Page 1 MB2650, MX622, XM3250 MFPs User's Guide September 2018 www.lexmark.com Machine type(s): 7018 Models: 676, 678, 679, 686...
Page 2: Table Of Contents
Contents Contents Safety information..................7 Conventions................................7 Product statements..............................7 Learning about the printer................. 10 Finding information about the printer......................10 Selecting a location for the printer......................... 11 Printer conﬁgurations............................13 Attaching cables..............................14 Using the control panel............................ 15 Understanding the status of the power button and indicator light............15 Setting up and using the home screen applications......
Page 3 Contents Loading paper and specialty media............27 Setting the size and type of the specialty media..................27 Conﬁguring Universal paper settings......................27 Loading trays..............................27 Loading the multipurpose feeder......................... 29 Linking trays................................30 Paper support....................31 Supported paper sizes............................31 Supported paper types............................ 33 Supported paper weights..........................33 Printing......................34 Printing from a computer..........................34...
Page 4 Contents E-mailing...................... 43 Using the automatic document feeder and scanner glass..............43 Setting up the e‑mail function........................43 Conﬁguring e‑mail settings..........................43 Sending an e-mail..............................44 Creating an e-mail shortcut..........................44 Faxing......................45 Setting up the printer to fax..........................45 Using the automatic document feeder and scanner glass..............51 Sending a fax...............................51 Scheduling a fax..............................
Page 5 Contents FTP..................................105 USB Drive................................110 Network/Ports..............................116 Security................................129 Reports................................137 Help..................................138 Troubleshooting............................... 138 Printing the Menu Settings Page......................... 139 Securing the printer..................140 Locating the security slot..........................140 Erasing printer memory..........................140 Erasing printer hard disk memory....................... 140 Encrypting the printer hard disk........................141 Restoring factory default settings.........................141 Statement of Volatility............................
Page 6 Contents Paper jam in the ﬁnisher..........................182 Staple jam in the ﬁnisher..........................184 Troubleshooting..................186 Network connection problems........................186 Hardware options problems......................... 188 Issues with supplies............................190 Paper feed problems............................191 Printing problems.............................194 Faxing problems..............................223 Scanning problems............................226 Contacting customer support........................230 Upgrading and migrating.................231 Hardware................................231 Software................................
Page 7: Safety Information
CAUTION—POTENTIAL INJURY: Only a Lexmark Inline Surge Protector that is properly connected between the printer and the power cord provided with the printer may be used with this product. The use of non-Lexmark surge protection devices may result in a risk of ﬁre, property damage, or poor printer performance.
Page 8 Make sure that there is adequate clearance around the printer. CAUTION—TIPPING HAZARD: Installing one or more options on your printer or MFP may require a caster base, furniture, or other feature to prevent instability causing possible injury. For more information on supported conﬁgurations, see www.lexmark.com/multifunctionprinters.
Page 9 Safety information CAUTION—TIPPING HAZARD: To reduce the risk of equipment instability, load each tray separately. Keep all other trays closed until needed. CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.
Page 10: Learning About The Printer
Finding information about the printer What are you looking for? Find it here Initial setup instructions: See the setup documentation that came with the printer or go to http://support.lexmark.com. • Connecting the printer • Installing the printer software More setup and instructions for using the printer: Information Center—Go to...
Page 11: Selecting A Location For The Printer
Learning about the printer What are you looking for? Find it here The latest supplemental information, updates, and customer Go to http://support.lexmark.com. support: Note: Select your country or region, and then • Documentation select your product to view the appropriate support site.
Page 12 Learning about the printer • Make sure that airﬂow in the room meets the latest revision of the ASHRAE 62 standard or the CEN Technical Committee 156 standard. • Provide a ﬂat, sturdy, and stable surface. • Keep the printer: –...
Page 13: Printer Configurations
CAUTION—TIPPING HAZARD: Installing one or more options on your printer or MFP may require a caster base, furniture, or other feature to prevent instability causing possible injury. For more information on supported conﬁgurations, see www.lexmark.com/multifunctionprinters. CAUTION—TIPPING HAZARD: To reduce the risk of equipment instability, load each tray separately.
Page 14: Attaching Cables
Learning about the printer Attaching cables CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, do not set up this product or make any electrical or cabling connections, such as the power cord, fax feature, or telephone, during a lightning storm. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 15: Using The Control Panel
Learning about the printer Using the control panel Use the Display • View printer messages and supply status. • Set up and operate the printer. Home button Go to the home screen. Power button Turn on or turn off the printer. Note: To turn off the printer, press and hold the power button for ﬁve seconds.
Page 16 Learning about the printer Indicator light Printer status The printer requires user intervention. Power button light Printer status The printer is off, ready, or processing data. Solid amber The printer is in Sleep mode. Blinking amber The printer is in Hibernate mode.
Page 17: Setting Up And Using The Home Screen Applications
Setting up and using the home screen applications Setting up and using the home screen applications Note: These applications are supported only in some printer models. Using the home screen Note: Your home screen may vary depending on your home screen customization settings, administrative setup, and active embedded solutions.
Page 18: Customizing The Home Screen
Setting up and using the home screen applications Touch Shortcut Center Organize all shortcuts. App Proﬁles Access application proﬁles. Scan Proﬁles Scan and save documents directly to the computer. Scan and save documents directly to an FTP server. Bookmarks Organize all bookmarks. Change Language Change the language on the display.
Page 19: Creating A Shortcut
Setting up and using the home screen applications Creating a shortcut From the home screen, touch Shortcut Center. Note: The icon and name may have been changed. For more information, contact your administrator. Select a printer function, and then touch Create Shortcut. Note: The Secure E‑mail function is not supported.
Page 20: Configuring Eco-Settings
Setting up and using the home screen applications Conﬁguring Eco‑Settings From the home screen, touch Eco‑Settings. Conﬁgure Eco‑Mode or Schedule Power Modes. Apply the changes. Using Customer Support From the home screen, touch Customer Support. Print or e‑mail the information. Note: For information on conﬁguring the application settings, see the Customer Support Administrator’s Guide.
Page 21: Setting Up Device Quotas
Touch Create, and then take note of the authorization code. Note: The authorization code is valid only for 24 hours. Open a web browser, and then go to https://lexmark.cloud-connect.co. Click Next, and then accept the Terms of Use. Enter the authorization code, and then click Connect.
Page 22: Managing Bookmarks
Setting up and using the home screen applications Managing bookmarks Creating bookmarks Use bookmarks to print frequently accessed documents that are stored in servers or on the web. Open a web browser, and then type the printer IP address in the address ﬁeld. Notes: •...
Page 23: Managing Contacts
Setting up and using the home screen applications Notes: • You can create folders or bookmarks inside a folder. To create a bookmark, see “Creating bookmarks” on page • To manage folders, click Bookmark Setup. Managing contacts Adding contacts Open a web browser, and then type the printer IP address in the address ﬁeld. Notes: •...
Page 24 Setting up and using the home screen applications • If you are using a proxy server, then temporarily disable it to load the web page correctly. Click Address Book. Do either of the following: • From the Contacts section, click a contact name, and then edit the information. •...
Page 25: Setting Up And Using The Accessibility Features
Setting up and using the accessibility features Note: For more information on the accessibility features of your printer model, see the Accessibility Guide at http://support.lexmark.com. Enabling Magniﬁcation mode From the control panel, press and hold the 5 key until you hear a voice message.
Page 26: Adjusting The Voice Guidance Speech Rate
Setting up and using the accessibility features Gesture Function Access parts of the zoomed image that are beyond the limits of the screen. Note: This gesture requires the use of two ﬁngers to drag across a zoomed image. Swipe up then left Exit an application and return to the home screen.
Page 27: Loading Paper And Specialty Media
Loading paper and specialty media Loading paper and specialty media Setting the size and type of the specialty media The trays automatically detect the size of plain paper. For specialty media like labels, card stock, or envelopes, do the following: From the home screen, navigate to: Settings >...
Page 28 Loading paper and specialty media Adjust the paper guides to match the size of the paper that you are loading. Flex, fan, and align the paper edges before loading. Load the paper stack with the printable side facedown, and then make sure that the side guides ﬁt snugly against the paper.
Page 29: Loading The Multipurpose Feeder
Loading paper and specialty media Loading the multipurpose feeder Open the multipurpose feeder. Adjust the guide to match the size of the paper that you are loading. Flex, fan, and align the paper edges before loading. Load paper with the printable side faceup. Notes: •...
Page 30: Linking Trays
Loading paper and specialty media • Load envelopes with the ﬂap facedown on the left side. • Load European envelopes with the ﬂap facedown and entering the printer ﬁrst. Warning—Potential Damage: Do not use envelopes with stamps, clasps, snaps, windows, coated linings, or self‑stick adhesives.
