- Page 1 使用説明書/困ったときには/安全にご使用いただくために User’s Guide/Trouble shooting/Safety precautions BOC703-100...
-
Page 2: Table Of Contents
ENGLISH Contents Parts Name ........... 30 Unloading a Used instax SQUARE Before Use ..........31 Film Pack ..........39 Inserting/Charging the Battery ..31 About the LED Indication....40 Inserting the Battery ........31 SPECIFICATIONS ......... 41 Charging the Battery ........32 TROUBLE SHOOTING ...... -
Page 3: Parts Name
Parts Name Battery remaining LED USB connector cover Battery cover Film remaining LED USB connector Back cover Print exit Back cover lock POWER button REPRINT button... -
Page 4: Before Use
Before Use • Before using the printer, install the instax SHARE application on your device. • When you are using an Android OS device, search for “instax SHARE” in the Google Play, then install the application. * System requirements of an Android OS device: Android Ver 4.0.3 or later and Google Play are installed. • When you are using an iOS device, search for “instax SHARE”... -
Page 5: Charging The Battery
Inserting/Charging the Battery (Continued) Charging the Battery Charging Indicator Be careful of the orientation. Connect the USB cable Indication Battery status/Action with the mark ( ) on the terminal facing up. Lights red (ON) Charging is in progress. Flashes red (OFF) Lights orange (ON) Charging is half completed. -
Page 6: Loading The Instax Square Film Pack
• When you load the film pack, never press the two rectangular holes on the back of the film pack. • Never use a film pack beyond its shelf life; otherwise, it may damage the printer. Use FUJIFILM Instant Film “instax SQUARE” only. The instax mini film or instax WIDE film cannot be used. Notes on the film pack • Each FUJIFILM Instant Film “instax SQUARE”... -
Page 7: Turning On/Off The Printer
Turning on/off the Printer Loading the instax SQUARE Film Pack (Contunued) Press and hold the POWER button for approx. 1 second to turn the printer on or off. Close the back cover. Make sure the back cover Turning the printer on lights up the battery remaining lock clicks into place. -
Page 8: Connecting And Printing
Connecting and Printing Ÿ Notes on Printing 1. Place the printer vertically. 2. When printing, put the printer on a steady surface such as a desk. Wireless LAN Setup for iOS Devices When you are using an iOS device, follow the procedure below to perform wireless LAN setup. Start the downloaded application “instax SHARE”. - Page 9 Connecting and Printing (Continued) ⁄ ¤ Enter the factory default Tap “Connect and print”. password (1111) or the one you specified, then tap “OK”. Before tapping “Connect The printer starts printing. and print”, tapping 1111 When printing, put the the lower right displays the printer on a steady surface edit menu.
-
Page 10: When Connection Is Already Established
Connecting and Printing When connection is already established: Press and hold the POWER button for approx. Select the picture to print or 1 second to turn the printer on. take a picture. The battery remaining LED lights up. Tap “Print”. ⁄ The printer starts printing. Ÿ... -
Page 11: Reprinting
Connecting and Printing (Continued) Reprinting Press the REPRINT button once. When the film has been ejected (the printer stops making a sound), grasp Ÿ the edge of the film, then take it out. 1 film remaining LED turns off every time you print an image. -
Page 12: Deleting An Image
Unloading a Used instax SQUARE Film Pack Deleting an Image When no film is left, all the film remaining LEDs flash Press and hold the REPRINT button for more than 5 slowly. Unload the film pack. seconds with the printer on. Ÿ... -
Page 13: About The Led Indication
About the LED Indication Film remaining LED indication Battery remaining LED indication The film remaining LED indicates film remaining, The battery remaining LED indicates the printer status printer operation, or error warning. while charging the battery, or battery life of the printer. 1 film remaining LED turns off every time you print an See page 32 for indications while charging the battery. -
Page 14: Specifications
SPECIFICATIONS instax SP-3 Recording method 3-color exposure with OLED Film FUJIFILM Instant Film “instax SQUARE” (Purchased separately) Photo capacity 10 prints/pack Image size 62 mm×62 mm/2.4 in.×2.4 in. Supported image size 800×800 dots Printing resolution 12.5 dots/mm (318 dpi, 80 μm dot pitch) -
Page 15: Trouble Shooting
TROUBLE SHOOTING During printing Problems Possible Causes Solutions The printer cannot be 1 The battery power is low. (The 1 Charge the battery fully. turned on. battery remaining LED is flashing 2 Insert the battery correctly. red.) 3 Press and hold the POWER button for approx. 1 2 The battery is not inserted correctly. - Page 16 Solutions The film pack cannot 1 The film pack is not for your printer. 1 Use FUJIFILM Instant Film “instax SQUARE” only. be loaded, or cannot be 2 The film pack is not being loaded (No other films can be used.) loaded smoothly.
