DRYPIX 7000
SERVICE MANUAL
REMOVAL AND ADJUSTMENT (MC)

Advertisement

Table of Contents
loading

Related Manuals for FujiFilm DRYPIX 7000

Summary of Contents for FujiFilm DRYPIX 7000

  • Page 1 DRYPIX 7000 SERVICE MANUAL REMOVAL AND ADJUSTMENT (MC)
  • Page 2 1, 3-11, 13-17, 20, 22, 23, 26, 27, 33-39, 44, 46-149 04/01/2003 Revised (FM3978) 1, 10, 11, 15, 16, 22, 23, 28, 31, 35, 37, 44, 54-57, 60, 75-77, 90-94, 107-109, 118, 120, 135, 141-149 006-259-02 DRYPIX 7000 Service Manual MC-1 04.01.2003 FM3978...
  • Page 3 The screws painted in yellow must be adjusted after the installation of parts. When installing parts, follow the check/adjustment procedure provided. <NOTE> When removing the covers, insert shutter into the film tray to prevent exposure of film to light. 006-259-00 DRYPIX 7000 Service Manual MC-2 10.15.2002 FM3343...
  • Page 4 CHECK procedures. Whenever this is shown, be sure to refer to " CHECK/ Adjusting procedure". • FIT ON icon: When installing parts, this is indicated if alignment to the boss is required. 006-259-01 DRYPIX 7000 Service Manual MC-3 11.10.2002 FM3601...
  • Page 5 REF. No. (example 3 ) in the SERVICE PARTS LIST Volume (exploded view). For the above example, the item to be referred for “MC Upper Conveyor Unit Exit Motor (MD2)” is “SP ”. 006-259-01 DRYPIX 7000 Service Manual MC-4 11.10.2002 FM3601...
  • Page 6 FP7Z0513.EPS REF. No. 2-BR3X8 DT3X6 DT3X6 3-BR3X10 FP7Z0503.EPS 006-259-01 SP-30 11.10.2002 FM3600 FP7C0006.EPS To refer to the service parts information on “MC Upper Conveyor Unit Exit Motor (MD2)”, refer to “SP ”. 006-259-01 DRYPIX 7000 Service Manual MC-5 11.10.2002 FM3601...

  • Page 7: Table Of Contents

    MC-24 3.4 Tray Detection Switch (SA12, SA22, SA32) MC-25 3.5 Tray Lock Assembly MC-26 3.6 Tray Loading Unit Rail MC-30 3.7 Tray Rail 3.8 Squeezing Roller MC-32 3.9 Special Screw MC-34 FP7C0001.EPS 006-259-01 DRYPIX 7000 Service Manual MC-6 11.10.2002 FM3601...
  • Page 8 5.12 Grip Idle Gear MC-80 5.13 Lower Conveyor Unit MC-82 6. SUB-SCANNING UNIT 6.1 Sub-Scanning Unit MC-92 6.2 Sub-Scanning Motor (ME1) MC-94 6.3 Sub-Scanning Roller MC-98 6.4 Film Leading Edge Detection Sensor (SE1) FP7C0002.EPS 006-259-01 DRYPIX 7000 Service Manual MC-7 11.10.2002 FM3601...
  • Page 9 9.1 Film Release Unit MC-126 9.2 Density Measurement Light-Emitting Board (LED15A) 10. CONTROLLER 10.1 Operation Panel MC-128 10.2 Controller Assembly MC-130 10.3 HDD MC-132 MC-134 10.4 PC Board MC-135 10.5 MCT Board FP7C0003.EPS 006-259-01 DRYPIX 7000 Service Manual MC-8 11.10.2002 FM3601...
  • Page 10 12. VERSION UPGRADE AND 12.1 Preparations (Same for Version Upgrades FULL INSTALLATION OF and Full Installation) MC-141 MAIN UNIT SOFTWARE 12.2 Version Upgrade 12.3 Full Installation MC-144 13. BOARD SETTING AND LED LIGHTNG INFORMATION FP7C0004.EPS 006-259-01 DRYPIX 7000 Service Manual MC-9 11.10.2002 FM3601...

  • Page 11: Covers

    • Upper right side cover • Side ejection cover 2-T4x12 Upper left side cover Jam clear cover Operation panel fixing screw 2-T4x12 Upper right side cover Side ejection cover 2-T4x8 BR3x12 3-BR3x8 FP7C0100.EPS 006-259-02 DRYPIX 7000 Service Manual MC-10 04.01.2003 FM3978...
  • Page 12 8-T4x25 Film release unit cover Left side cover BR3x8 Rear cover 8-T4x16 Front cover 8-T4x16 8-BR3x8 Right side cover Lower front cover FP7C0101.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-02 DRYPIX 7000 Service Manual MC-11 04.01.2003 FM3978...

  • Page 13: Frame

    FRAME FP7Z0211.EPS BCR Assembly FP7C0201.EPS Removing Procedure Remove the following cover. • Rear cover Remove the trays “3.2 Tray” 006-259-00 DRYPIX 7000 Service Manual MC-12 10.15.2002 FM3343...
  • Page 14 <REMARKS> Attaching position of the BCR 35 x 43 cm size 26 x 36/20 x 25 cm size Shield plate Shield plate FP7B0542.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-13 11.10.2002 FM3601...

  • Page 15: Tray Loading Unit

    Steps that differ between the three units are indicated separately. Removing Procedure Remove the following covers. • Rear cover Remove the trays. “3.2 Tray” 006-259-01 DRYPIX 7000 Service Manual MC-14 11.10.2002 FM3601...
  • Page 16 MC-15 Remove the tray inside cover. Tray inside cover [Remove] 4-TP4x8 FP7C0301.EPS 006-259-02 DRYPIX 7000 Service Manual MC-15 04.01.2003 FM3978...
  • Page 17 [Release] Clamp SA13 Bracket (4) #1 [Remove] 2-BR4x8 FP7C0302.EPS (5) #4 [Disconnect] Connector SA11 (5) #3 [Release] Clamp x 2 (5) #5 [Remove] 3-BR4x8 Tray loading unit Film pack/shutter detection sensor FP7C0303.EPS 006-259-02 DRYPIX 7000 Service Manual MC-16 04.01.2003 FM3978...
  • Page 18 Reinstalling Procedure Reinstall in the reverse order of removal. <INSTRUCTIONS> Bind the extra length of the cable so that it does not come out of the tray insertion portion. Clamp [Bind] Cable FP7B0552.EPS 006-259-01 DRYPIX 7000 Service Manual MC-17 11.10.2002 FM3601...