Page 31: Paper Support
Paper support Paper support Supported paper sizes Paper size Tray Multipurpose Two‑sided Scanner glass feeder printing 210 x 297 mm (8.3 x 11.7 in.) 210 x 148 mm (8.3 x 5.8 in.) A5 LEF* 148 x 210 mm (5.8 x 8.3 in.) 105 x 148 mm (4.1 x 5.8 in.) JIS B5...
Page 32 Paper support Paper size Tray Multipurpose Two‑sided Scanner glass feeder printing Legal 216 x 356 mm (8.5 x 14 in.) Folio 216 x 330 mm (8.5 x 13 in.) Universal 76.2 x 127 mm to 216 x 356 mm (3 x 5 in. to 8.5 x 14 in.) 7 3/4 Envelope (Monarch) 98 x 191 mm...
Page 33: Supported Paper Types
Paper support Supported paper types Paper type Tray Multipurpose Two‑sided Scanner glass feeder printing Plain paper Card stock Transparency Recycled Paper labels Bond Letterhead Preprinted Colored Paper Light Paper Heavy Paper Rough/Cotton Envelope Rough envelope One‑sided paper labels designed for laser printers are supported for occasional use. It is recommended to print 20 or fewer pages of paper labels per month.
Page 34: Printing
Printing from a mobile device using Lexmark Mobile Print Lexmark Mobile Print allows you to send documents and images directly to a supported Lexmark printer. Open the document, and then send or share the document to Lexmark Mobile Print. Note: Some third‑party applications may not support the send or share feature. For more information, see the documentation that came with the application.
Page 35: Printing From A Flash Drive
Printing Printing from a mobile device using AirPrint AirPrint is a mobile printing solution that allows you to print directly from Apple devices to an AirPrint‑certiﬁed printer. Note: This application is supported only in some Apple devices. From the home screen of your mobile device, launch a compatible application. Select an item to print, and then tap the share icon.
Page 36: Supported Flash Drives And File Types
Printing Supported ﬂash drives and ﬁle types Flash drives • Lexar JumpDrive S70 (16GB and 32GB) • SanDisk Cruzer (16GB and 32GB) • PNY Attache (16GB and 32GB) Notes: – The printer supports high‑speed USB ﬂash drives with full‑speed standard. –...
Page 37: Configuring Confidential Jobs
Printing Conﬁguring conﬁdential jobs From the control panel, navigate to: Settings > Security > Conﬁdential Print Setup Conﬁgure the settings. Max Invalid PIN Set the number of times an invalid PIN can be entered. Note: When the limit is reached, the print jobs for that user name are deleted. Conﬁdential Job Set the expiration time for conﬁdential print jobs.
Page 38: Printing From A Cloud Connector Profile
Printing From the printer home screen, release the print job. • For conﬁdential print jobs, navigate to: Held jobs > select your user name > Conﬁdential > enter the PIN > select the print job > conﬁgure the settings > Print •...
Page 39: Canceling A Print Job
Printing Canceling a print job From the printer control panel From the home screen, touch Job Queue. Note: You can also access this setting by touching the top section of the home screen. Select the job to cancel. From the computer Depending on the operating system, do either of the following: •...
Page 40: Copying
Copying Copying Using the automatic document feeder and scanner glass Automatic document feeder (ADF) Scanner glass • Use the ADF for multiple‑page or two-sided documents. • Load an original document faceup. For multiple‑page documents, make sure to align the leading edge before loading.
Page 41: Copying On Letterhead
Copying Copying on letterhead Load an original document into the ADF tray or on the scanner glass. From the home screen, touch Copy > Copy From > select the size of the original document. Touch Copy To, and then select the paper source that contains the letterhead. If you loaded the letterhead into the multipurpose feeder, then navigate to: Copy To >...
Page 42: Copying Multiple Pages Onto A Single Sheet
Copying Copying multiple pages onto a single sheet Load an original document into the ADF tray or on the scanner glass. From the home screen, touch Copy > Pages per Side. Adjust the settings. Copy the document. Creating a copy shortcut Note: You may need administrative rights to create a shortcut.
Page 43: E-Mailing
E-mailing E-mailing Using the automatic document feeder and scanner glass Automatic document feeder (ADF) Scanner glass • Use the ADF for multiple‑page or two-sided documents. • Load an original document faceup. For multiple‑page documents, make sure to align the leading edge before loading.
Page 44: Sending An E-Mail
E-mailing Enter the needed information. Apply the changes. Sending an e-mail Using the control panel Load an original document into the ADF tray or on the scanner glass. From the home screen, touch E-mail, and then enter the needed information. Note: You can also enter the recipient using the address book or shortcut number.
Page 45: Faxing
Faxing Faxing Setting up the printer to fax Notes: • The following connection methods are applicable only in some countries or regions. • During the initial printer setup, clear the fax function check box and any other function you plan to set up later, and then touch Continue.
Page 46 Faxing CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, do not use the fax feature during a lightning storm. CAUTION—POTENTIAL INJURY: To reduce the risk of ﬁre, use only a 26 AWG or larger telecommunications (RJ-11) cord when connecting this product to the public switched telephone network.
Page 47 Faxing Connected to different wall jacks Connect one end of the telephone cable to the line port of the printer. Connect the other end of the cable to an active analog wall jack. Notes: • If you have only one telephone number on your line, then set the printer to receive faxes automatically. •...
Page 48 There may be an adapter plug installed in the telephone port of the printer. Do not remove the adapter plug from the telephone port of the printer if you are connecting to a serial or cascaded telephone system. Part name Part number Lexmark adapter plug 40X8519...
Page 49 Faxing Connecting the printer to a non‑RJ11 wall jack Connect one end of the telephone cable to the line port of the printer. Connect the other end of the cable to the RJ11 adapter, and then connect the adapter to the wall jack. If you want to connect another device with a non‑RJ11 connector to the same wall jack, then connect it directly to the telephone adapter.
Page 50 Faxing Connecting the printer to a wall jack in Germany The German wall jack has two kinds of ports. The N ports are for fax machines, modems, and answering machines. The F port is for telephones. Connect the printer to any of the N ports. Connect one end of the telephone cable to the line port of the printer.
Page 51: Using The Automatic Document Feeder And Scanner Glass
Faxing Setting the fax date and time From the home screen, touch Settings > Device > Preferences > Date and Time > Conﬁgure. Conﬁgure the settings. Conﬁguring daylight saving time From the home screen, touch Settings > Device > Preferences > Date and Time > Conﬁgure. In the Time Zone menu, select Custom.
Page 52: Scheduling A Fax
Faxing For Windows users With a document open, click File > Print. Select the printer, and then click Properties, Preferences, Options, or Setup. Click Fax > Enable fax, and then enter the recipient number. If necessary, conﬁgure other fax settings. Send the fax job.
Page 53: Adjusting The Fax Darkness
Faxing In the Resolution menu, select a setting. Fax the document. Adjusting the fax darkness Load an original document into the ADF tray or on the scanner glass. From the home screen, touch Fax, and then enter the needed information. Adjust the Darkness setting.
Page 54: Scanning
Scanning Scanning Using the automatic document feeder and scanner glass Automatic document feeder (ADF) Scanner glass • Use the ADF for multiple‑page or two-sided documents. • Load an original document faceup. For multiple‑page documents, make sure to align the leading edge before loading.
Page 55: Scanning To A Flash Drive
Scanning Scanning to a ﬂash drive Load an original document into the ADF tray or on the scanner glass. Insert the ﬂash drive. Select Scan to USB and adjust the settings if necessary. Note: If the USB Drive screen does not appear, then select USB Drive on the control panel. Scan the document.
Page 56: Sending Scanned Documents To A Computer
Scanning Sending scanned documents to a computer Load an original document into the ADF tray or on the scanner glass. From the home screen, touch Scan Proﬁles > Scan To Computer. Select the scan proﬁle where you want to save the document. Scanning to a Cloud Connector proﬁle Load the document into the ADF tray or on the scanner glass.
Page 57: Understanding The Printer Menus
• Remote Operator Panel Restore Factory Defaults • • Notiﬁcations Maintenance • • Power Management Visible Home Screen Icons • • Information Sent to Lexmark About This Printer Print • • Layout • • Finishing PostScript • • Setup •...
Page 58: Device
Understanding the printer menus Help • • Print All Guides Information Guide • • Connection Guide Media Guide • • Copy Guide Mono Quality Guide • • E‑mail Guide Moving Guide • • Fax Guide Print Quality Guide • • FTP Guide Supplies Guide Troubleshooting...
Page 59 Understanding the printer menus Menu item Description Date and Time Conﬁgure the settings for Network Time Protocol (NTP). Network Time Protocol Notes: Enable NTP [On*] • Enable Authentication appears only in some printer NTP Server models. Enable Authentication • When Enable Authentication is set to MD5 key, Key ID and Password appear.
