2.4.1

COM1 Connector (CN1)

This is a high rise 9-pin D-Sub connector for COM1 serial port interface. The pin
assignments of RS-232/422/485 are listed in the table below.
Pin
RS-232
1
DCD#
2
RXD
3
TXD
4
DTR#
5
GND
6
DSR#
7
RTS#
8
CTS#
9
RI#
[*]
Note
2.4.2

DisplayPort++ and HDMI Connector (CN2)

CN2 is a double-deck connector comprising an upper connector for DisplayPort++ (CN2A)
and a lower connector for HDMI (CN2B).
Pin
Signal
1
LANE 0
2
GND
3
LANE 0#
4
LANE 1
5
GND
6
LANE 1#
7
LANE 2
8
GND
9
LANE 2#
10
LANE 3
11
GND
12
LANE 3#
13
Detect Pin
14
GND
15
AUX CH
16
GND
17
AUX CH#
18
Hot Plug Detect
19
GND
20
DP_PWR(3.3V)
16
[*]
[*]
RS-422
RS-485
TX-
485-
TX+
485+
RX+
N/C
RX-
N/C
GND
GND
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
: Signals of COM1, COM2 can be RS-232/422/485 by BIOS setting.
Pin
Signal
21
DATA2
22
GND
23
DATA2#
24
DATA1
25
GND
26
DATA1#
27
DATA0
28
GND
29
DATA1#
30
Clock
31
GND
32
Clock#
33
NC
34
NC
35
SCL
36
SDA
37
GND
38
+5V POWER
39
Hot Plug Detect
[*]
Board and Pin Assignments
CN2A
CN2B
