TEC EO1-32004 Owner's Manual

Label/receipt printer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TEC Label/Receipt Printer
H-9000N-US
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for TEC TEC EO1-32004

Summary of Contents for TEC TEC EO1-32004

  • Page 1 TEC Label/Receipt Printer H-9000N-US Owner’s Manual...

  • Page 3: Safety Summary

    Do not attempt to effect repairs or modifications to this equipment. If a fault occurs that cannot be rectified using the procedures described in this manual, turn off the power, unplug the machine, then contact your authorized TOSHIBA TEC representative for assistance. Meanings of Each Symbol This symbol indicates warning items (including cautions).
  • Page 4 • Utilize our maintenance services. After purchasing the machine, contact your authorized TOSHIBA TEC representative for assistance once a year to have the inside of the machine cleaned. Otherwise, dust will build up inside the machines and may cause a fire or a malfunction. Cleaning is particularly effective before humid rainy seasons.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ････････････････････････････････ ･････････････････････ 1-1 APPLICABLE MODEL ･･････････････････････････････････････････ 1-2 ACCESSORIES････････････････････････････････････････････････ 1-2 SPECIFICATION ････････････････････････････････ ･････････････････････ 2-1 PRINTER ･････････････････････････････････････････････････････ 2-1 OPTION ･･････････････････････････････････････････････････････ 2-2 APPEARANCE ････････････････････････････････ ･･････････････････････ 3-1 DISPLAY････････････････････････････････ ････････････････････････････ 3-1 KEY LAYOUT ････････････････････････････････ ･･･････････････････････ 5-1 PROGRAMMING KEYBOARD ･･･････････････････････････････････ 5-1 OPERATION KEYBOARD AND SPEED KEYBOARD ･･･････････････ 5-3 SELF SERVICE KEYBOARD ････････････････････････････････････...
  • Page 6 15. CLEANING THE PRINT HEAD ････････････････････････････････ ････････ 15-1 16. TROUBLESHOOTING ････････････････････････････････ ･･･････････････ 16-1 CAUTION: 1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA TEC. 2. The contents of this manual my be changed without notification.

  • Page 7: Introduction

    INTRODUCTION 1. INTRODUCTION The H-9000 is a label/receipt printer developed to comprise a system along with the SL-9000 series scales(SL-9000-FFB/FFR/FFH, H-9100). As a cash register it records details of all item sales, cash and other media taken, and prints a fully itemised receipt. It can also be programmed with numerous types of special offer, applicable to both labelling and cash register operations.

  • Page 8: Applicable Model

    INTRODUCTION 1.1 APPLICABLE MODEL H-9000-N-US The description of the model number is as follows. H - 9 0 0 0 - N - U S 1.2 ACCESSORIES Owner’s Manual (EO1-32004) Receipt Cutter NOTE : Check that there are no missing or incorrect parts in the accessories. N: LAN (Option) is available.

  • Page 9: Specification

    SPECIFICATION 2. SPECIFICATION 2.1 PRINTER Item Unit Price Presettable Minimum Price Display Power Requirement Power Consumption Temperature Limits Relative Humidity Message Display Unit Price Total Price Capacity of PLU Memory Print Head Media Issue Method Dot Density Print Speed Available Print Width Recommended Media Thermal Label Variable Length Label...
  • Page 10 Board (SL-9000N only) Drawer NOTES: 1. Contact TOSHIBA TEC H.Q. or your nearest TOSHIBA TEC representative. 2. Order from TOSHIBA TEC Parts Center or purchase locally. 3. When purchasing memory modules locally, select one having the following specifications. ■ Maker: HITACH Static RAM (OP-9000-SRAM-512KB) ■...

  • Page 11: Appearance

    APPEARANCE 3. APPEARANCE Programming Keypad Print head Main Power Switch The following sections describe the controls of the H-9000, its routine maintenance and some basic safety and operating precautions. You must be familiar with these before attempting to use the H- 9000.