Page 60 Understanding the printer menus Remote Operator Panel Menu item Description External VNC Connection Connect an external Virtual Network Computing (VNC) client to the remote control panel. Don’t Allow* Allow Authentication Type Set the authentication type when accessing the VNC client server.
Page 61 Understanding the printer menus Menu item Description E‑mail Alerts Setup Conﬁgure the printer to send e‑mail alerts to a list of contacts when the printer requires user intervention. Error Prevention Set the printer to ﬂush automatically blank pages or pages with partial prints after a jammed page is cleared.
Page 62 Understanding the printer menus Menu item Description Jam Content Recovery Set the printer to reprint jammed pages. Jam Recovery Auto* Jam Content Recovery Specify how to restart a scan job after resolving a paper jam. Scanner Jam Recovery Job level Page level* Note: An asterisk (*) next to a value indicates the factory default setting.
Page 63 Send printer usage and performance information to Lexmark. Save Note: Information Send Time appears only when you select any of Supplies and Page Usage (Anonymous) the settings in Information Sent to Lexmark, except None of the Above. Device Performance (Anonymous) None of the Above*...
Page 64 Understanding the printer menus Menu item Description Headphone Volume Adjust the headphone volume. 1–10 (5*) Note: This menu item appears only when a headphone is attached to the printer. Enable Voice Guidance When Enable Voice Guidance when a headphone is attached to the printer. Headphone Is Attached Off* Speak Passwords/PINs...
Page 65 Understanding the printer menus Maintenance Conﬁguration Menu Menu item Description USB Conﬁguration Change the USB driver mode of the printer to improve its compatibility with a personal computer. USB PnP USB Conﬁguration Set whether the USB device driver enumerates as a USB Simple device (single interface) or as a USB Composite device USB Scan to Local (multiple interfaces).
Page 66 Understanding the printer menus Menu item Description Tray Conﬁguration Set the printer to resolve paper- or envelope-related change prompts. Action for Prompts Prompt user* Continue Use current Reports Print reports about printer menu settings, status, and event logs. Menu Settings Page Event Log Event Log Summary Supply Usage And Counters...
Page 67 Understanding the printer menus Menu item Description Device Operations Set the printer to operate in a special mode, in which it attempts to continue offering as much functionality as possible, despite Safe Mode known issues. Off* For example, when set to On and the duplex motor is nonfunctional, the printer performs one‑sided printing for a two‑sided print job.
Page 68 Understanding the printer menus Menu item Description Scanner Conﬁguration Print a test page that shows the scanner margin settings. Scanner Manual Registration Print Quick Test Scanner Conﬁguration Determine the byte order of a TIFF‑formatted scan output. Tiff Byte Order CPU Endianness* Little Endian Big Endian Scanner Conﬁguration...
Page 69: Print
Understanding the printer menus Visible Home Screen Icons Menu Description Visible Home Screen Icons Specify which icons to show on the home screen. Copy Note: The icons may vary depending on your home screen customization settings, E‑mail administrative setup, and active embedded solutions. Status/Supplies Job Queue Change Language...
Page 70 Understanding the printer menus Menu item Description Blank Pages Print blank pages that are included in a print job. Print Do Not Print* Collate Keep the pages of a print job stacked in sequence, particularly when printing multiple copies of the job. Off [1,1,1,2,2,2]* On [1,2,1,2,1,2] Separator Sheets...
Page 71 Understanding the printer menus Finishing Menu item Description Staple Job Specify the staple position for all print jobs. Off* Note: This menu item appears only when a staple ﬁnisher is installed. 1 staple, top left corner 2 staples, left 1 staple, top right corner 2 staples, top 1 staple, bottom left corner 2 staples, bottom...
Page 72 Understanding the printer menus Menu item Description Job Waiting Preserve print jobs requiring supplies so that jobs not requiring the missing supplies can print. Off* Note: This menu item appears only when a printer hard disk is installed. Job Hold Timeout Set the time in seconds that the printer waits for user intervention before it holds jobs that require unavailable resources and continues to print other 0–255 (30*)
Page 73 Understanding the printer menus Menu item Description Toner Darkness Determine the lightness or darkness of text images. 1–10 (8*) Halftone Enhance the printed output to have smoother lines with sharper edges. Normal* Detail Brightness Adjust the brightness of the printed output. ‑6 to 6 (0*) Contrast Adjust the contrast of the printed output.
Page 74 Understanding the printer menus Menu item Description Log Action at Near Full Specify how the printer responds when the hard disk is nearly full. None* Note: The value deﬁned in Log Near Full Level determines when this action E‑mail Current Log is triggered.
Page 75 Understanding the printer menus Menu item Description Scale to Fit Scale the page content to ﬁt the selected paper size. Off* Annotations Specify whether to print annotations in the PDF. Do Not Print* Print Note: An asterisk (*) next to a value indicates the factory default setting. PostScript Menu item Description...
Page 76 Understanding the printer menus Menu item Description Font Source Choose the source which contains the default font selection. Resident* Notes: Disk • Flash and Disk appear only in some printer models. Download • For Flash and Disk to appear, make sure that they are not read‑ or Flash write‑protected.
Page 77 Understanding the printer menus Menu item Description Auto LF after CR Set the printer to perform a line feed after a carriage return control command. Off* Tray Renumber Conﬁgure the printer to work with print drivers or applications that use different source assignments for the paper source.
Page 78 Understanding the printer menus Menu item Description Orientation Set the page orientation for HTML documents. Portrait* Landscape Margin Size Set the page margin for HTML documents. 8–255 mm (19*) Backgrounds Print background information or graphics for HTML documents. Do Not Print Print* Note: An asterisk (*) next to a value indicates the factory default setting.
Page 79: Paper
Understanding the printer menus Paper Tray Conﬁguration Menu item Description Default Source Set the paper source for all print jobs. Tray [x] (1*) Note: Multipurpose Feeder appears only when Conﬁgure MP is set to Multipurpose Feeder Cassette. Manual Paper Manual Envelope Paper Size/Type Specify the paper size or paper type loaded in each paper source.
Page 80 Understanding the printer menus Media Conﬁguration Universal Setup Menu item Description Units of Measure Specify the unit of measurement for the universal paper. Inches Note: Inches is the U.S. factory default setting. Millimeters is the Millimeters international factory default setting. Portrait Width Set the portrait width of the universal paper.
Page 81: Copy
Understanding the printer menus Media Types Menu item Description Plain Specify the texture and weight of the paper loaded. Card Stock Select from the following options: Transparency Paper Texture Recycled Smooth Labels Normal* Bond Rough Envelope Paper Weight Rough Envelope Light Letterhead Normal*...
Page 82 Understanding the printer menus Menu item Description Sides Specify the scanning behavior based on the original document. 1 sided to 1 sided* 1 sided to 2 sided 2 sided to 1 sided 2 sided to 2 sided Separator Sheets Specify whether to insert blank separator sheets when printing. None* Between Copies Between Jobs...
Page 83 Understanding the printer menus Menu item Description Header/Footer Apply a header or footer on the printed output. Top left Top middle Top right Bottom left Bottom middle Bottom right Overlay Specify the overlay text printed on each page of the copy job. Conﬁdential Copy Draft...
Page 84 Understanding the printer menus Menu item Description Background Removal Adjust the amount of background visible on a scanned image. Background Detection Level Auto Center Align the content at the center of the page. Off* Mirror Image Create a mirror image of the original document. Off* Negative Image Create a negative image of the original document.
Page 85: Fax
Understanding the printer menus Fax Mode Menu item Description Fax Mode Select a fax mode. Analog* Fax Server Disabled Note: An asterisk (*) next to a value indicates the factory default setting. Analog Fax Setup General Fax Settings Menu item Description Fax Name Identify your fax machine.
Page 86 Understanding the printer menus Menu item Description Caller ID Show the telephone number of the person sending the fax. Alternate Fax Number Masking Specify the format for masking an outgoing fax number. Off* From Left From Right Digits to Mask Specify the number of digits to mask in an outgoing fax number.
Page 87 Understanding the printer menus Menu item Description Orientation Specify the orientation of the original document. Portrait* Landscape Sides Specify the page orientation of text and graphics when scanning a two‑sided document. Off* Long Edge Short Edge Content Type Improve the output result based on the content of the original document. Text* Text/Photo Photo...
Page 88 Understanding the printer menus Menu item Description Color Dropout Specify which color to drop during scanning, and adjust the dropout setting for that color. None* Green Blue Default Red Threshold 0–255 (128*) Default Green Threshold 0–255 (128*) Default Blue Threshold 0–255 (128*) Contrast Set the contrast of the output.
