  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    Table of Contents Multimedia ........44 Table of Contents ......2 Usage Notice ........3 Accessing Multimedia Files ....44 How to access Multimedia mode ..44 Safety Information .......3 Appendices ........62 Precautions .........4 Installing and Cleaning the Optional Introduction ........6 Dust Filter .........62 Package Overview ......6 MMA Support List ......63 Product Overview .......7...

  • Page 3: Usage Notice

    Usage Notice Safety Information The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 4: Precautions

    Usage Notice Precautions Please follow all warnings, precautions and main- tenance as recommended in this user�s guide. ▀■ Warning- Do not look into the projector’s lens when the lamp is on. The bright light may hurt and damage your eyes. ▀■...
  • Page 5 Usage Notice  Turn off and unplug the power plug from the AC outlet before cleaning the product.  Use a soft dry cloth with mild detergent to clean the display housing. Disconnect the power plug from AC outlet if the product is not ...

  • Page 6: Introduction

    Introduction Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact your nearest customer service center. Standard Accessories Power Enter Exit Zoom+ Auto Reset Input Keystone Volume Zoom- Blank...

  • Page 7: Product Overview

    Introduction Product Overview Main Unit  The interface is subject to model’s specifications.  Do not block pro- jector in/out air vents and keep a minimum 30cm distance. 1. Control Panel 6. Speaker 2. Focus Switch 7. Power Socket 3. Ventilation (inlet) 8.

  • Page 8: Control Panel

    Introduction Control Panel 1. Power LED 2. Enter 3. Temp LED 4. Lamp LED 5. Menu 6. Input 7. Four Directional Select Keys 8. Power/Standby button 9. IR Receiver English...

  • Page 9: Input/Output Connections

    Introduction Input/Output Connections VGA1-In/YPbPr Connector (PC Analog Signal/Component Video Input/HDTV/YPbPr) HDMI2 Input Connector HDMI1 Input Connector USB Connector (Connect to PC for Remote Mouse  The interface function) is subject to RJ45 connector model’s USB Type A Connector specifications. Power Socket Interactive connector (3.5mm mini-jack, depending on Model) VGA-Out/VGA2-In Connector...

  • Page 10: Remote Control

    Introduction Remote Control Infrared transmitter LED Indicator Power On/Off Four Directional Select Keys Menu Power Exit Zoom in Reset Auto Source Enter Zoom out Volume +/- Exit Keystone +/- Image Zoom+ Black screen Aspect ratio Reset Input Auto VGA1  Some keys HDMI1 Keystone Volume...

  • Page 11: Installation

    Installation Connecting the Projector Connect to Computer/Notebook DVD Player, Set-top Box, HDTV receiver Router / Network Switch MOLEX  Due to the Microphone difference in applications for External Display each country, some regions may have different accessories. Audio Output  (*) Optional accessory 1....................*RS232 Cable 2....................

  • Page 12: Connect To Video Sources

    Installation Connect to Video Sources DVD Player, Set-top Box, HDTV receiver Composite Video Output  Due to the difference in Microphone applications for each country, some regions may have different accessories.  (*) Optional accessory Audio Output 1..........*15-Pin to 3 RCA Component/HDTV Adaptor 2....................*HDMI Cable 3....................*Audio Cable 4..................

  • Page 13: Powering The Projector On / Off

    Installation Powering the Projector On / Off Powering On the Projector 1. Securely connect the power cord and signal cable. When connected, the POWER/STANDBY LED will turn Orange. 2. Turn on the lamp by pressing “ ” button either on the projector or on the remote.

  • Page 14: Powering Off The Projector

    Installation Powering Off the Projector 1. Press the “ ” button on the remote control or on the control panel to turn off the projector. The following message will be displayed on the screen. Press the “ ” button again to confirm otherwise the message will disappear after 10 seconds.

  • Page 15: Adjusting The Projected Image

    Installation Adjusting the Projected Image Adjusting the Projector�s Height The projector is equipped with elevator feet for adjusting the image height. 1. Locate the adjustable foot you wish to modify on the underside of the projector. 2. Rotate the adjustable ring clockwise to raise the projector or counter clockwise to lower it.

  • Page 16: Adjusting The Projector�S Focus

    Installation Adjusting the Projector�s Focus To focus the image, slide the focus switch to left/right until the image is clear.  1080p series: The projector will focus at distances from 1.443 to 1.887 feet (0.437 to 0.572 meters).  WXGA series: The projector will focus at distances (lens to wall) from 1.59~2.16 feet (0.49~0.66 meters) Focus switch English...

