strain relief, then steps 3–5 in “Power Supply Cord Connection” section. Then go to “Venting Requirements.”...
- Page 11 Install Strain Relief Power supply cord strain relief Direct wire strain relief Attach power supply cord Attach direct wire strain relief strain relief Unscrew the removable conduit connector (A) and any Unscrew the removable conduit connector (A) and any screws from a 19 mm (3/4") strain relief. Put the threaded screws from a 19 mm (3/4") strain relief.
- Page 12 Power Supply Cord Connection Direct Wire Connection Use where local codes permit connecting cabinet-ground conductor to neutral wire. Prepare your 3-wire cable for direct connection A. Spade terminal with up-turned ends B. 19 mm (3/4") strain relief with ring terminals Connect neutral wire Direct wire cable must have 1.52 m (5 ft) of extra length so dryer may be moved if needed.
- Page 13 VENTING Connect ground wire Venting Requirements Place hooked end of ground wire power supply cable under the center terminal block screw (hook facing right). Squeeze hooked end together and securely tighten screw. Connect active wire WARNING: To reduce the risk of fire, this dryer MUST BE EXHAUSTED OUTDOORS.
- Page 14 Exhaust hoods: Plan Vent System Must be at least 305 mm (12") from ground or any object that may obstruct exhaust (such as flowers, rocks, bushes, Recommended exhaust installations or snow). Recommended Styles: Typical installations vent the dryer from the rear of the dryer. Other installations are possible.
- Page 15 Special provisions for mobile home installations: Alternate installations for close clearances The exhaust vent must be securely fastened to a noncombustible Venting systems come in many varieties. Select the type best portion of the mobile home structure and must not terminate for your installation.
- Page 16 Vent System Chart MAKE GAS CONNECTION (Long Vent Models Only) Number of Connect gas supply to dryer 90° turns Type Box/louvered or elbows of vent or Angled hoods Rigid metal 36.6 m (120 ft.) Rigid metal 33.5 m (110 ft.) Rigid metal 30.5 m (100 ft.) Flared...
- Page 17 CONNECT VENT LEVEL DRYER Connect vent to exhaust outlet Level dryer Check levelness of dryer from side to side. Repeat from front to back. NOTE: The dryer must be level for the moisture sensing system to operate correctly. Using a 102 mm (4") clamp, connect vent to exhaust outlet in dryer.
- Page 18 POWER CORD INSTALLATION Secure power cord (on some models) IMPORTANT: To be performed by Whilrpool Corporation authorised service personnel only. Secure the power cord by seating the connection on the cord lock. Place the cord lock cover and push until it snaps. Make sure the power cord connection is seated on the cord lock and that the cord lock clamps correctly.
- Page 19 REVERSE DOOR SWING Lift door off top screws (OPTIONAL) NOTE: Magnetized screwdriver is helpful. Lift door until top screws in dryer cabinet are in large part of Place towel on dryer hinge slot. Pull door forward off screws. Set door (handle side up) on top of dryer.
- Page 20 Attach door hinges Switch door catch, bezel, and plug Plug Catch and bezel Remove the door catch, bezel, and plug from the inside of the inner door by squeezing and pulling/pushing them. Place the door catch, bezel, and plug on the sides opposite from where they were.
- Page 21 Remove and transfer Check door strike alignment hinge hole plugs Use a small, flat-blade screwdriver to gently remove 4 hinge hole plugs on left side of dryer cabinet. Transfer plugs into Close door and check that door strike aligns with door hinge holes on opposite side of dryer cabinet.
- Page 22 Whirlpool EMEA S.p.A., Via Carlo Pisacane n. 1, 20016 Pero (MI), Italy :ممثل االتحاد األوروبي Whirlpool Corporation, 2000 N M 63, Benton Harbor, MI 49022 USA :الجهة المصنعة . أو قم باالتصال بالبائع الذي اشتريت المجفف منه أو شركة صيانة معتمدةwww.whirlpool.com/accessories لمزيد من المعلومات، يرجى زيارتنا في الموقع W10849532D ..
