Code Alarm Professional Series CA 6550 Owner's Manual

Code Alarm Professional Series CA 6550 Owner's Manual

2 way lcd vehicle security and remote start system professional series

Advertisement

PROFESSIONAL
SERIES
CA 6550
Owner's Guide
2 Way LCD Vehicle Security and
Remote Start System
IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is
applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR
SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.
2009 Audiovox Electronics Corporation. All rights reserved.
1

Advertisement

Table of Contents
loading

Summary of Contents for Code Alarm Professional Series CA 6550

  • Page 1 PROFESSIONAL SERIES CA 6550 Owner’s Guide 2 Way LCD Vehicle Security and Remote Start System IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is applicable to most vehicles. However, due to the configuration of some vehicles, some functions AND/OR SAFETY PRECAUTIONS may not apply.
  • Page 2: Table Of Contents

    Table of Contents Using Your Remote Control ... 3 Arming the Security System ... 3 Passive Arming Bypass ... 3 Bypassing the Shock Sensor ... 3 Hidden Alarm Function ... 3 Disarming the Security System ... 3 Two Stage Door Unlock (optional) ... 4 Valet Mode ...
  • Page 3: Using Your Remote Control

    Using Your Remote Control Arming the Security System To arm the system, exit the vehicle, close all doors, then press the parking lights will flash 2 times, indicating the system is armed, has locked the doors (if equipped and connected) and activated the starter disable feature. The LED status indicator will blink steadily, once per second.
  • Page 4: Two Stage Door Unlock (Optional)

    Two Stage Door Unlock (Optional) If this feature is enabled on your system, pressing the unlock only the driver’s door. Press remaining doors. Valet Mode To engage valet mode: 1. Turn the ignition key to the ON position. 2. Press and hold the emergency override button. 3.
  • Page 5: Using The Progressive Car Finder Feature

    Using the Progressive Car Finder Feature Press the button to locate your vehicle. The system will sound 5 times at low volume, increasing in volume each time the button is pressed. Using the Personal Protection Alarm (Panic) Press and hold the alarm.
  • Page 6: Using Your Remote Vehicle Starter

    Using Your Remote Vehicle Starter Remote Starting Your Vehicle To activate the remote vehicle start function, press and release the times within 2 seconds. The system will sound, the parking lights will flash 1 time and the system will check the vehicle to ensure it is safe to start. If all safety parameters are correct, the vehicle will start within 5 seconds.
  • Page 7: Operating The 2 / 3 Hour Start Up Timer Mode

    Operating the 2 / 3 Hour Start Up Timer Mode The system has the ability to start the vehicle every 2 or 3 hours for a 48 hour period. This feature is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to periodically start the engine.
  • Page 8: Operating The Daily Start Timer

    Operating the Daily Start Timer The system has the ability to start your vehicle based on a 24-hour countdown timer. This feature requires a two-part activation sequence. From the remote, pressing both the & timer (the vehicle will start 24 hours from this time). Next, When you are finished operating the vehicle for the day, perform the following steps to complete the process.
  • Page 9: Led And Siren/Horn Indications

    LED and Siren/Horn Indications LED Display Indications SLOW FLASH FAST FLASH ON (SOLID) 2 FLASH... PAUSE 3 FLASH... PAUSE 4 FLASH... PAUSE 5 FLASH... PAUSE Siren/Horn Indications Chirps Parking Light Flash Indications Flashes ON (SOLID) 2009 Audiovox Electronics Corporation. All rights reserved. Function DISARMED ARMED...
  • Page 10: Additional 2-Way Lcd Remote Control Functions

    Additional 2-Way LCD Remote Control Functions Check Vehicle Status Press and release 2 times then press respond with one melody sound and display the current status of the vehicle. Display Illumination Press and hold the button for 1 second. The display will illuminate for 5 seconds.
  • Page 11 Button Lock Press and release on or off. Illumination Press and release illumination on or off. When on, the display will illuminate when it receives or sends a command. 2 Car Mode To control a second security system enter 2 car mode by pressing together for 3 seconds.
  • Page 12: Lcd Remote Control Icon's

    LCD Remote Control ICON’s LOCK SYSTEM ARMED TRANSMITTING TRUNK TRIGGER HOOD TRIGGER SYSTEM TRIGGER BATTERY INDICATOR VIBRATE/SILENT MODE 2 CAR MODE ALARM CLOCK TIMER START MODES UNLOCK VALET MODE IGNITION ON/TRIGGER DOOR TRIGGER FULL SHOCK TRIGGER TIME COUNT DOWN BATTERY SAVE MODE MELODY MODE TIME DISPLAY ENGINE RUNNING...
  • Page 13: Transmitter Button Functions

    Transmitter Button Functions 2009 Audiovox Electronics Corporation. All rights reserved.
  • Page 14 2009 Audiovox Electronics Corporation. All rights reserved.
  • Page 15: Replacing Remote Control Batteries

    Replacing Remote Control Batteries 1-Way 4 Button Remote Control: The batteries (model CR2016) inside each remote control should last approximately 1 year under normal use. When the batteries become weak you will notice the remote control range (the distance from the vehicle the remote control will work) deteriorate and the small LED on the remote control will dim.
  • Page 16 2009 Audiovox Electronics Corporation. All rights reserved.
  • Page 17: Warranty Information

    Code Systems, Inc. Limited Lifetime Warranty Code Systems Inc. (“CODE”) warrants to the ORIGINAL PURCHASER of this CODE vehicle security product (the “Product”), purchased from an authorized CODE dealer, that (except as provided below) should this Product under normal use and conditions, be proven defective in material or workmanship DURING THE LIFETIME OF THE VEHICLE IN WHICH IT WAS ORIGI- NALLY INSTALLED, such defect(s) will be repaired or replaced (at CODE’s option) without charge for parts directly related to repairs of the defect(s).
  • Page 18 Audiovox Electronics Corporation. Customer Service 1-800-421-3209 WWW.CODE-ALARM.COM FCC COMPLIANCE This device complies with Part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2.

This manual is also suitable for:

Ca 6550Professional seriesProfessional ca 6550
