Installation Guide
Trane® Commercial Touch Screen
Programmable Zone Sensor
for ReliaTel™ and Symbio® 400/700/800
Controls
Part Number:
Symbio® 400: X13790993001 (SEN02587)
ReliaTel™: X13790994001 (BAYSENS924)
Symbio® 700/800: X13791009001 (BAYSENS800)
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
April 2022
SAFETY WARNING
BAS-SVN028K-EN

Advertisement

Table of Contents
loading

Summary of Contents for Trane ReliaTel

  • Page 1 Installation Guide Trane® Commercial Touch Screen Programmable Zone Sensor for ReliaTel™ and Symbio® 400/700/800 Controls Part Number: Symbio® 400: X13790993001 (SEN02587) ReliaTel™: X13790994001 (BAYSENS924) Symbio® 700/800: X13791009001 (BAYSENS800) SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
  • Page 2 (Global Harmonized System of Classification and compounds have the same potential impact to the Labeling of Chemicals) guidelines for information on environment. Trane advocates the responsible handling of allowable personal exposure levels, proper all refrigerants-including industry replacements for CFCs respiratory protection and handling instructions.
  • Page 3 Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.
  • Page 4: Table Of Contents

    ......5 ReliaTel Field Upgrade Procedure ..27 Symbio 400 .
  • Page 5: Equipment/Software Supported

    Voyager 3, and Odyssey™ CV/SZVAV/Multi-speed indoor fan equipment that uses the ReliaTel control system. For proper operation, the ReliaTel RTRM board must be installed in the equipment with software version 19.2 or later. In addition, the BCI-R board must be installed with software version 6.00 or later.
  • Page 6: Installation

    Installation Location Guidelines • Do not install on an outside wall. • Do not install in areas with direct heat source. • Do not install near any air discharge grill. • Do not install in areas exposed to direct sunlight. •...
  • Page 7: Zone Sensor Wiring

    HVAC equipment. Communication Wire Use the correct communication wire to ensure reliable communication between the zone sensor and the HVAC equipment. Trane recommends the following wire supplier and wire type. Important: This sensor can only be used with standalone HVAC equipment.
  • Page 8: Reliatel Systems

    Zone Sensor Wiring ReliaTel Systems extension wire to prevent contact with the metal enclosure and circuit boards. The zone sensor and the BCI-R form a two-node BACnet • Set the link switch on the BCI-R to BACnet. MS/TP network. Wire the system as shown in the...
  • Page 9: Symbio 400/Symbio 400B Systems

    Zone Sensor Wiring Symbio 400/Symbio 400B Systems The zone sensor and the Symbio 400/Symbio 400B form a two-node BACnet MS/TP network. Wire the system as shown in the schematic below. BAS-SVN028K-EN...
  • Page 10 Zone Sensor Wiring BAS-SVN028K-EN...
  • Page 11: Symbio 700 Systems

    Zone Sensor Wiring Symbio 700 Systems • The Symbio 700 controller must be configured for a single setpoint zone sensor for proper operation by using the Symbio Service and Installation App: The zone sensor and the Symbio 700 form a two node BACnet MS/TP network.
  • Page 12: Symbio 800 Systems

    Zone Sensor Wiring Symbio 800 Systems The zone sensor and the Symbio 800 form a two node BACnet MS/TP network. Wire the system as shown in the schematic below. BAS-SVN028K-EN...
  • Page 13: General Information

    General Information The sensor displays Power on during initial power-up and zone sensor switches to the internal temperature advances to display the Home Screen. sensor for temperature control. All user accessible functions are easily set from the Home – Temp sensor failure could be from OAT, MAT, RAT, screen: SAT (DAT) or space temp.
  • Page 14: Configuring Settings On The Home Screen

    Configuring Settings on the Home Screen Icon buttons displayed on the Home screen can be changed by selecting 1 of 3 available home screen configurations. See menu 1/2 Setup > 1/2 Display > User HMI. Cool/Heat Mode • Off: the system will not cool nor heat the space. •...
  • Page 15: Menu Navigation