  • Page 17: Adjusting Projection Image Size (Diagonal)

    Installation Adjusting Projection Image Size (Diagonal) 1080p series: Projection Image Size from 80” to 100” (2.03  to 2.54 meters).  WXGA series: The projector will focus at distances (lens to wall) from 1.59~2.16 feet (0.49~0.66 meters) Top View Screen Screen (W) Projection Distance (D) Width...
  • Page 18 Installation 1080P (16:9) Wall mount installation measurement chart Distance from Distance from surface of Distance from Distance from top Distance from surface of Diagonal Diagonal Image width Image height whiteboard top of image to of image to top of top of image to image size (S) image size (S) whiteboard to...

  • Page 19: User Controls

    User Controls Control Panel & Remote Control Control Panel Using the Control Panel Refer to the “Power On/Off the Projector” POWER section on pages 13-14. Enter Press “Enter” to confirm your item selection. INPUT Press “INPUT” to select an input signal. Press “MENU”...

  • Page 20: Remote Control

    User Controls Remote Control Using the Remote Control Infrared transmitter Sends signals to the projector. LED Indicator. Refer to the “Power On/Off the Power Projector” section on pages 15-16. Power Exit Press “Exit” to close the OSD menu. Zoom in Zoom in the projector display.
  • Page 21 User Controls Using the Remote Control Press “VGA1” to choose VGA IN 1 VGA1 connector. Momentarily turns off/on the audio and Blank screen video. Press “HDMI1” to choose HDMI IN 1 HDMI1 Power connector. Press “HDMI2” to choose HDMI IN 2 HDMI2 connector.

  • Page 22: Ir Remote Codes

    User Controls IR Remote codes NEC_CODE Custom Code Data legend Byte1 Byte2 Byte3 Byte4 Power Left Enter Down Menu Zoom+ Exit Auto Reset Input Zoom- Keystone+ Keystone - Volume- Volume+ Blank/1 Image/2 Aspect3 VGA1 /4 Freeze/5 HDMI1/6 VGA2 /7 HDMI2 /8 S-Video /9 English...

  • Page 23: Structure

    User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. Structure Note: Please note that the on-screen display (OSD) menus vary according to the signal type selected and the pro jector model you are using.
  • Page 24 User Controls English/German/French/Italian/Spanish/ Polish/Swedish/Dutch/Portugese/Japanese/ Language Traditional Chinese/ Simplified Chinese/ Korean/Russian/Arabic/Norsk/Turkish/Danish Left Top, Right Top, Center, Left Bottom, Right Menu Location Bottom Settings Closed Caption Off/CC1/CC2/CC3/CC4 VGA OUT Off/On (Standby) LAN (Standby) Off/On VGA-2 (Function) Inout/Output Test Pattern Off/On Reset to Default Yes/No Speaker On/Off...
  • Page 25 User Controls Model Name SNID Source Options Information Resolution SW Version Aspect Ratio Off/On 3D Invert On/Off Frame Packing Side-by-Side (Half) 3D Format Top amd Bottom Frame Sequential Field Sequential 1080p @ 24 96Hz/144Hz Interactive Interactive Setting On/Off(interactive SKU only) Status DHCP Client On/Off...

  • Page 26: How To Operate

    User Controls How to operate To open the OSD menu, press “Menu” on the Remote Control or Projector Keypad. When OSD is displayed, use the ▲▼ keys to select any item in the main menu. While making a selection on a particular page, press the ►...

  • Page 27: Picture

    User Controls Picture Color Mode There are many factory presets optimized for various types of im- ages. Use the ◄ or ► button to select the item. Bright: For brightness optimization.  PC: For meeting presentation.  Movie: For playing video content. ...
  • Page 28 User Controls Sharpness Adjust the sharpness of the image. Press the ◄ button to decrease the sharpness.   “Sharpness”, “Sat- uration” and “Hue” Press the ► button to increase the sharpness.  functions are only supported under Saturation video mode. Adjust a video image from black and white to fully saturated color.

  • Page 29: Screen

    User Controls Screen Aspect Ratio Auto: Keep the image with original width-height ratio and maxi-  mize the image to fit native horizontal or vertical pixels. 4:3: The image will be scaled to fit the screen and displayed  using a 4:3 ratio. 16:9: The image will be scaled to fit the width of the screen and ...
  • Page 30 User Controls V. Position Press the ◄ button to move the image down.  Press the ► button to move the image up.  Digital Zoom Press the ◄ button to reduce the size of an image.  Press the ► button to magnify an image on the projection ...

