  • Page 1 Projector ® User’s Manual...

  • Page 2: Table Of Contents

    APPENDICES ..................39 Projector Problems ........................39 How to use web browser to control your projector ..............41 Crestron RoomView Control Tool .....................42 Installing and Cleaning the Optional Dust Filter ...............44 Compatibility Modes .........................45 Ceiling Mount Installation ......................48 Optoma global offices .......................49 English...

  • Page 3: Safety

    SAFETY The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appli- ance.
  • Page 4 Precautions Please follow all warnings, precautions and maintenance as recommended in this user’s guide. ▀■ Warning- Do not look into the projector’s lens when the light source is on. The bright light may hurt and damage your eyes. ▀■ Warning- To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture. ▀■...

  • Page 5: Regulation & Safety Notices

    - Watching 3D projection may also cause motion sickness, perceptual after effects, disorientation, eye strain and decreased postural stability. It is recommended that users take frequent breaks to lessen the potential of these effects. If your eyes show signs of fatigue or dryness or if you have any of the above symptoms, imme- diately discontinue use of this device and do not resume using it for at least thirty minutes after the symptoms have subsided.
  • Page 6 However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
  • Page 7 Safety notice LASER RADIATION DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT WAVE LENGTH: 450-460 nm / MAX OUTPUT: 15.9 mW / PULSE DURATION: 1.25 ms IEC 60825-1:2014 CLASS 1 LASER PRODUCT / RISK GROUP 2 Possibly hazardous optical radiation emitted from this product. Do not stare into the beam, May be harmful to the eyes.

  • Page 8: Introduction

    INTRODUCTION Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. Projector Power Cord VGA Cable Remote Control C D User Manual ...

  • Page 9: Product Overview

    INTRODUCTION Product Overview Main Unit Note: Do not block projector inlet or outlet air vents. Item Item 1. Keypad 8. Input / Output Connections 2. Focus Ring 9. Lens 3. Ventilation (inlet) 10. Tilt-Adjustment Foot 4. IR Receiver 11. Kensington Lock 5.

  • Page 10: Control Panel

    INTRODUCTION Control Panel Item Item 1. On/Standby LED 6. Source 2. Enter 7. Four Directional Select Keys 3. Temp LED 8. Power/Standby button 4. Lamp LED 9. IR Receiver 5. Menu 10 English...

  • Page 11: Connections

    INTRODUCTION Connections F1 F2 11 10 14 15 16 Item Item 1. Microphone connector 11. HDBaseT connector (Depending on Model) 2. Audio In connector 12. RJ45 3. VGA In/ YPbPr connector 13. Power Socket 4. Audio Out connector 14. 3D Sync Out (5V) connector 5.

  • Page 12: Remote Control

    INTRODUCTION Remote Control Item Key code 1. Power On Power on the projector. 2. Geometric Correction Launch the Geometric Correction menu. 3. F1:Test pattern Display a test pattern. 4. Display Mode Select the display mode. 5. Four directional select keys To select items or make adjustments.
  • Page 13 INTRODUCTION Item Key code 17. Power Off Power off the projector. 18. PIP/PBP Menu Launch the PIP/PBP menu. 19. F2:LAN Settings Launch the LAN Setting Menu. 20. AV Mute Momentarily turns off/on the audio and video. 21. Enter Confirm your item selection. 22.

  • Page 14: Setup And Installation

    SETUP AND INSTALLATION Connecting Source to the Projector Connect to Computer/Notebook Note: Due to the difference in applications for each country, some regions may have different accessories. (*) Optional accessory MOLEX Router / Network Switch Microphone External Display Audio Output Item Item 1.
  • Page 15 SETUP AND INSTALLATION Connect to Video Sources DVD Player, Set-top Box, HDTV receiver Microphone Audio Output Item Item 1. HDMI Cable 5. Microphone cable 2. Audio In Cable 6. RJ-45 cable (Cat5 cable) 3. Power Code 7. 12V DC Jack 4.

  • Page 16: Powering The Projector On/Off

    SETUP AND INSTALLATION Powering the Projector On/Off Powering On the Projector 1. Securely connect the power cord and signal cable. When connected, the POWER/STANDBY LED will turn Red. 2. Turn on the lamp by pressing the “ ” button either on the projector or on the remote. At this moment, the POWER/ STANDBY LED will now turn Blue.

  • Page 17: Warning Indicator

    SETUP AND INSTALLATION Powering Off the Projector 1. Press the “ ” button on the remote control or on the control panel to turn off the projector. The following message will be displayed on the screen. Press the “ ” button again to confirm otherwise the message will disappear after 10 seconds. When you press the “...