  • Page 19: Tray

    Tray FP7C0323.EPS Removing Procedure Remove the following cover. • Rear cover <NOTE> When pulling out the tray from the equipment, insert shutter in the tray to prevent exposure of film to light. 006-259-00 DRYPIX 7000 Service Manual MC-18 10.15.2002 FM3343...
  • Page 20 MC-19 Remove the tray. [Push slightly] Tray [Release manually] Tray lock FP7B0506.EPS [Push] Stopper [Pull out] Tray [Push] Stopper Tray FP7C0304.EPS 006-259-00 DRYPIX 7000 Service Manual MC-19 10.15.2002 FM3343...
  • Page 21 [Push] Rail (Left) [Release] Latch [Release] Latch [Push] Rail (Right) FP7C0305.EPS Reinstalling Procedure Reinstall in the reverse order of removal. However, there is no need to pull out the rail pushed into the equipment. 006-259-01 DRYPIX 7000 Service Manual MC-20 11.10.2002 FM3601...
  • Page 22 MC-21 BLANK PAGE 006-259-00 DRYPIX 7000 Service Manual MC-21 10.15.2002 FM3343...

  • Page 23: Film Pack/Shutter Detection Sensor (Sa11, Sa21, Sa31)

    Film Pack/Shutter Detection Sensor (SA11, SA21, SA31) FP7C0324.EPS Removing Procedure Remove the tray. “3.2 Tray” Remove the tray inside cover. Tray inside cover [Remove] 4-TP4x8 FP7C0301.EPS 006-259-02 DRYPIX 7000 Service Manual MC-22 04.01.2003 FM3978...
  • Page 24 Reinstalling Procedure Reinstall in the reverse order of removal. <INSTRUCTIONS> Bind the extra length of the cable so that it does not come out of the tray insertion portion. Clamp [Bind] Cable FP7B0552.EPS 006-259-02 DRYPIX 7000 Service Manual MC-23 04.01.2003 FM3978...

  • Page 25: Tray Detection Switch (Sa12, Sa22, Sa32)

    Tray Detection Switch (SA12, SA22, SA32) FP7C0325.EPS Reinstalling Procedure <INSTRUCTIONS> Check that the connectors are connected at the correct positions. Tray lock switch SA12-NC SA12-COM FP7C0307.EPS Reinstall in the reverse order of removal. 006-259-00 DRYPIX 7000 Service Manual MC-24 10.15.2002 FM3343...

  • Page 26: Tray Lock Assembly

    Connector SOLA11 [Disconnect] Connector SA13 [Disconnect] Connector SA12-COM [Release] Clamp [Disconnect] Connector SA12-NC Tray lock assembly FP7C0308.EPS Reinstalling Procedure Reinstall in the reverse order of removal. Tray lock assembly Back side FP7C0309.EPS 006-259-00 DRYPIX 7000 Service Manual MC-25 10.15.2002 FM3343...

  • Page 27: Tray Loading Unit Rail

    Inner slide rail FP7C0320.EPS Remove the tray loading unit rail. [Push to rear] Inner slide rail [Remove] 4-T4x4 [Remove] 4-T4x4 Tray loading unit rail Auxiliary plate Tray loading unit rail [Remove] 2-T4x4 FP7C0310.EPS 006-259-01 DRYPIX 7000 Service Manual MC-26 11.10.2002 FM3601...
  • Page 28 Place the tip in front and behind the right rail of the tray loading unit on the aperture of the tray loading unit, tighten the rail temporarily with the screws. Auxiliary plate [Temporarily tighten] 2-T4x4 Tray loading unit rail (right) [Tighten] 2-T4x4 Aperture [Temporarily tighten] 2-T4x4 Aperture FP7C0312.EPS 006-259-01 DRYPIX 7000 Service Manual MC-27 11.10.2002 FM3601...
  • Page 29 • After reinstalling the tray loading unit rail, insert the tray into the tray loading unit, and check that it moves smoothly. • Apply bonding to the ten screws securing the tray loading unit rail. 006-259-02 DRYPIX 7000 Service Manual MC-28 04.01.2003 FM3978...
  • Page 30 MC-29 BLANK PAGE 006-259-00 DRYPIX 7000 Service Manual MC-29 10.15.2002 FM3343...

  • Page 31: Tray Rail

    Tray Rail FP7C0328.EPS Removing Procedure Remove the tray. “3.2 Tray” Remove the tray rail. [Remove] 5-T4x4 Tray rail Tray rail CHECK CHECK [Remove] 5-T4x4 FP7C0313.EPS 006-259-00 DRYPIX 7000 Service Manual MC-30 10.15.2002 FM3343...
  • Page 32 CHECK/Adjusting Procedure • After reinstalling the tray rail, insert the tray into the tray loading unit, and check that it moves smoothly. • Apply bonding to the ten screws securing the tray rail. 006-259-02 DRYPIX 7000 Service Manual MC-31 04.01.2003 FM3978...

  • Page 33: Squeezing Roller

    When removing the squeezing roller, be careful not to damage the bearing of the tray, Remove the squeezing roller. [Remove] Squeezing roller [Pull] Bearing FP7C0315.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-00 DRYPIX 7000 Service Manual MC-32 10.15.2002 FM3343...
  • Page 34 MC-33 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-33 11.10.2002 FM3601...

  • Page 35: Special Screw

    Special Screw FP7C0333.EPS Removing Procedure Remove the tray. “3.2 Tray” Remove the upper rear cover of the tray. Remove the special screws. Upper rear cover [Remove] Special Screw (2) #1 [Remove] 3-Q4x6 FP7C0318.EPS 006-259-01 DRYPIX 7000 Service Manual MC-34 11.10.2002 FM3601...
  • Page 36 REMARKS> These special screws are producing the click sound when inserting shutters. Shutter Ball bearing Tray surface Special screw FP7C0319.EPS Reinstall in the reverse order of removal. 006-259-02 DRYPIX 7000 Service Manual MC-35 04.01.2003 FM3978...