    Menu Navigation Interface Flowchart, Part 1 to set the device configuration parameters. The following pages provide a flow chart of features. Tapping on one of the six selections on the 1/2 Setup page or advancing to 2/2 Setup page allows the installer access Note: The installer password is 4017 and cannot be changed.
  • Page 16: Interface Flowchart, Part 2

    Menu Navigation Interface Flowchart, Part 2 BAS-SVN028K-EN...
  • Page 17: Interface Flowchart, Part 3

    Menu Navigation Interface Flowchart, Part 3 BAS-SVN028K-EN...
  • Page 18: Interface Flowchart, Part 4

    Unit address equipment (0-127). Defines the baud rate of the zone sensor. Default is Baud rate 76800 (use default value unless directed by Trane Technical Support). Indicates if a network is established between the Status zone sensor and the HVAC equipment.
  • Page 19: Menu Definitions

    SP(a) (Symbio 800 range: 19 to 36 BTU/lb [26 to 66 kJ/kg]) (ReliaTel range: 19 to 28 BTU/lb [26 to 47 kJ/kg]) Defines the use of schedule optimization. • On – Optimal start: HVAC equipment will start a calculated amount of time prior to a schedule occupied event.
  • Page 20 • Schedule – zone sensor time schedule. • Motion – motion sensor or external dry contact wired to zone sensor. (a)The parameter is only displayed when the zone sensor is connected to a ReliaTel or Symbio 800 control system. BAS-SVN028K-EN...
  • Page 21: Setpoints

    Menu Definitions Setpoints Defines the temperature setpoints used for space temperature control. • Unocc. Cool – unoccupied cooling setpoint temperature (Maximum; 90°F [32.2°C]). • Occ. cool – occupied cooling setpoint temperature. Cooling/Heating Setpoints • Occ. heat – occupied heating setpoint temperature. •...
  • Page 22: Display

    Menu Definitions Display Defines the Home screen button configuration. Refer to the illustration under User HMI the Interface Flowchart section in this document. Defines the background color for the home page: white, green, blue, gray, Color dark gray. Select space temperature or space temperature setpoint to be displayed on Main display Home screen.
  • Page 23: Clock, Schedule, Setpoints, And Options

    Menu Definitions Clock, Schedule, Setpoints, and Options Defines the time and date used with the programmable time schedule function.: • Time format – AM-PM: 12 hour format (displays as 8:00 PM). – 24 Hours: 24 hour form (displays as 20:00 hours). •...
  • Page 24: Service View

    – Online: data is being passed. – Offline: data is not being passed. • MAT low limit: On – economizer is being limited due to low mixed 4/7 Service View ReliaTel/ air temperature. Off – normal temp. Symbio 800 • DAT sensor fail: On – sensor fail. Off – sensor normal.
  • Page 25: Installation Instructions

    (Optional) Connect motion sensor or space temperature sensor to zone sensor terminals 17 and 18. Apply power to the HVAC equipment. Proceed to the Zone Sensor Configuration checklist. ReliaTel BCI-R ✔ Remove power from the HVAC equipment and apply electrical lock out/tag out procedures.
  • Page 26: Zone Sensor Configuration

    Zone sensor configuration is complete. Navigate to menu — 4/7 Service View. Confirm the following: • Unit status = Online If Unit status = Offline repeat the zone sensor configuration process. If problems persist, contact Trane Technical support (1-877-788-7263). BAS-SVN028K-EN...
  • Page 27: Reliatel Field Upgrade Procedure

    When ReliaTel controlled equipment is modified in the field in a manner that changes the point configuration of the unit, the BCI-R must interrogate the ReliaTel control system to learn the new points list of the equipment. This action only takes place during initial power-up after the BCI-R device memory has been cleared.
  • Page 28: Specifications

    Specifications Sensor Operating 32°F to 122°F (0°C to 50°C). Temperature Storage Temperature -22°F to 122°F (-30°C to 50°C). Storage and Operating 0% to 95%, non-condensing. Humidity Range Temperature Control +/-0.9°F (+/-0.5°C) @ 70F (21°C) typical calibrated. Accuracy Temperature Sensor +/-0.2°F (+/-0.1°C). Resolution Room Air Temperature -40°F to 122°F (- 40°C to 50°C).
  • Page 29 For more information, please visit trane.com or tranetechnologies.com. Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