  • Page 18: Adjusting The Projected Image

    SETUP AND INSTALLATION Adjusting the Projected Image Adjusting the Projector’s Height The projector is equipped with elevator feet for adjusting the image height. 1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable ring clockwise to raise the projector or counter clockwise to lower it. Repeat with the remaining feet as needed.
  • Page 19 SETUP AND INSTALLATION Adjusting Projector Focus and Zoom 1. To adjust the image size, turn the zoom ring clockwise or anticlockwise to increase or decrease the projected image size. 2. To adjust the focus, turn the focus ring clockwise or anticlockwise until the image is sharp and legible. The projector will focus at distances (lens to wall) from 4.27 ~ 25.59 feet (1.3-7.8 meters).
  • Page 20 SETUP AND INSTALLATION Width Height Lens shift position center of lens (Hd) Lens Shift Adjustment Resolution Vertical Shift Range (Vs) Horizontal Shift Range (Hs) WUXGA 1080P Image Offset image size Screen Size WxH Projection Distance (D) Offset (Hd) inch inch inch inch Diagonal...

  • Page 21: User Controls

    USER CONTROLS Using the Control Panel Description Name Refer to the “Power On/Off the Projector” section on pages 16- POWER Enter Confirm a selected item. Select an input signal INPUT Launch the on-screen display (OSD) menu. To exit OSD, press MENU “MENU”...

  • Page 22: On-Screen Display Menus

    USER CONTROLS On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. How to operate To open the OSD menu, press “Menu” on the Remote Control or Projector Keypad. When OSD is displayed, use ▲▼...

  • Page 23: Structure

    USER CONTROLS Structure Note: Please note that the on-screen display (OSD) menus vary according to the signal type selected and the pro- jector model you are using. Main Menu Sub Menu Setting Bright/Presentation/Movie/sRGB/Blending/DICOM SIM./User Color Mode (Change Color Mode to User Mode if customer changes the settings) Wall Color White/ Light Yellow/ Light Blue/ Pink/ Dark Green...
  • Page 24 USER CONTROLS Main Menu Sub Menu Setting English/German/French/Italian/Spanish/Polish/Swedish/ Dutch/Portugese/Japanese/Traditional Chinese/ Simplified Language Chinese /Korean/Russian/Arabic/Norsk/Turkish/Danish/ Finnish/Greek/Hungarian/Czech/Romania/Thai/Farsi/Vietnam /Indonesian/Slovakian Menu Location Left Top, Right Top, Center, Left Bottom, Right Bottom VGA OUT Settings Off/On (Standby) LAN (Standby) Off/On Test Pattern None / Grid / White Direct Power On On/Off 12V Trigger...
  • Page 25 USER CONTROLS Main Menu Sub Menu Setting Logo Default/User Logo Capture Auto Source On/Off Input VGA, HDMI-1, HDMI-2, Dongle, HDBaseT Auto Power Off (Min.) Sleep Timer (Min.) SSI Hours Used (Normal) SSI Settings SSI Hours Used (ECO) SSI Power Mode Normal,ECO High Altitude On/Off [Default Off]...
  • Page 26 USER CONTROLS Main Menu Sub Menu Setting Auto/On 3D Invert On/Off Frame Packing Side-by-Side (Half) 3D Format Top and Bottom Frame Sequential 1080p @ 24 96Hz/144Hz Status DHCP Client On/Off IP Address Subnet Mask Gateway Network Store MAC Address Group Name Projector Name Location Contact...

  • Page 27: Picture

    USER CONTROLS Picture Color Mode There are many factory presets optimized for various types of images. Use the ◄ or ► button to select the item. • Bright: For brightness optimization. • Presentation: For meeting presentation. • Movie: For playing video content. •...
  • Page 28 USER CONTROLS Saturation Adjust a video image from black and white to fully saturated color. • Press the ◄ button to decrease the amount of saturation in the image. • Press the ► button to increase the amount of saturation in the image. Adjust the color balance of red and green.

  • Page 29: Screen

    USER CONTROLS Screen Aspect Ratio • Auto: Keep the image with original width-height ratio and maximize the image to fit native horizontal or vertical pixels. • 4:3: The image will be scaled to fit the screen and displayed using a 4:3 ratio. •...
  • Page 30 USER CONTROLS Projection • Front: The image is projected straight on the screen. • Front Ceiling: This is the default selection. When selected, the image will turn upside down. • Rear: When selected, the image will appear reversed. • Rear Ceiling: When selected, the image will appear reversed in upside down position. Geometric Correction •...

  • Page 31: Settings

    USER CONTROLS Settings Language Choose the multilingual OSD menu. Press the ◄ or ► button into the sub menu and then use the ▲ or ▼ button to select your preferred language. Press ► on the remote control to finalize the selection. Menu Location Choose the menu location on the display screen.
  • Page 32 USER CONTROLS Reset Choose “Yes” to return the parameters on all menus to the factory default settings. 32 English...

  • Page 33: Volume

    USER CONTROLS Volume Speaker • Choose “On” to enable the speaker. • Choose “Off” to disable the speaker. Line Out • Choose “On” to enable the line out function. • Choose “Off” to disable the line out function. Microphone • Choose “On”...