  • Page 37: Removal Unit

    REMOVAL UNIT FP7Z0411.EPS Removal Unit FP7C0412.EPS Removing Procedure Remove the tray loading unit. “3.1 Tray Loading Unit” 006-259-01 DRYPIX 7000 Service Manual MC-36 11.10.2002 FM3601...
  • Page 38 (3) #1 [Disconnect] Connecter CNB1 (3) #2 (3) #1 [Remove] 4-BR4x8 [Disconnect] Connecter MB11 (2) #2 [Remove] Shield cover Removal unit CHECK (2) #1 [Remove] Shield cover BR3x8 FP7C0401.EPS 006-259-02 DRYPIX 7000 Service Manual MC-37 04.01.2003 FM3978...
  • Page 39 Secure the gear while pressing the flange of the idle gear against the gears in the arrow direction shown below. Upper removal unit Idle gear Upper conveyor unit Middle removal unit Idle gear Middle conveyor unit Lower removal unit Lower conveyor unit Idle gear FP7C0402.EPS 006-259-01 DRYPIX 7000 Service Manual MC-38 11.10.2002 FM3601...
  • Page 40 MC-39 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-39 11.10.2002 FM3601...

  • Page 41: Removal Drive Cam

    Remove the gear 1 and gear 2. [Remove] Gear 1 Gear fixing cover (2) #1 [Release] Clamp [Remove] Gear 2 (2) #2 Bearing (2) #1 [Remove] E6 (2) #3 [Release] Clamp [Remove] 4-DT3x6 FP7C0403.EPS 006-259-00 DRYPIX 7000 Service Manual MC-40 10.15.2002 FM3343...
  • Page 42 Insert pins such as hexagonal wrench into the two holes on gear 1, and adjust the phase of the removal drive cam. Reinstall gear 2. Gear 1 (2) #1 [Insert] Pin [Reinstall] Gear 2 FP7C0405.EPS 006-259-00 DRYPIX 7000 Service Manual MC-41 10.15.2002 FM3343...
  • Page 43 FP7C0406.EPS Secure the gear fixing cover with the screws. Secure the cable with the clamp. CHECK/Adjusting Procedure After reinstalling the removal drive cam, check that the suction cup arm assembly moves smoothly. 006-259-00 DRYPIX 7000 Service Manual MC-42 10.15.2002 FM3343...
  • Page 44 MC-43 BLANK PAGE 006-259-00 DRYPIX 7000 Service Manual MC-43 10.15.2002 FM3343...

  • Page 45: Suction Cup Arm

    Suction Cup Arm FP7C0414.EPS 4.3.1 Removal/Reinstallation Removing Procedure Remove the tray. “3.2 tray” Remove the tray inside cover. Tray inside cover [Remove] 4-TP4x8 FP7C0301.EPS 006-259-02 DRYPIX 7000 Service Manual MC-44 04.01.2003 FM3978...
  • Page 46 MC-45 Remove the suction cup arm. (3) #2 [Disconnect] Connector Suction cup arm (3) #1 (3) #3 [Release] Clamp [Remove] 4-BR3x8 FP7C0407.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-00 DRYPIX 7000 Service Manual MC-45 10.15.2002 FM3343...
  • Page 47 [Disconnect] Connector [Connect] Connector FP7C0542.EPS Change the attaching position of the film release plate. [Remove] 4-DT3x6 [Secure] 4-DT3x6 For 20 x 25 cm size Mark [Move] Film release plate x 2 FP7C0543.EPS 006-259-01 DRYPIX 7000 Service Manual MC-46 11.10.2002 FM3601...
  • Page 48 To return the film size from 20 x 25 cm to other sizes, refer to the following figure and change the attaching position of the film release plate. Not used For 20x25 cm size For 35x43, 26x36 cm sizes FP7C0544.EPS 006-259-01 DRYPIX 7000 Service Manual MC-47 11.10.2002 FM3601...

  • Page 49: Suction Cup

    Suction Cup FP7C0415.EPS Removing Procedure Remove the suction cup arm. “4.3 Suction Cup Arm” Remove the suction cup. [Remove] Suction cup [Remove] Nozzle FP7C0408.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-48 11.10.2002 FM3601...
  • Page 50 MC-49 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-49 11.10.2002 FM3601...

  • Page 51: Bellows

    Remove the suction cup arm. “4.3 Suction Cup Arm” <INSTRUCTIONS> Rotate the bellows in the tightened state to remove. Remove the bellows. CHECK [Remove] Bellows [Pull out] Bellows [Lower] Plate O ring Stopper FP7C0409.EPS 006-259-01 DRYPIX 7000 Service Manual MC-50 11.10.2002 FM3601...
  • Page 52 Push down the plate, and with an approximately 50 mm space between the plate and stopper, push the suction cup against the film. Two minutes later, check that the space is still 50 mm. [Push down] Plate 50mm Stopper Film FP7C0411.EPS 006-259-01 DRYPIX 7000 Service Manual MC-51 11.10.2002 FM3601...

  • Page 53: Conveyor Unit

    CONVEYOR UNIT FP7Z0511.EPS Upper Conveyor Unit FP7C0521.EPS Removing Procedure Insert the shutter into the film tray. Remove the following covers. • Upper right side cover • Rear cover Remove the cleaning roller. 006-259-01 DRYPIX 7000 Service Manual MC-52 11.10.2002 FM3601...
  • Page 54 If the equipment mounts film tray 2, loosen the screws securing the idle gear of the middle conveyor unit. Upper removal unit Upper conveyor unit Middle removal unit [Loosen] 2-BR3x6 Middle conveyor unit Lower removal unit Lower conveyor unit FP7C0540.EPS 006-259-01 DRYPIX 7000 Service Manual MC-53 11.10.2002 FM3601...
  • Page 55 MC-54 Remove the sub-scanning unit fixing bracket. Sub-scanning unit fixing bracket [Remove] 4-BR4x8 FP7C0613.EPS Reinstall the sub-scanning unit fixing bracket at the position shown below. [Tighten] 2-BR4x8 Sub-scanning unit fixing bracket FP7C0546.EPS 006-259-02 DRYPIX 7000 Service Manual MC-54 04.01.2003 FM3978...
  • Page 56 MC-55 Remove the screws securing the sub-scanning unit. [Remove] 2-BR4x8 Sub-scanning unit FP7C0535.EPS Remove the upper conveyor unit removing jig. [Remove] BR4x8 Upper conveyor unit removing jig FP7C0533.EPS 006-259-02 DRYPIX 7000 Service Manual MC-55 04.01.2003 FM3978...
  • Page 57 [Disconnect] [Disconnect] Connector CND4 Connector CND4 [Disconnect] [Disconnect] Connector MD4 Connector MD2 [Disconnect] Connector CLD1 Shield cover [Remove] BR3x8 Upper conveyor unit [Remove] BR3x8 [Remove] 5-BR4x8 [Disconnect] [Release] Clamp Connector CND6 FP7C0501.EPS 006-259-02 DRYPIX 7000 Service Manual MC-56 04.01.2003 FM3978...
  • Page 58 Secure the gear while pressing the flange of the idle gear against the gears in the arrow direction shown below. Upper removal unit Upper conveyor unit Middle removal unit Idle gear Middle conveyor unit FP7C0541.EPS 006-259-02 DRYPIX 7000 Service Manual MC-57 04.01.2003 FM3978...