Page 89 Understanding the printer menus Admin Controls Menu item Description Automatic Redial Adjust the number of redial attempts based on the activity levels of recipient fax machines. 0–9 (5*) Redial Frequency Increase the time between redial attempts to increase the chance of sending fax successfully.
Page 90 Understanding the printer menus Menu item Description Conﬁrm Fax Number Ask the user to conﬁrm the fax number. Off* Dial Preﬁx Set a dialing preﬁx. Dialing Preﬁx Rules Establish a dialing preﬁx rule. Preﬁx Rule [x] Note: An asterisk (*) next to a value indicates the factory default setting. Fax Receive Settings Menu item Description...
Page 91 Understanding the printer menus Menu item Description Fax Footer Time Stamp Print the time stamp at the bottom of each page from a received fax. Receive* Print Holding Faxes Hold received faxes from printing until they are released. Held Fax Mode Off* Always On Manual...
Page 92 Understanding the printer menus Menu item Description Manual Answer Code Manually enter a code on the telephone number pad to begin receiving fax. 0–9 (9*) Notes: • This menu item appears only when the printer shares a line with a telephone.
Page 93 Understanding the printer menus Fax Cover Page Menu item Description Fax Cover Page Conﬁgure the settings for the fax cover page. Off by Default* On by Default Never Use Always Use Include To ﬁeld Off* Include From ﬁeld Off* From Include Message Field Off* Message:...
Page 94 Understanding the printer menus Menu item Description Receive Error Log Print a log for fax‑receive failures. Print Never* Print on Error Auto Print Logs Print all fax activity. Log Paper Source Specify the paper source for printing logs. Tray [x] (1*) Multipurpose Feeder Logs Display Identify the sender by remote fax name or fax number.
Page 95 Understanding the printer menus Fax Server Setup General Fax Settings Menu item Description To Format Specify a fax recipient. Note: If you want to use the fax number, then type the number sign (#) before a number. Reply Address Specify a reply address for sending fax. Subject Specify the fax subject and message.
Page 96 Understanding the printer menus Menu item Description Require Trusted Certiﬁcate Specify a trusted certiﬁcate when accessing the SMTP server. SMTP Server Authentication Set the authentication type for the SMTP server. No authentication required* Login / Plain NTLM CRAM‑MD5 Digest‑MD5 Kerberos 5 Device‑Initiated E‑mail Specify whether credentials are required for device‑initiated e‑mail.
Page 97 Understanding the printer menus Fax Server Scan Settings Menu item Description Image Format Specify the ﬁle format for the scanned image. TIFF (.tif) PDF (.pdf)* XPS (.xps) TXT (.txt) RTF (.rtf) DOCX (.docx) Content Type Improve the output result based on the content of the original document. Text Text/Photo* Photo...
Page 98: E-Mail
Understanding the printer menus E-mail E‑mail Setup Menu item Description Primary SMTP Gateway Type the IP address or host name of the primary SMTP server for sending e- mail. Primary SMTP Gateway Port Enter the port number of the primary SMTP server. 1–65535 (25*) Secondary SMTP Gateway Type the server IP address or host name of your secondary or backup SMTP...
Page 99 Understanding the printer menus Menu item Description User‑Initiated E‑mail Specify whether credentials are required for user‑initiated e‑mail. None* Use Device SMTP Credentials Use Session User ID and Password Use Session E‑mail address and Password Prompt user Use Active Directory Device Enable user credentials and group designations to connect to the SMTP server.
Page 100 Understanding the printer menus Menu item Description Global OCR Settings Conﬁgure the settings for optical character recognition (OCR). Recognized Languages Note: This menu item appears only if you have purchased and installed an Auto Rotate OCR solution. Despeckle Auto Contrast Enhance PDF Settings Set the PDF format of the scanned image.
Page 101 Understanding the printer menus Menu item Description Color Specify the color when scanning an image. Black and White Gray Color* Auto Resolution Set the resolution of the scanned image. 75 dpi 150 dpi* 200 dpi 300 dpi 400 dpi 600 dpi Darkness Adjust the darkness of the scanned image.
Page 102 Understanding the printer menus Menu item Description Color Dropout Specify which color to drop during scanning, and adjust the dropout setting for that color. Color Dropout None* Green Blue Default Red Threshold 0–255 (128*) Default Green Threshold 0–255 (128*) Default Blue Threshold 0–255 (128*) Auto Color Detect Set the amount of color that the printer detects from the original document.
Page 103 Understanding the printer menus Menu item Description Negative Image Create a negative image of the original document. Off* Shadow Detail Adjust the amount of shadow detail visible on a scanned image. ‑4 to 4 (0*) Scan Edge to Edge Allow edge‑to‑edge scanning of the original document. Off* Sharpness Adjust the sharpness of a scanned image.
Page 104 Understanding the printer menus Menu item Description Use Multi‑Page TIFF Choose between single- and multiple‑page TIFF ﬁles. TIFF Compression Set a compression option for TIFF ﬁles. LZW* JPEG Text Default Set the quality of text on a scanned image. 5–95 (75*) Text/Photo Default Set the quality of text or photo on a scanned image.
Page 105: Ftp
Understanding the printer menus Web Link Setup Menu item Description Server Set the printer to send e‑mail as a web link. Login Password Path File Name Web Link FTP Defaults Menu item Description Format Specify the ﬁle format for the scanned image. PDF (.pdf)* Note: The menu items may vary depending on your printer model.
Page 106 Understanding the printer menus Menu item Description PDF Settings Set the PDF format for the scanned image. PDF Version 1.5* Archival Version A‑1a* A‑1b Highly Compressed Off* Secure Off* Searchable Off* Archival (PDF/A) Off* Content Type Improve the output result based on the content of the original document. Text Text/Photo* Graphics...
Page 107 Understanding the printer menus Menu item Description Resolution Set the resolution of the scanned image. 75 dpi 150 dpi* 200 dpi 300 dpi 400 dpi 600 dpi Darkness Adjust the darkness of the scanned image. -4 to 4 (0*) Orientation Specify the orientation of text and graphics on the page.
Page 108 Understanding the printer menus Menu item Description Color Dropout Specify which color to drop during scanning, and adjust the dropout setting for that color. Color Dropout None* Green Blue Default Red Threshold 0–255 (128*) Default Green Threshold 0–255 (128*) Default Blue Threshold 0–255 (128*) Auto Color Detect Set the amount of color that the printer detects from the original document.
Page 109 Understanding the printer menus Menu item Description Negative Image Create a negative image of the original document. Off* Shadow Detail Adjust the amount of shadow detail visible on a scanned image. ‑4 to 4 (0*) Scan Edge to Edge Allow edge‑to‑edge scanning of the original document. Off* Sharpness Adjust the sharpness of a scanned image.
Page 110: Usb Drive
Understanding the printer menus Menu item Description Custom Job Scanning Turn on scanning of custom jobs by default. Off* Note: This menu item appears only when a hard disk is installed. Scan Preview Show a preview of the scan on the display. Note: This menu item appears only when a hard disk is installed.
Page 111 Understanding the printer menus Menu item Description PDF Settings Set the PDF format for the scanned image. PDF Version 1.5* Archival Version A‑1a* A‑1b Highly Compressed Off* Secure Off* Searchable Off* Archival (PDF/A) Off* Content Type Improve the output result based on the content of the original document. Text Text/Photo* Graphics...
Page 112 Understanding the printer menus Menu item Description Resolution Set the resolution of the scanned image. 75 dpi 150 dpi* 200 dpi 300 dpi 400 dpi 600 dpi Darkness Adjust the darkness of the scanned image. 1–9 (5*) Orientation Specify the orientation of text and graphics on the page. Portrait* Landscape Original Size...
Page 113 Understanding the printer menus Menu item Description Color Dropout Specify which color to drop during scanning, and adjust the dropout setting for that color. Color Dropout None* Green Blue Default Red Threshold 0–255 (128*) Default Green Threshold 0–255 (128*) Default Blue Threshold 0–255 (128*) Auto Color Detect Set the amount of color that the printer detects from the original document.
Page 114 Understanding the printer menus Menu item Description Negative Image Create a negative image of the original document. Off* Shadow Detail Adjust the amount of shadow detail visible on a scanned image. ‑4 to 4 (0*) Scan Edge to Edge Allow edge‑to‑edge scanning of the original document. Off* Sharpness Adjust the sharpness of a scanned image.
Page 115 Understanding the printer menus Flash Drive Print Menu item Description Number of Copies Set the number of copies. 1–9999 (1*) Paper Source Specify the paper source for the print job. Tray [x] (1*) Multipurpose Feeder Manual Paper Manual Envelope Collate Print multiple copies in a sequence.