- Page 17 LED status Problems Possible Causes Solutions ● A printer error has occurred. ● Turn the printer on. The film remaining LED flashes rapidly, then the printer turns itself off. ● The battery power is low. ● Charge the battery fully. The battery remaining LED flashes red slowly, When the remaining battery life is low, you then the printer turns...
- Page 18 ● The print head is dirty. ● Contact your FUJIFILM dealer or support center. A vertical line is printed across the finished print.
-
Page 19: Important Safety Notice
IMPORTANT SAFETY NOTICE This product has been designed with safety in mind, and to provide safe service when handled correctly and in accordance with the User’s Guide and instructions. It is important that both the product and the INSTAX film are handled properly and used only to print pictures as instructed in this User’s Guide and in the instax SQUARE film instructions. - Page 20 If anything is wrong with the printer, never attempt to repair it by yourself. You may be injured. If this product is dropped or damaged so that the inside is showing, do not touch it. Contact your FUJIFILM dealer. Do not touch any parts or projecting parts inside the back cover. You may be injured.
- Page 21 20cm or more away from person’s body in normal use position. FCC CAUTION Changes or modifications not expressly approved by FUJIFILM responsible for compliance could void the user’s authority to operate the equipment.
- Page 22 If your equipment contains easy removable batteries or accumulators, please dispose these separately according to your local requirements. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you have purchased the product.
- Page 23 INSTAX SQUARE FILM AND PRINT CARE See FUJIFILM Instant Film “instax SQUARE” for film use instructions. Follow all instructions for safe and proper use. 1 Keep the film in a cool and dry place. Do not leave the film in a place where the temperature is extremely high (e.g., in a closed car) for many hours.
- Page 24 ■ Use only in the country in which the device was purchased. This device conforms to regulations governing wireless network devices in the country in which it was purchased. Observe all location regulations when using the device. FUJIFILM does not accept liability for problems arising from use in other jurisdictions.
- Page 25 RFID tracking, immediately choose a new operating frequency for this device to prevent additional interference. If you notice that this device causes interference in low-voltage RFID tracing systems, contact a FUJIFILM representative. ■ Certification marks acquired by the printer are located inside the film chamber.
-
Page 26: Handling The Battery
Handling the Battery • Make sure that you use your printer correctly. Read these safety notes and your User’s Guide carefully before use. • After reading these safety notes, store them in a safe place. WARNING CAUTION This symbol indicates danger, which could result in injury or This symbol indicates possible damage, which could result in death. - Page 27 Required electric shock. Contact your FUJIFILM dealer. The Battery The following describes the proper use of batteries and how to prolong their life. Incorrect use can shorten battery life or cause leakage, overheating, fire, or explosion.
- Page 28 ■ Storage Performance may be impaired if the battery is left unused for extended periods when fully charged. Deplete the battery fully before storing it. If the printer will not be used for an extended period, remove the battery and store it in a dry place with an ambient temperature of from +15 °C to +25 °C (+59 °F to +77 °F).