  • Page 59: Film Positioning Motor (Lower) (Md6)

    Film Positioning Motor (Lower) (MD6) FP7C0522.EPS Removing Procedure Remove the following cover. • Right side cover Remove the film positioning motor (lower) (MD6). [Disconnect] Connector MD6 [Release] Clamp [Remove] 2-DT3x6 Film positioning motor (lower) MD6 FP7C0502.EPS 006-259-01 DRYPIX 7000 Service Manual MC-58 11.10.2002 FM3601...
  • Page 60 (MD6). [ Push ] Positioning guide Positioning guide assembly Positioning guide [ Push ] Positioning guide FP7C0503.EPS Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-59 11.10.2002 FM3601...

  • Page 61: Upper Conveyor Unit Exit Motor (Md2)

    (3) #2 [Remove] Upper conveyor unit exit motor (MD2) (2) #1 (2) #2 [Remove] E5 [Pull out] Upper conveyor unit exit clutch (CLD1) FP7C0504.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-02 DRYPIX 7000 Service Manual MC-60 04.01.2003 FM3978...
  • Page 62 MC-61 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-61 11.10.2002 FM3601...

  • Page 63: Cleaning Roller Grip Release Motor (Md4)

    Rotate the worm gear of the cleaning roller grip release motor (MD4) in the arrow direction shown in the figure with the hand so that it grips the cleaning roller. [Rotate] Worm gear FP7C0539.EPS 006-259-01 DRYPIX 7000 Service Manual MC-62 11.10.2002 FM3601...
  • Page 64 Cleaning roller grip release motor (MD4) FP7C0505.EPS Reinstalling Procedure Reinstall in the reverse order of removal. CHECK/Adjusting Procedure Reinstall the motor with the D cut side of the one-way gear assembly shaft facing up. 006-259-01 DRYPIX 7000 Service Manual MC-63 11.10.2002 FM3601...

  • Page 65: Film Positioning Assembly (Lower)

    Remove the grip position detection sensor bracket. Remove the connector bracket. (2) #2 [Disconnect] Connector SD3 (2) #1 [Remove] DT3x6 (2) #2 Grip position detection sensor bracket [Disconnect] Connector SD4 (3) #1 Connector bracket [Remove] BR3x8 FP7C0506.EPS 006-259-01 DRYPIX 7000 Service Manual MC-64 11.10.2002 FM3601...
  • Page 66 Remove the film positioning assembly (lower). Flange gear [Remove] E6 [Release] Clamp [Disconnect] Connector MD6 Film positioning assembly (lower) [Remove] 3-DT3x6 [Disconnect] Connector SD7 FP7C0507.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-65 11.10.2002 FM3601...

  • Page 67: Film Positioning Motor (Upper) (Md5)

    Remove the upper conveyor unit. “5.1 Upper Conveyor Unit” Remove the film positioning motor (upper) (MD5). [Disconnect] [Release] Clamp Connector MD5 Film positioning assembly (upper) Film positioning motor [Remove] (upper) (MD5) 2-DT3x6 FP7C0508.EPS 006-259-01 DRYPIX 7000 Service Manual MC-66 11.10.2002 FM3601...
  • Page 68 (MD5). [ Push ] Positioning guide Positioning guide assembly Positioning guide [ Push ] Positioning guide FP7C0503.EPS Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-67 11.10.2002 FM3601...

  • Page 69: Film Positioning Assembly (Upper)

    “5.1 Upper Conveyor Unit” Remove the film positioning motor (upper) (MD5). “5.6 Film Positioning Motor (Upper) (MD5)” Remove the conveyance guide. Conveyor guide [Remove] Guide [Remove] 2-DT3x6 [Release] Clamp [Disconnect] Connector SD1 FP7C0509.EPS 006-259-01 DRYPIX 7000 Service Manual MC-68 11.10.2002 FM3601...
  • Page 70 [Remove] 4-DT3x6 Stay (7) #1 [Remove] 2-DT3x6 Conveyor unit exit guide (8) #1 [Release] Clampx6 (7) #2 [Remove] 2-BR3x8 (8) #3 (8) #2 Film positioning assembly (upper) [Remove] 3-DT3x6 [Disconnect] Connector FP7C0511.EPS 006-259-01 DRYPIX 7000 Service Manual MC-69 11.10.2002 FM3601...
  • Page 71 Open the left and right positioning guides until they touch the sides when installing the film positioning motor (MD5). [ Push ] Positioning guide Positioning guide assembly Positioning guide [ Push ] Positioning guide FP7C0503.EPS Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-70 11.10.2002 FM3601...
  • Page 72 MC-71 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-71 11.10.2002 FM3601...

  • Page 73: Conveyor Unit Exit Guide

    [Release] Clamp Sensor bracket [Loosen] [Remove] DT3x6 Stay [Remove] 2-DT3x6 [Release] Conveyor unit exit guide [Remove] 4-DT3x6 [Remove] 2-BR3x8 Conveyor unit exit guide FP7C0512.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-72 11.10.2002 FM3601...
  • Page 74 MC-73 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-73 11.10.2002 FM3601...

  • Page 75: Conveyance Driving Roller (Upper)

    Conveyance Driving Roller (Upper) FP7C0529.EPS Remove the upper conveyor unit. “5.1 Upper Conveyor Unit” Remove the knob. Remove the handle. Knob (3) #1 [Remove] BR3x10 (2) #1 [Remove] BR3x8 Handle FP7C0513.EPS 006-259-01 DRYPIX 7000 Service Manual MC-74 11.10.2002 FM3601...
  • Page 76 [Remove] E6 (7) #1 [Remove] Bearing (8) #2 [Remove] Bearing (8) #1 [Remove] E6 (7) #1 [Remove] Bearing Conveyance driving roller (upper) FP7C0515.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-02 DRYPIX 7000 Service Manual MC-75 04.01.2003 FM3978...