Page 116: Network/Ports
Understanding the printer menus Menu item Description Separator Sheets Specify whether to insert blank separator sheets when printing. Off* Between Copies Between Jobs Between Pages Separator Sheet Source Specify the paper source for the separator sheet. Tray [x] (1*) Note: For Multipurpose Feeder to appear, set Conﬁgure MP to Cassette from the Multipurpose Feeder Paper menu.
Page 117 Menu item Description Setup Using Mobile App Conﬁgure the Wi‑Fi connection using Lexmark Mobile Assistant. Setup On Printer Panel Conﬁgure the Wi‑Fi connection using the control panel. Choose Network Note: 802.1x - RADIUS can be conﬁgured only from the Embedded Add Wi‑Fi Network...
Page 118 Understanding the printer menus Menu item Description Wireless Security Mode Set the security mode for connecting the printer to Wi‑Fi devices. Disabled* Note: 802.1x - RADIUS can be conﬁgured only from the Embedded Web Server. WPA2/WPA-Personal WPA2-Personal 802.1x - RADIUS WEP Authentication Mode Set the type of Wireless Encryption Protocol (WEP) for the printer.
Page 119 Understanding the printer menus Menu item Description IPv6 Enable and conﬁgure IPv6 settings in the printer. Enable IPv6 Enable DHCPv6 Off* Stateless Address Autoconﬁguration DNS Server Address Manually Assigned IPv6 Address Manually Assigned IPv6 Router Address Preﬁx All IPv6 Addresses All IPv6 Router Addresses Network Address View the network addresses.
Page 120 Understanding the printer menus Menu item Description IPv4 Enable Dynamic Host Conﬁguration Protocol (DHCP). Enable DHCP Note: DHCP is a standard protocol that allows a server to dynamically distribute IP addressing and conﬁguration information to clients. IPv4 Set the static IP address of your printer. Set Static IP Address IP Address Netmask...
Page 121 Understanding the printer menus Menu item Description Mac Binary PS Set the printer to process Macintosh binary PostScript print jobs. Auto* Notes: • On processes raw binary PostScript print jobs. • Off ﬁlters print jobs using the standard protocol. Energy Efficient Ethernet Reduce power consumption when the printer receives no data from the Ethernet network.
Page 122 Understanding the printer menus Menu item Description Enable mDNS Update multicast DNS settings. WINS Server Address Specify a server address for Windows Internet Name Service (WINS). Enable BOOTP Allow the BOOTP to assign a printer IP address. Off* Restricted Server List Specify an IP address for the TCP connections.
Page 123 Understanding the printer menus Menu item Description SNMP Versions 1 and 2c Conﬁgure Simple Network Management Protocol (SNMP) versions 1 and 2c to install print drivers and applications. Enabled Allow SNMP Set Enable PPM MIB SNMP Community SNMP Version 3 Conﬁgure SNMP version 3 to install and update printer security.
Page 124 Understanding the printer menus Menu item Description Base Conﬁguration Set the IPSec base conﬁguration. Default* Note: This menu item appears only when Enable IPSec is set to Compatibility Secure DH (Diffie‑Hellman) Group Proposal Set the IPSec encryption. modp2048 (14)* Note: This menu item appears only when Base Conﬁguration is set modp3072 (15) to Compatibility.
Page 125 Understanding the printer menus 802.1x Note: This menu appears only in network printers or printers that are attached to print servers. Menu item Description Active Let the printer join networks that require authentication before allowing access. Off* Note: To conﬁgure the settings of this menu item, access the Embedded Web Server.
Page 126 Understanding the printer menus Menu item Description Enable FTP/TFTP Send ﬁles using FTP. Local Domains Specify domain names for HTTP and FTP servers. Note: This menu item appears only in some printer models. HTTP Proxy IP Address Conﬁgure the HTTP and FTP server settings. Note: These menu items appear only in some printer models.
Page 127 Understanding the printer menus Menu item Description PCL SmartSwitch Set the printer to switch to PCL emulation when a print job received through a USB port requires it, regardless of the default printer language. Note: If PCL SmartSwitch is off, then the printer does not examine incoming data and uses the default printer language speciﬁed in the Setup menu.
Page 128 Understanding the printer menus Menu item Description Options Enable the Always Print As Image feature. Always Print As Image Off* Note: An asterisk (*) next to a value indicates the factory default setting. Wi‑Fi Direct Note: This menu appears only when a direct Wi‑Fi network is the active network. Menu item Description SSID...
Page 129: Security
Understanding the printer menus Security Login Methods Manage Permissions Menu item Description Function Access Control access to the printer functions. Access Address Book in Apps Modify Address Book Manage Shortcuts Create Proﬁles Manage Bookmarks Flash Drive Print Flash Drive Scan Copy Function Color Dropout E‑mail Function...
Page 130 Understanding the printer menus Menu item Description Apps Control access to printer applications. New Apps Slideshow Change Wallpaper Screen Saver Card Copy Scan Center Scan Center Custom 1 Scan Center Custom 2 Scan Center Custom 3 Scan Center Custom 4 Scan Center Custom 5 Scan Center Custom 6 Scan Center Custom 7...
Page 131 Understanding the printer menus Menu item Description Add User Create local accounts to manage access to the printer functions. User Name/Password User Name Password User Name/Password Accounts Add User User Name Accounts Add User Password Accounts Add User PIN Accounts Add User Schedule USB Devices Menu item...
Page 132 Understanding the printer menus Menu item Description Remote Syslog Facility Specify a facility code that the printer uses when sending log events to a remote 0 ‑ Kernel Messages server. 1 ‑ User‑Level Messages 2 ‑ Mail System 3 ‑ System Daemons 4 ‑...
Page 133 Understanding the printer menus Menu item Description E‑mail Log Cleared Alert Send e‑mail notiﬁcation to the administrator when a log entry is deleted. Off* E‑mail Log Wrapped Alert Send e‑mail notiﬁcation to the administrator when the log becomes full and begins to overwrite the oldest entries.
Page 134 Understanding the printer menus Login Restrictions Menu item Description Login failures Specify the number of failed login attempts before the user gets locked out. 1–10 (3*) Failure time frame Specify the time frame between failed login attempts before the user gets locked out. 1–60 minutes (5*) Lockout time Specify the lockout duration.
Page 135 Understanding the printer menus Menu item Description Reserve Job Expiration Set the expiration time that the printer stores print jobs for printing later. Off* 1 Hour 4 Hours 24 Hours 1 Week Require All Jobs to be Held Set the printer to hold all print jobs. Off* Keep duplicate documents Set the printer to print other documents with the same ﬁle name without overwriting...
Page 136 Understanding the printer menus Solutions LDAP Settings Follow LDAP Referrals Search the different servers in the domain for the logged-in user account. Off* LDAP Certiﬁcate Veriﬁcation Enable veriﬁcation of LDAP certiﬁcates. Mobile Services Management AirPrint Enable functions in the AirPrint software feature. Print Scan Miscellaneous...
Page 137: Reports
Understanding the printer menus Reports Menu Settings Page Menu item Description Menu Settings Page Print a report that contains the printer preferences, settings, and conﬁgurations. Device Menu item Description Device Information Print a report that contains information about the printer. Device Statistics Print a report about printer usage and supply status.
Page 138: Help
Understanding the printer menus Menu item Description Fax Call Log Print a report about the last 100 attempted, received, and blocked calls. Note: This menu item appears only when Enable Job Log is set to On. Network Menu item Description Network Setup Page Print a page that shows the conﬁgured network and wireless settings on the printer.
Page 139: Printing The Menu Settings Page
Understanding the printer menus Printing the Menu Settings Page From the home screen, touch Settings > Reports > Menu Settings Page.
Page 140: Securing The Printer
Securing the printer Securing the printer Locating the security slot The printer is equipped with a security lock feature. Attach a security lock compatible with most laptop computers in the location shown to secure the printer in place. Erasing printer memory To erase volatile memory or buffered data in your printer, turn off the printer.
Page 141: Encrypting The Printer Hard Disk
Securing the printer Encrypting the printer hard disk This process erases all contents in the hard disk. If necessary, back up important data from the printer before starting the encryption. From the home screen, touch Settings > Security > Disk Encryption > Start encryption. Follow the instructions on the display.
Page 142 Securing the printer Disposing of a printer hard disk • Degaussing—Flushes the hard disk with a magnetic ﬁeld that erases stored data • Crushing—Physically compresses the hard disk to break component parts and render them unreadable • Milling—Physically shreds the hard disk into small metal bits Note: To guarantee that all data are completely erased, destroy physically each hard disk where data is stored.
Page 143: Maintaining The Printer
Maintaining the printer Maintaining the printer Warning—Potential Damage: Failure to maintain optimum printer performance, or to replace parts and supplies, may cause damage to your printer. Adjusting the speaker volume Adjusting the default internal speaker volume From the control panel, navigate to: Settings >...