  • Page 12: Key Layout

    KEY LAYOUT 5. KEY LAYOUT 5.1 PROGRAMMING KEYBOARD ◇ PROG. ENTER ” È É Â NOTE: Blank keys have no function. ■ Programming Keyboard Function Name of Key 1. Clears numeric data just entered. CLEAR 2. Releases the scale from the error mode. Selects the upper case or lower case.
  • Page 13 KEY LAYOUT Name of Key 1. Displays the preceding PLU data. − 2. Used to set an auto code. 3. Calls the preceding label format # when setting the print position. Moves the cursor to left. ← Moves the cursor to right. →...

  • Page 14: Operation Keyboard And Speed Keyboard

    KEY LAYOUT 5.2 OPERATION KEYBOARD AND SPEED KEYBOARD NOTES: The numbers form 1- 70 indicate the speed key layout, but the actual keys have no number. Pressing the key enables another 70 PLUs assignment. The functions of the (1) and (2) keys can be changed according to the initial settings as follows. Initial Setting # 28-4 12-8...
  • Page 15 KEY LAYOUT ■ Operation Keyboard Function Name of Key Prints the customer label. PRT/* Saves tare and unit price after taking off the commodity from a platter. SAVE Sets the number of articles in “BY COUNT” mode. Displays the date. DT/TM Selects the item for change Print/OFF.

  • Page 16: Self Service Keyboard

    KEY LAYOUT ■ Operation Keyboard Function Name of Key This key is used for item or subtotal discount by entering a percentage. (Optional key by initial setting) Feeds the label. FEED Issues a test label. TEST Adjusts the zero point. ZERO Changes the label issue mode between Automatic issue and manual issue.
  • Page 17 Speed key can operate among unit-price change (prog-mod), read/reset-mode, security-mode. Of course panel-key can operate, those panel key don’t indicate top of key-sheet. NOTE: If you would like to switch the initial setting #13-2 to 1 please contact your authorized TOSHIBA TEC representative. 5- 6...

  • Page 18: Procedure Before Operation

    PROCEDURE BEFORE OPERATION 6. PROCEDURE BEFORE OPERATION Unpack the accessories and Printer from the carton. Install the options on the printer, if necessary. Refer to Safety Precautions in this manual and set up the Printer at a proper location. Load the Label or Receipt. (See Page 7-1.) Be sure to insert the Power Cord Plug into an AC outlet.

  • Page 19: Removal And Replacement Of Media

    REMOVAL AND REPLACEMENT OF MEDIA 7. REMOVAL AND REPLACEMENT OF MEDIA 1. Open the printer cover and turn the head-up lever to the right. 2. Pull out the roll stopper and backing paper stopper, then remove the receipt/label core with the backing paper.
  • Page 20 REMOVAL AND REPLACEMENT OF MEDIA 4. Insert the tip of the receipt/label into the print head. 5. Align the two media guides with the right edge of the receipt/label. Media Guide Thread the receipt/label as shown below. When using a label roll, take up the backing paper onto the winding roll and fix it with the backing paper stopper.

  • Page 21: Outline Of Operation

    Available after the POWER key is depressed while scaling. In the self service scale mode (the initial setting #13-2 is set to 1), these keys are unavailable. If you would like to switch the initial setting #13-2 to 1, please contact your authorized TOSHIBA TEC 8- 1...
  • Page 22 OUTLINE OF OPERATION ■ Registration mode FUNCTION ZERO SETTING LABEL FEED CALL PLU BY SPEED KEY CALL PLU BY PLU KEY RETURN TO PLU CALLING MODE TEMPORARY CHANGE OF DATE TARE CLEAR PRESET TARE 1 PRESET TARE 2 DIRECT TARE SAVE UNIT PRICE SAVE TARE TEST PRINT...