  • Page 77: Conveyance Driving Roller (Lower)

    (3) #2 [Remove] E6 Bearing (2) #3 (3) #1 [Remove] 4-DT3x6 [Remove] E6 Upper conveyor unit lower bracket (2) #1 Shield cover Drive transmission (2) #2 [Disconnect] gear [Release] Clamp Connector FP7C0517.EPS 006-259-02 DRYPIX 7000 Service Manual MC-76 04.01.2003 FM3978...
  • Page 78 [Remove] Bearing Conveyance driving roller (lower) (8) #2 [Remove] Bearing Conveyance grip roller (lower) (8) #1 (7) #1 [Remove] E6 [Remove] Bearing FP7C0519.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-02 DRYPIX 7000 Service Manual MC-77 04.01.2003 FM3978...

  • Page 79: Conveyor Unit Guide

    Remove the conveyance driving roller (lower). “5.10 Conveyance Driving Roller (Lower)” Remove the conveyor unit guide. Boss Conveyor unit guide Boss [Release] Conveyor unit guide [Remove] 2-BR3x8 FP7C0520.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-78 11.10.2002 FM3601...

  • Page 80: Grip Idle Gear

    [Reinstall] Grip idle gear Grip release gear [Attach] E6 FP7C0516.EPS 006-259-01 DRYPIX 7000 Service Manual MC-79 11.10.2002 FM3601...

  • Page 81: Lower Conveyor Unit

    Remove the lower conveyor unit. Idle gear Middle conveyor unit [Loosen] 2-BR3x6 [Remove] Lower conveyor unit Shield cover [Remove] 2-BR3x8 [Remove] 4-BR4x8 FP7C0537.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-80 11.10.2002 FM3601...
  • Page 82 Secure the gear while pressing the flange of the idle gear against the gears in the arrow direction shown below. Upper removal unit Upper conveyor unit Middle removal unit Middle conveyor unit Idle gear Lower removal unit Lower conveyor unit FP7C0538.EPS 006-259-01 DRYPIX 7000 Service Manual MC-81 11.10.2002 FM3601...

  • Page 83: Sub-Scanning Unit

    SUB-SCANNING UNIT FP7Z0611.EPS Sub-Scanning Unit FP7C0609.EPS 6.1.1 Removal/Reinstallation Removing Procedure Insert the shutter into the film tray. Remove the following covers. • Right side cover • Rear cover 006-259-01 DRYPIX 7000 Service Manual MC-82 11.10.2002 FM3601...
  • Page 84 Remove the sub-scanning unit fixing bracket. Sub-scanning unit fixing bracket [Remove] 4-BR4x8 FP7C0613.EPS Reinstall the sub-scanning unit fixing bracket at the position shown below. [Tighten] 2-BR4x8 Sub-scanning unit fixing bracket [Tighten] 2-BR4x8 Sub-scanning unit fixing bracket FP7C0614.EPS 006-259-01 DRYPIX 7000 Service Manual MC-83 11.10.2002 FM3601...
  • Page 85 (5) #1 (6) #1 LDD16A-CN9 [Remove] 2-BR3x8 [Loosen] 2-BR4x12 Connector cover FP7C0601.EPS (7) #2 [Disconnect] Connector ME1 (7) #2 [Disconnect] Connector CNS2 (7) #3 [Remove] BR4x12 (7) #3 [Remove] 2-BR4x8 Sub-scanning unit FP7C0602.EPS 006-259-01 DRYPIX 7000 Service Manual MC-84 11.10.2002 FM3601...
  • Page 86 MC-85 Reinstalling Procedure Insert the sub-scanning unit into the equipment, and temporarily secure with the screws. [Temporarily tighten] [Temporarily tighten] 2-BR4x8 BR4x12 [Temporarily tighten] 2-BR4x8 FP7C0616.EPS 006-259-01 DRYPIX 7000 Service Manual MC-85 11.10.2002 FM3601...
  • Page 87 Remove the sub-scanning unit fixing bracket, and reinstall it to its original position. CAUTION When removing the sub-scanning unit fixing bracket, be careful never remove the screws painted in red. CHECK/Adjusting Procedure Check that connectors are connected properly. 006-259-01 DRYPIX 7000 Service Manual MC-86 11.10.2002 FM3601...
  • Page 88 35 x 43cm size 26 x 36 cm size 20 x 25 cm size 27.5 ±1.0 26.0 ±1.0 14.5 ±1.0 D, E ≤ 1.2 ≤ 1.2 ≤ 1.2 | D - E | FP7C0622.EPS 006-259-01 DRYPIX 7000 Service Manual MC-87 11.10.2002 FM3601...
  • Page 89 MC-88 If the measured values are not the specified values, loosen the screws securing the sub-scanning unit. [Loosen] 2-BR4x8 [Loosen] 2-BR4x8 FP7C0617.EPS 006-259-01 DRYPIX 7000 Service Manual MC-88 11.10.2002 FM3601...
  • Page 90 Remove the sub-scanning unit fixing bracket. Sub-scanning unit fixing bracket [Remove] 4-BR4x8 FP7C0613.EPS Reinstall the sub-scanning unit fixing bracket at the position shown below. [Tighten] 2-BR4x8 Sub-scanning unit fixing bracket [Tighten] 2-BR4x8 Sub-scanning unit fixing bracket FP7C0614.EPS 006-259-01 DRYPIX 7000 Service Manual MC-89 11.10.2002 FM3601...
  • Page 91 Rotate the positioning screw in the clockwise or counterclockwise direction and adjust. <NOTE> Rotating once in the clockwise or counterclockwise direction changes the “D” and “E” on the printed film by about 0.5 mm. [Rotate] Positioning screw FP7C0615.EPS Film conveyance direction FP7C0624.EPS 006-259-02 DRYPIX 7000 Service Manual MC-90 04.01.2003 FM3978...
  • Page 92 Measure the “D” and “E” on the printed film and check that they meet the specified values. (10) If the measured values are not the specified values, repeat steps (3) to (9). 006-259-02 DRYPIX 7000 Service Manual MC-91 04.01.2003 FM3978...

  • Page 93: Sub-Scanning Motor (Me1)

    Removal/Reinstallation Removing Procedure Remove the sub-scanning unit. “6.1 Sub-Scanning Unit” Remove the sub-scanning motor (ME1). [Remove] Q4x14 Sub-scanning motor (ME1) [Remove] 4-TP4x8 FP7C0604.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-02 DRYPIX 7000 Service Manual MC-92 04.01.2003 FM3978...
  • Page 94 26 x 36 cm size 20 x 25 cm size 226.5 ±1.0 225.0 ±1.0 413.0 ±1.2 FP7C0623.EPS If the measured values are not the specified values, adjust the film conveyance amount. “Service Mode, [5-2-3] Adjusting subscanner”. 006-259-02 DRYPIX 7000 Service Manual MC-93 04.01.2003 FM3978...