  • Page 31: Setting

    User Controls Setting Language Choose the multilingual OSD menu. Press the ◄ or ► button into the sub menu and then use the ▲ or ▼ button to select your preferred language. Press ► on the remote control to finalize the selection.
  • Page 32 User Controls LAN (Standby) Choose “On” to enable LAN connection. Choose “Off” to disable LAN connection. VGA B (Function) Input: Choose “Input” to let the VGA port works as a VGA input  function. Output: Choose “Output” to enable the VGA Out function once ...

  • Page 33: Volume

    User Controls Volume Speaker Choose “On” to enable the speaker.  Choose “Off” to disable the speaker.  Line Out Choose “On” to enable the line out function.  Choose “Off” to disable the line out function.  Microphone Choose “On” to enable the microphone. ...

  • Page 34: Options

    User Controls Options Logo Use this function to set the desired startup screen. If changes are made they will take effect the next time the projector is powered Default: The default startup screen.  User: Use stored picture from “Logo Capture” function. ...
  • Page 35 User Controls Auto Power Off (Min) Sets the countdown timer interval. The countdown timer will start, when there is no signal being sent to the projector. The projector will automatically power off when the countdown has finished (in minutes). Laser Settings Refer to page 32.

  • Page 36: Options | Laser Settings

    User Controls Options | Laser Settings Laser Hours Used (Normal) Display the projection time of normal mode. Laser Hours Used (ECO) Display the projection time of ECO mode. Laser Power Mode Normal: Normal mode.  ECO: Use this function to dim the projector lamp which will ...
  • Page 37 User Controls  “Frame Sequen- Auto: When a HDMI 1.4a 3D timing identification signal is de-  tial” is supported tected, the 3D image is selected automatically. the DLP Link 3D input signals from Choose “On” to enable 3D function.  VGA / HDMI con- Choose “Auto”...

  • Page 38: Lan

    User Controls Status Display the network connection status.  IP, Subnet Mask, DHCP Gateway, and DNS configura- Configure the DHCP settings. tion assignment On: Choose “On” to let the projector to obtain an IP address  please access to automatically from your network. web control page.
  • Page 39 User Controls Gateway Display the default gateway of the network connected to the pro- jector. Display the DNS number. MAC Address Display the MAC address. Group Name Display the group name. Projector Name Display the projector name. Location Display the projector location. Contact Display the contact information.
  • Page 40 User Controls How to use web browser to control your projector 1. Turn on DHCP to allow a DHCP 4. Based on network web-page for the server to automatically assign an IP, or input-string in [tools] tab, the limitation manually enter the required network for Input-Length is in the below list information.
  • Page 41 User Controls When making a direct connection from your computer to the projector Step 1: Find an IP Address (192.168.0.100) from LAN function of projector. Step 2: Select apply and press “Enter” button to submit function or press “menu” key to exit.
  • Page 42 User Controls Crestron RoomView Control Tool Crestron RoomView™ provides a central monitoring station for 250+ control systems on a single Ethernet network (more are possible, the number depends on the combination of IP ID and IP address). Crestron RoomView monitors each projector, including projector’s online status, system power, lamp life, network setting and hardware faults, plus any custom attribute as defined by the Administrator.
  • Page 43 User Controls 3. Edit Attribute 4. Edit Event For further information, please visit: http://www.crestron.com & www.crestron.com/getroomview. English...