  • Page 34: Options

    USER CONTROLS Options Logo Use this function to set the desired startup screen. If changes are made they will take effect the next time the projector is powered on. • Default: The default startup screen. • User: Use stored picture from “Logo Capture” function. Logo Capture Press ►...
  • Page 35 USER CONTROLS Sleep Timer Sets the countdown timer. The countdown timer will start, with or without a signal being sent to the projector. The projector will automatically power off when the countdown has finished (in minutes). SSI Settings • SSI Hours Used (Normal) Display the projection time of normal mode.
  • Page 36 USER CONTROLS Note: Password default value is “000000” (first time). Always keep the password in your files. If the password is forgotten or lost, please contact your local autho- rized service center. Remote Setting IR function: When this function is “Off”, the projector cannot be operated by the remote control. Remote code: 00~99, default code (common code): 00 HDBaseT Control The projector will automatically detect the signal from HDBaseT transmitter supplied.
  • Page 37 USER CONTROLS Auto: When a HDMI 1.4a 3D timing identification signal is detected, the 3D image is selected automatically. • Choose “On” to enable 3D function. • Choose"Auto" to detected 3D signal automatically. 3D Invert If you see a discrete or overlapping image while wearing DLP 3D glasses, you may need to execute “Invert” to get best match of left/right image sequence to get the correct image.

  • Page 38: Lan

    USER CONTROLS Status Display the network connection status. DHCP Configure the DHCP settings. • On: Choose “On” to let the projector to obtain an IP address automatically from your network. • Off: Choose “Off” to assign IP, Subnet Mask, Gateway, and DNS configuration manually. IP Address Display an IP address.

  • Page 39: Appendices

    APPENDICES Projector Problems The projector stops responding to all controls If possible, turn off the projector, then unplug the power cord and wait at least 60 seconds before reconnect- ing power. Check that “Keypad Lock” is not activated by trying to control the projector with the remote control. If the remote control does not work Check if the operating angle of the remote control is within ±30°...
  • Page 40 APPENDICES Step 5: Click Use the following IP address, and type in as below: 1) IP address: 192.168.0.101 2) Subnet mask: 255.255.255.0 3) Default gateway: 192.168.0.254 Step 6: To open Internet Options, click IE web browser, click Internet Options, click the Connections tab and click “LAN Setting…”.

  • Page 41: How To Use Web Browser To Control Your Projector

    APPENDICES How to use web browser to control your projector 1. Turn on DHCP to allow a DHCP server to automatically assign an IP, or manually enter the required network information. 2. Then choose apply and press button to complete the configuration process. 3.

  • Page 42: Crestron Roomview Control Tool

    APPENDICES Crestron RoomView Control Tool Crestron RoomView™ provides a central monitoring station for 250+ control systems on a single Ethernet network (more are possible, the number depends on the combination of IP ID and IP address). Crestron RoomView monitors each projector, including projector’s online status, system power, lamp life, network setting and hardware faults, plus any custom attribute as defined by the Administrator.
  • Page 43 APPENDICES Edit Attribute Edit Event For more information, please visit http://www.crestron.com & www.crestron.com/getroomview. Network supports Crestron (Room View), AMX (Device Discovery) , PJLink and RS232 control. English 43...

  • Page 44: Installing And Cleaning The Optional Dust Filter

    APPENDICES Installing and Cleaning the Optional Dust Filter We recommend you clean the dust filter every 500 hours of operation, or more often if you are using the projector in a dusty environment. When the warning message appears on the screen, do the following to clean the air filter: Note: The optional dust filter should be used in dusty environments.

  • Page 45: Compatibility Modes

    APPENDICES Compatibility Modes A. VGA Analog (1) PC Signal Pixel CLK V.Frequency H.Frequency Modes Resolution EDID Description [Hz] [KHz] [MHz] 640x480 31.5 Established Timings 1 25,2 640x480 35.0 26.8 Established Timings 1 640x480 37.9 Established Timings 1 31.5 640x480 37.5 Established Timings 1 31.5 640x480...
  • Page 46 APPENDICES 720x576 576i 50(25) 15.6 13.5 (1440x576) 480p 720x480 59.94 31.5 27.0 576p 720x576 31.3 27.0 720p 1280x720 45.0 74.25 720p 1280x720 37.5 74.25 1080i 1920x1080 60(30) 33.8 74.25 1080i 1920x1080 50(25) 28.1 74.25 1080p 1920x1080 23.98/24 27.0 74.25 1080p 1920x1080 67.5 148.5...
  • Page 47 APPENDICES WXGA 1280x720 44.8 74.2 Standard Timing Identification WXGA: (Native)Detailed Timing / De- 1280x800 49.6 83.5 scriptor Block 1 XGA: Standard Timing Identification 1366x768 47.7 84.8 1440x900 59.9 106.5 Standard Timing Identification WXGA: Standard Timing Identification WSXGA+ 1680x1050 65.3 146.3 XGA: N/A 1920x720 44.35...

  • Page 48: Ceiling Mount Installation

    Ceiling Mount Installation 1. To prevent damage to your projector, please use the Optoma ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projec- tor meet the following specifications: •...

  • Page 49: Optoma Global Offices

    APPENDICES Optoma global offices For service or support, please contact your local office. Scandinavia 3178 Laurelview Ct. 888-289-6786 Lerpeveien 25 +47 32 98 89 90 Fremont, CA 94538, USA 510-897-8601 3040 Drammen +47 32 98 89 99 www.optomausa.com services@optoma.com Norway info@optoma.no...