  • Page 95: Sub-Scanning Roller

    Remove the belt cover. Remove the SUS belt. (6) #1 [Remove] Spring (5) #1 [Remove] BR4x8 Belt cover (4) #1 [Remove] BR3x10 SUS belt (6) #2 [Lower] SUS belt tensioner Handle FP7C0605.EPS 006-259-02 DRYPIX 7000 Service Manual MC-94 04.01.2003 FM3978...
  • Page 96 Sub-scanning unit entrance guide (9) #3 [Pull out] Sub-scanning unit roller (Right) (8) #1 Waveform washer [Remove] BR4x8 (9) #1 Sub-scanning roller (right) [Remove] BR4x8 (9) #2 [Lower] SUS belt tensioner FP7C0607.EPS 006-259-01 DRYPIX 7000 Service Manual MC-95 11.10.2002 FM3601...
  • Page 97 • When installing the sub-scanning roller, be sure to reinstall the waveform washer. • After reinstalling the sub-scanning roller, rotate the roller four or five times with the hand, and check that it turns smoothly. Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-96 11.10.2002 FM3601...
  • Page 98 MC-97 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-97 11.10.2002 FM3601...

  • Page 99: Film Leading Edge Detection Sensor (Se1)

    Removing Procedure Insert the shutter into the film tray. Remove the following covers. • Right side cover • Rear cover Remove the sub-scanning unit fixing bracket. Sub-scanning unit fixing bracket [Remove] 4-BR4x8 FP7C0613.EPS 006-259-01 DRYPIX 7000 Service Manual MC-98 11.10.2002 FM3601...
  • Page 100 MC-99 Reinstall the sub-scanning unit fixing bracket at the position shown below. [Tighten] 2-BR4x8 Sub-scanning unit fixing bracket [Tighten] 2-BR4x8 Sub-scanning unit fixing bracket FP7C0614.EPS 006-259-01 DRYPIX 7000 Service Manual MC-99 11.10.2002 FM3601...
  • Page 101 (7) #1 [Disconnect] Connector LDD16A-CN1 (7) #1 [Disconnect] Connector LDD16A-CN3 (7) #1 [Disconnect] Connector LDD16A-CN7 Shield plate (7) #1 [Disconnect] Connector (5) #1 (6) #1 LDD16A-CN9 [Remove] 2-BR3x8 [Loosen] 2-BR4x12 Connector cover FP7C0601.EPS 006-259-01 DRYPIX 7000 Service Manual MC-100 11.10.2002 FM3601...
  • Page 102 [Disconnect] Connector ME1 (7)#2 [Disconnect] Connector CNS2 (7)#3 [Remove] 2-BR4x8 Sub-scanning unit FP7C0619.EPS Remove the film leading edge detection sensor (SE1). [Disconnect] Connector Film leading edge detection sensor (SE1) [Remove] 2-BR3x8 FP7C0608.EPS 006-259-01 DRYPIX 7000 Service Manual MC-101 11.10.2002 FM3601...
  • Page 103 Reinstall in the reverse order of removal. However, perform the following when securing the sub-scanning unit into the equipment. Insert the sub-scanning unit into the equipment, and temporarily secure with the screws. [Temporarily tighten] 2-BR4x8 [Temporarily tighten] 2-BR4x8 FP7C0620.EPS 006-259-01 DRYPIX 7000 Service Manual MC-102 11.10.2002 FM3601...
  • Page 104 Rail of equipment FP7C0621.EPS Remove the sub-scanning unit fixing bracket, and reinstall it to its original position. CAUTION When removing the sub-scanning unit fixing bracket, be careful never remove the screws painted in red. 006-259-01 DRYPIX 7000 Service Manual MC-103 11.10.2002 FM3601...

  • Page 105: Scanning Optics Unit

    • Do not place your finger inside the laser beam window (at the bottom of the scanner unit). • Handle the optical unit gently, making sure not to subject it to shock. 006-259-01 DRYPIX 7000 Service Manual MC-104 11.10.2002 FM3601...
  • Page 106 MC-105 7.1.1 Removal/Reinstallation Removing Procedure Remove the sub-scanning unit. “6.1 Sub-scanning Unit” Remove the scanner unit. [Remove] 4-BR4x12 Scanner unit CHECK CHECK CHECK FP7C0701.EPS 006-259-01 DRYPIX 7000 Service Manual MC-105 11.10.2002 FM3601...
  • Page 107 [Tighten] 4-BR4x12 FP7C0702.EPS CHECK/Adjusting Procedure • Make sure that there is no gap between the sub-scanning unit positioning plate and scanner unit positioning parts. • Make sure that the connectors are connected properly. 006-259-01 DRYPIX 7000 Service Manual MC-106 11.10.2002 FM3601...
  • Page 108 “Printer name importing data” → [Control] → [File Save/Load] → [Save from the printer] → [Execute] FP7C0F09.EPS → The individual data is sent to the PC for servicing. When the data transfer is completed, the [File transfer is completed.] screen appears. 006-259-02 DRYPIX 7000 Service Manual MC-107 04.01.2003 FM3978...
  • Page 109 When the data transfer is completed, the [File transfer is completed.] screen appears. End the DPX7 PC Tool. Reboot the equipment, and start the M-Utility. Output the grid pattern using the M-Utility. “SERVICE MODE, [2-5] Grid” 006-259-02 DRYPIX 7000 Service Manual MC-108 04.01.2003 FM3978...
  • Page 110 (13) If they do not, change the value of “[4-3-2] Scanning Position” of the M-Utility. “SERVICE MODE, [4-3-2] Scanning Position” (14) Perform automatic density correction. “SERVICE MODE, [3-1] AUTO F.D.C.” (15) Check the film density. “SERVICE MODE, [3-2] Check Density” 006-259-02 DRYPIX 7000 Service Manual MC-109 04.01.2003 FM3978...

  • Page 111: Heat Development Unit

    Cooling Fan Assembly FP7C0814.EPS Removing Procedure Remove the following covers. • Jam clear cover • Upper left cover Remove the fan fixing bracket. Cooling fan assembly [Remove] 4-BR3x8 Fan fixing bracket FP7C0801.EPS 006-259-01 DRYPIX 7000 Service Manual MC-110 11.10.2002 FM3601...
  • Page 112 MC-111 Remove the cooling fan assembly. [Remove] 4-BR4x8 Cooling fan assembly [Disconnect] Connector CNG3 FP7C0802.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-111 11.10.2002 FM3601...

