1

SYSTEM OUTLINE

■ System outline
This repeater is used to build a network that connects distant repeaters through an LTE network*
Repeaters that do not have a gateway server can communicate with other repeaters by adding assist repeaters
and controllers.
Repeater + Gateway server (LTE*
Gateway
server
Area
Assist network
( Built only in specific areas in Japan
as of August 2021.)
Area
Repeater + Assist repeater
ID-RP2C ID-RP2L
* 1 Operating the repeater on the LTE network requires following:
• An optional UX-262 LTE unit
• Connecting to a Gateway Server
*
2 The FM repeater function is not usable in combination with other repeater functions.
)
1
LTE network
Trust server
Internet
Repeater + Assist repeater + Gateway server (Internet)
Gateway
server
1
Repeater + Gateway server (Internet)
Gateway
server
Area
Zone
Area
ID-RP2C ID-RP2L
1 or the Internet.
FM repeater* 2