  • Page 23: Programming Procedures

    PROGRAMMING PROCEDURES 9. PROGRAMMING PROCEDURES ■ How to access the Programming Menu Enter a menu number ESC. Password Programming starts NOTES: 1. When the selected menu ( and enter the password. 2. In Section 9.1, 9.2 and 9.3, items which have been sold on that day cannot be called before resetting (refer to Section 13.) unless Initial Set #1-4 is set to 1.
  • Page 24 PROGRAM/CHANGE TITLE ON DISPLAY/PRINT SEND/RECEIVE LOGO DATA PROGRAM IDIOM VENDOR NAME PROGRAM FREE FORMAT PROGRAMS PARAMETERS FOR LAN 9- 2 ■ Title and Contents of Programming Menu CONTENTS Contact a TOSHIBA TEC Page 9-12 9-13 9-14 9-16 9-16 9-17 9-18...
  • Page 25 PROGRAMMING PROCEDURES ■ How to enter characters Use the following procedure to enter a commodity name, address and ingredient message. Example) 1 st line: 2 nd line: 1 st line content SHIFT SHIFT NOTES: ← → 1. and keys 2. To insert a space, move the cursor to the next character to the space to be inserted, and press INSERT 3.

  • Page 26: Plu Data Edit

    PROGRAMMING PROCEDURES PLU DATA EDIT Menu Page: 1 Item No.: In this procedure, use operation keys (except when calling a PLU by using a speed key). The unit price stored in a PLU can be changed with this menu. <MENU> Page 1 NOTES: 1.

  • Page 27: Plu Data Setting

    PROGRAMMING PROCEDURES PLU DATA SETTING Menu Page: 1 Item No.: Setting or changing the contents of PLU (PLU#, UPC#, Commodity Name, etc). <MENU> Page 1 NEXT NEXT Enter PLU# ENTER (max. 6 dig.) Is status In what mode of initial set is PLU used? #1-6? WEIGH...
  • Page 28 PROGRAMMING PROCEDURES Pressing the key instead of the ↓ key returns to the preceding menu. Verification label of PLU data NOTES: 1. A UPC code is made up of a combination of an entered code and an AUTO CODE. Be sure to attach some will be ignored and an AUTO CODE will become an UPC code (see ex.

  • Page 29: Ingredient Message

    PROGRAMMING PROCEDURES INGREDIENT MESSAGE Menu Page: 1 Item No.: Ingredient messages can be printed on a label with a maximum of 54 characters per line using small letters or 32 characters per line using boldfaced small letters. Will print up to 38 lines. <MENU>...

  • Page 30: Nutrition Setting

    PROGRAMMING PROCEDURES NUTRITION SETTING Menu Page: 1 Item No.: Using the following procedure, nutrition information and caloric intake can be set. Serving Size and Servings Per Container consist of a maximum of a 18 characters. However, total number of characters including title characters must not exceed 30. <MENU>...
  • Page 31 PROGRAMMING PROCEDURES Additional Information Area 2∼6. (0∼99999 or 0.0∼999.9) Enter the vitamin A. (0∼999) Enter the Calcium. (0∼999) Additional Information Area 7 12 (0 999) PROG. ESC. Pressing the ↓ key instead of the returns to the preceding menu. NOTES: 1. When entering PLU#, be careful of the following. When a selected PLU# is not stored in the PLU file, an error occurs.
  • Page 32 PROGRAMMING PROCEDURES ● Set the Daily Value Table AUTO Basic Calories. CODE (Content No. 1) Enter the Basic Saturated Fat. (Content No. 3) Basic Sodium. (Content No. 5) Enter the Basic Dietary Fiber. (Content No. 7) NOTES: 1. DAILY VALUE (Max. 8 digits) 1) The contents of Daily value Contents No.
  • Page 33 PROGRAMMING PROCEDURES ● Deleting Nutrition Data DELETE ● Memory file sort The memory file is sorted when a memory full error occurs. ◇ Area for titles Area for entry data: Set in this menu (Nutrition Setting procedure.) Area for data: Enter the PLU# ENTER (max.

  • Page 34: Plu Verifying Label

    PROGRAMMING PROCEDURES PLU VERIFYING LABEL Menu Page: 1 Item No.: Verifies PLU data stored in the scale. <MENU> Page 1 CLEAR ENTER To interrupt To resume label issue label issue. which has been interrupted. NOTES: 1. Labels are printed in both batch mode and on-demand mode. 2.