  • Page 113: Filter Section Cooling Fan

    Remove the cooling fan assembly. “8.1 Cooling Fan Assembly” Remove the fan duct. Remove the filter section cooling fan. Fan duct [Remove] 4-BR3x8 Auxilary plate [Remove] 2-BR4x40 Filter section cooling fan FP7C0803.EPS 006-259-01 DRYPIX 7000 Service Manual MC-112 11.10.2002 FM3601...
  • Page 114 MC-113 Reinstalling Procedure <INSTRUCTIONS> Reinstall the filter section cooling fan as shown in the figure. Filter section cooling fan Label Cable Cooling fan assembly FP7C0804.EPS Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-113 11.10.2002 FM3601...

  • Page 115: Film Cooling Section

    “10.1 Operation Panel” Remove the film release unit. “9.1 Film Release Unit” Remove the film cooling section. Round hole [Release] Clamp CHECK [Disconnect] Connector THG10 Film cooling section CHECK [Remove] 5-BR4x8 [Loosen] 2-BR4x8 FP7C0805.EPS 006-259-01 DRYPIX 7000 Service Manual MC-114 11.10.2002 FM3601...
  • Page 116 • After reinstalling the film cooling section, rotate the jam handle, and check that it moves smoothly. 006-259-01 DRYPIX 7000 Service Manual MC-115 11.10.2002 FM3601...

  • Page 117: Heat Development Unit

    Remove the film release unit. “9.1 Film Release Unit” Remove the cooling fan assembly. “8.1 Cooling Fan Assembly” Remove the operation panel. “10.1 Operation Panel” Remove the film cooling section. “8.3 Film Cooling Section” 006-259-01 DRYPIX 7000 Service Manual MC-116 11.10.2002 FM3601...
  • Page 118 Remove the heat development unit. [Disconnect] Connector CNG2 Heat development unit [Disconnect] Connector CNG4 [Remove] 3-BR4x8 [Disconnect] Connector CNG1 [Disconnect] Connector MG1 [Release] Clamp FP7C0808.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-117 11.10.2002 FM3601...

  • Page 119: Heat Development Rack Assembly

    “9.1 Film Release Unit” Remove the film cooling section. “8.3 Film Cooling Section” Remove the cooling fan assembly together with the bracket. Cooling fan assembly [Remove] 2-BR3x8 Bracket Bracket [Remove] 4-BR4x8 [Disconnect] Connector CNG3 FP7C0823.EPS 006-259-02 DRYPIX 7000 Service Manual MC-118 04.01.2003 FM3978...
  • Page 120 Connector HEAT3 Rack fixing bracket (small) (8) #1 [Remove] CHECK BR4x8 Rack fixing bracket (small) (7) #1 (10) [Remove] TP4x8 [Remove] Heat development rack assembly [Remove] 2-BR4x8 Rack fixing bracket (large) FP7C0809.EPS 006-259-01 DRYPIX 7000 Service Manual MC-119 11.10.2002 FM3601...
  • Page 121 When reinstalling the adiabatic cover, do not sandwich the thermistor cable. Reinstall in the reverse order of removal. CHECK/Adjustment Procedure Check that connectors are connected properly. Third rack assembly THG7-9 HEAT3 Second rack assembly THG4-6 HEAT2 THG1-3 HEAT1 First rack assembly FP7C0810.EPS 006-259-02 DRYPIX 7000 Service Manual MC-120 04.01.2003 FM3978...
  • Page 122 MC-121 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-121 11.10.2002 FM3601...

  • Page 123: Heat Development Roller

    [Remove] Heater assembly (2) #1 [Remove] Fixing pin (long) (4) #1 [Remove] WP3x10 Bearing (2) #2 Heat development roller Bearing [Remove] Fixing pin (short) FP7C0811.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-122 11.10.2002 FM3601...
  • Page 124 MC-123 BLANK PAGE 006-259-01 DRYPIX 7000 Service Manual MC-123 11.10.2002 FM3601...

  • Page 125: Film Release Unit

    FILM RELEASE UNIT FP7Z0911.EPS Film Release Unit FP7C0904.EPS Removing Procedure Remove the following covers. • Jam clear cover • Upper left side cover • Upper right side cover • Side ejection cover 006-259-01 DRYPIX 7000 Service Manual MC-124 11.10.2002 FM3601...
  • Page 126 MC-125 Remove the film release unit. [Release] Clamp [Disconnect] Connector CNJ2 [Disconnect] Connector CNJ1 [Remove] 4-BR4x8 Film release unit FP7C0901.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-125 11.10.2002 FM3601...

  • Page 127: Density Measurement Light-Emitting Board (Led15A)

    (2) #1 Connector LED-CN85 [Remove] 2-BR3x8 (3) #1 [Remove] BR3x12 (3) #1 Shield [Remove] BR3x8 plate Spacer (2) #2 [Remove] Clamp Density measurement light-emitting board (LED15A) (2) #3 [Disconnect] Connector SJ1 FP7C0902.EPS 006-259-01 DRYPIX 7000 Service Manual MC-126 11.10.2002 FM3601...
  • Page 128 Press the LED cover of the density measurement light-emitting board against the position shown in the figure below, and secure. [Press] Density measurement light-emitting board (LED15A) FP7C0903.EPS Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-127 11.10.2002 FM3601...

  • Page 129: Operation Panel

    Remove the operation panel. [Disconnect] [Disconnect] [Disconnect] Connector [Disconnect] Connector Connector Connector PANEL-CN5 PANEL-CN7 PANEL-CN2 PANEL-CN1 Operation panel [Disconnect] Connector PANEL-CN8 [Disconnect] Connector PANEL-CN6 [Disconnect] [Remove] BR3x8 Connector PANEL-CN4 [Remove] 2-BR3x8 FP7C0104.EPS 006-259-01 DRYPIX 7000 Service Manual MC-128 11.10.2002 FM3601...
  • Page 130 MC-129 Reinstalling Procedure <NOTE> When reinstalling the upper left side cover, make sure that it does not interfere with the operation panel. Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-129 11.10.2002 FM3601...