  • Page 44: Multimedia

    Multimedia Accessing Multimedia Files This projector supports two methods to project the media files (photos, videos, music, documents) stored on following devices: a. Via Wireless dongle (optional) - wirelessly access the media files stored on your mobile phone, tablet PC, notebook, or desktop. b.
  • Page 45 Multimedia Mobile Display To access the media files stored on your mobile device or tablet PC, do the folllowing: 1. On Multimedia menu, select Mobile/Tablet. 2. On your mobile device or tablet PC, download “EZ-View” application App Store (iOS) or Play Store (Android). 3.
  • Page 46 Multimedia Laptop Display To access the media files stored on your laptop/notebook, do the folllowing: 1. On Multimedia menu, select Laptop. 2. Enable your laptop/notebook WiFi function, and search the AP name listed in the Wi-Fi network list. 3. On the WIFI initial connection, you will be prompted to enter a password.
  • Page 47 Multimedia 6. Wait until the connection is established. The media files on your laptop/notebook can be accessed using the projector. Desktop Display To access the media files stored on your desktop, do the folllowing: 1. On Multimedia menu, select Desktop. 2.
  • Page 48 Multimedia 3. After install complete. Launch “EZ-View” application and enter the control code shown on the right-bottom side of the screen. 4. Wait until the connection is established. The media files on your desktop can be accessed using the projector. EZ-View 1.
  • Page 49 Multimedia Supported File Format Multimedia Category File Format Photo BMP, JPG, PNG Music MP3, WMA Video AVI, MOV, MP4, RM, RMVB, DAT, MPG, ISO, TS, MKV, VOB, and WMV Document WORD, EXCEL, PPT*, PDF 1. On Multimedia menu, select USB Disk. Sometimes selecting USB is slower.
  • Page 50 Multimedia 3. Use the ▲▼ keys to select the file to view/play and press the “Enter” key to confirm. Photo 1. Select the Photo will enter to file list. Use up, down, left, right key to select the picture. 2. Select one picture and push the enter key. Push enter key to show the tool bar, push back key to display tool bar.
  • Page 51 Multimedia Functions Defined Degree change: 0, 90, 180, 270 Enter key looping Back key leave and no save function Zoom in: x1, x2, x3, x4 Enter key looping In zoom in mode use arrow key to move content. Back key leave and no save function Full screen Keep image ratio and no save function Previous image...
  • Page 52 Multimedia 2. Select the video file and push the enter key to play video. Push enter key to show the tool bar, push back key to display tool bar. Functions Key defined reverse left key forward right key play/ pause enter only show the play mode was repeat or single To configure the play mode, user can reach to...
  • Page 53 Multimedia 2. Select the audio file and push enter key to play music. Functions Key defined previous file up key next file down key rewind left key forward right key play/ pause enter only show the play mode was repeat or single To configure the play mode, user can reach to display mode settings/Music/repeat mode to change the repeat...
  • Page 54 Multimedia Office viewer 1. Select the office viewer will enter to file list. Use up and down key to select the document file. 2. Select one document and push the enter key. Push enter key to show the tool bar, push back key to display tool bar.
  • Page 55 Multimedia Close tool bar Enter key to use *Note 1. The decode time depend how many objects embedded in document file, not depend the size of file. *Note 2. Office viewer will set the display ratio by each document files. *Note 3.
  • Page 56 Multimedia System: Select this option to view the firmware version and  update firmware. Video: Select this option to change the display ratio and set  the repeat mode. Photo: Select this option to change the display ratio,  slideshow pattern, and slideshow duration. Music: Select this option to set the repeat mode .
  • Page 57 Multimedia AP setting  The AP setting defines the SSID between projector and user PC. The projector acts as a WIFI access point. PC/Laptops connects this WIFI access point can use the multimedia mirroring/streaming function with EZ-View software. This setting is similar with access point, user can define the SSID name, password here.
  • Page 58 Multimedia Following is the steps to configure the item. 1) Use the up/down to control the blue focus to select SSID item then push enter key. A virtual keyboard will popup and the SSID will be cleared for user input. When input completed, press the exit key on remote control and navigate with up/down key to proceed previous/next item.
  • Page 59 Multimedia 3) After that, move up/down key to select “V” then push enter key to finish AP setting. Projector media card will restart and need to wait couple of seconds. If you want to cancel configuration, move to “X” button and then push enter key. The SSID and PSK setting will drawback to original setting.
  • Page 60 Multimedia 3) After choosing the access point, user has to input the password in left side PSK window and then select OK to proceed. 4) Connection status will display on bottom side and will show successful once connection is completed. Check sign on the access point will display as blue.
  • Page 61 Multimedia For security reason,  security item do not have capability to change, only WPA2 encryption is supported in AP mode. In client mode setting, WPA/WPA2 are supported. English...

  • Page 62: Appendices

    Appendices Installing and Cleaning the Optional Dust Filter We recommend you clean the dust filter every 500 hours of operation, or more often if you are using the projector in a dusty environment. When the warning message appears on the screen, do the following to clean the air filter: The optional dust ...