  • Page 35: Address And Commercial Message Setting

    PROGRAMMING PROCEDURES ADDRESS AND COMMERCIAL MESSAGE SETTING Menu Page: 1 Item No.: A store address printed on label and a commercial message shown on the display can be set within the following character limits using the procedure below. Address: 32 characters×2 lines Message: 90 characters Receipt Header: 24 characters in the 1st/2nd line and 48 characters in the 3rd line...

  • Page 36: Combination Message

    PROGRAMMING PROCEDURES COMBINATION MESSAGE Menu Page: 1 Item No.: You can combine some messages set in Section 9.6 together and create a maximum of 24 different combination messages. Message construction NOTE: When the fixed message is selected, set “00” as the 1st and 2nd messages. Otherwise, set “00”...
  • Page 37 PROGRAMMING PROCEDURES 3. Display method varios depending on message construction. 1) message combination a. single message ･･･････ either scrolling or fixed is available. b. multiple message ･･････ scrolled regardless of selection. 2) logo combination Logo must be a single logo and a fixed display. When logos are combined, no message will be displayed.

  • Page 38: Special Information

    PROGRAMMING PROCEDURES SPECIAL INFORMATION Menu Page: 1 Item No.: When the Net Weight Statement label is selected, 3 lines (32 characters/line) of special information can be printed in the label position where the net weight data is to be printed. The special information can be printed in the weigh and By Count mode.

  • Page 39: Speed Key Setting

    PROGRAMMING PROCEDURES 9.10 SPEED KEY SETTING Menu Page: 1 Item No.: The H-9000 has a maximum of 70×2 speed keys which are very convenient to call PLUs quickly. (Refer to page 5-3 regarding the Key Layout.) <MENU> Page 1 Toggles the speed key Page Enter the PLU#.

  • Page 40: Print Format

    PROGRAMMING PROCEDURES 9.11 PRINT FORMAT Menu Page: 2 Item No.: The The H-9000 can memorize 5 different print formats. After print formats are set, you can call them by pressing the print format number. <MENU> Page 2 On-demand CHANGE Issue method Select “SENSIBILITY ADJUST”...
  • Page 41 PROGRAMMING PROCEDURES ■ Table 2: Label Format Number Table elect the format # for the label to be used by referring to the table below. Print format Format # Basic form Ingredient 00 (50) NON POS 10 (60) 11 (61) 12 (62) 13 (63) 14 (64)

  • Page 42: Date/Time Setting

    PROGRAMMING PROCEDURES 9.12 DATE/TIME SETTING Menu Page: 2 Item No.: Date, time, machine number, and store code are set with this procedure. <MENU> Page 2 Set the machine No. (max. 6 dig.) NOTES: 1. Express the time in a 24-hour military format. 2.
  • Page 43 9. ROGRAMMING PROCEDURES ■ PL-3 Operation Connect the PL-3 to the H-9000 by using RS-232C Cable, then turn on the power of the H-9000 and the PL-3. Insert a data disc into the PL-3 and adjust the transmission rate to the H-9000 ( BPS or : 2400 BPS) by using the rotary switch.
  • Page 44 9. ROGRAMMING PROCEDURES ■ Table 4: Transmission Item List ITEM # Title on the Display VERIFY PLU & ING. = CMT 2 READ PLU & ING. FM CMT 3 WRITE PLU TO CMT VERIFY PLU = CMT READ PLU FROM CMT WRITE ING.

  • Page 45: In-Line/Local

    PROGRAMMING PROCEDURES 9.14 IN-LINE/LOCAL Menu Page: 2 Item No.: When the H-9000 is used as a satellite in an in-line system, the “ID #” and “Transmission delay time” can be set by the following procedure. <MENU> Page 2 The transmission delay time can be set when in-line system is selected...

  • Page 46: Lon System

    PROGRAMMING PROCEDURES 9.15 LON SYSTEM Menu Page: 2 Item No.: The H-9000 Printers which consists of a master, satellites, and a backup master are connected each other by the LON cable to transmit data such as PLU, ING., NUTRI, etc. ID# 1 is reserved for the master terminal.
  • Page 47 PROGRAMMING PROCEDURES ■ Data Transmission The following data is down-line-loaded. Page 1: (0). All (PLU+ING+NUTRI) (1). PLU (2). ING. (3). NUTRITION (4). U. PRICE (5). DATE/TIME (6). MESSAGE LINK (Message) (7). LOCK SCALE (Check the LON cable) (8). OPEN SCALE (Release the lock after checking the LON cable.) (9).