  • Page 131: Controller Assembly

    [Disconnect] Shaded connector [Disconnect] Connector PC-CN4 [Disconnect] Connector PRINT16A-CN2 [Disconnect] Connector [Disconnect] Connector PRINT16A-CN4 [Release] Clamp Controller assembly [Disconnect] [Remove] Connector 3-BR3x8 PC-CN26 [Disconnect] Connector CNK1 [Release] [Disconnect] Clamp Connector PRINT16A-CN16 FP7C0A01.EPS 006-259-01 DRYPIX 7000 Service Manual MC-130 11.10.2002 FM3601...
  • Page 132 MC-131 [Pull out] Controller assembly FP7C0A02.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-131 11.10.2002 FM3601...

  • Page 133: Hdd

    10.2 FP7C0A05.EPS Removing Procedure Remove the controller assembly. “10.2 Controller Assembly” Remove the HDD. [Remove] 4-BR3x12 [Disconnect] Connector HDD [Disconnect] Connector HDD FP7C0A03.EPS Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-132 11.10.2002 FM3601...
  • Page 134 (12) Remove the CD-R from the PC for servicing. (13) Shutdown the PC for servicing. (14) Disconnect the network cable of the PC for servicing from the network to which the equipment is connected. 006-259-01 DRYPIX 7000 Service Manual MC-133 11.10.2002 FM3601...

  • Page 135: Pc Board

    Remove the PRN board, MCT board, and image memory board. “SERVICE PARTS LIST, 10. Controller” Disconnect all connectors on the PC board. Remove the PC board. Reinstalling Procedure Reinstall in the reverse order of removal. 006-259-01 DRYPIX 7000 Service Manual MC-134 11.10.2002 FM3601...

  • Page 136: Mct Board

    Turn ON the power of the equipment, and start the M-Utility. Install the software on the HD in the MCT board in the following order; “PRT INST” → “PRT OS” → “PRT APL”. “SERVICE MODE, [1-1-9] Reload Software” Reboot the equipment. 006-259-02 DRYPIX 7000 Service Manual MC-135 04.01.2003 FM3978...

  • Page 137: Sorter

    SORTER FP7C0B02.EPS Film Conveyance Timing Belt FP7C0B03.EPS Belt Structure Top belt Inside belt Bottom belt FP3F0S43.EPS 006-259-01 DRYPIX 7000 Service Manual MC-136 11.10.2002 FM3601...
  • Page 138 Reinstalling Procedure There are three timing belts. Install the inside belt first and then the top and bottom belts. Top belt Top belt Bottom belt Inside belt Bottom belt Inside belt FP3F0S42.EPS 006-259-01 DRYPIX 7000 Service Manual MC-137 11.10.2002 FM3601...
  • Page 139 Tension spring Top belt Fixing screw Bottom belt Inside belt Fixing screw Fixing screw Tension spring Tension spring FP3F0S40.EPS 006-259-01 DRYPIX 7000 Service Manual MC-138 11.10.2002 FM3601...

  • Page 140: Jam Removing Guide Plate Magnet

    Loosen the fixing screws of the magnet. Close the jam removing guide plate, and tighten magnet fixing screws where it touches the stopper. Stopper #2 [Push] Guide plate #1 [Loosen] Two screws #3 [Tighten] Two screws Magnet FP3F0S41.EPS 006-259-01 DRYPIX 7000 Service Manual MC-139 11.10.2002 FM3601...

  • Page 141: Preparations (Same For Version Upgrades And Full Installation)

    Turn ON the power of the equipment. Prepare the PC for servicing. “INSTALLATION, 10.1 Connecting the PC for Servicing to the Network” “INSTALLATION, 10.2 Starting the DPX7 PC Tool/Connecting to DPX7 PC Tool the Equipment” 006-259-01 DRYPIX 7000 Service Manual MC-140 11.10.2002 FM3601...

  • Page 142: Version Upgrade

    “Printer name” → [Soft Ver.UP] → “CD-ROM drive” → [Copy] FP7C0F01.EPS → The main unit software is copied to the FTP folder of the PC for servicing. When completed, [File Copy Finish!!] screen appears. 006-259-02 DRYPIX 7000 Service Manual MC-141 04.01.2003 FM3978...
  • Page 143 → The printer application program in the HD is installed in the MCT bard. When installation completed, the [Software Install Finish!!] screen appears. <REMARKS> The version of the main unit software is upgraded after the equipment is rebooted. 006-259-02 DRYPIX 7000 Service Manual MC-142 04.01.2003 FM3978...
  • Page 144 Click [Exit] to end DPX7 PC Tool. Remove the CD-R from the PC for servicing. Shutdown the PC for servicing. Disconnect the network cable of the PC for servicing from the network to which the equipment is connected. 006-259-02 DRYPIX 7000 Service Manual MC-143 04.01.2003 FM3978...

  • Page 145: Full Installation

    “Printer name” → [Soft Ver.UP] → “CD-ROM drive” → [Copy] FP7C0F01.EPS → The main unit software is copied to the FTP folder of the PC for servicing. When completed, [File Copy Finish!!] screen appears. 006-259-02 DRYPIX 7000 Service Manual MC-144 04.01.2003 FM3978...
  • Page 146 MCT board. [PRT APL] → [Install] FP7C0F03.EPS → The printer application program in the HD is installed in the MCT board. When installation completed, the [Software Install Finish!!] screen appears. 006-259-02 DRYPIX 7000 Service Manual MC-145 04.01.2003 FM3978...
  • Page 147 “Printer name” → [Control] → [File Save/Load] → [Load to the printer] → [Execute] FP7C0F06.EPS → The individual data in the PC for servicing is sent to the equipment. When the data transfer is completed, the [File transfer is completed.] screen appears. 006-259-02 DRYPIX 7000 Service Manual MC-146 04.01.2003 FM3978...
  • Page 148 “Printer name” → [Data Transfer] → [FROM FD] FP7C0F11.EPS → The individual data is copied to the PC for servicing. When the data copy is completed, the [FD File transfer is completed.] screen appears. 006-259-02 DRYPIX 7000 Service Manual MC-147 04.01.2003 FM3978...
  • Page 149 “Printer name” → [Control] → [System Config] → [Set Counters] “SERVICE MODE, [PC9-2-5] Set Counters” Set the number of remaining films. “Printer name” → [Control] → [System Config] → [Set Remain. Films] “SERVICE MODE, [PC9-2-6] Set Remain. Films” 006-259-02 DRYPIX 7000 Service Manual MC-148 04.01.2003 FM3978...
  • Page 150 (10) Remove the CD-R and FD from the PC for servicing. (11) Shutdown the PC for servicing. (12) Disconnect the network cable of the PC for servicing from the network to which the equipment is connected. 006-259-02 DRYPIX 7000 Service Manual MC-149 04.01.2003 FM3978...

Table of Contents