Page 144: Networking
Note: For Wi‑Fi‑network‑ready printer models, a prompt for Wi‑Fi network setup appears during initial setup. Using Lexmark Mobile Assistant Depending on your mobile device, download the Lexmark Mobile Assistant application from either the Google Play store or App Store online store.
Page 145 Maintaining the printer Using the personal identiﬁcation number (PIN) method From the control panel, navigate to: Settings > Network/Ports > Wireless > Wi‑Fi Protected Setup > Start PIN Method Copy the eight‑digit WPS PIN. Open a Web browser, and then type the IP address of your access point in the address ﬁeld. Notes: •...
Page 146: Cleaning Printer Parts
Maintaining the printer Cleaning printer parts Cleaning the printer CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock when cleaning the exterior of the printer, unplug the power cord from the electrical outlet and disconnect all cables from the printer before proceeding.
Page 147 Maintaining the printer Using a damp, soft, lint-free cloth, wipe the following areas: • ADF glass • ADF glass pad • Scanner glass...
Page 148 Maintaining the printer • Scanner glass pad Close the scanner cover. Open the ADF cover. Using a damp, soft, lint-free cloth, wipe the following areas: • ADF glass pad in the ADF cover...
Page 149: Ordering Parts And Supplies
Using genuine Lexmark parts and supplies Your Lexmark printer is designed to function best with genuine Lexmark parts and supplies. Use of third-party supplies or parts may affect the performance, reliability, or life of the printer and its imaging components. It can also affect warranty coverage.
Page 150 Ultra high yield 56F1U0E 56F2U0E 56F3U0E 56F4U0E 56F5U0E 56F6U0E Corporate Return Program toner cartridge* * Available only for contract‑managed printers. For more information, contact your Lexmark representative or system administrator. Lexmark MX622 regular toner cartridge Item Worldwide Regular toner cartridge 56F0UA0...
Page 151 Regular imaging unit 56F0ZA0 Corporate Return Program imaging unit* 56F0Z0E * This imaging unit is available only for contract‑managed printers. For more information, contact your Lexmark representative or system administrator. Ordering a maintenance kit Match the maintenance kit to the printer voltage.
Page 152 Maintaining the printer • The maintenance kit includes a fuser, MPF pick roller and separator pad, pick tires, separator roller assembly, and transfer roller. These parts may be individually ordered and replaced if necessary. Item Part number 200K maintenance kit, 100 V 41X1227 200K maintenance kit, 110 V 41X1225...
Page 153: Replacing Parts And Supplies
Maintaining the printer Replacing parts and supplies Replacing the toner cartridge Open door A. Remove the used toner cartridge.
Page 154 Maintaining the printer Unpack the new toner cartridge, and then shake it three times to redistribute the toner. Insert the new toner cartridge. Note: Use the arrows inside the printer as guides. Close door A.
Page 155 Maintaining the printer Replacing the imaging unit Open door A. Remove the toner cartridge. Remove the used imaging unit.
Page 156 Maintaining the printer Unpack the new imaging unit, and then shake it three times to redistribute the toner. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum.
Page 157 Maintaining the printer Close door A. Replacing the staple cartridge Open the stapler access door.
Page 158 Maintaining the printer Remove the staple cartridge. Remove the spare staple cartridge.
Page 159 Maintaining the printer Insert the spare staple cartridge. Note: Replace the spare staple cartridge for future use. Close the stapler access door. Replacing the pick tires Turn off the printer. Unplug the power cord from the electrical outlet, and then from the printer. Remove the tray.
Page 160 Maintaining the printer Remove the used pick tires one after the other. Unpack the new pick tires.
Page 161 Maintaining the printer Insert the new pick tires. Insert the tray. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 162 Maintaining the printer...
Page 163 Maintaining the printer Remove the tray insert, and then ﬂip the tray base. Remove the used pick roller assembly. Unpack the new pick roller assembly.
Page 164 Maintaining the printer Insert the new pick roller assembly. Flip the tray base, and then insert the tray insert.
Page 165 Maintaining the printer Align the printer with the optional tray, and then lower the printer until it clicks into place. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 166 Maintaining the printer Remove the used ADF separator roller. Unpack the new ADF separator roller. Warning—Potential Damage: To avoid damage and poor printer performance, handle this part with clean hands.
Page 167 Maintaining the printer Insert the new ADF separator roller until it clicks into place. Close the ADF cover.
Page 168: Moving The Printer
Make sure that there is adequate clearance around the printer. Note: Damage to the printer caused by improper moving is not covered by the printer warranty. Shipping the printer For shipping instructions, go to http://support.lexmark.com or contact customer support. Saving energy and paper Conﬁguring the power save mode settings Eco‑Mode...
Page 169: Recycling
Recycling Lexmark products To return Lexmark products for recycling: Go to www.lexmark.com/recycle. Select the product you want to recycle. Note: Printer supplies and hardware not listed in the Lexmark Collection and Recycling Program may be recycled through your local recycling center.
Page 170 The foam used in Lexmark packaging is recyclable where foam recycling facilities exist. Facilities may not exist in your area. When you return a cartridge to Lexmark, you can reuse the box that the cartridge came in. Lexmark recycles the box.
Page 171: Clearing Jams
Clearing jams Clearing jams Avoiding jams Load paper properly • Make sure that the paper lies ﬂat in the tray. Correct loading of paper Incorrect loading of paper • Do not load or remove a tray while the printer is printing. •...
Page 172: Identifying Jam Locations
Clearing jams Use recommended paper • Use only recommended paper or specialty media. • Do not load paper that is wrinkled, creased, damp, bent, or curled. • Flex, fan, and align the paper edges before loading. • Do not use paper that has been cut or trimmed by hand. •...
Page 173: Paper Jam In Door A
Clearing jams Jam location Optional staple ﬁnisher Finisher bin Paper jam in door A Remove the tray. Open door A.
Page 174 Clearing jams Remove the toner cartridge. Remove the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum. Doing so may affect the quality of future print jobs.
Page 175 Clearing jams Remove the jammed paper. CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it. Note: Make sure that all paper fragments are removed.
Page 176 Clearing jams Insert the imaging unit. Note: Use the arrows inside the printer as guides.
Page 177: Paper Jam In The Rear Door
Clearing jams Insert the toner cartridge. Note: Use the arrows inside the printer as guides. Close door A. Insert the tray. Paper jam in the rear door Open the rear door. CAUTION—HOT SURFACE: The inside of the printer might be hot. To reduce the risk of injury from a hot component, allow the surface to cool before touching it.
Page 178: Paper Jam In The Standard Bin
Clearing jams Close the rear door. Paper jam in the standard bin Remove the jammed paper. Note: Make sure that all paper fragments are removed.
Page 179: Paper Jam In The Duplex Unit
Clearing jams Paper jam in the duplex unit Remove the tray. Remove the jammed paper. Note: Make sure that all paper fragments are removed. Insert the tray.
Page 180: Paper Jam In Trays
Clearing jams Paper jam in trays Remove the tray. Remove the jammed paper. Note: Make sure that all paper fragments are removed. Insert the tray. Paper jam in the multipurpose feeder Remove paper from the multipurpose feeder. Remove the jammed paper. Note: Make sure that all paper fragments are removed.
Page 181: Paper Jam In The Automatic Document Feeder
Clearing jams Flex, fan, and align the paper edges before loading. Reload paper, and then adjust the paper guide. Paper jam in the automatic document feeder Remove all original documents from the ADF tray. Open the ADF cover. Remove the jammed paper.
Page 182: Paper Jam In The Finisher
Clearing jams Note: Make sure that all paper fragments are removed. Close the ADF cover. Paper jam in the ﬁnisher Paper jam in the ﬁnisher bin Remove paper from the ﬁnisher bin. Remove the jammed paper. Note: Make sure that all paper fragments are removed.
Page 183 Clearing jams Paper jam in the ﬁnisher rear door Open the ﬁnisher rear door. Remove the jammed paper. Note: Make sure that all paper fragments are removed. Open the ﬁnisher narrow door, and then remove any paper fragments. Close the doors.
Page 184: Staple Jam In The Finisher
Clearing jams Staple jam in the ﬁnisher Open the staple access door. Remove the staple cartridge holder. Lift the staple guard, and then remove the loose staples.
Page 185 Clearing jams Close the staple guard. Insert the staple cartridge holder. Close the staple access door.
Page 186: Troubleshooting
Troubleshooting Troubleshooting Network connection problems Cannot open Embedded Web Server Action Step 1 Go to step 2. Turn on the printer. Check if the printer is on. Is the printer on? Step 2 Go to step 3. Type the correct printer IP address in Make sure that the printer IP address is correct.
