Description of Instrument Functions
Prosonic M
FMU 40/41/42/43/44
with HART, PROFIBUS-PA
and Foundation Fieldbus
BA 240F/00/en/09.07
Nr. 52011048
Valid as of software version:
V 01.04.00 (amplifier)
V 01.04.00 (communication)