  • Page 48: Bar Code Format

    PROGRAMMING PROCEDURES 9.16 BAR CODE FORMAT Menu Page: 2 Item No.: With the H-9000 printer, four kinds of bar code formats are available. These formats can be changed freely. Example) Current format Flag Changed format Flag When changing the above example format into the weigh format described in NOTE 1, use the following procedure.
  • Page 49 PROGRAMMING PROCEDURES 2. When the in the following cases. ① Check digit (C/D) is at other than digit-13. ② Price check digit (PC/D) cannot be calculated. (Price is other than 4 or 5 digits.) ③ Price is not set serially beginning from P1 (P1 to P4, or P1 to P5). ④...

  • Page 50: Titles

    PROGRAMMING PROCEDURES 9.17 TITLES Menu Page: 2 Item No.: You can register and change displayed/printed titles of the additional information area for nutrition facts using the following procedure. Registered or changed titles are stored in the RAM. When ALL clear or RAM clear is executed, these titles will be cleared and the initial titles will resume.

  • Page 51: Transferring Logo Data

    PROGRAMMING PROCEDURES 9.18 TRANSFERRING LOGO DATA Menu Page: 2 Item No.: Logo data is created on a PC and stored into RAM through the CMT interface. Two different sizes of logos, 320x118 dots and 256x64 dots, are available on the H-9000. 64 KB of RAM area is secured for logo data, in which the maximum of 13 logos (320x118 dots) or 26 logos (256x64 dots) can be stored.

  • Page 52: Idiom Setting

    PROGRAMMING PROCEDURES Table 6: Error message during data transmission Error message DATA ERROR 9.19 IDIOM SETTING Menu Page: 2 Item No.: Up to 50 terms frequently appearing in ingredient messages can be preset using the following procedure. The idiom number must be set from 1 to 50 in order. One idiom can contain a maximum of 20 characters.

  • Page 53: Vendor Setting

    PROGRAMMING PROCEDURES 9.20 VENDOR SETTING Menu Page: 3 Item No.: Up to 40 vendors can be registered using the following procedure. The vendor number must be set from 0 to 39 in order. One vendor name can contain a maximum of 12 characters. <MENU>...

  • Page 54: Free Format Setting

    PROGRAMMING PROCEDURES 9.21 FREE FORMAT SETTING Menu Page: 3 Item No.: When using 57-mm wide labels, up to three print formats can be changed freely. characters can be rotated and magnified, and print items are selectable. Enter the coordinate of each print item’s lower left corner using the lower left corner of a label as the origin.
  • Page 55 PROGRAMMING PROCEDURES NOTES: 1. The following print items cannot be magnified. (1)LOGOs (2)Safe handling precautions (3) Ingredient messages (4)Barcode (5) FSP Block 2. Base label format numeric data is shown automatically. X coordinate: Y coordinate: Format data beyond the effective print area results in an error. 3.
  • Page 56 PROGRAMMING PROCEDURES (F) Weight (F) Weight (title) (F) Price (F) Price (title) (F) LOGO FSP block LOGO 2 When setting the print item position (X and Y), an error will occur in the following cases. (1) Entered “X” point + Print size “X” > 384 dots. (2) Entered “Y”...
  • Page 57 PROGRAMMING PROCEDURES 8. Print coordinate ∼ ∼ Commodity ↑ Label Length (0, 0) → X ∼ ∼ Address (383, 0) Address 384 dot 57 mm 9- 35 9.21 FREE FORMAT SETTING *1 Addresses are printed together with the previous label’s data.

