- Page 1 SRP 6570 HYDROSTATIC REVERSIBLE PLATE SRP 6570 USER MANUAL Safety, Operation and Maintenance © 2015 Stanley Black & Decker, Inc. New Britain, CT 06053 U.S.A. 75890 2/2016 Ver 3...
-
Page 2: Declaration Of Conformity
Disposizioni speciali: Misurazioni Representative in the Union: Patrick Vervier, Stanley Dubuis 17-19, rue Jules Berthonneau-BP 3406 41034 Blois Cedex, France. Vertreter in der Union/Représentant dans l’union/Representante en la Union/Rappresentante presso l’Unione Done at/Ort/Fait à/Dado en/Fatto a Stanley Hydraulic Tools, Milwaukie, Oregon USA... -
Page 3: Table Of Contents
REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN AUTHORIZED AND CERTIFIED DEALER. For the nearest authorized and certified dealer, call Stanley Hydraulic Tools at the number listed on the back of this manual and ask for a Customer Service Representative. -
Page 4: Safety Symbols
Always observe safety symbols. They are included for your safety and for the protection of the tool. LOCAL SAFETY REGULATIONS Enter any local safety regulations here. Keep these instructions in an area accessible to the operator and mainte- nance personnel. 4 ► SRP 6570 User Manual... -
Page 5: Forword
Also observe the corresponding rules and regulations valid in your country. Stanley is not liable for the function of the machine when used in an improper manner and for other than the intended purpose. -
Page 6: Safety
SAFETY This Stanley machine has been built according to the state of Safety information contained in the operating and the art in compliance with the pertinent rules. Nevertheless, maintenance instructions these machines can still constitute a hazard to persons and... - Page 7 Spare parts must comply with the technical requirements of the manufacturer. Therefore only use original spare parts. Hydraulic lines must previously be rendered pressureless, before working on them. Hydraulic oil discharging under pressure can cause serious injuries. SRP 6570 User Manual ◄ 7...
-
Page 8: Technical Data
ENGINE HATZ 1D81 S TYPE 1-CYL-4-STROKE DIESEL POWER OUTPUT 10.1 KW (13.7 HP) SPEED 3000 1/MIN COOLING FUEL CAPACITY 7 L (1.85 GAL) FUEL CONSUMPTION 2,5 L /H (0.66 GAL/H) MAX. SLOPING POSITION 30° 8 ► SRP 6570 User Manual... - Page 9 THE ACCELERATION VALUE WAS DETERMINED, TAKING INTO ACCOUNT THE FOLLOWING DIRECTIVES AND STANDARDS: EN 500-4 / DIN EN ISO 5349 1) AS THE PERMISSIBLE RATING SOUND LEVEL OF 85 DB (A) CAN BE EXCEEDED BY THIS MACHINE, OPERATORS MUST WEAR HEARING PROTECTORS. SRP 6570 User Manual ◄ 9...
-
Page 10: Operation
The machine is guided at the tow-bar grip. It is operated with the operating controls on the tow-bar. The SRP 6570 is suitable for all heavy compaction work in the fileds of civil Engineering and road construction. It can be used to compact all ground materials such as sand, gravel, slag, crushed stone, asphalt and composite sett paving. - Page 11 The handle can be fixed in upright (2) position. The tow-bar lock makes it easier to handle the machine when loading it. To prevent deflection, the tow-bar must not be locked during normal operation. Attention SRP 6570 User Manual ◄ 11...
- Page 12 • Allow the engine to run for 2-3 minutes in order to and the battery will not charge ! warm up. • If misfire ignition return the decompressor lever to its initial position and repeat steps 1-5. 12 ► SRP 6570 User Manual...
- Page 13 If the engine cuts-out because the supply of lubricating oil is insufficient, proceed as follows : • Locate the fault and have it rectified. • Press the lever few seconds. • Start the engine. SRP 6570 User Manual ◄ 13...
-
Page 14: Transport
After loading, the machine has to be attached in place (1). threaded fastenings in the base plate must be sealed Use the centre-of-gravity suspension point (2) in order to lift with the supplied screw plugs . the machine. 14 ► SRP 6570 User Manual... -
Page 15: Maintenance
Change ventilation filter ²) • • Clean suction filter ²) • Check the hydraulic hose lines • • Check screwed connections for tightness )See engine operating manual )Minimum once a year )for the first time SRP 6570 User Manual ◄ 15... - Page 16 First time after 20, SRP 6570 then with each hydr. oil change 5. Ventilation filter with each hydr. oil SRP 6570 change 6. Clean suction filter with each hydr. oil SRP 6570 change Alternative Lubrication Schedule 16 ► SRP 6570 User Manual...
- Page 17 • The color of the exhaust gas changes Never operate the engine without air filter element • Clean the air cover and -housing with lintfree cloth. • Carefully install the filter element. • Install the cover. SRP 6570 User Manual ◄ 17...
- Page 18 Inspect the rubber buffers for cracks and chipping as well as • Unscrew oil filling plug (1), check the oil level again and tightness and immediately replace if damaged. top off with oil if necessary. • Replace oil fill plug/dipstick (1). 18 ► SRP 6570 User Manual...
- Page 19 • Damage or deformation of hose fittings (impaired sealing function). • Hose slips out of the fitting. • Corrosion of fitting (degrading of function and strength). • Improper installation. • Use beyond the expiry date of max. 6 years. SRP 6570 User Manual ◄ 19...
- Page 20 • Add new oil, For oil quantity and type see the lubrication chart. • Screw in the oil fill screw and tighten (if necessary use a new seal). • Take a test run, check the oil level and if necessary top off. 20 ► SRP 6570 User Manual...
-
Page 21: Battery
• Keep at least one degassing opening unclosed, otherwise • Tightly screw in or press in the sealing plugs. explosion hazard (this also concerns the return transport of the • Wipe off any acid splashes. old battery). SRP 6570 User Manual ◄ 21... - Page 22 DIN IEC 60933-3… up to the maximum acid level (never refill acid, foreign matters or so-called optimizers). • In case of high electrolyte loss, consult Stanley. • In case of insufficient starting performance, check battery and possibly recharge it (see point 7.0.4).
-
Page 23: Troubleshooting
• If the cause of the fault cannot be located or remedied, an • Only qualified and authorised persons may carry out authorised Stanley Service Center should be contacted. repair work. • Always first check the most likely causes (fuses, •... - Page 24 Stanley Hydraulic Tools 3810 SE Naef Road Milwaukie, Oregon 97267-5698 USA (503) 659-5660 / Fax (503) 652-1780 www.stanleyhydraulics.com...
