- Page 1 2MP 4-in-1 IR Eyeball Cameras with 2.8-12mm Varifocal Lens GEBV | GEBVG User Manual Please read these instructions carefully before operating the unit and keep for further reference.
- Page 2 Intro Section CAUTION: • To reduce the risk of electric shock, do not open the camera, please consult a professional or contact your distributor. • To prevent fire or shock hazards, the power, input voltage, current, voltage polarity and operating temperature of this camera must meet the requirements stated.
-
Page 3: Table Of Contents
Contents 1.0 Introduction ......................4 1.1 Product Features ...................4 1.2 Product Dimensions ..................4 1.3 Specification....................5 2.0 OSD Menu Tree ....................6 3.0 Product Installation....................7 3.1 Note ......................7 3.2 Installation Method ..................7 3.3 Product Connection ..................8 4.0 FAQ’s ........................9... -
Page 4: Introduction
1.0 Introduction The Genie GEBV is a 2MP 1080p 4-in-1 (AHD, TVI, CVI and CVBS) eyeball camera equipped with a 2.8-12mm varifocal lens. The camera can transmit up to 300m in distance when using the AHD mode and is available in a White or Grey finish. -
Page 5: Specification
User Manual 2MP 4-in-1 IR Eyeball Cameras with 2.8-12mm Varifocal Lens 1.3 Specification Image Sensor 1/2.7” 2MP CMOS Sensor Image Size 1920 x 1080 Image System PAL / NTSC Resolution Electronic Shutter Auto / Manual Minimum Illumination Colour: 0.1 Lux @ (F1.2 AGC On) Camera B&W: 0.01 Lux @ (F1.2 AGC On) Lens... -
Page 6: Osd Menu Tree
2.0 OSD Menu Tree... -
Page 7: Product Installation
3.0 Product Installation 3.1 Note 1. Make sure the unit is powered off before installation. 2. Check that the power supply voltage is consistent with the electric voltage to prevent damage to the device. 3. Do not use in an environment beyond the boundaries of the temperature, and maintain good ventilation to prevent the risk of fire or electric shock. -
Page 8: Product Connection
User Manual 2MP 4-in-1 IR Eyeball Cameras with 2.8-12mm Varifocal Lens 3.3 Product Connection... -
Page 9: Faq's
4.0 FAQ’s Q: No picture with power on A: It may result from abnormal power supply. Please check if the power supply voltage and its polarity are correct. Also you will need to confirm if the wire connections and monitors are normal. Q: Unclear image output A: It is caused by incomplete adjustment of the lens back focus. - Page 10 Sales +44(0)1707 330541 Enquiries sales@genieproducts.co.uk Website www.genieproducts.co.uk...