  • Page 58: Programmed Data Verification Reports

    10. PROGRAMMED DATA VERIFICATION REPORTS 10. PROGRAMMED DATA VERIFICATION REPORTS The programmed data can be printed on journal paper. Before issuing these reports, load the journal paper. The programmed data verification reports cannot be issued with any label. The keys to be used in the following procedures are those on the numeric key pad, which is framed in black in the figure on page 5-3, but not on the programming keyboard.
  • Page 59 10. PROGRAMMED DATA VERIFICATION REPORTS Table 7 Menu # PLU programmed data report Commodity description report Speed key programmed data report Commodity and ingredient description report Grade line report Vendor name report Idiom report Set the data range of each programmed data verification report ●...

  • Page 60: Password Security

    11. PASSWORD SECURITY 11. PASSWORD SECURITY You can protect all menus (except REG. menu) and set two step passwords for access to protected menus. 11.1 SETTING PASSWORD AND PROTECT MENU <Menu> MAIN 0. PROG. 1. REG. 2. MARK DOWN 3. REWRAP 4.
  • Page 61 11. PASSWORD SECURITY Enter password B as 4 digits. Exclude menus for which password B cannot access. ○ × ○ ○ ー × ○: Valid ×: Invalid ー: Not need NOTES: 1. Select validity of the password by pressing the 2.

  • Page 62: Calling Menu By Entering Password

    11. PASSWORD SECURITY 11.2 CALLING MENU BY ENTERING PASSWORD ESC. Enter a menu No. ∼ Accessible without the password Accessible menu with the password peration NOTE: When the password is unknown, enter “HELP” instead, and you can access only security menu.

  • Page 63: Operating Procedures

    12. OPERATING PROCEDURES 12. OPERATING PROCEDURES ■ NOTES BEFORE STARTING OPERATION (1) Insert the power plug into the AC outlet and turn the power ON. (2) A sixteen-second scanning will be performed after pressing the (3) Do not move the unit while it is in operation. Should it become necessary to move it at any time, turn the power switch to the OFF position and be sure to readjust the level indicator after relocating the scale*.

  • Page 64: Weighing Operation

    12. OPERATING PROCEDURES 12.1 WEIGHING OPERATION NOTE: Weighing operation is available only when the optional scale unit is connected. Menu: REG., M.DOWN, or REWRAP Mode: WEIGH The weigh mode is used to weigh a commodity and to issue the label. The label contains data such as a weight, unit price (price per weight) and total price (calculated as a result of the weighing operation).

  • Page 65: Fix Price Operation

    12. OPERATING PROCEDURES 12.2 FIX PRICE OPERATION NOTE: This operation is available only when the optional scale unit is connected. The FIX mode (Fix Price Mode) is used to issue a label for a commodity of a fixed price PLU (i.e. the price determined by the store), the weight of which may vary from commodity to commodity.

  • Page 66: By Count Operation

    12. OPERATING PROCEDURES 12.3 BY COUNT OPERATION The BY-COUNT mode is used to issue the label of commodities of the same kind in a package (or may not be packed). The whole package quantity (or a certain quantity) and the whole package price (or the price per the quantity) are usually preset.
  • Page 67 12. OPERATING PROCEDURES Example) An open price item can be sold as below: ① 1 piece at 15 dollars ② 15 pieces at 10 dollars ③ 15 pieces sold at 0.5 dollars per 10 pieces Enter the PLU #. Press: Enter quantity Press: Enter quantity...

  • Page 68: Print Count Operation

    12. OPERATING PROCEDURES 12.4 PRINT COUNT OPERATION With this procedure, a specified number of the same labels can be issued. Menu: REG., M.DOWN, or REWRAP Mode: WEIGH, FIX or BY-COUNT Example A) When operating in Weigh mode. Set the number of labels. (Max.
  • Page 69 12. OPERATING PROCEDURES Example B) When operating in Fix or By Count mode. Press : Set the number of labels. (Max. 99) Press : Enter the PLU #. Press : Press, to save the PLU data : Place a commodity on the platter.
  • Page 70 12. OPERATING PROCEDURES Example C) When issuing only the nutrition information label. Note that nutrition information can be printed only on several types of label. Refer to Page 9-19. Select basic data and nutrition information labels or a nutrition information label by pressing this key.