Page 187 Troubleshooting Action Step 6 Go to step 7. Contact your administrator. Check if the web proxy servers are disabled. Are the web proxy servers disabled? Step 7 The problem is Contact customer solved. support. Access the Embedded Web Server. Did the Embedded Web Server open? Unable to read ﬂash drive Action Step 1...
Page 188: Hardware Options Problems
Troubleshooting Checking the printer connectivity From the home screen, touch Settings > Reports > Network > Network Setup Page. Check the ﬁrst section of the network setup page, and conﬁrm that the status is connected. If the status is not connected, then the LAN drop may be inactive, or the network cable may be malfunctioning.
Page 189 Troubleshooting Action Step 4 The problem is Contact customer solved. support. Check if the internal option is available in the print driver. Note: If necessary, manually add the internal option in the print driver to make it available for print jobs. For more information, see “Adding available options in the print driver”...
Page 190: Issues With Supplies
Troubleshooting Not enough free space in ﬂash memory for resources Try one or more of the following: • From the printer control panel, select Continue to clear the message and continue printing. • Delete fonts, macros, and other data stored in the ﬂash memory. •...
Page 191: Paper Feed Problems
The printer has detected a non‑Lexmark supply or part installed in the printer. Your Lexmark printer is designed to function best with genuine Lexmark supplies and parts. Use of third- party supplies or parts may affect the performance, reliability, or life of the printer and its imaging components.
Page 192 Troubleshooting Action Step 2 Contact customer The problem is support. solved. Make sure that paper type is set to Envelope. From the control panel, navigate to: Settings > Paper > Tray Conﬁguration > Paper Size/Type Send the print job. Does the envelope seal when printing? Collated printing does not work Action Step 1...
Page 193 Troubleshooting Action Step 2 The problem is Go to step 3. solved. From the control panel, navigate to: Settings > Paper > Tray Conﬁguration > Paper Size/Type Set the paper size and paper type to match the paper loaded in the linked trays. Print the document.
Page 194: Printing Problems
Troubleshooting Action Step 3 Contact customer The problem is support. solved. Load paper from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you are ready to use it. Print the document. Do paper jams occur frequently? Jammed pages are not reprinted Action...
Page 195 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the printer printing blank or white pages? Step 2 Go to step 3.
Page 196 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the print dark? Step 2 Go to step 3.
Page 197 Troubleshooting Action Step 6 Go to step 7. The problem is solved. Load paper from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you are ready to use it. Print the document. Is the print dark? Step 7 Go to step 8.
Page 198 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Are ﬁne lines not printed correctly?
Page 199 Troubleshooting Action Step 2 Go to step 3. The problem is solved. Load paper from a fresh package. Note: Paper absorbs moisture due to high humidity. Store paper in its original wrapper until you are ready to use it. Print the document. Is the paper folded or wrinkled? Step 3 Contact...
Page 200 Action Step 2 Go to step 3. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document.
Page 201 Troubleshooting Action Step 5 Go to step 6. The problem is solved. Remove the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum under the imaging unit.
Page 202 Troubleshooting Action Contact customer The problem is Check if the printer is using a genuine and supported Lexmark support. solved. toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Do horizontal light bands appear on prints?
Page 203 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the print light? Step 2 Go to step 3.
Page 204 Troubleshooting Action Step 4 Go to step 5. The problem is solved. Check the status of the toner cartridge, and replace if necessary. From the control panel, navigate to: Status/Supplies > Supplies Print the document. Is the print light? Step 5 Go to step 6.
Page 205 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document.
Page 206 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Is the paper curled? Step 2 Go to step 3.
Page 207 Troubleshooting Action Step 3 Go to step 4. The problem is solved. Depending on your operating system, specify the paper size and paper type from the Printing Preferences or Print dialog. Notes: • Make sure that the settings match the paper loaded. •...
Page 208 Troubleshooting Action Step 1 Go to step 2. The problem is solved. Adjust the guides in the tray to the correct position for the paper loaded. Print the document. Is the print crooked or skewed? Step 2 Go to step 3. The problem is solved.
Page 209 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document.
Page 210 Troubleshooting Action Step 3 Go to step 4. The problem is solved. Remove the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light may cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum under the imaging unit.
Page 211 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document.
Page 212 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document.
Page 213 Action Step 1 Go to step 2. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document.
Page 214 Do vertical dark lines or streaks appear on prints? Step 3 Go to step 4. The problem is solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document.
Page 215 Troubleshooting Action Step 4 Go to step 5. The problem is solved. Remove, and then insert the imaging unit. Warning—Potential Damage: Do not expose the imaging unit to direct light for more than 10 minutes. Extended exposure to light can cause print quality problems. Warning—Potential Damage: Do not touch the photoconductor drum under the imaging unit.
Page 216 Contact customer The problem is support. solved. Check if the printer is using a genuine and supported Lexmark toner cartridge. Note: If the toner cartridge is not supported, then install a supported one. Print the document. Do vertical dark streaks with missing images appear on prints? Vertical light bands Note: Before solving the problem, print the Print Quality Test Pages.
Page 217 Troubleshooting Action Contact customer The problem is Check if the printer is using a genuine and supported Lexmark support. solved. toner cartridge. Note: If the cartridge is not supported, then install a supported one. Print the document. Do vertical light bands appear on prints? Vertical white lines Note: Before solving the problem, print the Print Quality Test Pages.
Page 218 Troubleshooting Conﬁdential and other held documents do not print Action Step 1 The problem is Go to step 2. solved. From the control panel, check if the documents appear in the Held Jobs list. Note: If the documents are not listed, then print the documents using the Print and Hold options.
Page 219 Troubleshooting Slow printing Action Step 1 Go to step 2. The problem is solved. Make sure that the printer is not in Eco‑Mode and Quiet Mode. Print the document. Is the printer still printing slow? Step 2 Go to step 3. The problem is solved.
Page 220 Troubleshooting Action Step 6 Go to step 7. The problem is solved. Make sure that the printer is not overheating. Notes: • Allow the printer to cool down after a very long print job. • Observe the recommended ambient temperature for the printer.
Page 221 Troubleshooting Action Step 4 The problem is Go to step 5. solved. Turn off the printer, wait for about 10 seconds, and then turn on the printer. Print the document. Is the document printed? Step 5 The problem is Contact customer solved.
Page 222 Troubleshooting Action Step 5 Go to step 6. Insert the cables to the correct ports. Check if the cables connecting the printer and the computer are inserted to the correct ports. Are the cables inserted to the correct ports? Step 6 The problem is Go to step 7.
Page 223: Faxing Problems
Troubleshooting Action Step 3 The problem is Contact customer solved. support. Check if the trays are linked. For more information, see “Linking trays” on page Print the document. Is the document printed from the correct tray? Faxing problems Cannot send or receive faxes Action Step 1 The problem is...
Page 224 Troubleshooting Action Step 5 The problem is Go to step 6. solved. Check if the printer is connected to an analog phone service or to the correct digital connector. • If you are using an Integrated Services for Digital Network (ISDN) telephone service, then connect to an analog telephone port of an ISDN terminal adapter.
Page 225 Troubleshooting Can receive but not send faxes Action Step 1 The problem is Go to step 2. solved. Load the original document properly into the ADF tray or on the scanner glass. Can you send faxes? Step 2 The problem is Contact customer solved.
Page 226: Scanning Problems
Troubleshooting Poor fax print quality Action Step 1 The problem is Go to step 2. solved. Enhance the print quality. From the home screen, touch Settings > Print > Quality. Adjust the settings. Is the fax print quality satisfactory? Step 2 The problem is Go to step 3.
Page 227 Troubleshooting Partial copies of document or photo Action Step 1 The problem is Go to step 2. solved. Make sure that the document or photo is loaded facedown on the upper left corner of the scanner glass. Copy the document or photo. Is the document or photo copied correctly? Step 2 The problem is...
Page 228 Troubleshooting Action Step 1 Go to step 2. The problem is solved. Open the scanner cover. Using a damp, soft, lint‑free cloth, wipe the ADF glass and the white underside of the ADF cover. Close the scanner cover. Do vertical streaks still appear on scanned documents? Step 2 Contact customer...
Page 229 Troubleshooting Scanner does not close Action Remove obstructions that keep the scanner unit open. The problem is Contact customer solved. support. Did the scanner unit close correctly? Scanning takes too long or freezes the computer Action Close all applications that are interfering with the scan. Contact customer The problem is...
Page 230: Contacting Customer Support
Technical support via telephone is also available. In the U.S. or Canada, call 1-800-539-6275. For other countries or regions, go to http://support.lexmark.com.
Page 231: Upgrading And Migrating
Upgrading and migrating Upgrading and migrating Hardware Available internal options • Flash memory • Font cards • Firmware cards – Forms and Bar Code – IPDS – PRESCRIBE • Internal solutions port – RS-232C Serial Interface Card – Parallel 1284-B Interface Card –...