  • Page 63: Mma Support List

    Appendices MMA Support List Image Image Format Profile Color Space Size Limitation YUV400 8000 x 6000 YUV420 8000 x 6000 Baseline YUV422 8000 x 6000 YUV440 8000 x 6000 YUV444 8000 x 6000 JPEG YUV400 YUV420 Width <= 10240 & Progressive YUV422 height <= 6400...
  • Page 64 Appendices Video File Audio/ Codec Profile/Level Support Explanation Extensions Video Up to 1080P 30fps MJPEG 80Mbps Support less Up to High Profile , than 6 H.264/AVC Levels 1- 4.1 (1080P reference 30fps 25Mbps) frames Up to Advance Simple XVID profile (1080P 30fps 30Mbps) .avi Video...
  • Page 65 Appendices Main profile, Low and MPEG2 Main Levels (1080P 30fps 30Mbps) Video Support less Up to High Profile , than 6 H.264/AVC Levels 1- 4.1 reference (1080P 30fps 25Mbps) frames MPEG-1 Layer I, II MPEG-1 Video Layer III (mp3) LPCM Main profile, Low and D-picture not MPEG1...
  • Page 66 Appendices WMV3 Up to Main Profile; Low, Video (WMV Medium Level Ver9) (1080P 30fps 25Mbps) .wmv WMA2 Not Support Audio (WMA Ver9 WMA Ver9 Pro &Ver9.1) Subtitle Format Font Subtitle Size Standard SRT UTF-8 / UTF-16 8bits up to 1280 x 800 SSA/ASS Note: DO NOT support mixed code in subtitle files.
  • Page 67 Appendices British Word95 Because office Word97, 2000, 2002, 2003 viewer does not load all pages of support MS Word Up to Bold Text MS Word file at the 100MB in Simple Word 2007 (.docx), 2010 same time, Chinese (.docx) there are front no obvious limitations...

  • Page 68: Compatibility Modes

    Appendices Compatibility Modes VGA Analog  a. PC signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 640x480 31.5 640x480 35.0 640x480 37.9 640x480 37.5 640x480 43.3 640x480 61.9 720x400 31.5 800x600 35.1 800x600 37.9 800x600 48.1 SVGA 800x600 46.9 800x600 53.7 800x600...
  • Page 69 Appendices b. Extended wide timing Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 1280x720 44.8 1280x800 49.6 WXGA 1366x768 47.7 1440x900 59.9 WSXGA+ 1680x1050 65.3 c. Component signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 720x480 480i 59.94(29.97) 15.7 (1440x480) 720x576 576i...

  • Page 70: Hdmi Digital

    Appendices HDMI Digital  a. PC signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 640x480 31.5 640x480 35.0 640x480 37.9 640x480 37.5 640x480 43.3 640x480 61.9 720x400 31.5 800x600 35.1 800x600 37.9 800x600 48.1 SVGA 800x600 46.9 800x600 53.7 800x600 77.4 Apple, MAC II...
  • Page 71 Appendices b. Extended wide timing Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 1280x720 44.8 1280x800 49.6 WXGA 1366x768 47.7 1440x900 59.9 WSXGA+ 1680x1050 65.3 c. Video signal Modes Resolution V. Frequency [Hz] H. Frequency [Hz] 480p 640x480 59.94/60 31.5 720x480 480i 59.94(29.97)

  • Page 72: Rs232 Protocol Function List

    Appendices RS232 Protocol Function List A. VGA Analog (1) PC Signal V.Frequency H.Frequency Pixel CLK Modes Resolution EDID Description [Hz] [KHz] [MHz] 640x480 31.5 Established Timings 1 25..2 640x480 35.0 26.8 Established Timings 1 640x480 37.9 Established Timings 1 31.5 640x480 37.5 Established Timings 1...
  • Page 73 Appendices 640x480 37.5 Established Timings 1 31.5 640x480 43.3 36.0 720x400 31.5 28.3 Established Timings 1 SVGA 800x600 35.1 Established Timings 1 36.0 800x600 37.9 Established Timings 1 40.0 800x600 48.1 50.0 Established Timings 2 800x600 46.9 49.5 Established Timings 2 800x600 53.7 56.3...

  • Page 74: Regulation & Safety Notices

    Appendices Regulation & Safety Notices This appendix lists the general notices of your projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules.
  • Page 75 Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 76 Appendices Safety notice 450 4 1.66 WARNING - This projector is a Class 2 laser device that conforms with IEC 60825-1:2007 and CFR 1040.10 and 1040.11. - Class 2 laser product, Do Not Stare Into Beam. - This projector has built-in Class 4 laser module. Disassembly or modification is very dangerous and should never be attempted.

  • Page 77: Ceiling Mount Installation

    Ceiling Mount Installation 1. To prevent damage to your projector, please use the Optoma ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector...
  • Page 78 Appendices Optoma global offices For service or support, please contact your local office. Scandinavia 3178 Laurelview Ct. 888-289-6786 Lerpeveien 25 +47 32 98 89 90 Fremont, CA 94538, USA 510-897-8601 3040 Drammen +47 32 98 89 99 www.optomausa.com services@optoma.com Norway info@optoma.no...