  • Page 71: Issuing Labels With Net Weight Statement

    12. OPERATING PROCEDURES 12.5 ISSUING LABELS WITH NET WEIGHT STATEMENT NOTE: This operation is available only when the optional scale unit is connected. Menu: REG., M.DOWN, or REWRAP Mode: FIX When the initial settings #1-7 and #1-8 are set to 1, a Net Weight Statement is printed on the label. A unit price and a tare registered in each PLU are printed as a price and a net weight.
  • Page 72 12. OPERATING PROCEDURES NOTES: 1. To print NET WT. data, from the FIX mode, load a label which has an area to print a NET WT. Statement. 2. The quantity sold number and price data in NET WT. statement operation will be accumulated in the memory.

  • Page 73: Tare/Save Function Procedures

    12. OPERATING PROCEDURES 12.6 TARE/SAVE FUNCTION PROCEDURES NOTE: This operation is available only when the optional scale unit is connected. Menu: REG., M.DOWN, or REWRAP Mode: WEIGH or FIX (Tare % function is available in WEIGH mode only.) There aretwo kinds of tare subtraction procedures, one is “Direct tare”, the other is “Preset tare “. SAVE key is used to save the tare, unit price, and PLU data after taking a commodity from the platter.

  • Page 74: Calling And Printing Grade Lines

    12. OPERATING PROCEDURES 12.7 CALLING AND PRINTING GRADE LINES A grade line is a short message added to a commodity name. A grade line can be selected from maximum of 49 programmed grade lines and printed on the label. Menu: REG., M.DOWN, or REWRAP Mode: WEIGH or FIX, or BY COUNT Enter the PLU #.

  • Page 75: Calling And Printing Logos

    12. OPERATING PROCEDURES 12.8 CALLING AND PRINTING LOGOS When the initial set #10-7 is set to “1” or “2”, a logo containing a picture, a mark, a POP message, etc., can be printed on the ingredient label having 12 lines or more. Logo data is created on the PC and stored into the memory through the CMT/PL-3 interface.

  • Page 76: Selecting Print Item

    12. OPERATING PROCEDURES 12.9 SELECTING PRINT ITEM Menu: REG, M.DOWN, or REWRAP Mode: WEIGH, FIX, or BY COUNT Press: Select an item. (Refer to Table. 9) Print ←→ No print 1:Print 0:Non print Press: Table 9 Entry Packed on date Sell by date Commodity name Weight...

  • Page 77: Date Change

    12. OPERATING PROCEDURES NOTES: 1. A store code can be printed in place of a “packed on date” and “sell by date” by changing the initial settings #6-5 and #6-6. To print a store code, select “packed on date” or “sell by date” as a print item using the above procedure.

  • Page 78: Batch Print Mode (With 30 Items Run Assignment)

    12. OPERATING PROCEDURES 12.11 BATCH PRINT MODE (with 30 Items Run Assignment) Menu: REG., M.DOWN, or REWRAP Mode: FIX, or BY COUNT Up to 99 labels per PLU can be issued in non-scale mode. Up to 30 items can be preset. (However, 0 is preset, issuing will be canceled.) Enter the PLU #.
  • Page 79 12. OPERATING PROCEDURES ● Unit Price Change and G.Line/LOGO Call Enter the quantity. Call the Grade Line. Enter the required Grade Line# (1 to 49). Press: Call PLU designation LOGO. (*1) Enter the required LOGO# (1 to 26). Press: *1 By calling the PLU designation LOGO, the LOGO can be designated per PLU and printed. When the PLU dose not designate the LOGO, the LOGO programmed before entering Batch Print Mode is printed.
  • Page 80 12. OPERATING PROCEDURES ● Label Issue Stop or Cancel Clear an error or stop label issuing. Cancel output Press: Stop issuing the labels and cancel PLUs which have not been output. NOTES: 1. When the label for NET.WT statement is not selected, pressing the key in FIX mode results in an error.