Page 232 Upgrading and migrating Close the access cover. Connect the power cord to the printer, and then to the electrical outlet. Turn on the printer. Installing a memory card CAUTION—SHOCK HAZARD: To avoid the risk of electrical shock, if you are accessing the controller board or installing optional hardware or memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord from the electrical outlet before continuing.
Page 233 Upgrading and migrating Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board components or connectors. Unpack the memory card. Warning—Potential Damage: Do not touch the connection points along the edge of the card. Insert the memory card until it clicks into place.
Page 234 Upgrading and migrating Close the controller board access cover. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 235 Upgrading and migrating Unpack the optional card. Warning—Potential Damage: Do not touch the connection points along the edge of the card.
Page 236 Upgrading and migrating Push the card ﬁrmly into place. Note: The entire length of the connector on the card must touch and be ﬂush against the controller board. Warning—Potential Damage: Improper installation of the card may cause damage to the card and the controller board.
Page 237 Upgrading and migrating Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board components or connectors. Unpack the hard disk. Attach the hard disk to the controller board. Warning—Potential Damage: Do not touch or press the center of the hard disk.
Page 238 Upgrading and migrating Attach the hard disk interface cable to the controller board. Close the access cover. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 239 Upgrading and migrating Mounting bracket Thumbscrews Housing Interface cable Install the ISP into its housing. Secure the ISP in place and attach the ISP extended cable.
Page 240 Upgrading and migrating Open, and then remove the controller board access cover. Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity. Touch a metal surface on the printer before touching any controller board electronic components or connectors. Attach the ISP kit to the printer.
Page 241 Upgrading and migrating If a printer hard disk is installed, then remove the hard disk before installing the ISP. Unplug the hard disk interface cable from the controller board.
Page 242 Upgrading and migrating Connect the ISP extended cable to the ISP connector.
Page 243 Upgrading and migrating Install the hard disk.
Page 244 Upgrading and migrating Close the access cover. Connect the power cord to the printer, and then to the electrical outlet. CAUTION—POTENTIAL INJURY: To avoid the risk of ﬁre or electrical shock, connect the power cord to an appropriately rated and properly grounded electrical outlet that is near the product and easily accessible.
Page 245: Software
• From the software CD that came with your printer. • Go to http://support.lexmark.com, and then select your printer and operating system. Run the installer, and then follow the instructions on the computer screen. For Macintosh users, add the printer.
Page 246 Updating ﬁrmware Some applications require a minimum device ﬁrmware level to operate correctly. For more information on updating the device ﬁrmware, contact your Lexmark representative. From the Embedded Web Server, click Settings > Device > Update Firmware. Browse to locate the required ﬂash ﬁle.
Page 247: Notices
The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Page 248 Notices Trademarks Lexmark and the Lexmark logo are trademarks or registered trademarks of Lexmark International, Inc. in the United States and/or other countries. Google Cloud Print and Google Chrome are trademarks of Google Inc. Android and Google Play are trademarks of Google LLC.
Page 249 The WEEE logo signiﬁes speciﬁc recycling programs and procedures for electronic products in countries of the European Union. We encourage the recycling of our products. If you have further questions about recycling options, visit the Lexmark Web site at www.lexmark.com for your local sales office phone number.
Page 250 ENERGY STAR Any Lexmark product bearing the ENERGY STAR emblem on the product or on a start-up screen is certiﬁed to comply with Environmental Protection Agency (EPA) ENERGY STAR requirements as conﬁgured when shipped by Lexmark.
Page 251 The power consumption levels listed in the previous table represent time-averaged measurements. Instantaneous power draws may be substantially higher than the average. Values are subject to change. See www.lexmark.com for current values. Sleep Mode This product is designed with an energy-saving mode called Sleep Mode. The Sleep Mode saves energy by lowering power consumption during extended periods of inactivity.
Page 252 If this happens, the telephone company will provide advance notice in order for you to make necessary modiﬁcations to maintain uninterrupted service. If you experience trouble with this equipment, for repair or warranty information, contact Lexmark International, Inc. at www.lexmark.com...
Page 253 Notices This equipment contains no user serviceable parts. For repair and warranty information, contact Lexmark International, Inc. See the previous paragraph for contact information. Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission, or corporation commission for information.
Page 254 LEX-M14-002 A18-0046001 Using this product in Switzerland This product requires a Swiss billing tone ﬁlter (Lexmark part number 80D1877) to be installed on any line which receives metering pulses in Switzerland. Utilisation de ce produit en Suisse Cet appareil nécessite l’utilisation d’un ﬁltre de tonalité de facturation suisse (nº de référence Lexmark :...
Page 255 Teilenummer 80D1877) für jede Leitung installiert werden, über die in der Schweiz Zeitsteuertakte übertragen werden. Uso del prodotto in Svizzera Questo prodotto richiede un ﬁltro toni Billing svizzero, (codice Lexmark 80D1877) da installare su tutte le linee che ricevono impulsi remoti in Svizzera. Regulatory notices for wireless products This section contains regulatory information that applies only to wireless models.
Page 256 Note: To assure compliance with FCC regulations on electromagnetic interference for a Class A computing device, use a properly shielded and grounded cable such as Lexmark part number 1021231 for parallel attach or 1021294 for USB attach. Use of a substitute cable not properly shielded and grounded may result in a...
Page 257 The manufacturer of this product is: Lexmark International, Inc., 740 West New Circle Road, Lexington, KY, 40550 USA. The authorized representative is: Lexmark International Technology Hungária Kft., 8 Lechner Ödön fasor, Millennium Tower III, 1095 Budapest HUNGARY.
Page 258 —Is manufactured from new parts, or new and serviceable used parts, which perform like new parts —Is, during normal use, free from defects in material and workmanship If this product does not function as warranted during the warranty period, contact a Remarketer or Lexmark for repair or replacement (at Lexmark's option).
Page 259 Lexmark's liability for actual damages from any cause whatsoever will be limited to the amount you paid for the product that caused the damages. This limitation of liability will not apply to claims by you for bodily injury or damage to real property or tangible personal property for which Lexmark is legally liable.
Page 260 Notices This limitation of remedies also applies to claims against any Suppliers and Remarketers of Lexmark. Lexmark's and its Suppliers' and Remarketers' limitations of remedies are not cumulative. Such Suppliers and Remarketers are intended beneﬁciaries of this limitation. Additional rights...
Page 261: Index
Index Index connecting printer to distinctive ring service 50 About this Printer menu 69 cable connecting the printer accessing the controller Ethernet 14 to a wireless network 144 board 231 USB 14 connecting to a wireless network activating Voice Guidance 25 canceling a print job using PIN method 144 adapter plug 47...
Page 262 Index creating bookmarks 22 enabling the USB port 187 forwarding faxes 53 creating folders encrypting holding faxes 53 for bookmarks 22 printer hard disk 141 setting the date and time 51 creating shortcuts 19 enlarging copies 41 using the automatic document crooked print 207 environmental settings 168 feeder (ADF) 51...
Page 263 HTTP/FTP Settings 125 ordering 151 letterhead Image 78 replacing 155 copying on 41 Information Sent to Lexmark 63 importing a conﬁguration ﬁle Lexmark Mobile Print IPSec 123 using the Embedded Web using 34 Job Accounting 73 Server 245...
Page 264 191 printing 188 method 144 incorrect margins 202 noise emission levels 248 personal identiﬁcation numbers jammed pages are not Non‑Lexmark supply 191 enabling 26 reprinted 194 non‑volatile memory 141 photos job prints from the wrong erasing 140 copying 40 tray 222 Not enough free space in ﬂash...
Page 265 Index Non‑Lexmark supply 191 removing paper jam scanning freezes the Not enough free space in ﬂash in door A 173 computer 229 memory for resources 190 repeat print jobs 37 scanning takes too long 229 Replace cartridge, printer region printing from a Macintosh...
Page 266 33 crooked or skewed print 207 enabling 187 dark print 195 using ﬁne lines are not printed genuine Lexmark parts 149 correctly 197 toner cartridge genuine Lexmark supplies 149 folded or wrinkled paper 198 ordering 149 using Customer Support 20...
Page 267 Index verify print jobs 37 printing from a Macintosh computer 37 printing from Windows 37 vertical dark lines on prints 214 vertical dark streaks on output when scanning from the ADF 227 vertical streaks on prints 214 viewing a fax log 53 virtual keyboard using 26 Voice Guidance...

This manual is also suitable for:

Mx622 Xm3250 Mx622ade Mb2650adwe

Lexmark MB2650 User Manual

Quick Links

Troubleshooting

Related Manuals for Lexmark MB2650

Summary of Contents for Lexmark MB2650

This manual is also suitable for:

Table of Contents
