Return to Menu IP Phone 2004 User Guide BCM50 2.0 Business Communications Manager Document Status: Standard Document Version: 02.01 Document Number: NN40050-108 Date: September 2006...
Page 2
Nortel Networks. Trademarks Nortel, the Nortel logo, and the Globemark are trademarks of Nortel Networks. Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. All other trademarks and registered trademarks are the property of their respective owners.
Chapter 1 Getting started The BCM50 2.0 IP Phone 2004 brings voice and data to your desktop. Introduction This guide contains information about: • telephone buttons and lights • telephone display • telephone setup • how to make and answer calls •...
Chapter 1 Getting started IP Phone 2004 button and light descriptions Figure 2 shows the IP Phone 2004 lights and buttons. Figure 2 IP Phone 2004 Table 1 shows a description of the lights and buttons. IP Phone 2004 Table 1 NN40050-108 NN40050-108 buttons...
Page 7
Feature The following buttons are reserved for future development. Leave Message button (programmable memory button #09) Enables you to send voice mail messages. For more information on voice mail messaging, refer to your CallPilot Quick Reference Card. Navigation cluster buttons Enables you to view items stored in your Call Log.
• the extension number of the telephone (DN: 340) • a line for general information (Nortel Networks) • the date and time when the telephone is not in use, and changes to show features and call information when the telephone is in use...
Language choice • Ring type Note: For more information about the features available on your telephone and how to use them, refer to the BCM50 2.0 Telephone Features User Guide (NN40020-100). Display contrast level Adjust the contrast for the telephone display.
Chapter 1 Getting started Feature Press *504. Select the Alternate Language 4 for the telephone display. Ring type To select a different ring type for your telephone: Feature Press NEXT Press 1, 2, 3, 4, or Press to store the ring type. NN40050-108 NN40050-108 or to hear the different ring types.
• memory buttons Note: For more information about the features available on your telephone and how to use them, refer to the BCM50 2.0 Telephone Features User Guide (NN40020-100). Basic call features You can make external and internal calls using the following features: •...
Chapter 2 Features and buttons When you hear an external dial tone, dial the external telephone number. Note: Contact your System Administrator for a list of line pool codes. When entering a line pool access code on PRI lines, you do not hear dial tone. To make internal calls using intercom buttons: Lift the handset.
• To switch to your headset when you are on a handset call, press handset. Lift the handset to switch back. • To switch to your headset when you are on a Handsfree call, press back. Mute • While on a call, press microphone is off.
Chapter 2 Features and buttons (underline) identifies a new item ¯ identifies answered calls § identifies long distance calls identifies that the information has been shortened To view your Call Log: Press to view old items. Press to view new items. Press to return to the last viewed item.
Page 15
Press OK to store the number. To program internal autodial: Press Feature *2. Press a memory button. Dial the extension number. Press OK to store the number. To use features: Press Feature *3. Press a memory button. Press Feature and enter the feature code. Press OK to store the feature code.
Page 16
Chapter 2 Features and buttons NN40050-108 NN40050-108...