  • Page 81: Visual Commodity Library

    12. OPERATING PROCEDURES 12.12 VISUAL COMMODITY LIBRARY Menu: REG., M.DOWN, or REWRAP Mode: WEIGH, FIX, or BY COUNT In the following procedure, entering a group # (the upper two digits of PLU#) allows you to call 6 commodities which belong to the group. This function is convenient when calling a commodity which PLU# you do not know.

  • Page 82: Floating Vendor

    12. OPERATING PROCEDURES 12.13 FLOATING VENDOR Menu: REG Mode: WEIGH, FIX, or BY COUNT Floating vendor function allows you to register different commodities sales together. This function is available when the Initial Setting #11-1 is set to 1 and using a receipt. Be sure to select IN-LINE in Section 9.15 LON SYSTEM even if no scale is connected, then enter the ID# 1, turn the power off and then on.
  • Page 83 Initial 3-6 (G. Line Print Position) 0: Right side on bottom line of commodity name 1: Left side on bottom line of commodity name If you would like to switch the initial setting # please contact your authorized TOSHIBA TEC representative. ■...

  • Page 84: Total Operation

    13. TOTAL OPERATION 13. TOTAL OPERATION In Read or Reset mode you can issue a sales report or reset report with either a label or journal paper. Menu: READ or RESET READ The totals will not be cleared as they are printed on labels or journal paper. RESET The totals will be cleared as they are printed on labels or journal paper.

  • Page 85: Hourly Total Report

    13. TOTAL OPERATION 13.1 HOURLY TOTAL REPORT Ex.) REPORT Menu NOTES: 1. When issuing an hourly report, hours with no sales are not printed. 2. An hourly report is printed as follows: 1) Label: Issued sequentially in on-demand mode. 2) Journal paper: Issued with journal paper. 3) Label with backing paper: Issued sequentially in batch mode.

  • Page 86: Vendor Total Report

    13. TOTAL OPERATION Individual Total Ex.) Individual PLU Total (PLU #100) Block Total Ex.) UPC Block Total (UPC #100100∼100199) NOTE: The key represents 0 through 9. The most significant digit in the starting number is ◇ followed by an appropriate number of Zone Total Ex.) PLU Zone Total (PLU #100∼107) Enter PLU Total...

  • Page 87: Error Message Table

    14. ERROR MESSAGE TABLE 14. ERROR MESSAGE TABLE If you annot solve the problem with the following solution instruction, do not attempt further trouble shooting, by yourself. Authorized Service representative for assistance. Do not attempt to repair or adjust alone, because electrical equipment is dangerous. Take the following action if an error message has appeared on the commodity name display along with the buzzer sounding.
  • Page 88 14. ERROR MESSAGE TABLE ● Label lssue Mode Message DATA ENTRY ERROR PLU NOT FOUND TOTALS OVERFLOW MEMORY WILL BE FULLED PLU DATA ERROR PRT FAILURE DETECTED Printer trouble. LABEL OVER RUN ● Report and Reset Mode Message PLU NOT FOUND PRT FAILURE DETECTED Printer trouble.
  • Page 89 14. ERROR MESSAGE TABLE ● CMT Operation Mode Message MISMATCH SCALE SPEC BAD TAPE OR CMT TIME OUT ERROR ● LON System Mode Error message COMMUNICATION 1. The power of the master or ERROR 2. LON cable is broken. SEQUENCE ERROR The power was not turned OFF and ON again after setting ID #.

  • Page 90: Cleaning The Print Head

    15. CLEANING THE PRIT HEAD 15. CLEANING THE PRINT HEAD Care must be taken not to injure your fingers with the receipt cutter during installing, removing or cleaning it. If the print head is dirty, printing will not be clear. The print head should be cleared with a print head cleaner everyday before use, according to the following procedure: 1.

  • Page 91: Troubleshooting

    16. TROUBLESHOOTING 16. TROUBLESHOOTING This scale has been manufactured under strict quality control. If you have any trouble, however, DO NOT ATTEMPT TO FIX IT BY YOURSELF. Pull the power plug out of the outlet, and contact your Authorized Service representative. Problems “...
  • Page 94 PRINTED IN SINGAPORE EO1-32004B...
