Chapter 5
Code 128 is the most flexible of all the common linear symbologies.
It supports alpha and numeric characters easily, has the highest number
of characters per inch, and is variable length.
See page 6 for information on setting the minimum and maximum lengths.
Enable Code 128 *
Disable Code 128
UCC/EAN 128
Enable *
UCC/EAN 128
Code ID Enable
Function 1
Character Send
Define UCC/EAN 128
Group Separator
CODE 128 AND UCC/EAN 128 SETTINGS
Minimum Length (5 *)
Maximum Length (48 *)
Character Do Not Send *
To Define UCC/EAN 128 Group Separator:
1. Scan Define UCC/EAN 128 Group Separator
2. Scan ASCII code from pages 31-34
3. Scan Define UCC/EAN 128 Group Separator
Note:
Default Group Separator is GS
18
UCC/EAN 128
D i s a b l e
UCC/EAN 128
Code ID Disable *
Function 1
*Default
